Speakers Land Rover Range Rover L322

Entertainment Systems 19 illustrations ~502 words

SPECIFICATIONS

DescriptionNm
Tailgate speaker to casing bolts10
Tailgate speaker to tailgate Torx screws10

TORQUE SPECIFICATIONS

DESCRIPTION & OPERATION

The speaker configuration depends on the level of audio unit fitted to the vehicle. The following details the speaker configuration and control for each system.

Scheme 21

Scheme 21: SPEAKER COMPONENT LOCATION
Scheme 21: SPEAKER COMPONENT LOCATION
ItemDescription
1Left-hand (LH) front door woofer
2LH front door mid-range
3LH front door tweeter
4Center fill speaker - Logic7 only
5Right-hand (RH) front door tweeter
6RH front door mid-range
7RH front door woofer
8RH rear door mid-woofer
9RH rear door mid-high range - Logic7 only
10Tail door surround - Logic7 only (2 off)
11Subwoofer
12LH rear door mid-woofer
13LH rear door mid-high range - Logic7 only

Scheme 22

Scheme 22: DSP SYSTEM AMPLIFIER
Scheme 22: DSP SYSTEM AMPLIFIER

The Digital Sound Processor (DSP) amplifier is located in the rear LH side of the luggage compartment. The DSP amplifier drives eleven speakers; two front door mid-range, four front and rear door bass, four front and rear door tweeters on eight channels and a passive subwoofer. The amplifier produces 320 Watts of digital amplification to power the speakers.

Scheme 23

Scheme 23: HARMAN/KARDON LOGIC7 AMPLIFIER
Scheme 23: HARMAN/KARDON LOGIC7 AMPLIFIER

The Logic7 amplifier is located in the rear LH side of the luggage compartment. The Logic7 amplifier drives fourteen speakers on 5.1 surround channels; two front door mid-range, four front and rear door bass, four front and rear door tweeters on eight channels and a passive subwoofer as on the DSP system, but with two additional surround sound speakers located in the upper tail door and a Center surround speaker located in the fascia.

Scheme 24

Scheme 24: DSP SYSTEM - SPEAKER CONTROL DIAGRAM
Scheme 24: DSP SYSTEM - SPEAKER CONTROL DIAGRAM
ItemDescription
1DSP amplifier
2RH front door tweeter
3RH front door mid-range speaker
4RH front door woofer
5RH rear door mid-high range speak
6RH rear door mid-woofer
7Subwoofer
8LH rear door mid-woofer
9LH rear door mid-high range
10LH front door woofer
11LH front door mid-range
12LH front door tweeter

Scheme 25

Scheme 25: LOGIC 7 SYSTEM - SPEAKER CONTROL DIAGRAM
Scheme 25: LOGIC 7 SYSTEM - SPEAKER CONTROL DIAGRAM
ItemDescription
1Logic7 amplifier
2Center fill speaker
3RH front door tweeter
4RH front door mid-range speaker
5RH front door woofer
6RH rear door mid-high range speaker
7RH rear door mid-woofer
8Tail door surround speaker - RH
9Subwoofer
10Tail door surround speaker - LH
11LH rear door mid-woofer
12LH rear door mid-high range speaker
13RH front door woofer
14RH front door mid-range speaker
15RH front door tweeter

Scheme 26

Scheme 26: REMOVAL
Scheme 26: REMOVAL
  1. Remove the front door trim panel. Refer to «FRONT DOOR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the front door speaker wiring harness.
  3. Remove the front door speaker. Remove the 4 screws. Disconnect the electrical connector.

INSTALLATION

  1. Install the front door speaker. Connect the electrical connector. Install the screws.
  2. Install the front door speaker wiring harness.
  3. Install the front door trim panel. Refer to «FRONT DOOR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 27

Scheme 27: REMOVAL
Scheme 27: REMOVAL
  1. Remove the rear door trim panel. Refer to «REAR DOOR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the speaker. Disconnect the electrical connector. Remove the 4 screws.
  1. Install the speaker Tighten the screws. Connect the electrical connector.
  2. Install the rear door trim panel. Refer to «REAR DOOR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 28

Scheme 28: REMOVAL
Scheme 28: REMOVAL

Scheme 29

Scheme 29
Scheme 29
  1. Remove the instrument panel center speaker grille.
  2. Remove the instrument panel speaker. Remove the 3 screws. Disconnect the electrical connector.
  1. Install the instrument panel speaker. Connect the electrical connector. Tighten the 3 screws.
  2. Install the instrument panel center speaker grille.

REMOVAL

Note. The procedure to remove the quarter panel speaker is shown in the D-pillar trim panel procedure.

  1. Remove the D-pillar trim panel. Refer to «D-PILLAR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  1. Install the D-pillar trim panel. Refer to «D-PILLAR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 30

Scheme 30: REMOVAL
Scheme 30: REMOVAL
  1. Remove the tailgate trim panel. Refer to «TAILGATE TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the tailgate speaker assembly. Remove the 10 Torx bolts. Disconnect the 2 electrical connectors.
  3. Remove the tailgate speaker. Remove the 6 bolts.
  1. Install the tailgate speaker. Tighten the bolts to 10 Nm (7 lb.ft).
  2. Install the tailgate speaker assembly. Connect the electrical connectors. Tighten the Torx bolts to 10 Nm (7 lb.ft).
  3. Install the tailgate trim panel. Refer to «TAILGATE TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .

Scheme 31

Scheme 31: REMOVAL
Scheme 31: REMOVAL

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Refer to «FRONT DOOR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation)
  2. See Figure.
  3. See figure.

Scheme 36

Scheme 36: INSTALLATION
Scheme 36: INSTALLATION

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. See figure.
  2. See figure.
  3. See figure.
  4. See figure.
  5. Refer to «FRONT DOOR TRIM PANEL»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
