Starting System (4.2l) Land Rover Range Rover L322

Starter 5 illustrations ~407 words

SPECIFICATIONS

ItemSpecification
Starter motor
MakeDenso
TypeRA - Pre-engaged
Voltage12
Current consumption1.8 kW

STARTER MOTOR

DescriptionNm
* B+ terminal nut10
Starter motor bolts45
Starter motor heat shield bolts45

TORQUE SPECIFICATIONS

CAUTION* Damage to the internal connections will occur if this torque is exceeded

Scheme 1

Scheme 1: STARTING SYSTEM
Scheme 1: STARTING SYSTEM

GENERAL

The starter motor is rated as a 1.8kW and is a Denso level three-sealed unit. It is an RA type starter motor, which is of the offset design with the solenoid being directly behind the pinion to give a more positive engagement to the ring gear. The motor is geared directly to the pinion. The starter motor is of the pre-engaged type and comprises a series wound motor and an overrunning clutch. This starter incorporates labyrinth-breathing tubes to help with sealing and drainage.

The starter solenoid is energized by a signal from the Engine Control Module (ECM) when the ignition switch is moved to the crank position. When engine cranking is requested, the ECM checks that a valid key code has been received before granting the crank request.

The power for starter operation is supplied on a substantial single cable connected direct from the battery positive terminal. The cable is connected to the solenoid via a copper threaded stud with an anti-rotational device and secured with a nut.

The starter motor is located on the rear RH side of the engine block. The motor is secured to the block and protrudes through an aperture to drive the flywheel via a ring gear.

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
  2. Raise and support the vehicle.
  3. Remove the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  4. Remove the RH front wheel.
  5. Remove the engine compartment RH heat shield. Remove the 2 nuts. Remove the 2 screws.
  6. Remove the starter motor heat shield. Remove the 2 bolts.
  7. Release the starter motor. Remove the 2 bolts.
  8. Remove the starter motor. Release the terminal cover. Remove the terminal nut insulator. Remove the nut. Disconnect the 2 electrical connectors.

INSTALLATION

  1. Install the starter motor. Clean the component mating faces. Connect the electrical connectors. Tighten the nut to 10 Nm (7 lb.ft). Install the terminal nut insulator. Install the terminal cover. Tighten the bolts to 45 Nm (33 lb.ft).
  2. Install the starter motor heat shield. Tighten the bolts to 45 Nm (33 lb.ft).
  3. Install the engine compartment RH heat shield. Tighten the screws. Tighten the nuts.
  4. Install the front wheel. Tighten the wheel nuts to 140 Nm (103 lb.ft).
  5. Install the engine undershield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
  6. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
