Contents Wiring diagrams Section: Fuel System All sections

Fuel Charging and Controls (v8 5.0l Petrol) Land Rover Range Rover L322

Fuel System 52 illustrations ~3154 words

SPECIFICATIONS

WARNINGDo not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related components. Highly flammable vapors are always present and may ignite. Failure to follow these instructions may result in personal injury.
WARNINGBefore any work is carried out on the fuel system, ground the vehicle to earth and maintain the ground connection until the work is complete.
CAUTIONBefore disconnecting or removing components, make sure the area around the joint faces and connections are clean. Plug open connections to prevent contamination.

Note. Tighten the fuel rail high pressure fuel pump fuel line unions and fuel rail crossover pipe unions as it is instructed in service information.

DescriptionNm
Ignition coil-on-plugs retaining bolts7
Spark plugs20
Fuel rail retaining boltStage 1 - 20 Stage 2 - 30
Fuel rail crossover pipe unions21
Fuel rail crossover pipe retaining bolts8
Fuel pressure regulator33
Fuel rail high pressure fuel pump fuel line unions21
Fuel rail high pressure fuel pump fuel line M8 bolt25
Fuel rail high pressure fuel pump fuel line M6 bolt11
Fuel rail high pressure fuel pump fuel line M5 nut6
Fuel rail high pressure fuel pump fuel line shield M10 bolt29
Fuel rail high pressure fuel pump fuel line shield M6 bolt11
Fuel rail high pressure fuel pump torx bolts12
Throttle body retaining bolts17
Accessory drive belt idler pulley retaining bolts25
Halfshaft bearing retaining bolts22
Right-hand engine mount to front subframe retaining bolts56
Right-hand engine mount bracket to engine mount retaining nut100

TORQUE SPECIFICATIONS

COMPONENT LOCATION

Item NumberDescription
1Crossover tube
2LH (left hand) fuel rail
3Fuel injector (8 off)
4HP (high pressure) fuel lines
5HP fuel pumps and covers
6RH (right hand) fuel rail
7FRP (fuel rail pressure) sensor
8LP (low pressure) fuel lines

INTRODUCTION

The fuel charging and controls system is a gasoline DI (direct injection) system controlled by the engine control module (ECM).

The fuel charging and controls system consists of

  1. LP and HP fuel lines.
  2. Two HP fuel pumps.
  3. Two fuel rails and a crossover tube.
  4. A fuel rail pressure (FRP) sensor.
  5. Eight fuel injectors.

LP fuel from the pump in the fuel tank is pressurized by the HP fuel pumps and supplied to the fuel injectors via the fuel rails and crossover tube. The engine control module (ECM) controls the fuel injectors and HP fuel pumps to inject the required volume of fuel into the combustion chambers.

Scheme 27

Scheme 27: LOW AND HIGH PRESSURE FUEL LINES
Scheme 27: LOW AND HIGH PRESSURE FUEL LINES
Item NumberDescription
ALP fuel lines
BHP fuel lines
1Acoustic cover
2Heat reflective and insulation sleeves

The LP fuel line connects the HP fuel pumps to the fuel delivery line from the fuel tank and lines system. A quick release connector at the start of the LP fuel line is held in a clip integrated into the left-hand (LH) ignition coils cover. P-clips secure the LP fuel line to the rear of each cylinder head and to the right-hand (RH) side of the cylinder block. A heat reflective and insulation sleeves are installed on the LP fuel line where it runs behind the right-hand (RH) exhaust manifold.

The HP fuel lines connect the HP fuel pumps to the right-hand (RH) fuel rail and the crossover tube. Two P-clips and a pipe clamp attach the HP fuel lines to the cylinder block and the right-hand (RH) cylinder head respectively. An integral bracket on the front HP fuel line is attached to a stud on the front-upper right-hand (RH) timing cover. An acoustic cover is installed on the bottom of the front HP fuel line.

HIGH PRESSURE FUEL PUMPS

Item NumberDescription
1Crankshaft
2Auxiliary drive chain
3Auxiliary camshaft
4Tappet
5HP fuel pump
6Acoustic cover

The two HP fuel pumps are identical mechanically-driven pumps installed on the right-hand (RH) side of the sump body, behind the generator. An O-ring seals each of the HP fuel pumps in the sump body. The front HP fuel pump is identified as No. 1 pump; the rear HP fuel pump is identified as No. 2 pump. An acoustic cover is installed on each of the HP fuel pumps.

The HP fuel pumps are single-plunger pumps. The plunger of each pump extends through the sump body and the carrier of the auxiliary camshaft. A tappet on the end each plunger is operated by a two-lobe cam on the auxiliary camshaft. A spring installed on the outside of the plunger ensures the plunger and tappet remain in contact with the cam.

The auxiliary camshaft is driven by the crankshaft, via the auxiliary drive chain, at engine speed. The auxiliary camshaft is timed to match the pump delivery strokes with crankshaft position.

Item NumberDescription
1PRV (pressure relief valve)
2To HP fuel lines
3Check valve
4Plunger
5From LP fuel lines
6Damper chamber
7Fuel metering valve

In addition to the plunger, each HP fuel pump contains

  1. A damper chamber
  2. A fuel metering valve
  3. A check valve
  4. A PRV.

The damper absorbs pressure pulses from the plunger when the fuel metering valve is open at the start of the delivery stroke.

The fuel metering valve regulates the output pressure from the HP fuel pump. The fuel metering valve is a normally open solenoid valve controlled by the engine control module (ECM). During the inlet stroke of the plunger the fuel metering valve is de-energized, which allows LP fuel into the pumping chamber. The engine control module (ECM) energizes the fuel metering valve closed during the delivery stroke of the plunger, which forces the fuel in the pumping chamber through the check valve into the HP lines. By changing the closing point of the fuel metering valve, the engine control module (ECM) can determine the volume of fuel output during the delivery stroke, and thus the pressure in the HP side of the system.

The check valve prevents the return of HP fuel to the pumping chamber during the inlet stroke of the plunger.

The PRV protects the HP side of the system from excessive pressure if there is a failure of the fuel metering valve. If the pump delivery pressure increases to 195 - 204 bar (2828 - 2959 lbf/in 2 ), the PRV opens and returns fuel to the inlet side of the plunger.

FUEL RAILS AND CROSSOVER TUBE

Item NumberDescription
1LH fuel rail
2Crossover tube
3Fuel injector
4RH fuel rail
5FRP sensor

The fuel rails and crossover tube are made from stainless steel. Bolts attach each fuel rail to the related cylinder head. The crossover tube connects the front high pressure line to the left-hand (LH) fuel rail, which ensures there is equal pressure in the two fuel rails. Two P-clips attach the crossover tube to the intake manifold.

The rear of the right-hand (RH) fuel rail incorporates a threaded boss for installation of the fuel rail pressure (FRP) sensor.

FUEL RAIL PRESSURE SENSOR

The fuel rail pressure (FRP) sensor provides the engine control module (ECM) with a continuous signal of fuel rail pressure. The fuel rail pressure (FRP) sensor is installed in the rear of the right-hand (RH) fuel rail. The fuel rail pressure (FRP) sensor is screwed into a threaded boss in the fuel rail. A flying lead and three pin connector provides the interface with the engine harness.

The fuel rail pressure (FRP) sensor contains a steel diaphragm fitted with strain gages, which are incorporated into a Wheatstone bridge. The output from the Wheatstone bridge is processed by the engine control module (ECM) to derive a pressure value.

FUEL INJECTORS

The fuel injectors spray fuel from the fuel rail directly into the combustion chambers. The fuel injectors are installed close to the center of the combustion chambers, between the inlet and exhaust valves and next to the spark plug.

The fuel injectors are a push fit in the fuel rails and the cylinder heads. On each fuel injector, a rubber O-ring seals the head of the fuel injector in the fuel rail. A teflon ring seals the nozzle of the fuel injector in the cylinder head. A clamp locks each fuel injector to the fuel rail.

Each fuel injector contains a solenoid-operated needle valve, which opens when the solenoid winding is energized. While the needle valve is open, fuel is sprayed into the combustion chamber. The solenoid winding is connected to a power feed and a ground from the engine control module (ECM), which operates the fuel injectors with a two stage power supply. Initially the engine control module (ECM) supplies the fuel injectors with 65 V, then once the boost current reaches 11 A the power supply is switched to battery voltage. The engine control module (ECM) meters the amount of fuel injected into the combustion chambers by adjusting the time that the solenoid winding is energized.

There are six holes around the tip of the nozzle through which the fuel is sprayed. Two of the holes direct fuel below the spark plug. The other four holes direct fuel evenly around the remainder of the combustion chamber.

If a fuel injector fails, the engine will suffer from unstable idle speed, poor noise, vibration and harshness (NVH) and poor emissions performance.

CONTROL DIAGRAM

Note. A = Hardwired

Scheme 28

Scheme 28: CONTROL DIAGRAM
Scheme 28: CONTROL DIAGRAM
Item NumberDescription
1Battery
2BJB (battery junction box) (50 A megafuse)
3CJB (central junction box) (ignition relay)
4No. 1 HP fuel pump
5No. 2 HP fuel pump
6Fuel injectors
7ECM
8FRP sensor

PRINCIPLES OF OPERATION

The engine control module (ECM) controls the output from the HP fuel pumps to deliver the required volume of fuel at pressures up to 150 bar (2175 lbf/in 2 ).

The engine control module (ECM) also uses the signal from the fuel rail pressure (FRP) sensor to calculate the time the fuel injectors need to be energized to deliver the correct mass of fuel to the combustion chambers.

For a detailed description of the fuel charging and controls system and operation, refer to the relevant Description and Operation instructions of the workshop information. Refer to Fuel Charging and Controls .

INSPECTION AND VERIFICATION

CAUTIONDiagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not guarantee confirmation of a fault and may also cause additional faults in the vehicle being checked and/or the donor vehicle.

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION Mechanical Electrical Fuel level Fuel leaks Damaged fuel lines Damaged push connect fittings Fuel contamination/grade/quality Throttle body Damaged fuel tank filler pipe cap Damaged fuel tank filler pipe Fuses Loose or corroded electrical connectors Harnesses Sensor(s) Engine Control Module (ECM)
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, verify the symptom and refer to the Symptom Chart, alternatively check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

SYMPTOM CHART

SymptomPossible CausesAction
Engine cranks, but does not fireEngine breather system disconnected/restricted Ignition system Fuel system Electronic engine controlEnsure the engine breather system is free from restriction and is correctly installed. Check for ignition system, fuel system and electronic engine control DTCs and refer to the relevant DTC Index
Engine cranks and fires, but will not startEvaporative emissions purge valve Fuel pump Spark plugs HT short to ground (tracking) check rubber boots for cracks/damage Ignition systemCheck for evaporative emissions, fuel system and ignition system related DTCs and refer to the relevant DTC Index
Difficult cold startEngine coolant level/anti-freeze content Battery Electronic engine controls Exhaust Gas Recirculation (EGR) valve stuck open Fuel pump Purge valveCheck the engine coolant level and condition. Ensure the battery is in a fully charged and serviceable condition. Check for electronic engine controls, engine emissions, fuel system and evaporative emissions system related DTCs and refer to the relevant DTC Index
Difficult hot startInjector leak Electronic engine control Purge valve Fuel pump Ignition system EGR valve stuck openCheck for injector leak, install new injector as required. Check for electronic engine controls, evaporative emissions, fuel system, ignition system and engine emission system related DTCs and refer to the relevant DTC Index
Difficult to start after hot soak (vehicle standing, engine off, after engine has reached operating temperature)Injector leak Electronic engine control Purge valve Fuel pump Ignition system EGR valve stuck openCheck for injector leak, install new injector as required. Check for electronic engine controls, evaporative emissions, fuel system, ignition system and engine emission system related DTCs and refer to the relevant DTC Index
Engine stalls soon after startBreather system disconnected/restricted ECM relay Electronic engine control Ignition system Air intake system restricted Air leakage Fuel linesEnsure the engine breather system is free from restriction and is correctly installed. Check for electronic engine control, ignition system and fuel system related DTCs and refer to the relevant DTC Index. Check for blockage in air filter element and air intake system. Check for air leakage in air intake system
Engine hesitates/poor accelerationFuel pressure, fuel pump, fuel lines Injector leak Air leakage Electronic engine control Throttle motor Restricted accelerator pedal travel (carpet, etc) Ignition system EGR valve stuck open Transmission malfunctionCheck for fuel system related DTCs and refer to the relevant DTC Index. Check for injector leak, install new injector as required. Check for air leakage in air intake system. Ensure accelerator pedal is free from restriction. Check for electronic engine controls, ignition, engine emission system and transmission related DTCs and refer to the relevant DTC Index
Engine backfiresFuel pump/lines Air leakage Electronic engine controls Ignition system Sticking variable camshaft timing (VCT) hubCheck for fuel system failures. Check for air leakage in intake air system. Check for electronic engine controls, ignition system and VCT system related DTCs and refer to the relevant DTC Index
Engine surgesFuel pump/lines Electronic engine controls Throttle motor Ignition systemCheck for fuel system failures. Check for electronic engine controls, throttle system and ignition system related DTCs and refer to the relevant DTC Index
Engine detonates/knocksFuel pump/lines Air leakage Electronic engine controls Sticking VCT hubCheck for fuel system failures. Check for air leakage in intake air system. Check for electronic engine controls and VCT system related DTCs and refer to the relevant DTC Index
No throttle responseElectronic engine controls Throttle motorCheck for electronic engine controls and throttle system related DTCs and refer to the relevant DTC Index
Poor throttle responseBreather system disconnected/restricted Electronic engine control Transmission malfunction Traction control event Air leakageEnsure the engine breather system is free from restriction and is correctly installed. Check for electronic engine controls, transmission and traction control related DTCs and refer to the related DTC Index. Check for air leakage in intake air system

DTC INDEX

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to Diagnostic Trouble Code (DTC) Index - 5.0L, DTC: Module Name: Engine Control Module .

GENERAL EQUIPMENT

Pneumatic vacuum gun

CLEANING

WARNINGDo not carry out any repairs to the fuel system with the engine running. Failure to follow this instruction may result in personal injury.
WARNINGDo not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related components. Highly flammable vapors are always present and may ignite. Failure to follow these instructions may result in personal injury.
WARNINGIf fuel contacts the eyes, flush the eyes with cold water or eyewash solution and seek immediate medical attention.
WARNINGPlace the vehicle in a well ventilated, quarantined area and arrange ' No Smoking/Petrol Fumes' signs about the vehicle.
WARNINGWash hands thoroughly after fuel handling, as prolonged contact may cause irritation. Should irritation develop, seek medical attention.
WARNINGDo not carry or operate cellular phones when working on or near any fuel related components. Highly flammable vapors are always present and may ignite. Failure to follow these instructions may result in personal injury.
CAUTIONBefore using the cleaning fluid, protect all electrical components and connectors with lint-free non-flocking material.
CAUTIONMake sure that all parts removed from the vehicle are placed on the lint-free non-flocking material.
CAUTIONMake sure that any protective clothing worn is clean and made from lint-free non-flocking material.
CAUTIONMake sure that clean non-plated tools are used. Clean tools using a new brush that will not lose its bristles, prior to starting work on the vehicle.
CAUTIONUse a steel topped workbench and cover it with clean, lint-free non-flocking material.
CAUTIONMake sure the workshop area in which the vehicle is being worked on is as clean and as dust free as possible. Foreign matter from work on clutches, brakes or from machining or welding operations can contaminate the fuel system and may result in later malfunction.
  1. Using a new brush that will not lose its bristles, brush the components being removed and the surrounding area.
  2. Using a pneumatic vacuum gun, remove all traces of foreign material. Refer to: «GENERAL EQUIPMENT»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__general-equipment)

FUEL INJECTION COMPONENT CLEANING USING PRESSURE CLEANER

WARNINGIf fuel contacts the eyes, flush the eyes with cold water or eyewash solution and seek immediate medical attention.
WARNINGPlace the vehicle in a well ventilated, quarantined area and arrange ' No Smoking/Petrol Fumes' signs about the vehicle.
WARNINGWash hands thoroughly after fuel handling, as prolonged contact may cause irritation. Should irritation develop, seek medical attention.
WARNINGDo not carry or operate cellular phones when working on or near any fuel related components. Highly flammable vapors are always present and may ignite. Failure to follow these instructions may result in personal injury.
WARNINGDo not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related components. Highly flammable vapors are always present and may ignite. Failure to follow these instructions may result in personal injury.
CAUTIONMake sure that any protective clothing worn is clean and made from lint-free non-flocking material.
CAUTIONMake sure the workshop area in which the vehicle is being worked on is as clean and as dust free as possible. Foreign matter from work on clutches, brakes or from machining or welding operations can contaminate the fuel system and may result in later malfunction.
CAUTIONBefore using the cleaning fluid, protect all electrical components and connectors with lint-free non-flocking material.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34
  1. Fuel additive procedure CAUTION: Make sure the correct additive is used in this step. Failure to carry out this instruction may cause damage to the vehicle. Open the fuel filler door and remove the cap. Empty the fuel additive into the fuel filler pipe. Install the fuel filler cap and close the fuel filler door.
  2. Refer to: «ENGINE COVER - REMOVAL AND INSTALLATION»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  3. Release the breather from the air intake elbow.
  4. Install the cleaning equipment to a suitable location under the hood.
  5. Remove the cleaning equipment filler cap. Empty the induction system cleaning fluid into the cleaning equipment. Install the filler cap.
  6. Position the intake system cleaning tool into intake elbow and secure with the clamp.
  7. Connect a suitable compressed air line to the cleaning equipment. Set the pressure to 4 bar.
  8. Start and run the engine.
  9. Open the ball valve on the cleaning equipment and allow the cleaning fluid to spray into the intake elbow. Raise the engine speed to 1200 rpm and hold until the cleaning fluid spray has stopped.
  10. Air line release procedure Close the ball valve. Release the air pressure in the cleaning equipment. Disconnect the air line.
  11. Connect the breather to the air intake elbow.
  12. Refer to: «ENGINE COVER - REMOVAL AND INSTALLATION»(/land-rover/range-rover/l322-2009-2012/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  13. Engine cycling procedure Start the engine. Allow the engine to idle for 30 seconds. Raise the engine speed to 1500 rpm and hold for 3 minutes until a temperature of 70°C is achieved. Allow the engine to idle for 30 seconds. Switch off the engine.
  14. Connect the approved diagnostic equipment to the vehicle.
  15. Follow on screen prompts and check for DTC's (Diagnostic Trouble Codes).
  16. Clear the DTC's following the on screen procedure.
  17. Disconnect the approved diagnostic equipment from the vehicle.

REMOVAL

  1. See «Fuel Rail LH»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol) .

INSTALLATION

  1. See «Fuel Rail LH»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol) .

SPECIAL TOOL(S)

303-1450 Spark Plug Remover/Installer 310-197 Remover, Fuel Injector 310-198 Installer, Teflon Seal 310-199 Re-shape Tool, Teflon Seal 310-200-01 Fuel Rail Installation Guide Pins - Threaded 310-200-02 Fuel Rail Installation Guide Pins - Unthreaded

CAUTIONMake sure that tools and equipment are clean and free of foreign material and lubricant.
CAUTIONAlways carry out the cleaning process before carrying out any repairs to the fuel injection system components. Failure to follow this instruction may result in foreign matter ingress to the fuel injection system.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Refer to «Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
  2. Refer to «Fuel System Pressure Release - V8 5.0L Petrol/V8 S/C 5.0L Petrol»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-system-general-information) .
  3. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information__specifications) .
  4. Refer to «FUEL INJECTION COMPONENT CLEANING - GENERAL PROCEDURES»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  5. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  6. Spark Plug Remover/Installer (303-1450), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools)
  7. Remover, Fuel Injector (310-197), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools)

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52
  1. Install new O-ring seals.
  2. Install new Teflon seals. Installer, Teflon Seal (310-198), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools)
  3. See figure Re-shape Tool, Teflon Seal (310-199), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools)
  4. Fuel Rail Installation Guide Pins - Threaded (310-200-01), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools) Fuel Rail Installation Guide Pins - Unthreaded (310-200-02), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools)
  5. Torque: 20 Nm
  6. Fuel Rail Installation Guide Pins - Threaded (310-200-01), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools) Fuel Rail Installation Guide Pins - Unthreaded (310-200-02), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools)
  7. Torque: 20 Nm
  8. Torques: Bolt 2: 30 Nm Bolt 3: 30 Nm Bolt 1: 30 Nm Bolt 4: 30 Nm
  9. Spark Plug Remover/Installer (303-1450), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol__special-tools) Torque: 20 Nm
  10. Torque: 7 Nm
  11. Torques: Unions: 21 Nm Bolts: 8 Nm
  12. Torque: 21 Nm
  13. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  14. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information__specifications) .

303-1450 Spark Plug Remover/Installer 310-197 Remover, Fuel Injector 310-198 Installer, Teflon Seal 310-199 Re-shape Tool, Teflon Seal 310-200-01 Fuel Rail Installation Guide Pins - Threaded 310-200-02 Fuel Rail Installation Guide Pins - Unthreaded

CAUTIONMake sure that tools and equipment are clean and free of foreign material and lubricant.
CAUTIONAlways carry out the cleaning process before carrying out any repairs to the fuel injection system components. Failure to follow this instruction may result in foreign matter ingress to the fuel injection system.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58
  1. Refer to «Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
  2. Refer to «Fuel System Pressure Release - V8 5.0L Petrol/V8 S/C 5.0L Petrol»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-system-general-information) .
  3. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information__specifications) .
  4. Refer to «FUEL INJECTION COMPONENT CLEANING - GENERAL PROCEDURES»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  5. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  6. Raise and support the vehicle.
  7. Lower the vehicle.
  8. Spark Plug Remover/Installer (303-1450), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  9. Remover, Fuel Injector (310-197), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. Install new O-ring seals.
  2. Install new Teflon seals. Installer, Teflon Seal (310-198), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  3. Re-shape Tool, Teflon Seal (310-199), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  4. Fuel Rail Installation Guide Pins - Threaded (310-200-01), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol) Fuel Rail Installation Guide Pins - Unthreaded (310-200-02), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  5. Torque: 20 Nm
  6. Fuel Rail Installation Guide Pins - Threaded (310-200-01), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol) Fuel Rail Installation Guide Pins - Unthreaded (310-200-02), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  7. Torque: 20 Nm
  8. Torques: Bolt 2: 30 Nm Bolt 3: 30 Nm Bolt 1: 30 Nm Bolt 4: 30 Nm
  9. Spark Plug Remover/Installer (303-1450), refer to «SPECIAL TOOL(S)»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol) Torque: 20 Nm
  10. Torque: 7 Nm
  11. See figure NOTE: LH illustration shown, RH is similar.
  12. Raise and support the vehicle.
  13. See figure CAUTION: Lubricate only the union threads with clean engine oil. NOTE: Engine shown removed for clarity. NOTE: Install the bolt and unions finger tight before final tightening. NOTE: Remove and discard the blanking caps.
  14. Lower the vehicle.
  15. Raise the vehicle.
  16. Torques: Unions (1): 21 Nm M6 (2): 11 Nm M8 (3): 25 Nm M5 nut (4): 6 Nm
  17. Torque: 21 Nm
  18. See figure NOTE: Engine shown removed for clarity.
  19. Lower the vehicle.
  20. Torques: Unions: 21 Nm Bolts: 8 Nm
  21. Torque: 21 Nm
  22. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  23. Connect the battery ground lead. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information__specifications) .
CAUTIONAlways carry out the cleaning process before carrying out any repairs to the fuel injection system components. Failure to follow this instruction may result in foreign matter ingress to the fuel injection system.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

ALL VEHICLES

  1. Refer to «Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
  2. Refer to «Fuel System Pressure Release - 5.0L»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-system-general-information) .
  3. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  4. Engine Oil Draining and Filling, refer to «Engine (V8 5.0L Petrol)»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol)
  5. Refer to «FUEL INJECTION COMPONENT CLEANING - GENERAL PROCEDURES»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  6. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  7. Raise and support the vehicle.
  8. Refer to «Engine Mount RH»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol) .
  9. Refer to «Generator - Vehicles Without: Supercharger»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#generator-and-regulator-v8-50l-gasolinev8-sc-50l-gasoline) .

LEFT-HAND DRIVE VEHICLES

Scheme 63

Scheme 63
Scheme 63

ALL VEHICLES

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68
  1. Loosen the Torx screws a turn each at a time.

ALL VEHICLES

Scheme 69

Scheme 69: INSTALLATION
Scheme 69: INSTALLATION

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71
  1. Torque: 11 Nm
  2. Loosen the Torx screws half a turn each.
  3. Torque: 11 Nm
  4. Lower the vehicle.
  5. Raise and support the vehicle.
  6. Torques: Unions (1): 21 Nm M6 (2): 11 Nm M8 (3): 25 Nm M5 nut (4): 6 Nm
  7. Torque: 21 Nm
  8. Torques: Unions: 21 Nm M6: 11 Nm
  9. Torque: 21 Nm
  10. Torque: 25 Nm

LEFT-HAND DRIVE VEHICLES

  1. Torque: 24 Nm
  2. Torque: 100 Nm

ALL VEHICLES

  1. Refer to «Generator - Vehicles Without: Supercharger»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#generator-and-regulator-v8-50l-gasolinev8-sc-50l-gasoline) .
  2. Refer to «Engine Mount RH»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol) .
  3. Lower the vehicle.
  4. See figure NOTE: Do not tighten at this stage. NOTE: Remove and discard the blanking caps.
  5. Torques: Unions: 21 Nm Bolts: 8 Nm
  6. Torque: 21 Nm
  7. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  8. Engine Oil Draining and Filling. Refer to «Engine (V8 5.0L Petrol)»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol)
  9. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
CAUTIONAlways carry out the cleaning process before carrying out any repairs to the fuel injection system components. Failure to follow this instruction may result in foreign matter ingress to the fuel injection system.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74
  1. Refer to «Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions»(/land-rover/range-rover/l322-2009-2012/remont/dtc-index/#dtc-index-general-information) .
  2. Refer to «Fuel System Pressure Release - 5.0L»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-system-general-information) .
  3. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  4. Engine Oil Draining and Filling. Refer to «Engine (V8 5.0L Petrol)»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol)
  5. Refer to «FUEL INJECTION COMPONENT CLEANING - GENERAL PROCEDURES»(/land-rover/range-rover/l322-2009-2012/remont/fuel-system/#fuel-charging-and-controls-v8-50l-petrol)
  6. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  7. See figure CAUTION: Be prepared to collect escaping fluids. CAUTION: Make sure that all openings are sealed. Use new blanking caps.
  8. Raise and support the vehicle.
  9. Refer to «Engine Mount RH»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol) .
  10. Refer to «Generator - Vehicles Without: Supercharger»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#generator-and-regulator-v8-50l-gasolinev8-sc-50l-gasoline) .
  11. Loosen the Torx screws a turn each at a time.

Scheme 75

Scheme 75
Scheme 75
  1. Torque: 11 Nm
  2. Loosen the Torx screws half a turn each.
  3. Torque: 11 Nm
  4. Lower the vehicle.
  5. Raise and support the vehicle.
  6. Torques: Unions (1): 21 Nm M6 (2): 11 Nm M8 (3): 25 Nm M5 nut (4): 6 Nm
  7. Torque: 21 Nm
  8. Torques: Unions: 21 Nm M6: 11 Nm
  9. Torque: 21 Nm
  10. Torque: 25 Nm
  11. Refer to «Generator - Vehicles Without: Supercharger»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#generator-and-regulator-v8-50l-gasolinev8-sc-50l-gasoline) .
  12. Refer to «Engine Mount RH»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol) .
  13. Lower the vehicle.
  14. Torques: Unions: 21 Nm Bolts: 8 Nm
  15. Torque: 21 Nm
  16. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  17. Engine Oil Draining and Filling. Refer to «Engine (V8 5.0L Petrol)»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#engine-v8-50l-petrol)
  18. Connect the battery earth lead. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 76

Scheme 76: REMOVAL
Scheme 76: REMOVAL

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  2. Refer to «AIR CLEANER OUTLET PIPE T-CONNECTOR»(/land-rover/range-rover/l322-2009-2012/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-50l-gasoline)
  3. Torque: 17 Nm
  1. To install, reverse the removal procedure.
  2. Using the approved diagnostic equipment, clear the powertrain control module (PCM) adaptions.

More articles — Engine
