VIN Number
The VIN number will be found in three locations
- 1. Stamped on the front of the RH front suspension turret.
- 2. At the bottom of the windshield glass on the LH side of the vehicle and visible from the outside.
- 3. UK, Europe and ROW - Not NAS/Canada - On the VIN plate attached to the LH inner wing, forward of the suspension turret.
- 4. NAS/Canada - On the Tire Data/Specification label attached to the front of the LH B-pillar.
Scheme 1
Scheme 2
Scheme 3
| VIN Position | Character | Identifies |
|---|---|---|
| 1 - 3 - World identifier | SAL | Land Rover (UK) |
| 4, 5 - Vehicle type | LM | Range Rover |
| 6 - Class | A | Standard |
| 7 - Body style | M | 4 Door |
| 7 - Body style | K | Armoured |
| 8 - Engine | 2 | 368DT - V8 3.6 Diesel |
| 8 - Engine | 7 | 368DT - V8 3.6 Diesel with DPF |
| 8 - Engine | D | 508PN - AJ V8 5.0 NA Petrol |
| 8 - Engine | E | 508PS - AJ V8 5.0 SC Petrol |
| 9 - Transmission and steering | 3 | RHD Automatic |
| 9 - Transmission and steering | 4 | LHD Automatic |
| 10 - Model year | A | 2010 |
| 11 - Plant | A | Solihull |
| 12 - 17 - Serial number | 1 2 3 4 5 6 | Unique six digit serial number |
Note. # Active belts with driver and passenger frontal air bags and side inflatable restraint (1st and 2nd row) and driver knee air bag.
| VIN Position | Character | Identifies |
|---|---|---|
| 1 - 3 - World identifier | SAL | Land Rover (UK) |
| 4 - Model range | M | Range Rover |
| 5 - Class | E | #HSE (without luxury pack, with logic 7 and Bi-Xenon) |
| 5 - Class | F | #SE (with luxury pack, logic 7 and Bi-Xenon) |
| 5 - Class | H | #Westminster |
| 5 - Class | N | #China |
| 5 - Class | P | #Autobiography |
| 6 - Body style | 1 | 4 Door Station Wagon |
| 7 - Engine | 2 | 368DT - V8 3.6 Diesel |
| 7 - Engine | D | 508PN - V8 5.0 NA Petrol |
| 7 - Engine | E | 508PS - V8 5.0 SC Petrol |
| 8 - Transmission and steering | 4 | LHD Automatic |
| 9 - Check digit | * | Derived by calculation |
| 10 - Model year | A | 2010 |
| 11 - Plant | A | Solihull |
| 12 -17 - Serial number | 1 2 3 4 5 6 | Unique six digit serial number |
Scheme 4
The VIN plate contains the following information
- A - Reserved
- B - Engine Description
- C - Country
- D - Diesel Indicator
- E - Reserved
- F - Headlamp Code/initial aim value - If shown
- G - Color code/group
- H - Type/Approval Number - If shown
- I - VIN Number
- J - Gross Vehicle Weight
- K - Gross Train Weight
- L - Front Axle Weight
- M - Rear Axle Weight
Scheme 5
The Certification Label contains the following VIN information
- A - VIN Number
- B - Bar code identification
Scheme 6
The Tire Pressure Certification Label contains the following VIN information
- A - VIN Number
- B - Vehicle Type
Unit/Assembly Serial Number Locations
The 3.6 Liter V8 Diesel Engine Serial Number is stamped on the RH side of the cylinder block.
The 5.0 Liter SC and 5.0 Liter NA V8 Petrol Engine Serial Number is stamped on the LH side of the cylinder block.
The transmission serial number is on a plate attached to the LH side of the transmission casing.
The Front Differential Serial Number is stamped on top of the differential casing and is located above the removable cross member.
Scheme 7
The Rear Differential Serial Number is stamped on the underside of the differential casing adjacent to the front mounting.
The Transfer Case serial number is stamped on the RH side of the transfer case and may also be on a bar coded self-adhesive label attached to the case.
Scheme 8
The commission plate is mounted on the hood locking platform and contains the contact details for Land Rover Special Vehicles, the paint code, contract number and date of commission of the vehicle.
