Glass, Frames and Mechanisms Land Rover Range Rover L322

Scheme 1

OVERVIEW

Electric windows are installed in all 4 doors. The front windows are controlled by their respective door modules integrated into the window switch packs. The rear windows are controlled by the GEM. The GEM and the door modules communicate with each other on the P bus.

Window operating features are market dependent and include one-shot opening and closing, convenience opening and closing, and anti-trap. Market options for window operation are set centrally in the GEM.

Individual window switches are installed in each of the 3 passenger doors. Window switches for all of the windows, and a child lock switch to isolate the rear windows, are installed in the driver's door.

All of the window switches have 2 switching positions in each direction. The first switching position operates the window in the inching mode, where the window moves until the switch is released or until it reaches the fully open or closed position. The second switching position operates the window in the one-shot mode.

Scheme 2

Note. A heated windshield is not available on vehicles fitted with infra-red reflecting glass.

The laminated windshield is bonded, and sealed, to the body aperture using PU sealant. Heat bonded to the inner surface of the windshield is the optical unit for the rain/light sensor.

Tinted green, with an anti-glare strip, and infra-red reflecting glass available as an optional extra, the windshield has 2 separate heating systems.

Vertical fine-wire multi-strand elements are fitted between the glass laminations to de-ice and de-mist the windshield. At the bottom of the screen 6 horizontal heating elements bonded to the interior glass surface prevent the wiper blades freezing to the windshield during adverse weather conditions. Refer to Control Components .

The windshield is supplied with the heating element flat foil connectors fitted to a molded sealed terminal block. This terminal block is wired to a connector for connecting to the vehicle harness.

The following should be noted when replacing the windshield

1. Ensure that the windshield is electrically disconnected
2. Before and during fitting the windshield ensure that the heater elements foil connectors are taped back to avoid damage to the connectors
3. Avoid excessive use of sealant. When correctly fitted the sealant bed should not exceed 5 mm in thickness.

REAR SCREEN

The rear screen is made from green tinted, tempered glass and is bonded to the upper tail door frame using PU sealant. Fitted to the inner surface of the rear screen are the heating elements and antenna for the audio system and central locking systems.

The heating element is connected by 2 lucar terminals while the antenna is connected to the vehicle by a 2-pin connector at the top of the screen.

The following should be noted when replacing the rear screen

1. Ensure that the screen is electrically disconnected.
2. Avoid excessive use of sealant. When correctly fitted the sealant bed should not exceed 5 mm in thickness.

Scheme 3

Scheme 4

Cable operated window regulators powered by an electric motor are installed in each of the doors.

Anti-trap Sensors

An anti-trap sensor is installed along the top of each window aperture, just outside the travel path of the window glass. Each anti-trap sensor consists of a rubber covered contact strip connected to ground and to a power supply from the door modules (front windows) or GEM (rear windows). When the anti-trap sensor is pressed the resistance across the contact strip is reduced. If a window is being closed and the door module/GEM detects a drop in resistance across the associated anti-trap sensor, it immediately (in less than 20 milliseconds) reverses the window.

Scheme 5

Note. A = Hardwired; B = K bus; C = Diagnostic DS2 bus; M = P bus

PRINCIPLES OF OPERATION

Electric window operation using the window switches is enabled while the ignition switch is in positions I and II, and for 16 minutes after switching from position I to position 0. Window operation is immediately disabled when a front door is opened.

When the switches in the driver's door are used to operate the passenger windows or the child lock, the driver door module (DDM) outputs a related message on the P bus. The passenger door module or the GEM respond to the message by operating the appropriate window or the child lock function. While the child lock is engaged, the GEM ignores inputs from the rear window switches, and the driver door module illuminates a light emitting diode (LED) in the child lock switch.

END OF TRAVEL SHUT OFF

End of travel shut off for the window motors is determined by monitoring the current draw of the motors. Each time it switches on a window motor, the door module or GEM measures the window motor current for 22 milliseconds, in 2 milliseconds intervals. The maximum value measured within that time is stored as the switch-on current, which must be 5 A minimum. When the window motor current next exceeds the switch-on current minus 2 A, the door module/GEM assumes the window has reached the end of its travel and, after 0.5 second, switches off the power supply to the window motor, even if a window switch is still being activated.

Measuring the switch-on current for each switching operation automatically compensates for changes of load with varying ambient conditions etc.

To protect the window motors from overheating if the end of travel shut off function fails, window motor activation in both directions is limited to 8 seconds.

ANTI-TRAP

The anti-trap function is enabled for window closing in both the inching and one-shot modes. If an anti-trap sensor is activated while a window is closing, the window motor is reversed. The reversing time is proportionate to the preceding closing time and varies between 0.5 and 2.0 seconds.

In an emergency, for example if the anti-trap sensor is faulty, the anti-trap function can be overridden by holding the window switch in the one-shot closed position.

CONVENIENCE OPENING AND CLOSING

Convenience opening and closing is enabled provided the ignition switch is not in position I or above. The windows and roof opening panel (where fitted) can be opened and closed in sequence, while unlocking and locking the vehicle, using the driver's door lock or the remote handset.

Convenience closing begins after a time delay of 1.5 seconds when the door lock is held in the lock position or the remote handset lock button is pressed and held. The anti-trap function is enabled during convenience closing. The closing operation also stops immediately the door lock is released from the lock position or the remote handset lock button is released. The window motors are switched in pairs, with the rear ones switched first followed 1 second later by the front ones. The roof opening panel begins closing when all of the windows are closed or 3.5 seconds after convenience closing started, whichever occurs first.

North American Specification (NAS) vehicles leave the factory with convenience closing configured 'OFF'. This feature can be configured 'ON' using the customer personalization feature.

Convenience opening begins after a time delay of 2.5 seconds when the door lock is held in the unlock position or the remote handset unlock button is pressed and held. The opening operation stops immediately the door lock is released from the unlock position or the remote handset unlock button is released. The window motors are switched in pairs, with the front ones switched first followed 1 second later by the rear ones. The roof opening panel begins opening 3.5 seconds after convenience opening started.

Operating the windows and roof opening panel in sequence allows a degree of selective operation, e.g. the windows can be closed and the roof opening panel left open when locking the vehicle and using convenience closing.

REPETITION BLOCKING

To prevent the window motors from overheating, the door modules and the GEM record the run time for each motor they control. The run time, in seconds, is added to a counter on completion of each activation, and 1 second is deducted from the counter for every 3 seconds the window motor is inactive. If the counter exceeds 60 seconds, no new activation for the window motor is accepted until the counter is below 60 seconds again. The only exception is a reversing operation triggered by the anti-trap function, which is always accepted regardless of the counter value.

PRINCIPLE OF OPERATION

For a detailed description of the glass, frames and mechanisms and operation, refer to the relevant Description and Operation section of the workshop manual. REFER to: Glass, Frames and Mechanisms (501-11 Glass, Frames and Mechanisms, Description and Operation).

INSPECTION AND VERIFICATION

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage. Mechanical Electrical Window control switches condition and installation Window motors/regulators Window channels/runners Window cables Fuses Harnesses and connectors Window lift relay Window control switches Window motors
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the cause is not visually evident, verify the symptom and refer to the Symptom Chart, alternatively check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

SYMPTOM CHART

DTC INDEX

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to GENERAL INFORMATION .

PINPOINT TEST A: WINDOW(S) NOISY DURING OPERATION

PINPOINT TEST B: WINDOW(S) INOPERATIVE (MOTOR NOISE CANNOT BE HEARD)

PINPOINT TEST C: WINDOW(S) INOPERATIVE (MOTOR NOISE CAN BE HEARD)

PINPOINT TEST D : SLOW OR PARTIAL WINDOW OPERATION

PINPOINT TEST E : WIND NOISE BETWEEN THE DOOR WINDOW GLASS AND SEAL

PINPOINT TEST F : FRONT DOOR WINDOW GLASS BOUNCE BACK

DOOR GLASS SETTING PROCEDURE

Note. Make sure that this procedure is carried out if any concern is with noise or if directed by a pinpoint test.

Scheme 6

1. Remove the door trim panel as necessary. REFER to: Front Door Trim Panel (501-05, Removal and Installation) / Rear Door Trim Panel (501-05, Removal and Installation).
2. Release but do not remove the door window glass retaining clip(s) bolt(s).
3. Operate the window switch up and down seven times to make sure that the door window glass is correctly installed to the door window seal.
4. Install the door window glass to the retaining clips, first to the front retaining clip and then to the rear.
5. Push the door window glass to the rear of the door to make sure correct installation in to the door window glass seal.
6. Tighten the door window glass retaining clip bolts to 10 Nm.
7. Check the system for normal operation.

Scheme 7

1. Remove the front door trim panel. Refer to «Front Door Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
2. Remove the driver door window control switch. Remove the 4 screws.

INSTALLATION

1. Install the driver door window control switch. Tighten the screws.
2. Install the front door trim panel. Refer to «Front Door Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 8

Scheme 9

1. Remove the front door window glass. See «Front Door Window Glass»(/land-rover/range-rover/l322-2005-2009/remont/windows/#glass-frames-and-mechanisms) .
2. Release the front door window regulator and motor from the side impact protection beam. Disconnect the electrical connector. Remove the bolt. Remove the clip. Remove the clamp.
3. Remove the front door window regulator and motor. Remove and discard the 2 lower bolts. Remove the 3 upper bolts.

1. Install the front door window regulator and motor. Remove the 2 clips. Install the clamp. Tighten the 4 upper bolts to 10 Nm (7 lb.ft). Tighten the 2 new lower bolts to 10 Nm (7 lb.ft). Install the clip.
2. Connect the front door window regulator and motor electrical connector.
3. Install the front door window glass. See «Front Door Window Glass»(/land-rover/range-rover/l322-2005-2009/remont/windows/#glass-frames-and-mechanisms) .

Scheme 10

1. Lower the front door window glass.
2. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
3. Remove the side air bag module. Refer to «Side Air Bag Module»(/land-rover/range-rover/l322-2005-2009/remont/airbag/#supplemental-restraint-system) .
4. Disconnect the door speaker electrical connector.
5. Remove the front door inner weathershield.
6. Release the front door window glass from the regulator. Loosen the 2 bolts.
7. Remove the front door window glass.

1. Install the front door window glass. Install the bolts, but do not tighten fully at this stage.
2. Raise the front door window glass. Check and adjust the alignment of the front door window glass. Tighten the 2 bolts to 10 Nm (7 lb.ft).
3. Install the front door inner weathershield.
4. Connect the door speaker electrical connector.
5. Install the side air bag module. Refer to «Side Air Bag Module»(/land-rover/range-rover/l322-2005-2009/remont/airbag/#supplemental-restraint-system) .

REMOVAL

Note. The following equipment is required: Cutting wire and handles. Reciprocating cutting knife. Glazing knife. Windshield glass replacement kit. Sealant applicator. Suction cups. Felt covered table or a felt covered glazing support stand.

Scheme 11

Scheme 12

Scheme 13

1. Remove the rear window wiper pivot arm. Refer to «Rear Window Wiper Pivot Arm»(/land-rover/range-rover/l322-2005-2009/remont/wiperwasher-systems/#wipers-and-washers) .
2. Remove the liftgate lower trim panel. Refer to «Liftgate Lower Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Remove the liftgate LH and RH inner side trim panels.
4. Remove the liftgate window glass outer finisher trim panel.
5. Disconnect the 3 electrical connectors from the liftgate window glass.
6. Apply protection to the exterior paintwork, adjacent to the liftgate window glass.
7. Using a glazing knife, cut through the lower edge of the liftgate window glass sealant from the inside. Do not use the oscillating type of glazing knife, as the Liftgate window glass is very close to the liftgate.
8. Cut through the remaining top and sides of the liftgate window glass sealant, using the cutting wire method as required. Use of a reciprocating flat blade glazing knife is permissible.
9. With assistance, remove the liftgate window glass. Attach suction cups to aid liftgate window glass removal.
10. Remove the 2 liftgate window glass support blocks from the liftgate.
11. Remove the liftgate window glass sealant from the liftgate. Make sure when the sealant has been removed that the finished surface is clean and smooth.
12. Remove liftgate window glass sealant from the liftgate window glass. Make sure when the sealant has been removed, that the surface is clean and smooth and without damage to the obscuration band.

Scheme 14

Scheme 15

1. Install the finisher trim to the liftgate window glass.
2. Install the liftgate window glass support blocks to the liftgate.
3. With assistance, install the liftgate window glass and centralize in the liftgate aperture. Use masking tape to establish reference marks and to aid as an alignment guide. Attach suction cups to aid alignment and install.
4. With assistance, remove the liftgate window glass and place on the felt covered supports.
5. Using the recommended solvent, clean the sealant mating faces of the liftgate and the liftgate window glass.
6. Apply etch primer to any liftgate bare metal.
7. Apply primer over the previously applied etch primer.
8. Apply glass primer to the sealant mating face of the liftgate window glass and allow to cure.
9. Apply activator over the old sealant on the liftgate and allow to cure.
10. Install the pre-cut nozzle to sealant cartridge and remove the lid and shake out the crystals, followed by installing the cartridge to the applicator tool. If necessary, modify the nozzle to achieve the required bead section.
11. Apply a continuous bead of sealant to the liftgate window glass as shown.
12. With assistance, install and align the liftgate window glass. Lightly press the liftgate window glass to seat the sealant.
13. Remove the masking tape and exterior paintwork protection.
14. Connect the liftgate window glass electrical connectors.
15. Test the liftgate window glass sealant for leaks. If water is used as a means for the leak check, then allow sealant to dry before testing. Spray water around the liftgate window glass, mark any area that leaks. Dry the liftgate window glass and sealant before applying additional sealant.
16. Install the liftgate LH and RH inner side trim panels.
17. Install the liftgate lower trim panel. Refer to «Liftgate Lower Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
18. Install the rear window wiper pivot arm. Refer to «Rear Window Wiper Pivot Arm»(/land-rover/range-rover/l322-2005-2009/remont/wiperwasher-systems/#wipers-and-washers) .

Scheme 16

Scheme 17

Scheme 18

1. Lower the rear door window glass.
2. Remove the rear door trim panel. Refer to «Rear Door Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
3. Disconnect the door speaker electrical connector.
4. Remove the rear door inner weathershield.
5. Remove the rear door upper trim panel. Release the 2 clips. Disconnect the electrical connector.
6. Remove the rear window glass guide channel. Remove the 3 screws.
7. Remove the rear door window glass. Remove the bolt.

1. Install the rear door window glass. Install the bolt and tighten to 10 Nm (7 lb.ft).
2. Install the rear window glass guide channel. Install the 3 screws. Install the seal.
3. Install the rear door upper trim panel. Connect the electrical connector.
4. Connect the door speaker electrical connector.
5. Install the rear door inner weathershield.
6. Check correct operation of the rear door window glass.
7. Install the rear door trim panel. Refer to «Rear Door Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 19

1. Remove the rear door window glass. See «Rear Door Window Glass»(/land-rover/range-rover/l322-2005-2009/remont/windows/#glass-frames-and-mechanisms) .
2. Remove the rear door window regulator and motor. Disconnect the electrical connector. Remove and discard the lower bolt. Remove the 2 upper bolts.

1. Install the rear door window regulator and motor. Remove the two clips from the rear door window regulator and motor. Tighten the 2 upper bolts to 10 Nm (7 lb.ft). Tighten the new bolt to 10 Nm (7 lb.ft).
2. Connect the rear door window glass regulator and motor electrical connector.
3. Install the rear door window glass. See «Rear Door Window Glass»(/land-rover/range-rover/l322-2005-2009/remont/windows/#glass-frames-and-mechanisms) .

Note. The following equipment is required: Cutting wire and handles. Reciprocating cutting knife. Glazing knife. Glass replacement kit. Sealant applicator. Suction cups. Felt covered table or a felt covered glazing support stand.

Scheme 20

1. Remove the rear quarter panel molding. Refer to «Rear Quarter Panel Molding»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .
2. Remove the access panel from the loadspace trim panel.
3. Disconnect the antenna module electrical connector.
4. Apply protection to the exterior paintwork, adjacent to the rear quarter window glass.
5. Apply protection to the internal trim, adjacent to the rear quarter window glass.
6. Remove the upper and lower rear quarter window glass finishers. Cut through the bonded finishers, to gain access to the rear quarter window glass sealant.
7. Cut through the rear quarter window glass sealant from the outside. Use of a reciprocating flat blade glazing knife is permissible.
8. If required, use a glazing cutting wire to remove any remaining sealant.
9. Remove the rear quarter window glass.
10. Remove the sealant from the rear quarter window glass aperture. Make sure when the sealant has been removed that the finished surface is clean and smooth.

Scheme 21

1. Using the recommended solvent, clean the mating face of the rear quarter window glass aperture.
2. Apply etch primer to any bare metal.
3. Apply primer over the etch primer.
4. Apply glass primer to the sealant face of the rear quarter window glass and allow to cure.
5. Apply activator over the old sealant on the rear quarter window glass aperture and allow to cure.
6. Install the pre-cut nozzle to sealant cartridge and remove the lid and shake out the crystals, followed by installing the cartridge to the applicator tool.
7. Apply a continuous bead of sealant to the rear quarter window glass as shown.
8. With assistance, install and align the rear quarter window glass. Lightly press the rear quarter window glass into the rear quarter window glass aperture to seat the sealant.
9. Connect the antenna module electrical connector.
10. Install the access panel to the loadspace trim panel.
11. Remove the protection, from the interior and exterior rear quarter window glass area.
12. Test the sealer for leaks, apply additional sealer if necessary. If water is used, allow sealer to dry before testing. Spray water around the glass and check for leaks. Mark any area that leaks. Dry the glass and sealer then apply additional sealer.
13. Install the rear quarter panel molding. Refer to «Rear Quarter Panel Molding»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .

Note. The following equipment is required: Cutting wire and handles. Reciprocating cutting knife. Glazing knife. Windshield glass replacement kit. Sealant applicator. Suction cups. Felt covered table or a felt covered glazing support stand.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Remove the roof moldings. Refer to «Roof Molding»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .
2. Remove the windshield glass moldings. See «Windshield Molding»(/land-rover/range-rover/l322-2005-2009/remont/windows/#glass-frames-and-mechanisms) .
3. Remove the cowl panel grille. Refer to «Cowl Panel Grille»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels__cowl-panel-grille) .
4. Remove the interior rear view mirror. Refer to «Interior Rear View Mirror»(/land-rover/range-rover/l322-2005-2009/remont/heated-glassdefoggers/#rear-view-mirrors) .
5. Remove the A-pillar trim panels. Refer to «A-Pillar Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
6. Disconnect the 2 electrical connectors from the heated windshield glass element.
7. Apply protection to the exterior paintwork, adjacent to the windshield glass.
8. Apply masking tape to the defroster ducts.
9. Apply protection to the instrument panel and interior of the vehicle.
10. Remove the windshield glass upper molding.
11. Using a flat blade cutting tool and working from the outside, cut through the windshield glass sealant securing both sides and the upper section. Use of a reciprocating flat blade glazing knife is permissible. If necessary use a cutting wire to cut through any remaining windshield glass sealant securing the sides and the upper section.
12. Working from the inside and using a glazing knife, cut through the windshield glass sealant securing the lower section. Use of a reciprocating flat blade glazing knife is permissible.
13. With assistance, remove the windshield glass. Use suction cups to aid removal.
14. Remove the 4 windshield glass support blocks from the vehicle body.
15. Remove the windshield glass sealant from the vehicle body. Make sure when the sealant has been removed that the finished surface is clean and smooth.
16. Remove the windshield glass sealant from the windshield glass. Make sure when the sealant has been removed, that the surface is clean and smooth and without damage to the obscuration band.

Scheme 26

Scheme 27

1. Install the windshield glass upper molding.
2. Install the windshield glass support blocks to the vehicle body.
3. With assistance, install the windshield glass and centralize in the vehicle body aperture.
4. Use masking tape to establish reference marks and to aid as an alignment guide.
5. With assistance, remove the windshield glass.
6. Using the recommended solvent, clean the mating faces of the vehicle body windshield glass aperture and windshield glass.
7. Apply etch primer to the vehicle body windshield glass aperture.
8. Apply primer over the previously applied etch primer.
9. Apply glass primer to the sealant mating face of the windshield glass and allow to cure.
10. Apply activator over the old sealant on the vehicle body windshield glass aperture and allow to cure.
11. Install the pre-cut nozzle to sealant cartridge and remove the lid and shake out the crystals, followed by installing the cartridge to the applicator tool.
12. Apply a continuous bead of sealant to the windshield glass as shown.
13. With assistance, install and align the windshield glass. Lightly press the windshield glass to seat the sealant.
14. Remove the masking tape and exterior paintwork protection.
15. Test the windshield glass sealant for leaks. If water is used as a means for the leak check, then allow sealant to dry before testing. Spray water around the windshield glass, mark any area that leaks. Dry the windshield glass and sealant before applying additional sealant.
16. Connect the heated windshield glass element, electrical connectors.
17. Install the A-pillar trim panels. Refer to «A-Pillar Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
18. Install the interior rear view mirror. Refer to «Interior Rear View Mirror»(/land-rover/range-rover/l322-2005-2009/remont/heated-glassdefoggers/#rear-view-mirrors) .
19. Install the cowl panel grille. Refer to «Cowl Panel Grille»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels__cowl-panel-grille) .
20. Install the windshield glass moldings. See «Windshield Molding»(/land-rover/range-rover/l322-2005-2009/remont/windows/#glass-frames-and-mechanisms) .
21. Install the roof moldings. Refer to «Roof Molding»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .

Scheme 28

1. Remove the 4 clips securing the windscreen molding.
2. Remove the windshield molding. Release the 4 clips.
3. Remove and discard the 4 clips from the windshield molding.
4. Remove and discard the 4 clips from the A-pillar.

1. Install new clips to the A-pillar.
2. Install new clips to the windshield molding.
3. Install the windshield molding. Secure with the new clips.

See also:
• Control Components
• GENERAL INFORMATION
• Front Door Trim Panel
• Specifications
• Side Air Bag Module
• Rear Window Wiper Pivot Arm
• Rear Quarter Panel Molding
• Cowl Panel Grille
• Interior Rear View Mirror
• Front Door Window Glass - Removal and Installation
