REMOVAL Land Rover Range Rover L322

REMOVAL

1. Remove the floor console stowage compartment. Open the floor console stowage compartment lid. Remove the 2 screws. Using a suitable tool, carefully release the 2 clips. Disconnect the cigar lighter electrical connector.
2. Remove the cigar lighter assembly. Remove the cigar lighter. With extreme care release the 2 clips and remove the cigar lighter inner housing. Remove the cigar lighter housing.

1. Install the cigar lighter assembly.
2. Install the floor console stowage compartment. Connect the cigar lighter electrical connector. Secure the 2 clips. Install the 2 screws. Close the floor console stowage compartment lid.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Position the front seats fully forward. Reposition both of the front seat backrests for access.
2. Remove the floor console stowage compartment lid LH hinge trim. Remove the floor console stowage compartment lid hinge pin LH bolt.
3. Remove the floor console stowage compartment lid hinge pin. Using a suitable tool, remove the floor console stowage compartment lid hinge pin.
4. Remove the floor console stowage compartment lid RH hinge trim.
5. Release the cellular phone handset holder lid damper. Remove the cellular phone handset holder lid damper clevis pin clip. Remove the cellular phone handset holder lid damper clevis pin.
6. Release the floor console stowage compartment lid damper. Release the cellular phone handset holder from the floor console stowage compartment lid. Remove the floor console stowage compartment lid damper screw.
7. Remove the floor console stowage compartment lid. Remove the tool. Release the floor console stowage compartment lid hinge pin RH sleeve clips. Remove the floor console stowage compartment lid hinge pin RH sleeve.

1. Install the floor console stowage compartment lid. Install the floor console stowage compartment lid hinge pin RH sleeve. Secure the floor console stowage compartment lid hinge pin RH sleeve clips. Using a suitable tool, align the floor console stowage compartment lid.
2. Secure the floor console stowage compartment lid damper. Install the floor console stowage compartment lid damper screw. Secure the cellular phone handset holder to the floor console stowage compartment lid.
3. Secure the cellular phone handset holder lid damper. Install the cellular phone handset holder lid damper clevis pin. Install the cellular phone handset holder lid damper clevis pin clip.
4. Install the floor console stowage compartment lid RH hinge trim.
5. Install the floor console stowage compartment lid hinge pin. Remove the tool.
6. Install the floor console stowage compartment lid LH hinge trim. Install the floor console stowage compartment lid hinge pin LH bolt.
7. Reposition the front seats to their original position.

Scheme 33

Scheme 34

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
2. Remove the floor console stowage compartment. Open the floor console stowage compartment lid. Remove the 2 screws. Carefully release the 2 clips. Disconnect the cigar lighter electrical connector.
3. Remove the center console LH side finisher trim panel. Using a suitable tool, carefully release the 3 clips.
4. Remove the center console RH side finisher trim panel. Using a suitable tool, carefully release the 3 clips.
5. Remove the selector lever knob. Refer to «Transmission Selector Lever Knob»(/land-rover/range-rover/l322-2005-2009/remont/automatic-trans/#automatic-transmissiontransaxle-external-controls-44l)
6. Remove the climate controlled seat switch trim panel. Carefully release the 4 clips. Remove the 2 front screws from the floor console upper panel.
7. Reposition the floor console upper panel. Using a suitable tool, carefully release the 4 clips. Remove the 4 screws.
8. Disconnect the parking brake switch electrical connector.
9. Remove the floor console upper panel. Release the 3 wiring harness clips. Disconnect the 3 electrical connectors.
10. Remove the floor console cup holder. Remove the 6 screws.
11. Remove the parking brake switch. Remove the parking brake switch trim panel. Remove the 2 screws.
12. Remove the upper floor console stowage compartment. Remove the 4 screws.
13. Remove the ride and handling optimization switch assembly. Remove the 6 screws.

1. Install the ride and handling optimization switch assembly. Install the 6 screws.
2. Install the upper floor console stowage compartment. Install the 4 screws.
3. Install the parking brake switch. Install the 2 screws. Install the parking brake switch trim panel.
4. Install the floor console cup holder. Install the 6 screws.
5. Install the floor console upper panel. Connect the 3 electrical connectors. Attach the 3 wiring harness clips.
6. Connect the parking brake switch electrical connector.
7. Reposition the floor console upper panel. Secure the 4 clips. Install the 4 screws.
8. Install the climate controlled seat switch trim panel. Install the 2 front screws to the floor console upper panel. Secure the 4 clips.
9. Install the selector lever knob. Refer to «Transmission Selector Lever Knob»(/land-rover/range-rover/l322-2005-2009/remont/automatic-trans/#automatic-transmissiontransaxle-external-controls-44l)
10. Install the center console LH side finisher trim panel. Secure the 3 clips.
11. Install the center console RH side finisher trim panel. Secure the 3 clips.
12. Install the floor console stowage compartment. Connect the cigar lighter electrical connector. Secure the 2 clips. Install the 2 screws. Close the floor console stowage compartment lid.
13. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the plenum chamber. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
4. Recover the air conditioning (A/C) refrigerant. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
5. Remove the instrument panel reinforcement. See «INSTRUMENT PANEL REINFORCEMENT»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
6. Release the battery positive cable. Remove the nut.
7. Remove the plenum chamber support. Remove the 3 bolts. Remove the 2 nuts.
8. Using 3 suitable pipe clamps, clamp the 3 heater core coolant hoses.
9. Disconnect the 3 heater core coolant hoses. Position a container to collect the fluid spillage. Release the 3 clips. Install blanking caps to the exposed ports.
10. Remove the grommet.
11. Disconnect the 2 A/C refrigerant lines. Remove the 2 bolts. Remove and discard the 2 O-ring seals. Install blanking caps to the exposed ports. Remove the grommet.
12. Release the heater and evaporator core housing from the bulkhead. Remove the 3 nuts.
13. Reposition the windshield wiper motor for access. Mark the position of the wiper linkage to aid assembly. Remove the windshield wiper motor to wiper linkage assembly nut. Remove the windshield wiper motor to support bracket bolts.
14. Release the in-vehicle crossbeam from the bulkhead. Remove the 2 bolts.
15. Remove the steering column. Refer to «Steering Column»(/land-rover/range-rover/l322-2005-2009/remont/steering-column/#steering-column) .
16. Release the wiring harness from the driver side of the in-vehicle crossbeam. RH drive vehicles only: Remove and discard the tie-strap. Release the 3 wiring harness clips.
17. Release the wiring harness from the center of the in-vehicle crossbeam. Release the wiring harness fir tree clip. Release the 2 wiring harness clips. Remove and discard the tie-strap.
18. Disconnect the main wiring harness to the A/C wiring harness. Disconnect the 2 electrical connectors.
19. Disconnect the audio wiring harness to the main wiring harness. Disconnect the 2 electrical connectors. Release the 2 electrical connectors from the in-vehicle crossbeam.
20. Disconnect the passive anti-theft system (PATS) electrical connector.
21. Release the gearshift interlock cable from the in-vehicle crossbeam. Remove and discard the tie-strap.
22. Release the wiring harness clip from the passenger side of the in-vehicle crossbeam.
23. Disconnect the rear blower motor electrical connector. Release the electrical connector from the clip.
24. Release the wiring harness from the passenger side of the in-vehicle crossbeam. Release the 8 clips.
25. Release the wiring harness from the passenger side of the in-vehicle crossbeam. Remove and discard the tie-strap.
26. Remove the passenger side footwell duct. Remove the screw.
27. Release the battery positive cables. Remove and discard the tie-strap.
28. Disconnect the 4 electrical connectors from the air suspension control module. Release the wiring harness clip.
29. Remove the audio unit 4 screws and wiring harness clip.
30. Disconnect the 4 electrical connectors and remove the audio unit.
31. Release the central junction box (CJB) from the in-vehicle crossbeam. Release the 2 relays from the passenger side of the in-vehicle crossbeam. Release the wiring harness clip. Remove the 4 screws. Reposition the CJB assembly for access.
32. Release the wiring harness carrier from the in-vehicle crossbeam. Remove and discard the tie-strap.
33. Remove the 2 nuts from the heater and evaporator core housing to the in-vehicle crossbeam.
34. Release the in-vehicle crossbeam from the bulkhead. Remove the 4 nuts. Remove the 2 bolts.
35. Reposition the in-vehicle crossbeam for access.
36. Remove the 3 nuts securing the wiring harness carrier to the in-vehicle crossbeam. Release the wiring harness carrier from the in-vehicle crossbeam.
37. Remove the heater and evaporator core housing to floor ducts. Position the heater and evaporator core housing assembly in an upwards direction.
38. With assistance, remove the in-vehicle crossbeam. Release the wiring harness rearwards for in-vehicle crossbeam removal access.

1. With assistance, install the in-vehicle crossbeam.
2. Install the heater and evaporator core housing to floor ducts.
3. Locate the wiring harness carrier to the in-vehicle crossbeam and install the nuts.
4. Install the in-vehicle crossbeam to the bulkhead. Tighten the nuts to 25 Nm (18 lb.ft). Tighten the bolts to 25 Nm (18 lb.ft).
5. Secure the heater and evaporator core housing to the in-vehicle crossbeam.
6. Secure the wiring harness to the in-vehicle crossbeam. Secure with a tie-strap.
7. Install the CJB. Secure the wiring harness clip. Install the screws. Install the 2 relays to the passenger side of the in-vehicle crossbeam.
8. Install the audio unit. Connect the electrical connectors.
9. Secure the audio unit. Install the screws. Secure the wiring harness clip.
10. Connect the electrical connectors to the air suspension control module. Secure the wiring harness clip.
11. Secure the battery positive cables. Secure with a tie-strap.
12. Install the passenger side footwell duct. Install the screw.
13. Secure the wiring harness to the passenger side of the in-vehicle crossbeam. Secure the wiring harness clips.
14. Secure the wiring harness. Secure with a tie-strap.
15. Secure the wiring harness clips to the passenger side of the in-vehicle crossbeam.
16. Connect and secure the rear blower motor electrical connector.
17. Secure the wiring harness to the passenger side of the in-vehicle crossbeam.
18. Secure the gearshift interlock cable to the in-vehicle cross beam. Secure with a tie-strap.
19. Connect the PATS module electrical connector.
20. Connect the audio wiring harness to the main wiring harness. Connect the electrical connectors. Secure the electrical connectors to the in-vehicle crossbeam.
21. Connect the main wiring harness to the A/C wiring harness. Connect the electrical connectors.
22. Secure the wiring harness to the center of the in-vehicle crossbeam. Secure the wiring harness clips. Secure the wiring harness clip. Secure with a tie-strap.
23. Secure the wiring harness to the driver side of the in-vehicle crossbeam. Secure the wiring harness clips.
24. Install the in-vehicle crossbeam to bulkhead bolts. Tighten the bolts to 25 Nm (18 lb.ft).
25. Install the steering column. Refer to «Steering Column»(/land-rover/range-rover/l322-2005-2009/remont/steering-column/#steering-column) .
26. Install the windshield wiper motor. Reposition the windshield wiper motor. Install the bolts. Tighten the bolts to 10 Nm (7 lb.ft). Reposition the wiper linkage to its original position. Install the windshield wiper motor to wiper linkage assembly nut. Tighten the nut to 25 Nm (18 lb.ft).
27. Install the heater and evaporator core housing to bulkhead. Tighten the nuts to 10 Nm (7 lb.ft).
28. Connect the A/C refrigerant lines. Install the grommet. Remove the blanking plugs. Clean the component mating faces. Lubricate and install the new O-rings. Tighten the bolts to 25 Nm (18 lb.ft).
29. Connect the coolant hoses to the heater core pipes. Remove the blanking plugs. Install the rubber grommet. Connect the coolant hoses and secure with the clips. Remove the container. Remove the coolant hose clamps.
30. Install the plenum chamber support. Tighten the bolts and nuts to 10 Nm (7 lb.ft).
31. Connect the battery positive cable. Tighten to 20 Nm (15 lb.ft).
32. Install the instrument panel reinforcement. See «INSTRUMENT PANEL REINFORCEMENT»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
33. Recharge the A/C system. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
34. Install the plenum chamber. Refer to «Plenum Chamber»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
35. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. Remove the floor console. See «FLOOR CONSOLE»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
2. Release the climate control assembly. Release the 4 clips.
3. Remove the climate control assembly. Disconnect the 4 electrical connectors.
4. Remove the climate controlled seat switch. Release the 4 clips. Disconnect the 2 electrical connectors.
5. Remove the instrument panel center reinforcement. Remove the 6 Torx screws.

1. Install the instrument panel center reinforcement. Tighten the Torx screws.
2. Install the climate controlled seat switch. Connect the 2 electrical connectors. Secure the 4 clips.
3. Install the climate control assembly. Connect the 4 electrical connectors. Secure the 4 clips.
4. Install the floor console. See «FLOOR CONSOLE»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the instrument cluster. Refer to «Instrument Cluster»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-cluster) .
4. Remove the driver side floor console extension. Remove the screw. Release the 2 clips.
5. Release the driver side closing trim panel. Remove the 4 screws. Remove the clip.
6. Remove the driver side closing trim panel. Disconnect the 2 electrical connectors. Release the vehicle diagnostic socket.
7. Remove the 6 lower screws from the instrument panel lower section.
8. Remove the instrument cluster finish panel. Remove the 2 screws.
9. Release the instrument panel lower section. Remove the 2 upper screws.
10. Remove the instrument panel lower section. Release the driver lower air bag module harness. Disconnect the driver lower air bag module electrical connector. Disconnect the footwell lamp electrical connector.
11. Remove the footwell lamp assembly. Release the 2 clips.
12. Remove the driver lower air bag module. Remove the 10 nuts.

1. Install the driver lower air bag module. Tighten the nuts to 8 Nm (6 lb.ft).
2. Install the footwell lamp assembly. Secure with the 2 clips.
3. Install the instrument panel lower section. Connect the footwell lamp electrical connector. Connect the driver lower air bag module electrical connector. Secure the driver lower air bag module harness.
4. Secure the instrument panel lower section. Install the 2 upper screws.
5. Install the instrument cluster finish panel. Install the 2 screws.
6. Install the 6 lower screws to the instrument panel lower section.
7. Install the driver side closing trim panel. Attach the vehicle diagnostic socket. Connect the 2 electrical connectors.
8. Secure the driver side closing trim panel. Install the 4 screws. Install the clip.
9. Install the driver side floor console extension. Secure the 2 clips. Install the screw.
10. Install the instrument cluster. Refer to «Instrument Cluster»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-cluster) .
11. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the lower center registers panel assembly. See «LOWER CENTER REGISTERS PANEL ASSEMBLY»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Remove the 4 screws securing the integrated control panel (ICP) bracket to the instrument panel reinforcement.
5. Remove the ICP assembly. Disconnect the 3 electrical connectors. Disconnect the 3 coaxial cables.
6. Remove the transponder coil from the ignition switch. Disconnect the electrical connector.
7. Release the ignition switch from the ignition switch mounting bracket. Remove the 2 screws.
8. Remove the clockspring. Refer to «Clockspring»(/land-rover/range-rover/l322-2005-2009/remont/airbag/#supplemental-restraint-system) .
9. Remove the steering column extension gaiter. Release the 4 clips.
10. Remove the climate controlled seat switch. Refer to «Climate Controlled Seat Switch»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
11. Remove the floor console. See «FLOOR CONSOLE»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
12. Remove the driver side footwell duct. Remove the 2 screws.
13. Disconnect the rear blower motor electrical connector. Release the rear blower motor electrical connector from the clip.
14. Release the instrument panel reinforcement. Remove the 10 screws.
15. With assistance, remove the instrument panel reinforcement. Disconnect the sunload sensor electrical connector. Release the ICP wiring harness clip. Release the instrument cluster wiring harness clip.
16. Remove the sunload sensor. Release the 2 clips.
17. Remove the instrument panel center reinforcement. Remove the 6 screws.
18. Remove the ignition switch mounting bracket. Remove the 3 screws.
19. Remove the instrument panel ducting. Remove the 14 screws.

1. Install the instrument panel ducting. Install the 14 screws.
2. Install the ignition switch mounting bracket. Install the 3 screws.
3. Install the instrument panel center reinforcement. Install the 6 screws.
4. Install the sunload sensor.
5. With assistance, install the instrument panel reinforcement. Secure the instrument cluster wiring harness clip. Secure the ICP wiring harness clip. Connect the sunload sensor electrical connector.
6. Secure the instrument panel reinforcement. Install the screws.
7. Connect and secure the rear blower motor wiring harness electrical connector.
8. Install the driver side footwell duct. Install the 2 screws.
9. Install the floor console. See «FLOOR CONSOLE»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
10. Install the climate controlled seat switch. Refer to «Climate Controlled Seat Switch»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
11. Install the steering column extension gaiter. Secure in the 4 clips.
12. Install the clockspring. Refer to «Clockspring»(/land-rover/range-rover/l322-2005-2009/remont/airbag/#supplemental-restraint-system) .
13. Secure the ignition switch to the ignition switch mounting bracket. Install the 2 screws.
14. Install the transponder coil. Connect the electrical connector.
15. Install the ICP assembly. Connect the 3 electrical connectors. Connect the 3 coaxial cables.
16. Install the screws securing the ICP to the instrument panel.
17. Install the lower center registers panel assembly. See «LOWER CENTER REGISTERS PANEL ASSEMBLY»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
18. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Note. The passenger air bag is installed to the underside of the instrument panel upper section.

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the upper glove compartment. See «UPPER GLOVE COMPARTMENT»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Disconnect the passenger air bag module electrical connector. Release the passenger air bag module harness.
5. Remove the 2 bolts securing the passenger air bag module to the in-vehicle crossbeam.
6. Remove the driver side register trim panel. Refer to «Driver Side Register Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
7. Remove the upper center registers. Refer to «Upper Center Registers»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
8. Remove the instrument panel center speaker grille.
9. With assistance, remove the instrument panel upper section. Remove the 10 screws. Slide the instrument panel upper section away from the windshield and disconnect the instrument panel center speaker electrical connector.
10. Remove the instrument cluster finish panel. Remove the 4 screws.
11. Remove the instrument panel center speaker. Remove the 4 screws.
12. Remove the passenger air bag module. Remove the 8 nuts.

1. Install the passenger air bag module. Tighten the nuts to 8 Nm (6 lb.ft).
2. Install the instrument panel center speaker. Install the 4 screws.
3. Install the instrument cluster finish panel. Install the 4 screws.
4. With assistance, install the instrument panel upper section. Connect the instrument panel center speaker electrical connector. Install the 10 screws.
5. Install the instrument panel center speaker grille.
6. Install the upper center registers. Refer to «Upper Center Registers»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
7. Install the driver side register trim panel. Refer to «Driver Side Register Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
8. Install the 2 bolts securing the passenger air bag module to the in-vehicle crossbeam.
9. Connect the passenger air bag module electrical connector. Secure the passenger air bag module harness.
10. Install the upper glove compartment. See «UPPER GLOVE COMPARTMENT»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
11. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the instrument panel lower section. See «INSTRUMENT PANEL LOWER SECTION»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Release the lower center registers panel assembly. Release the 6 clips.
5. Remove the lower center registers panel assembly. Disconnect the 5 electrical connectors. Release the temperature blend door control cable.
6. Remove the glove compartment switch. Release the 3 clips.
7. Remove the center registers. Release the 4 clips.
8. Remove the ignition switch surround. Release the 3 clips.

1. Install the ignition switch surround.
2. Install the center registers. Secure the 4 clips.
3. Install the glove compartment switch.
4. Install the lower center registers panel assembly. Attach the temperature blend door control cable. Connect the 5 electrical connectors. Position and secure the clips.
5. Install the instrument panel lower section. See «INSTRUMENT PANEL LOWER SECTION»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
6. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Open the lower glove compartment.
3. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
4. Remove the cowl side trim panel. Refer to «Cowl Side Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
5. Remove the floor console extension trim panel. See «FLOOR CONSOLE EXTENSION»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
6. Remove the passenger side closing trim panel. Remove the 3 screws. Disconnect the footwell lamp electrical connector.
7. Remove the passenger side register trim panel. Refer to «Passenger Side Register Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
8. Release the lower glove compartment. Remove the retaining screw.
9. Open the lower glove compartment to the service position.
10. Remove the 8 screws from the lower glove compartment.
11. Remove the lower glove compartment. Disconnect the electrical connector from the footwell lamp. Disconnect the electrical connector from the lower glove compartment lamp. Disconnect the electrical connector from the lower glove compartment latch.
12. Remove the lower glove compartment lamp.
13. Remove the lower glove compartment latch. Remove the 3 screws.
14. Remove the lower glove compartment lid. Remove the 6 screws from the lower glove compartment lid. Collect the lower glove compartment striker.

1. Install the lower glove compartment lid. Position the lower glove compartment striker. Install the 6 screws to the lower glove compartment lid.
2. Install the lower glove compartment latch. Install the 3 screws.
3. Install the lower glove compartment lamp.
4. Install the lower glove compartment. Connect the lower glove compartment latch electrical connector. Connect the lower glove compartment lamp electrical connector. Connect the footwell lamp electrical connector. Align the lower glove compartment.
5. Secure the lower glove compartment. Install the 8 screws.
6. Close the lower glove compartment.
7. Attach the lower glove compartment. Install the 3 screws. Install the retaining screw.
8. Install the passenger side register trim panel. Refer to «Passenger Side Register Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/automatic-hvac-system/#air-distribution-and-filtering) .
9. Install the passenger side closing trim panel. Connect the footwell lamp electrical connector. Install the 3 screws.
10. Install the floor console extension trim panel. See «FLOOR CONSOLE EXTENSION»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
11. Install the cowl side trim panel. Refer to «Cowl Side Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
12. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 92

1. Open the lower glove compartment.
2. Remove the lower glove compartment lid. Remove the 6 screws from the lower glove compartment lid. Collect the lower glove compartment striker. Disconnect the footwell lamp electrical connector.
3. Remove the footwell lamp assembly. Release the 2 clips.

1. Install the footwell lamp assembly.
2. Install the lower glove compartment lid. Connect the footwell lamp electrical connector. Position the lower glove compartment striker. Install the 6 screws.
3. Close the lower glove compartment.

Scheme 93

Scheme 94

Scheme 95

1. Release the overhead console. Open the sunglasses compartment. Remove the 2 screws. Release the 6 clips.
2. Remove the overhead console. Disconnect the 4 electrical connectors.
3. Remove the front interior lamp. Release the 2 clips.
4. Remove the roof opening panel switch. Carefully release the 2 clips.
5. Remove the overhead console blanking trim. Release the 4 clips.
6. Release the tire pressure monitoring system receiver.
7. Remove the cellular phone microphone. Release the 3 clips.
8. Remove the 4 clips from the overhead console.

1. Install the 4 clips to the overhead console.
2. Install the cellular phone microphone. Secure the 3 clips.
3. Secure the tire pressure monitoring system receiver.
4. Install the overhead console blanking trim. Secure the 4 clips.
5. Install the roof opening panel switch. Secure in the 2 clips.
6. Install the front interior lamp. Secure the 2 clips.
7. Install the overhead console. Connect the 4 electrical connectors.
8. Secure the overhead console. Secure the 6 clips. Install the 2 screws. Close the sunglasses compartment.

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the lower glove compartment. See «LOWER GLOVE COMPARTMENT»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
4. Remove the 2 screws from the compact disc (CD) changer bracket.
5. Open the upper glove compartment.
6. Remove the upper glove compartment finisher trim panel. Remove the screw. Release the 3 clips.
7. Remove the 3 screws from the upper glove compartment.
8. Remove the upper glove compartment. Disconnect the upper glove compartment latch electrical connector. If installed, disconnect the electrical connector from the portable camera docking station. Disconnect the coaxial cable from the portable camera docking station. Disconnect the CD changer electrical connector.
9. Remove the CD changer. Remove the 3 screws securing the CD changer bracket to the upper glove compartment.
10. Remove the upper glove compartment latch. Remove the 3 screws.
11. Release and remove the portable camera from the portable camera docking station.
12. Remove the portable camera docking station. Remove the 2 screws.
13. Remove the upper glove compartment lid. Remove the 6 screws from the upper glove compartment lid. Collect the upper glove compartment striker.

1. Install the upper glove compartment lid. Position the upper glove compartment striker. Install the 6 screws to the upper glove compartment lid.
2. Install the portable camera docking station. Install the 2 screws.
3. Install the portable camera to the portable camera docking station.
4. Install the upper glove compartment latch. Install the 3 screws.
5. Install the CD changer. Install the 3 screws securing the CD changer bracket to the upper glove compartment.
6. Install the upper glove compartment. Connect the CD changer electrical connector. Connect the portable camera docking station coaxial cable. Connect the portable camera docking station electrical connector. Connect the upper glove compartment latch electrical connector.
7. Install the 3 screws to the upper glove compartment.
8. Install the upper glove compartment finisher trim panel. Secure the 3 clips. Install the screw.
9. Close the upper glove compartment.
10. Install the 2 screws to the CD changer bracket.
11. Install the lower glove compartment. See «LOWER GLOVE COMPARTMENT»(/land-rover/range-rover/l322-2005-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) .
12. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 104

1. Open the upper glove compartment.
2. Remove the upper glove compartment lid. Remove the 6 screws from the upper glove compartment lid. Collect the upper glove compartment striker.

1. Install the upper glove compartment lid. Position the upper glove compartment striker. Install the 6 screws.
2. Close the upper glove compartment.

See also:
• Air Bag and Safety Belt Pretensioner Supplemental Restraint System (SRS)
• Air Distribution and Filtering
• Interior Lighting
• Specifications
• Front Seat
• Transmission Selector Lever Knob
• Register
• Standard Workshop Practices
• Air Conditioning (A/C) System Recovery, Evacuation and Charging
• Steering Column
• Instrument Cluster
• Cowl Side Trim Panel
• INSTRUMENT PANEL
