SPECIFICATIONS
| WARNING | Vehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG RESTRAINT SYSTEMS article in RESTRAINTS. |
Note. When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle.
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10PA20 10-Cyl. |
| Compressor Belt Tension |
| New | 139-191 lbs. (63-87 kg) |
| Used | 66-110 lbs. (20-50 kg) |
| Compressor Oil Capacity | (1) 4.8 ozs. |
| Refrigerant (R-134a) Capacity | 26.5-29.9 ozs. |
| System Operating Pressures (2) |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 21-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Use Denso/ND-OIL 8 refrigerant oil. (2) At 86-95°F (30-35°C) and engine speed at 1500 RPM. |
| (1) | Use Denso/ND-OIL 8 refrigerant oil. |
| (2) | At 86-95°F (30-35°C) and engine speed at 1500 RPM. |
A/C SYSTEM SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor-To-Bracket Bolts | 18 (25) |
| A/C Compressor Bracket-To-Engine Bolts | 18 (25) |
| Alternator Pivot Bolt | 41 (56) |
| Drive Belt Adjusting Bar Bracket Bolts/Nut | 18 (25) |
| Drive Belt Adjusting Bar |
| Bracket-To-Adjusting Bar | 13 (18) |
| Drive Belt Adjusting Lock Bolt | 13 (18) |
| INCH Lbs. (N.m) |
| Compressor Hoses | 89 (10) |
| Condenser Lines | 89 (10) |
| Pressure Switch | 89 (10) |
| Receiver-Drier Lines | 53 (6) |
Scheme 22: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Scheme 23: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
