TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Air bag sensor assembly bolts | 13 (17) |
| Front air bag sensor bolt | 13 (17) |
| Front seat belt outer anchor bolt | 31 (42) |
| Passenger-side air bag module bolts | 15 (20) |
| Rear air bag sensor bolts | 15 (20) |
| Seat belt pretensioner lower bolt | 31 (42) |
| Seat track bolts | 27 (37) |
| Side air bag sensor bolts | 15 (20) |
| Steering wheel retaining nut | 37 (50) |
| INCH Lbs. (N.m) | |
| Driver-side air bag module screws | 78 (8.8) |
| Seat belt pretensioner upper bolt | 66 (7.5) |
| Seat position sensor bolt | 71 (8.0) |
| Side air bag module nut | 53 (6.0) |
| Side curtain air bag module bolts | 87 (9.8) |
TORQUE SPECIFICATIONS
