Maintenance Information: Overview Lexus ES XV20

Procedures 13 illustrations ~1256 words

FUSE IDENTIFICATION

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Scheme 1

Scheme 1: Fuse & Circuit Breaker Identification - Toyota
Scheme 1: Fuse & Circuit Breaker Identification - Toyota

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. 1 - A/C 10 Amp - Air Conditioning System
  2. 2 - SPARE 10 Amp - Spare Fuse
  3. 3 - SPARE 15 Amp - Spare Fuse
  4. 4 - SPARE 30 Amp - Spare Fuse
  5. 5 - ALT-S 5 Amp - Charging System
  6. 6 - HEAD (RH-HI) 15 Amp - Right Hand Headlight
  7. 7 - EFI 15 Amp - Multiport Fuel Injection System/Sequential Fuel Injection System
  8. 8 - HORN 10 Amp - Horn, Theft Deterrent System
  9. 9 - HAZ 10 Amp - Emergency Flashers
  10. 10 - AM2 30 Amp - Gauge & Meter, SRS Airbag System, Multiport Fuel Injection System/Sequential Fuel Injection System, "IGN" & "ST" Fuses
  11. 11 - TEL 5 Amp - No Circuit
  12. 12 - HEAD (LH-HI) 15 Amp - Left Hand Headlight
  13. 13 - RAD NO.1 20 Amp - Audio System
  14. 14 - DOME 7.5 Amp - Theft Deterrent System, Daytime Running Light System, Clock, Locking With Wireless Remote Control System, Ignition Switch Light, Personal Light, Trunk Light, Electric Moon Roof Lamp, Interior Light, Vanity Mirror Light, Door Courtesy Light, Power Door Lock System
  15. 15 - ECU-B 7.5 Amp - Cruise Control System, Anti-Lock Brake System, SRS Airbag System
  16. 16 - DRL NO.2 5 Amp (Canada Vehicles) - Daytime Running Light System
  17. 17 - HEAD (LH-LO) 10 Amp - Left Hand Head Light
  18. 18 - HEAD (RH-LO) 10 Amp - Right Hand Headlight
  19. 19 - SEAT HEATER 20 Amp - No Circuit
  20. 20 - HEATER 10 Amp - Air Conditioning System, Rear Window Defogger, Starting System
  21. 21 - GAUGE 10 Amp - Gauges & Meters, Back-Up Lights, Cruise Control System, Charging System, Traction Control System, Daytime Running Light System, Power Windows, Service Reminder Indicators & Warning Buzzers
  22. 22 - WIPER 20 Amp - Windshield Wipers & Washer
  23. 23 - MIRROR-HEATER 10 Amp - Outside Rear View Mirror Defogger
  24. 24 - ECU-IG 15 Amp - Cruise Control System, Anti-Lock Brake System, Power Antenna, SRS Air Bag System, Traction Control System, Daytime Running Light System, Locking With Wireless Remote Control System, Multiport Fuel Injection System/Sequential Fuel Injection System
  25. 25 - IGN 5 Amp - Gauges & Meters, Charging System, SRS Airbag System, Multiport Fuel Injection System/Sequential Fuel Injection System
  26. 26 - STOP 15 Amp - Stop Lights, Cruise control System, High-Mounted Stop Light, Anti-Lock Brake System, Shift Lock Control System, Multiport Fuel Injection System/Sequential Fuel Injection System
  27. 27 - TAIL 10 Amp - Parking Lamps, License Plate Lights, Tail Lights, Front Side Marker Lights, Daytime Running Light System, Multiport Fuel Injection System/Sequential Fuel Injection System
  28. 28 - POWER-OUTLET 15 Amp - Power Outlet
  29. 29 - OBD 7.5 Amp - On-Board Diagnosis System
  30. 30 - FOG 15 Amp - No Circuit
  31. 31 - STARTER 5 Amp - Gauges & Meters, Multiport Fuel Injection System/Sequential Fuel Injection System
  32. 32 - DOOR 25 Amp - Power Door Lock System, Theft Deterrent System, Fuel Filler Door Control System
  33. 33 - PANEL 7.5 Amp - Gauge & Meter, Audio System, Cigarette Lighter, Glove Box Light, Clock, Instrument Panel Light Control, Service Reminder Indicators, Air Conditioning Control Panel Lights, Ashtray Lights, Emergency Flashers, Seat Heater Control System, Daytime Running Light System, Rear Window Defogger, Electronically Controlled Automatic Transmission System
  34. 34 - TURN 7.5 Amp - Emergency Flasher
  35. 35 - RAD-NO.2 7.5 Amp - Audio System, Power Antenna
  36. 36 - CIG 15 Amp - Cigarette Lighter, Shift Lock Control System, Power Rear View Mirror Controls, Theft Deterrent System, Power Door Lock System, SRS Airbag System, Outside Rear View Mirror Defogger, Air Conditioning System
  37. 37 - CDS 30 Amp - Electric Cooling Fans
  38. 38 - RDI FAN 30 Amp - Electric Cooling Fans
  39. 39 - MAIN 40 Amp - "HEAD (RH-HI)", "HEAD (RH-LO)" Fuses
  40. 40 - HTR 50 Amp - "AM1", "A/C" Fuses
  41. 41 - DEF 40 Amp - Rear Window Defogger
  42. 42 - PWR 30 Amp - Power Window Control System, Power Seat, Electric Moon Roof
  43. 43 - AM1 40 Amp - Headlamp Cleaner
  44. 44 - ALT 100 Amp - "RDI FAN", "CDS" Fuses
  45. 45 - ABS 60 Amp - Anti-Lock Brake System

Scheme 10

Scheme 10: Fuse & Circuit Breaker Identification - Lexus
Scheme 10: Fuse & Circuit Breaker Identification - Lexus

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. 1 - ABS 60 Amp - ABS System
  2. 2 - DRL NO.2 5 Amp (Canada Vehicles) - Daytime Running Light System
  3. 3 - H-LP LH (LO) 10 Amp (Canada Vehicles) - Left Hand Headlight (Low Beam)
  4. 4 - H-LP RH (LO) 10 Amp (Canada Vehicles) - Right Hand Headlight (Low Beam)
  5. 5 - ALT 100 Amp - Charging System
  6. 6 - CDS NO.2 30 Amp - No Circuit
  7. 7 - HTR 50 Amp - Air Conditioning System, Seat Heater
  8. 8 - MAIN 40 Amp - Headlight, Starting System
  9. 9 - DOME 7.5 Amp - Theft Deterrent System, Clock, Door Courtesy Light, Interior Light, Ignition Switch Light, Wireless Remote Control System
  10. 10 - ECU-B 10 Amp - Cruise Control System, Air Conditioning System, Power Seat System
  11. 11 - RAD NO.1 20 Amp - Audio System
  12. 12 - HAZ 10 Amp - Emergency Flashers, Turn Signal Lights
  13. 13 - AM2 30 Amp - Starting System
  14. 14 - TEL 5 Amp - Telephone
  15. 15 - H-LP LH 15 Amp (USA Vehicles) - Left Hand Headlight (High Beam) H-LP LH 15 Amp (Canada Vehicles) - Left Hand Headlight (High Beam)
  16. 16 - ALT-S 5 Amp - Charging System
  17. 17 - H-LP RH 15 Amp (USA Vehicles) - Right Hand Headlight (High Beam) H-LP RH 15 Amp (Canada Vehicles) - Right Hand Headlight (High Beam)
  18. 18 - EFI 15 Amp - Multiport Fuel Injection
  19. 19 - HORN 10 Amp - Theft Deterrent System
  20. 20 - RDI FAN 30 Amp - Electronic Cooling Fan System
  21. 21 - CDS 30 Amp - Air Conditioning System
  22. 22 - A/C 10 Amp - No Circuit
  23. 23 - S-HTR 20 Amp - Seat Heater System
  24. 24 - HTR 10 Amp - Air Conditioning System
  25. 25 - GAUGE 10 Amp - Gauges & Meters, Service Reminder Indicators & Warning Buzzers, Back-Up Light, Door Courtesy Light, Seat Heater, Power Window System
  26. 26 - WIP 20 Amp - Windshield Wipers & Washer
  27. 27 - M/HTR 10 Amp - Outside Rear View Mirror Defogger
  28. 28 - ECU-IG 15 Amp - Cruise Control System, Anti-Lock Brake System, Shift Lock System, Power Antenna, Theft Deterrent System, Electronic Modulated Suspension, Anti-Lock Brake System, Shift Lock System, Power Seat System, Wireless Remote System
  29. 29 - IGN 5 Amp - SRS Airbag System, Multiport Fuel Injection
  30. 30 - STOP 15 Amp - Stop Lights, High Mounted Stop Light, Cruise Control System, Electronic Modulated Suspension, Anti-Lock Brake System, Shift Lock System, Power Seat System, Multiport Fuel Injection
  31. 31 - TAIL 10 Amp - Tail Light, Side Marker Lights, License Plate Lights
  32. 32 - PWR OUTLET 15 Amp - Power Outlet
  33. 33 - OBD 7.5 Amp - On-Board Diagnosis System
  34. 34 - FOG 15 Amp - Fog Lights
  35. 35 - ST 5 Amp - Starting System
  36. 36 - DOOR 25 Amp - Door Courtesy Light, Theft Deterrent System, Power Door Lock System, Trunk Lid Opener, Fuel Filler Door Opener
  37. 37 - PANEL 7.5 Amp - Instrument Panel Lights, Glovebox Light
  38. 38 - TURN 7.5 Amp - Emergency Flashers, Turn Signal Lights
  39. 39 - RAD NO.2 7.5 Amp - Audio System
  40. 40 - CIG 15 Amp - Cigarette Lighter, Clock, SRS Airbag System, Theft Deterrent System
  41. 41 - DEF 40 Amp - Rear Window Defogger, Outside Rear View Mirror Defogger
  42. 42 - PWR 30 Amp - Power Window, Power Seat System, Electric Moon Roof
  43. 43 - AM1 40 Amp - No Circuit
