Anti-Lock Control - Stability Assist Land Rover Range Rover L322

Anti-Lock/traction Control 1 illustration ~115 words

SPECIFICATIONS

ItemSpecification
Yaw rate sensorBosch DRS MM3.10

GENERAL SPECIFICATION

DescriptionNm
Yaw rate sensor retaining bolts6

TORQUE SPECIFICATIONS

Scheme 17

Scheme 17: REMOVAL
  1. Disconnect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  2. Remove the floor console. For additional information, refer to «Floor Console»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
  3. Remove the yaw rate sensor. Disconnect the electrical connector. Remove the 2 bolts.

INSTALLATION

  1. Install the yaw rate sensor. Install the 2 bolts and tighten to 7 Nm (5 lb.ft). Connect the electrical connector.
  2. Install the floor console assembly. For additional information, refer to «Floor Console»(/land-rover/range-rover/l322-2009-2012/remont/gauges-instrument-panels/#instrument-panel-and-console) .
  3. Connect the battery ground cable. For additional information, refer to «Specifications»(/land-rover/range-rover/l322-2009-2012/remont/charging-system/#battery-and-charging-system-general-information) .
  4. Using the Land Rover approved diagnostic system, calibrate a new yaw rate sensor.
