Four-Wheel Drive Systems Land Rover Range Rover L322

SPECIFICATIONS

TORQUE SPECIFICATIONS

REMOVAL

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 71

Scheme 72

1. Raise and support the vehicle.
2. Remove the transmission support insulator nut, bolt and damper. Support the transmission.
3. Remove the shift motor. Lower the transmission. Disconnect the electrical connector. Remove the 4 Torx bolts.

INSTALLATION

1. Install the shift motor. Clean the components. Tighten the Torx bolts to 25 Nm (18 lb.ft). Connect the electrical connector.
2. Install the transmission support insulator nut, bolt and damper. Raise the transmission. Tighten the nut and bolt to 115 Nm (85 lb.ft).
3. Calibrate a new transfer case shift motor using the diagnostic tool.

Scheme 73

1. Raise and support the vehicle.
2. Remove the transmission support insulator nut, bolt and damper. Support the transmission.
3. Remove the high/low range sensor. Lower the transmission. Disconnect the electrical connector. Remove the 2 Torx bolts.

1. Install the high/low range sensor. Clean the components. Tighten the Torx bolts to 6 Nm (4 lb.ft). Connect the electrical connector.
2. Install the transmission support insulator nut, bolt and damper. Tighten the bolt to 115 Nm (85 lb.ft).
3. Calibrate a new high/low range sensor using the diagnostic tool.

1. Raise and support the vehicle.
2. Remove the transfer case clutch solenoid. Position a container to collect the fluid spillage. Use the diagnostic tool to energize the solenoid. Remove the 3 Torx screws. Detach from the selector lever. Disconnect the electrical connector.

1. Install the transfer case clutch solenoid. Clean the components. Connect the electrical connector. Use the diagnostic tool to energize the solenoid. Install to the selector lever. Tighten the Torx screws to 6 Nm (4 lb.ft).
2. Check and top-up the transfer case fluid level.
3. Calibrate a new transfer case control solenoid using the diagnostic tool.

1. Raise and support the vehicle. WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.
2. See figure Remove the transmission support insulator nut, bolt and damper. Support the transmission.
3. See figure CAUTION: To avoid damage to the joints or gaiters, do not allow the transmission to hang on the driveshafts. CAUTION: Discard the bolts. Remove the high/low range sensor. Lower the transmission. Disconnect the electrical connector. Remove the 2 Torx bolts.

1. First step CAUTION: Make sure that new bolts are installed. Install the high/low range sensor. Clean the components. Tighten the Torx bolts to 6 Nm (4 lb.ft). Connect the electrical connector.
2. Install the transmission support insulator nut, bolt and damper. Tighten the bolt to 115 Nm (85 lb.ft).
3. Calibrate a new high/low range sensor using the diagnostic tool.
