Engine Cooling (4.2l) Land Rover Range Rover L322

SPECIFICATIONS

FLUIDS

CAPACITY

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

Scheme 1

Scheme 2

Scheme 3

GENERAL

The cooling system employed is of the pressure relief by-pass type, which allows coolant to circulate around the engine and the heater circuit while the thermostat main valve is closed. The primary function of the cooling system is to maintain the engine within an optimum temperature range under changing ambient and engine operating conditions. Secondary functions are to provide heating for the passenger compartment and cooling for the transmission fluid and engine oil.

The cooling system comprises

1. A radiator
2. A charge air cooler
3. A passenger compartment heater matrix
4. An engine driven coolant pump
5. An electric coolant pump
6. A thermostat
7. An expansion tank
8. An electro-viscous cooling fan
9. An Oil Cooler Mixer Valve (OCMV)
10. Connecting hoses and pipes
11. Oil to coolant Transmission Oil Cooler (TOC) and Engine Oil Coolers (EOC)
12. Air blast EOC
13. Electric condenser fan (hot markets only).

ENGINE COOLING SYSTEM

The coolant is circulated by a centrifugal pump mounted on the front of the engine and driven by an ancillary drive 'polyvee' belt. The coolant pump circulates coolant through the cylinder block and cylinder heads via a chamber located in the 'vee' of the engine. Having passed through the engine the coolant returns to the thermostat housing. The coolant then progresses down the 'top hose' to the heater pipe. The heater pipes lead to the bulkhead and return to the engine side of the thermostat. The engine contains a conventional wax thermostat, which is positioned such that the wax's temperature is controlled by both the coolant from the radiator and the bypass. The thermostat housing also contains a sprung loaded valve, which limits the amount of coolant using the bypass. At low engine speeds most coolant is diverted through the heater. At higher engine speeds the bypass opens to protect the heater matrix from to higher pressures and flow rates. This means the engine can run without coolant flowing through the bypass temporarily, to improve heater performance. The radiator is a cross-flow type with an aluminium matrix and has a drain tap on the lower right-hand rear face. The lower radiator mountings are located part way up the end tanks. The mountings are fitted with rubber bushes, which sit on plastic mounts clipped into the chassis rails. The radiator upper is mounted by pins, which are pushed through the bonnet locking platform above the radiator assembly. The top and bottom hoses are mounted to the inlet and outlet sides of the thermostat housing. The coolant expansion tank is fitted behind the RH side headlight in the engine compartment. The tank allows any air trapped in the coolant to be removed. The liquid cooled Transmission Oil Cooler (TOC) is mounted to the fan cowl. It is fed coolant from the sub-cooled section of the radiator, which is controlled by the Oil Cooler Mixer Valve (OCMV). The liquid cooled Engine Oil Cooler (EOC) is fed coolant from the sub-cooled section of the radiator, which is controlled by the OCMV. It is also mounted to the fan cowl below the TOC. Both the TOC and the EOC are connected in parallel. An additional air blast engine oil cooler is mounted in the RH front wheel arch for enhanced oil cooling performance at high speeds (supercharged derivatives only). The OCMV is a 2-stage valve which controls the heating and cooling of the engine and transmission oils. The operation of the first stage is to warm up both oils from cold to improve emissions and driveability. The second stage is fully operational once the coolant temperature reaches 91° C (196°F) and allows cooling of both oils (starts to open at 84°C (183°F)). The charged air out of the supercharger is cooled using water to air intercoolers integral with the inlet manifold, one for each bank. The coolant for the charge air cooling is driven by an electric pump at constant speed and is mounted on the engine radiator end tank. The coolant for these intercoolers is cooled using a radiator positioned in front of the air conditioning condenser. The intercooler circuit shares the engine coolant via a vortex connection situated in the radiator top hose.

Scheme 4

Note. The engine radiator and the intercooler circuits are filled using the same expansion tank.

For additional airflow through the radiator matrix, particularly when the vehicle is stationary or slow moving, there is an engine driven electro-viscous unit. This unit functions as a normal viscous fan, but with electronic control over the level of engagement of the viscous clutch. The Engine Control Module (ECM), which determines the required fan speed, controls the level of clutch engagement. The ECM determines engagement based on the coolant, ambient and transmission oil temperatures and Air Conditioning (A/C) system pressure. The fan is mounted using a RH thread (LH thread for naturally aspirated derivatives). The viscous fan unit is electronically controlled by the ECM to optimise fan speed for all operating conditions.

Note. If the electrical connections to the viscous fan are disconnected the fan will 'idle' and overheating may result. The ECM stores the appropriate fault codes in this case. A 'check engine light' will also be displayed on the instrument cluster.

ENGINE COOLING SYSTEM OPERATION

Note. Cooling System Coolant Flow

Scheme 5

When the engine is running the coolant pump is driven by the ancillary drive belt. This forces coolant to circulate around the engine and heater, while the thermostat and bypass valve are shut. As the temperature and pressure increases the bypass valve is forced open allowing coolant to circulate through the bypass valve. When the temperature reaches 88°C (190°F) the main thermostat begins to open allowing coolant to circulate through the main radiator. As the thermostat progressively opens (fully open at 95°C (203°F)), the bypass valve progressively closes forcing any coolant through the heater or radiator. Coolant flows through the radiator from the top RH tank to the bottom LH tank and is cooled by air passing through the matrix. A small flow of coolant from the top of the engine is directed to the expansion tank where any 'trapped' air is separated. The expansion tank also controls the cooling system running pressures. The charge air cooling circuit constantly flows coolant around the system with the engine running or with the ignition on position II. When the engine is running the two circuits are considered to be separate systems and the coolant does not transfer between the two. The temperature of the cooling system is monitored by the ECM via the Engine Coolant temperature (ECT) sensor located in the coolant housing. The ECM uses signals from this sensor to control the cooling fan operation. For additional information, refer to: Electronic Engine Controls - Description & Operation . To control the cooling fan, the ECM sends a Pulse Width Modulated (PWM) signal to the cooling fan clutch. The frequency of the PWM signal is used by the cooling fan clutch to control the level of clutch engagement. The ECM varies the duty cycle of the PWM signal between 0 and 100% to vary the clutch engagement and thus fan speed. The ECM operates the fan in response to inputs from the ECT sensor, the transmission oil temperature sensor and the A/C switch and pressure sensor. For additional information, refer to: Auxiliary Climate Control - Description & Operation . The speed of the cooling fan is also influenced by vehicle road speed. The ECM adjusts the speed of the cooling fans to compensate for the ram effect of vehicle speed, using the Controller Area Network (CAN) road speed signal received from the Anti-lock Braking System (ABS) module.

COOLING SYSTEM DRAINING, FILLING AND BLEEDING

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Position the vehicle on a lift.
2. Set the heater controls to maximum.
3. Disconnect the battery ground cable.
4. Remove the engine cover. Refer to «Engine Cover - 4.2L, Vehicles With: Supercharger»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
5. Remove the coolant expansion tank cap.
6. Remove the engine undershield.
7. Drain the coolant. Position a container to collect the fluid. Attach a hose to the radiator drain tap. Open the tap.
8. Close the radiator drain tap and remove the hose. Remove the container.
9. Connect the battery ground cable.
10. Connect exhaust extraction hoses to the tail pipes.
11. Stage 1.Top-up and bleed the cooling system. Remove the coolant expansion tank cap. Add coolant to the expansion tank as required. Start and run the engine.
12. When coolant runs from the expansion tank, bubble free, tighten the bleed screw.
13. Stage 2. Set the heating system to MAX heat, the blower motor to MAX speed and the air distribution to the instrument panel registers. Add coolant to the expansion tank as required. Install the coolant expansion tank cap. Loosen the coolant expansion tank bleed screw. Start and run the engine. Allow the engine to run until hot air is emitted from the instrument panel registers, while observing the engine temperature gauge.
14. Switch the engine off and allow to cool.
15. Check for leaks and then fill the coolant expansion tank to the MAX mark.
16. Install the engine cover. Refer to «Engine Cover - 4.2L, Vehicles With: Supercharger»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
17. Clean any spilt coolant from the vehicle.
18. Install the engine undershield.
19. Disconnect the exhaust extraction hoses from the tail pipes.

COOLING SYSTEM PRESSURE TEST

Note. The following procedure will enable the cooling system to be pressure tested for condition and leaks. Stage 1 will check the expansion tank cap register seal and the cap for leaks. Stage 2 will check the entire cooling system.

Note. It will be necessary to use the cooling system test kit, Part Number 511 3301 006 00, which is available under the equipment programmer.

Scheme 10

Scheme 11

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
2. Raise and support the vehicle.
3. Remove the radiator splash shield. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
4. Examine the coolant hoses for signs of cracking, distortion and security of the hose connections.
5. Disconnect the coolant expansion tank bleed hose. Release the clip.
6. Install the 'T' piece adaptor (part of the cooling system test kit) between the coolant expansion tank and the coolant bleed hose. Secure with the 2 clips.
7. Check the pressure pump and gauge prior to connection. Operate the pump plunger twice noting the reading on the pressure gauge. Make sure the pressure reading remains constant until the pressure release button is pressed.
8. Install the coolant pressure pump assembly. Connect to the 'T' piece.
9. Pressurize the cooling system. Slowly pressurize the cooling system to 1.0 bar (100 kPa) (14.5 psi). Check the pressure remains above 0.9 bar (90 kPa) (13 psi) after waiting for 30 seconds. During the pressure drop check, listen for a hissing noise from the expansion tank cap.
10. Depressurize the cooling system. Disconnect the 'T' piece. Connect the coolant expansion tank bleed hose. Secure the clip.
11. Remove the coolant expansion tank cap.
12. Install adaptor K83 to the coolant expansion tank. Clean the component mating faces. Lubricate the seal.
13. Install the coolant pressure pump assembly. Slowly pressurize the cooling system to 1.5 bar (150kPa) (22 psi), check the pressure over a 5 minute period. A small pressure decay of approximately 0.15 bar (15 kPa) (1 psi) over the first minute is normal, as the air in the expansion tank cools. If the pressure continues to drop after the initial tolerance, there is a coolant leak.
14. Identify and replace the defective component. Repeat the pressure test. When the pressure over time remains constant, depressurize and remove the pressure pump and gauge. Install the coolant expansion tank cap.
15. Install the radiator access panel. Refer to «Engine Undershield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
16. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .

REMOVAL

Scheme 12

Scheme 13

Scheme 14

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
2. Remove the coolant expansion tank cap.
3. Disconnect the 2 hoses from the coolant expansion tank. Clamp the hoses Release the 2 clips.
4. Disconnect the coolant low level sensor electrical connector.
5. Remove the coolant expansion tank. Remove the 2 bolts. Release from the clip.

INSTALLATION

1. Install the coolant expansion tank. Secure with the clip. Tighten the bolts to 10 Nm (7 lb.ft).
2. Connect the coolant low level sensor electrical connector.
3. Connect the expansion tank coolant hoses. Secure with the clips. Remove the hose clamps.
4. Top-up the coolant. Fill with coolant to approximately 30mm ABOVE the maximum cold fill line.
5. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
6. Bleed the air from the cooling system. Make sure that the expansion tank cap is removed. Connect exhaust extraction hoses to the tail pipes. Start and run the engine. Hold the engine at 3000 RPM for 1 minute. Return the engine to idle for five minutes. Hold the engine at 3000 RPM for 1 minute. Make sure that the coolant level is maintained to approximately 30mm ABOVE maximum cold fill line during the bleed procedure (with the expansion tank cap removed).
7. Check all coolant hoses for visible signs of coolant leaks.
8. Install the expansion tank cap after making sure that the final coolant level is 30mm above the maximum cold fill line.

COOLING FAN

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Viscous coupling spanner 303-1142 Viscous coupling pulley retaining tool 303-1143

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
2. Raise and support the vehicle.
3. Recover the A/C refrigerant. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
4. Remove the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
5. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
6. Release the A/C line from the cooling fan shroud. Remove the Allen bolt. Release from the 3 clips. Remove and discard the O-ring seal.
7. If installed, release the pollution sensor.
8. Release the cooling fan wiring harness. Disconnect the electrical connector. Release the 2 clips.
9. Release the automatic transmission fluid cooler. Remove the Torx screw. Release from the 2 clips.
10. Release the engine oil cooler. Remove the Torx screw. Release from the 2 clips.
11. Release the 2 coolant hoses from the cooling fan shroud. Release from the 4 clips.
12. Remove the cooling fan shroud lower clip.
13. Remove the 2 cooling fan shroud upper clips.
14. Remove the 2 cooling fan shroud Torx screws.
15. Using the special tools, release the cooling fan.
16. Remove the cooling fan and shroud.
17. Remove the viscous coupling from the cooling fan. Remove the 4 bolts.

1. Attach the viscous coupling to the cooling fan. Tighten the bolts to 10 Nm (7 lb.ft).
2. Install the cooling fan and shroud. Tighten the cooling fan to 65 Nm (48 lb.ft). Install the clips. Tighten the Torx screws.
3. Secure the coolant hoses.
4. Attach the engine oil cooler. Secure in the clips. Tighten the Torx screw.
5. Attach the automatic transmission fluid cooler. Secure in the clips. Tighten the Torx screw.
6. Attach the cooling fan wiring harness. Secure the clips. Connect the electrical connector.
7. If installed, attach the pollution sensor.
8. Connect the A/C line. Install a new O-ring seal. Tighten the Allen bolt to 10 Nm (7 lb.ft).
9. Install the radiator splash shield. Refer to «Radiator Splash Shield»(/land-rover/range-rover/l322-2005-2009/remont/exterior-body-panels/#front-end-body-panels) .
10. Install the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
11. Recharge the A/C system. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(/land-rover/range-rover/l322-2005-2009/remont/ac-compressor/#climate-control-system-general-information) .
12. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
2. Raise and support the vehicle.
3. Remove the air cleaner assembly. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
4. Remove the radiator grille. Refer to «Radiator Grille»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .
5. Drain the cooling system. See «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-system-draining-filling-and-bleeding) .
6. Remove the cooling fan. See «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
7. Release the coolant expansion tank. Remove the 2 bolts. Release from the clip. Tie the coolant expansion tank aside.
8. Release the auxiliary coolant pump. Remove the bolt.
9. Disconnect the 2 upper coolant hoses from the radiator. Release the 2 clips.
10. Disconnect the 2 lower coolant hoses from the radiator. Release the 2 clips.
11. Disconnect the 2 coolant hoses from the supercharger radiator. Release the 2 clips.
12. Release the power steering fluid reservoir. Remove the 3 bolts. Tie the reservoir aside.
13. Disconnect the refrigerant line from the A/C condenser. Remove the Allen bolt. Remove and discard the O-ring seal.
14. Release the power steering fluid cooler. Remove the clip.
15. Release the radiator assembly. Remove the 2 screws. Remove the 2 support brackets.
16. With assistance, remove the radiator assembly.
17. Remove the radiator.

1. Install the radiator.
2. With assistance, install the radiator assembly. Install the support brackets. Tighten the screws.
3. Secure the power steering fluid cooler. Install the clip.
4. Connect the A/C refrigerant line. Clean the components. Install a new O-ring seal. Tighten the Allen bolt to 10 Nm (7 lb.ft).
5. Attach the power steering fluid reservoir. Tighten the bolts to 10 Nm (7 lb.ft).
6. Connect the supercharger radiator coolant hoses. Secure with the clips.
7. Connect the radiator coolant hoses. Secure with the clips.
8. Install the auxiliary coolant pump and align with bracket register. Tighten the bolt to 6 Nm (4 lb.ft).
9. Attach the coolant expansion tank. Secure with the clip. Tighten the bolts to 10 Nm (7 lb.ft).
10. Install the air cleaner assembly. Refer to «Air Cleaner»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
11. Install the cooling fan. See «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
12. Install the radiator grille. Refer to «Radiator Grille»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .
13. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
14. Refill and bleed the cooling system. See «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-system-draining-filling-and-bleeding) .

Scheme 36

Scheme 37

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
2. Remove the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
3. Disconnect the thermostat housing coolant hose. Position an absorbent cloth to collect fluid spillage. Clamp the hose to minimize coolant loss. Release the clip.
4. Remove the thermostat housing. Remove the 3 bolts. Remove and discard the O-ring seal.
5. Release and remove the thermostat. Position the thermostat housing in a vice.

1. Install the thermostat.
2. Install the thermostat housing. Clean the components. Install a new O-ring seal. Tighten the bolts to 10 Nm (7 lb.ft).
3. Connect the thermostat housing coolant hose. Secure with the clip. Remove the hose clamp.
4. Install the air intake resonator. Refer to «Intake Air Resonator»(/land-rover/range-rover/l322-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-42l) .
5. Top-up and bleed the coolant.
6. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
2. Raise and support the vehicle.
3. Drain the cooling system. See «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-system-draining-filling-and-bleeding) .
4. Remove the cooling fan. See «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
5. Remove the cooling fan belt. Note the fitted position. Rotate the cooling fan belt tensioner clockwise. Loosen the cooling fan belt tensioner bolt to aid the removal of the belt.
6. Remove the cooling fan pulley. Remove the 3 bolts.
7. Remove the cooling fan drive hub bearing. Remove the 5 bolts.
8. Remove the cooling fan belt tensioner. Remove the bolt.
9. Release the accessory drive belt. Rotate the accessory drive belt tensioner counter-clockwise, using a 3/8 " drive wrench.
10. Remove the accessory drive belt.
11. Disconnect the coolant manifold to coolant reservoir hose. Release the clip.
12. Remove the coolant pump pulley. Remove the 3 bolts.
13. Remove the coolant pump. Remove the 5 bolts. Discard the gasket.

Scheme 45

1. Install the coolant pump. Clean the component mating faces. Install a new gasket. Tighten the bolts to 10 Nm (7 lb.ft).
2. Install the coolant pump pulley. Tighten the bolts to 10 Nm (7 lb.ft).
3. Connect and secure the coolant hose. Clean the component mating faces.
4. Install the accessory drive belt.
5. Install the cooling fan belt tensioner. Tighten the bolt to 40 Nm (30 lb.ft).
6. Install the cooling fan drive hub bearing. Tighten the bolts to 10 Nm (7 lb.ft).
7. Install the cooling fan pulley. Tighten the bolts evenly to 25 Nm (18 lb.ft).
8. Install the cooling fan belt. Tighten the cooling fan belt tensioner bolt to 40 Nm (30 lb.ft). Rotate the cooling fan belt tensioner clockwise.
9. Install the cooling fan. See «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
10. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
11. Refill the cooling system. See «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-system-draining-filling-and-bleeding) .

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
2. Raise and support the vehicle.
3. Drain the cooling system. See «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-system-draining-filling-and-bleeding) .
4. Remove the cooling fan. See «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
5. Remove the cooling fan belt. Note the fitted position. Rotate the cooling fan belt tensioner clockwise. Loosen the cooling fan belt tensioner bolt to aid the removal of the belt.
6. Remove the coolant hose support bracket. Remove the 2 bolts. Release the 2 coolant hoses.
7. Disconnect the coolant manifold to radiator hose. Remove the clip.
8. Disconnect the thermostat housing to radiator hose. Release the clip.
9. Disconnect the coolant manifold to coolant reservoir hose. Release the clip.
10. Disconnect the coolant manifold bleed hose. Release the clip.
11. Disconnect the engine coolant temperature (ECT) sensor electrical connector.
12. Disconnect the cylinder block coolant hose. Release the clip.
13. Release the coolant manifold. Remove the 4 Torx screws. Position the wiring harness bracket aside. Remove and discard the 2 O-ring seals.
14. Disconnect the coolant manifold rear hose. Rotate the coolant manifold. Release the clip.
15. Remove the coolant manifold.
16. Remove the ECT sensor. Remove the clip. Remove and discard the O-ring seal.
17. Remove the thermostat housing. Remove the 3 bolts. Discard the O-ring seal.

1. Install the thermostat housing. Clean the components. Install a new O-ring seal. Tighten the bolts to 10 Nm (7 lb.ft).
2. Install the ECT sensor. Clean the component mating faces. Install a new O-ring seal. Secure with the clip.
3. Install the coolant manifold. Clean the components. Install new O-ring seals. Connect the rear hose and secure with the clip. Connect the cylinder block hose and secure with the clip. Attach the wiring harness bracket. Tighten the Torx screws to 10 Nm (7 lb.ft).
4. Connect the remaining coolant hoses. Secure with the clips.
5. Connect the ECT sensor electrical connector.
6. Install the coolant hose support bracket. Tighten the bolts to 6 Nm (4 lb.ft). Secure the coolant hoses.
7. Install the cooling fan belt. Tighten the cooling fan belt tensioner bolt to 40 Nm (30 lb.ft). Rotate the cooling fan belt tensioner clockwise.
8. Install the cooling fan. See «Cooling Fan»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-fan) .
9. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information) .
10. Refill and bleed the cooling system. See «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover/l322-2005-2009/remont/cooling-fan/#engine-cooling-42l__cooling-system-draining-filling-and-bleeding) .

See also:
• Electronic Engine Controls - Description & Operation
• Auxiliary Climate Control - Description & Operation
• Engine Cover - 4.2L, Vehicles With: Supercharger
• Specifications
• Engine Undershield
• Air Conditioning (A/C) System Recovery, Evacuation and Charging
• Intake Air Resonator
• Radiator Grille
• Cooling System Draining, Filling and Bleeding
• Cooling Fan
