Engine Ignition (4.2l) Land Rover Range Rover L322

Ignition System 5 illustrations ~400 words

SPECIFICATIONS

ItemSpecification
Spark plugs
MakeNGK
Type1FR5N10 Iridium plug
Gap1.0 mm (0.039 in)
Ignition coils
MakeDenso
Type2W93-12A366-BA
Firing Order1-5-4-2-6-3-7-8

GENERAL SPECIFICATION

DescriptionNm
Ignition coil bolt6
Spark plugs25

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: ENGINE IGNITION
ItemDescription
1Ignition coil
2Capacitor
3Spark plug

GENERAL

The 4.2L engine ignition system has a single iridium tipped spark plug per cylinder, with each spark plug powered by an on-plug ignition coil. The ignition coils are directly driven by the engine control module (ECM).

Power for the ignition coils is supplied from the main relay and a fuse in the battery junction box (BJB). A capacitor is connected in parallel with the power supplies to the ignition coils to suppress RFI (radio frequency interference).

Each ignition coil contains a power stage to switch the current in the primary circuit. The ECM controls the switching with a signal to the power stage. The ECM monitors operation of the ignition coils using a feedback signal from each of the power stages. If a fault is detected the ECM stores an appropriate fault code.

The ECM varies the dwell time of the ignition coils depending on battery voltage and engine speed, to ensure a constant energy level is produced in the secondary coil each time the power stage is switched. This ensures a good spark is always produced by the spark plug without excessive primary current flow, thus avoiding overheating or damage to the ignition coils.

The ECM calculates the ignition timing for individual cylinders from

  1. Engine speed.
  2. Camshaft position.
  3. Engine load.
  4. Engine temperature.
  5. The knock control function.
  6. The shift control function.
  7. The idle speed control function.

CONTROL DIAGRAM

Note. A = Hardwired connection

Scheme 2

Scheme 2: CONTROL DIAGRAM
ItemDescription
1Battery
2Maxi fuse 62, central junction box (CJB)
3Fuse 25, crank feed, CJB
4Ignition switch
5Fuse 31, ignition feed, CJB
6ECM
7Ignition coil and spark plug 5
8Ignition coil and spark plug 2
9Ignition coil and spark plug 3
10Ignition coil and spark plug 8
11Capacitor
12Ignition coil and spark plug 4
13Ignition coil and spark plug 7
14Ignition coil and spark plug 6
15Ignition coil and spark plug 1
16Fuse 11, BJB
17Main relay
18Fusible link 2, CJB

Scheme 3

Scheme 3: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
  2. Remove the ignition coil-on-plugs. See «Ignition Coil-On-Plug»(/land-rover/range-rover/l322-2005-2009/remont/ignition-system/#engine-ignition-42l) .
  3. Remove the remaining ignition coil-on-plugs.
  4. Clean the area surrounding the spark plugs.
  5. Remove the spark plugs.

INSTALLATION

  1. Install the spark plugs. Tighten the spark plugs to 25 Nm (18 lb.ft).
  2. Install the ignition coil-on-plug. See «Ignition Coil-On-Plug»(/land-rover/range-rover/l322-2005-2009/remont/ignition-system/#engine-ignition-42l) .
  3. Install the remaining coil-on-plugs.
  4. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .

Scheme 4

Scheme 4: REMOVAL

Scheme 5

Scheme 5
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
  2. Remove the engine cover. Refer to «Engine Cover - 4.2L, Vehicles With: Supercharger»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  3. Remove the ignition coil cover. Release from the 2 clips.
  4. Disconnect the ignition coil-on-plug electrical connector.
  5. Remove the ignition coil-on-plug. Remove the bolt. Remove and discard the seal.
  1. To install, reverse the removal procedure. Tighten the bolt to 6 Nm (4 lb.ft).
