Engine Immobiliser System (Diagnostic Codes & Symptom Tests): Overview Lexus CT I

Door Locks & Anti-Theft Systems 6 illustrations ~469 words

DESCRIPTION

If communication between the remote start ECU and certification ECU (smart key ECU assembly) cannot be performed even if a remote start operation is performed to try changing the power source mode to on (IG) or start the hybrid control system, this DTC is stored.

When the remote start ECU does not respond to the certification ECU (smart key ECU assembly), this DTC is stored. When communication with the remote start ECU is established and a remote start operation is performed, this DTC is cleared.

DTC CodeDTC Detection ConditionTrouble AreaDTC Output Confirmation Operation
B2779One of the following conditions is met (1 trip detection logic*): A remote start communication error occurs. Response is not possible. Registration has not been performed.Remote start ECU Wire harness or connector Main body ECU (multiplex network body ECU) Certification ECU (smart key ECU assembly)A remote start operation is performed.
  1. *: Only output while a malfunction is present.
Vehicle Condition when Malfunction DetectedFail-safe Operation when Malfunction Detected
Hybrid control system does not start with remote start operationHybrid control system cannot be started by remote start operation only

VEHICLE CONDITION AND FAIL-SAFE OPERATION WHEN MALFUNCTION DETECTED

DTC CodeData List and Active Test
B2779Wireless Starter Com ID Wireless C Code

RELATED DATA LIST AND ACTIVE TEST

Scheme 246

Scheme 246: WIRING DIAGRAM

When an open or short circuit is detected in the transponder key amplifier coil built into the power switch, the certification ECU (smart key ECU assembly) stores this DTC. This DTC is also stored as a past DTC.

DTC CodeDTC Detection ConditionTrouble AreaDTC Output Confirmation Operation
B2784The transponder key amplifier coil built into the power switch is open (see below) or shorted (determined by communication with certification ECU (smart key ECU assembly)) (1 trip detection logic*). Terminal VC5, TXCT or CODE is open (includes disconnection of the power switch). The transponder key amplifier coil built into the power switch is open.Power switch Wire harness or connector Certification ECU (smart key ECU assembly)With park (P) selected, the key is held against the power switch and a hybrid control system start operation is performed by pressing and holding the power switch when the key battery is depleted.
  1. *: Only output while a malfunction is present.
Vehicle Condition when Malfunction DetectedFail-safe Operation when Malfunction Detected
Hybrid control system cannot be started when key battery is depleted by holding key against power switch and pressing and holding power switch with park (P) selected

VEHICLE CONDITION AND FAIL-SAFE OPERATION WHEN MALFUNCTION DETECTED

DTC CodeData List and Active Test
B2784

RELATED DATA LIST AND ACTIVE TEST

Scheme 247

Scheme 247: WIRING DIAGRAM

When there is a short to GND in the power supply for the transponder key amplifier of the power switch, the certification ECU (smart key ECU assembly) stores this DTC.

DTC CodeDTC Detection ConditionTrouble AreaDTC Output Confirmation Operation
B278AA short to GND in the power supply of the transponder key amplifier of the power switch (VC5 - VC5) (1 trip detection logic*).Wire harness or connector Power switch Certification ECU (smart key ECU assembly)With park (P) selected, the key is held against the power switch and a hybrid control system start operation is performed by pressing and holding the power switch when the key battery is depleted.
  1. *: Only output while a malfunction is present.
Vehicle Condition when Malfunction DetectedFail-safe Operation when Malfunction Detected
Hybrid control system cannot be started when key battery is depleted by holding key against power switch and pressing and holding power switch with park (P) selected

VEHICLE CONDITION AND FAIL-SAFE OPERATION WHEN MALFUNCTION DETECTED

DTC CodeData List and Active Test
B278A

RELATED DATA LIST AND ACTIVE TEST

Scheme 248

Scheme 248: WIRING DIAGRAM

When an internal malfunction occurs in the ID code box (immobilizer code ECU), the certification ECU (smart key ECU assembly) stores this DTC.

DTC CodeDTC Detection ConditionTrouble AreaDTC Output Confirmation Operation
B2790An internal malfunction occurs in the ID code box (immobilizer code ECU) (EEPROM access malfunction) (1 trip detection logic*).ID code box (immobilizer code ECU) Certification ECU (smart key ECU assembly)An immobilizer set/unset operation is performed (the power switch is turned off or on (IG) while carrying the key).
  1. *: Only output while a malfunction is present.
Vehicle Condition when Malfunction DetectedFail-safe Operation when Malfunction Detected
Power switch on (READY): Hybrid control system cannot be started next time Hybrid control system stopped: Hybrid control system cannot be started

VEHICLE CONDITION AND FAIL-SAFE OPERATION WHEN MALFUNCTION DETECTED

DTC CodeData List and Active Test
B2790

RELATED DATA LIST AND ACTIVE TEST

When there are communication malfunctions between the power management control ECU and ID code box (immobilizer code ECU), or when the communication ID codes do not match, the power management control ECU stores this DTC.

DTC CodeDTC Detection ConditionTrouble AreaDTC Output Confirmation Operation
B2799Either condition is met (1 trip detection logic*): A malfunction in the communication or communication lines between the power management control ECU and ID code box (immobilizer code ECU). A matching communication code cannot be verified during communication between the power management control ECU and ID code box (immobilizer code ECU).ID code box (immobilizer code ECU) Power management control ECU Wire harness or connectorEither condition is met: Within 10 seconds of a hybrid control system start operation being performed (with park (P) selected and the brake pedal depressed, press the power switch while carrying the key). If there is a malfunction, the hybrid control system stops (communication begins within 3 seconds of the hybrid control system start operation being performed, and DTCs are stored after 6 seconds). 10 seconds after the power switch is turned on (IG) after reconnecting the cable to the negative (-) terminal of the auxiliary battery (communication begins within 3 seconds of the power switch being turned on (IG), and DTCs are stored after 6 seconds).
  1. *: Only output while a malfunction is present.
Vehicle Condition when Malfunction DetectedFail-safe Operation when Malfunction Detected
Hybrid control system cannot be started

VEHICLE CONDITION AND FAIL-SAFE OPERATION WHEN MALFUNCTION DETECTED

DTC CodeData List and Active Test
B2799

RELATED DATA LIST AND ACTIVE TEST

Scheme 249

Scheme 249: WIRING DIAGRAM

When the communication line (IMI - EFIO) between the power management control ECU and ID code box (immobilizer code ECU) is stuck high, the power management control ECU stores this DTC.

DTC CodeDTC Detection ConditionTrouble AreaDTC Output Confirmation Operation
B279AThe communication line (IMI - EFIO) between the power management control ECU and ID code box (immobilizer code ECU) is stuck high (1 trip detection logic*).Wire harness or connector (disconnection or break in wire harness is main cause) ID code box (immobilizer code ECU) Power management control ECUTurn the power switch on (IG) and wait 6 seconds.
  1. *: Only output while a malfunction is present.
Vehicle Condition when Malfunction DetectedFail-safe Operation when Malfunction Detected
Hybrid control system cannot be startedHybrid control system cannot be started

VEHICLE CONDITION AND FAIL-SAFE OPERATION WHEN MALFUNCTION DETECTED

DTC CodeData List and Active Test
B279A

RELATED DATA LIST AND ACTIVE TEST

Scheme 250

Scheme 250: WIRING DIAGRAM

This code is stored when a power management control ECU that is incompatible with the engine immobilizer system is installed to the vehicle.

DTC CodeDTC Detection ConditionTrouble AreaDTC Output Confirmation Operation
B279CA power management control ECU that is incompatible with the engine immobilizer system is installed (1 trip detection logic*).Power management control ECUCheck for DTCs.
  1. *: Only output while a malfunction is present.
Vehicle Condition when Malfunction DetectedFail-safe Operation when Malfunction Detected
Hybrid control system cannot be started

VEHICLE CONDITION AND FAIL-SAFE OPERATION WHEN MALFUNCTION DETECTED

DTC CodeData List and Active Test
B279C

RELATED DATA LIST AND ACTIVE TEST

  1. The certification ECU (smart key ECU assembly) blinks the security indicator light when the immobilizer is set (the power switch is off).

Scheme 251

Scheme 251: WIRING DIAGRAM
