Wipers and Washers Land Rover Range Rover L322

Wiper/washer Systems 12 illustrations ~1509 words

SPECIFICATIONS

DescriptionNmLb-ft
Front wiper arms to linkage nut3425
Wiper linkage to front wiper motor
Nut2518
Bolts107
Rear window wiper motor bolts107
Rear wiper arm to motor nut1310
Washer reservoir to body bolts32.2

TORQUE SPECIFICATIONS

PRINCIPLE OF OPERATION

For a detailed description of the wipers and washers systems and operation, refer to the relevant Description and Operation . Refer to See Wipers and Washers . .

INSPECTION AND VERIFICATION

CAUTIONDiagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not guarantee confirmation of a fault and may also cause additional faults in the vehicle being checked and/or the donor vehicle.

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION Mechanical Electrical Windshield and rear window for damage or contamination e.g. road film or general residue deposits Wiper blades, arms and linkage for wear, security, damage and freedom of movement Windshield/Rear window/Headlamp washer fluid level Washer pipes and jets for leaks, restrictions and damage Battery condition and state of charge Fusible links Fuses Relays Electrical connections Front and rear wiper motors Wiper switch Washer pumps Rain/light sensor Heated front washer jets Ignition switch Light switch Ambient air temperature sensor Central Junction Box (CJB) Battery Junction Box (BJB) Anti-Lock Braking System (ABS) module Automatic Temperature Control Module (ATCM) Instrument Cluster (IPC) module Controller Area Network (CAN) circuits
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step
  4. If the cause is not visually evident, verify the symptom and refer to the Symptom Chart, alternatively check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

SYMPTOM CHART

SymptomPossible CausesAction
Wiper blade(s) drag/judder across the windshield/rear windowContamination of the windshield/rear window Incorrectly installed wiper arm(s) Wiper arm(s) incorrectly aligned to the screen Wiper arm(s) spring tension inadequateClean the windshield/rear window. Check for the correct installation and tension of the wiper arm(s). Refer to the relevant section of the workshop manual. Rectify as necessary.
Very slow operation of the wiper(s) across the windshield/rear windowLow battery voltage Front wiper linkage seized or fouling Wiper circuit fault Wiper switch fault, high resistanceCheck the battery condition and state of charge. Check the wiper linkage for fouling. Disconnect the motor from the linkage. Refer to the relevant section of the workshop manual. Check the linkage operation. Check for DTCs indicating a wiper circuit fault. Rectify as necessary.
Wiper(s) inoperative
Noisy operation of wiper(s)Wiper motor/linkage faultLift the wiper arm(s) from the windshield/rear window and recheck the noise level during the wiper sweep operation.
Noisy operation of washersWasher motor(s) faulty Washer system blocked or partially blockedListen for washer motor operation. Check and top up washer fluid level. Check and rectify blocked washer circuit. Check the wiper/washer circuit for DTCs indicating a fault. Rectify as necessary.
Washers do not operateFluid level low Washer circuit blocked Washer circuit faulty

DTC Index

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to Diagnostic Trouble Code (DTC) Index - DTC: Module Name: Central Junction Box .

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL
  1. Remove the interior rear view mirror. Refer to «Interior Rear View Mirror»(/land-rover/range-rover/l322-2009-2012/remont/heated-glassdefoggers/#rear-view-mirrors) .
  2. Remove the rain sensor. Release the 2 clips.

INSTALLATION

  1. Install the rain sensor. Secure with the clips.
  2. Install the interior rear view mirror. Refer to «Interior Rear View Mirror»(/land-rover/range-rover/l322-2009-2012/remont/heated-glassdefoggers/#rear-view-mirrors) .
  3. Using the Land Rover approved diagnostic equipment, calibrate the new rain sensor.

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL
  1. Remove the rear window wiper pivot arm. See «Rear Window Wiper Pivot Arm»(/land-rover/range-rover/l322-2009-2012/remont/wiperwasher-systems/#wipers-and-washers) .
  2. Disconnect the rear window washer hose from the rear window wiper motor.
  3. Disconnect the 2 electrical connectors from the rear window wiper motor.
  4. Remove the 3 bolts securing the rear window wiper motor to the liftgate.
  5. Remove the rear window wiper motor from the liftgate window glass seal.
  6. Remove the rear window wiper motor seal from the liftgate window glass.
  7. Remove the 3 compression limiters from the rear window wiper motor mountings. Release and collect the 3 mountings from the rear window wiper motor.
  1. Install the mountings and insert the compression limiters to the rear window wiper motor.
  2. Install a new rear window wiper motor to the liftgate window glass seal.
  3. Install the rear window wiper motor. Tighten the bolts to 10 Nm (7 lb.ft).
  4. Connect the electrical connectors to the rear window wiper motor.
  5. Connect the rear window washer hose to the rear window wiper motor.
  6. Install the rear window wiper pivot arm. See «Rear Window Wiper Pivot Arm»(/land-rover/range-rover/l322-2009-2012/remont/wiperwasher-systems/#wipers-and-washers) .

Scheme 3

Scheme 3: REMOVAL
Scheme 3: REMOVAL

Scheme 4

Scheme 4
Scheme 4
  1. Remove the liftgate upper trim panel. Refer to «Liftgate Upper Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the 3 bolts from the rear spoiler.
  3. Close the liftgate. Reposition the rear spoiler for access.
  4. Remove the rear window wiper pivot arm. Raise the nut cover on the rear window wiper pivot arm and remove the nut.
  1. Install the rear window wiper pivot arm. Align the rear window wiper pivot arm to the liftgate window glass. Tighten the nut to 13 Nm (10 lb.ft). Close the rear window wiper pivot arm nut cover.
  2. Open the liftgate. Reposition the rear spoiler to the liftgate.
  3. Install the bolts to the rear spoiler. Tighten the bolts to 10 Nm (7 lb.ft).
  4. Install the liftgate upper trim panel. Refer to «Liftgate Upper Trim Panel»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

REMOVAL

  1. Remove the front LH fender splash shield. Refer to «Fender Splash Shield»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#front-end-body-panels) .
  2. Position a container to collect any windshield washer reservoir spillage.
  3. Disconnect the windshield washer pump electrical connector. Remove the windshield washer pump hose.
  4. Remove the windshield washer pump. Remove and discard the seal.
  1. Install the windshield washer pump. Clean the component mating faces. Install a new seal.
  2. Connect the electrical connector. Connect the hose to the pump.
  3. Fill the windshield washer reservoir with the correct fluid and concentration.
  4. Install the front LH fender splash shield. Refer to «Fender Splash Shield»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#front-end-body-panels) .

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL
  1. Remove the front LH fender splash shield. Refer to «Fender Splash Shield»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#front-end-body-panels) .
  2. Release the filler neck from the windshield washer reservoir. Position a container to collect any windshield washer reservoir spillage. Remove and discard the seal.
  3. Disconnect the 3 electrical connectors from the windshield washer reservoir pumps.
  4. Disconnect the 3 hoses from the windshield washer reservoir pumps.
  5. Disconnect the low washer fluid warning indicator switch electrical connector.
  6. Disconnect the windshield washer reservoir vent pipe.
  7. Remove the windshield washer reservoir. Remove the 2 bolts. Release the windshield washer reservoir from the front mounting.
  8. Remove the 3 windshield washer reservoir pumps and discard the 3 seals.
  1. Install the windshield washer reservoir pumps. Clean the component mating faces. Install new seals.
  2. Install the windshield washer reservoir. Tighten the bolts to 3 Nm (2.2 lb.ft).
  3. Connect the windshield washer reservoir vent pipe.
  4. Connect the low washer fluid warning indicator switch electrical connector.
  5. Connect the windshield washer reservoir electrical connectors.
  6. Connect the windshield washer reservoir pump hoses.
  7. Install the windshield washer reservoir filler neck. Clean the component mating faces. Install a new seal to the windshield washer filler neck.
  8. Fill the windshield washer reservoir with the correct fluid and concentration.
  9. Install the front LH fender splash shield. Refer to «Fender Splash Shield»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#front-end-body-panels) .

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL

Scheme 7

Scheme 7
Scheme 7
  1. Remove the battery.
  2. Remove the bulkhead access cover. Release the 2 clips.
  3. Disconnect the windshield wiper intermittent wipe relay.
  1. Install the windshield wiper intermittent wipe relay.
  2. Install the bulkhead access cover. Secure the clips.
  3. Install the battery.

Scheme 8

Scheme 8: REMOVAL
Scheme 8: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  2. Remove the windshield wiper motor. Mark the position of the windshield wiper motor linkage to aid assembly. Remove the windshield wiper motor to windshield wiper motor linkage assembly nut. Release the wiper linkage assembly from the windshield wiper motor. Remove the 3 windshield wiper motor to support bracket bolts. Disconnect the electrical connector.
  1. Install the windshield wiper motor. Tighten the bolts to 10 Nm (7 lb.ft). Connect the electrical connector.
  2. Carry out the windshield wiper motor park operation. Connect the battery ground cable. Turn the ignition key to the ON position and make sure the windshield wiper motor is in the park position, turn the ignition key to the OFF position. Disconnect the battery ground cable.
  3. Install the windshield wiper motor and linkage. Reposition the windshield wiper motor linkage to its original position. Install the windshield wiper motor to windshield wiper motor linkage assembly nut. Tighten the nut to 25 Nm (18 Ib.ft).
  4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

WINDSHIELD WIPER PIVOT ARM

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Aligner windshield wiper 100-055 (LRT-84-001)

Scheme 9

Scheme 9: WINDSHIELD WIPER PIVOT ARM
Scheme 9: WINDSHIELD WIPER PIVOT ARM

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL
  1. Remove the nut cover from the windshield wiper pivot arm and remove the nut.
  2. Remove the windshield wiper pivot arm from the pivot shaft.
  3. Release the windshield wiper pivot arm to windshield wiper blade locking clip.
  4. Release the windshield wiper blade from the windshield wiper pivot arm.

Scheme 11

Scheme 11: INSTALLATION
Scheme 11: INSTALLATION

Scheme 12

Scheme 12
Scheme 12
  1. Install the new windshield wiper blade to the windshield wiper pivot arm.
  2. Push the windshield wiper blade fully home, to engage the windshield wiper pivot arm locking clip, check the windshield wiper blade for retention.
  3. Install the windshield wiper pivot arm to the windshield wiper pivot shaft. Install the nut but do not fully tighten at this stage.
  4. Align the special tool between points A and B on the windshield wiper pivot arm. Align the face of the windshield wiper pivot arm to the special tool angle of 86 degrees.
  5. Retaining an 86 degrees angle, set the respective windshield wiper pivot arm to the dimension shown. Passenger side C = 58 mm (2.283 inches). Drivers side D = 40.5 mm (1.594 inches). The measurement must be taken from the plenum chamber glass seal, to the lip of the windshield wiper blade adjacent to the windshield wiper pivot arm fulcrum.
  6. Tighten the windshield wiper pivot arm nut to 34 Nm (25 lb.ft).
  7. Install the windshield wiper pivot arm nut cover.
  8. Close the hood.
  1. Remove the cowl panel grille. Refer to «Cowl Panel Grille»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#front-end-body-panels__cowl-panel-grille) .
  2. Remove the plenum chamber. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  3. Disconnect the windshield wiper motor electrical connector.
  4. Remove the windshield wiper assembly. Remove the 5 bolts.
  1. Install the windshield wiper motor assembly. Tighten the bolts to 10 Nm (7 lb.ft).
  2. Connect the windshield wiper motor electrical connector.
  3. Install the plenum chamber. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2009-2012/remont/automatic-hvac-system/#air-distribution-and-filtering) .
  4. Install the cowl panel grille. Refer to «Cowl Panel Grille»(/land-rover/range-rover/l322-2009-2012/remont/exterior-body-panels/#front-end-body-panels__cowl-panel-grille) .
