Safety Belt System Land Rover Range Rover L322

Airbag 15 illustrations ~991 words

SPECIFICATIONS

DescriptionNm
Safety belt retractor bolt31
Safety belt height adjuster nut31
Front safety belt upper anchor bolt50
Rear safety belt upper anchor bolt31
Safety belt guide bolt6
Front safety belt buckle bolt40
Rear safety belt buckle bolt25

TORQUE SPECIFICATIONS

Scheme 49

Scheme 49: SAFETY BELT SYSTEM
Scheme 49: SAFETY BELT SYSTEM
Item NumberDescription
1Height adjuster
2Buckle
3Anchor point
4Retractor

Scheme 50

Scheme 50
Scheme 50
Item NumberDescription
1Retractor
2Anchor point
3Outer belt buckle
4Outer and center belt buckles

GENERAL

Three point safety belts are installed at all seat positions. The front safety belts incorporate load limiters and have height adjusters on the B/C pillar. The rear outer safety belts have height adjusters on the D pillar.

On NAS vehicles, all passenger safety belts are the ALR (automatic locking retractor) type for use with child restraint systems.

A safety belt warning lamp and associated message are activated on the instrument cluster, by the lighting control module (LCM), at the beginning of each ignition cycle, as a reminder to fasten safety belts.

Child safety seat tether anchors are installed on the back of each rear outer seat.

REMOVAL

WARNINGPersons working on the supplemental restraint system (SRS) must be fully trained and have been issued with the safety guidelines.
WARNINGAllow a period of 10 minutes to elapse after disconnecting the battery before undertaking any work on the SRS.
WARNINGThe SRS electrical connectors are unique. DO NOT force, or attempt to connect electrical connectors to the wrong sockets.
WARNINGThe correct procedures must always be used when working on SRS components.
WARNINGIt is imperative that before any work is undertaken on the SRS system, the appropriate information is read thoroughly.
WARNINGAlways disconnect both battery cables before beginning work on the SRS system. Disconnect the ground cable first. Never reverse connect the battery.
WARNINGTake extra care when handling SRS components.

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
  3. Remove the front seat. Refer to «Front Seat - Removal and Installation»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
  4. Release the 2 lower tension straps from the front seat base. Reposition the front seat backrest cover for access.
  5. Remove the front seat side trim panel support. Release the 2 clips.
  6. Remove the front seat backrest hinge cover. Remove the 2 screws. Release the clip.
  7. Disconnect the front safety belt buckle electrical connector. Release the wiring harness clip.
  8. Remove the front safety belt buckle. Remove and discard the bolt.

Scheme 55

Scheme 55: INSTALLATION
Scheme 55: INSTALLATION
  1. Install the front safety belt buckle. Install a new bolt and tighten to 40 Nm (30 lb.ft).
  2. Connect the front safety belt buckle electrical connector. Secure the wiring harness clip.
  3. Reposition the front safety belt buckle wiring harness.
  4. Install the front seat backrest hinge cover. Secure the clip. Install the 2 screws.
  5. Install the front seat side trim panel support. Secure the 2 clips.
  6. Secure the 2 lower tension straps to the front seat base. Reposition the front seat backrest cover.
  7. Install the front seat. Refer to «Front Seat - Removal and Installation»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
  8. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 56

Scheme 56: REMOVAL
Scheme 56: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .
  2. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(/land-rover/range-rover/l322-2005-2009/remont/oem-general-information/#general-information) .
  3. Remove the B-pillar trim panel. Refer to «B-Pillar Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  4. Remove the safety belt guide. Remove the 2 bolts.
  5. Release the safety belt from the safety belt shoulder height adjuster. Remove and discard the nut.
  6. Remove the front safety belt. Release the front safety belt retractor. Remove and discard the bolt.

INSTALLATION

  1. Install the front safety belt. Secure the front safety belt retractor. Install the new bolt and tighten to 31 Nm (23 lb.ft).
  2. Secure the safety belt to the safety belt shoulder height adjuster. Install the new nut and tighten to 31 Nm (23 lb.ft.).
  3. Install the safety belt guide. Tighten the bolts to 6 Nm (4.4 lb.ft).
  4. Install the B-pillar trim panel. Refer to «B-Pillar Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  5. Connect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover/l322-2005-2009/remont/charging-system/#charging-system-general-information__specifications) .

Scheme 57

Scheme 57: REMOVAL
Scheme 57: REMOVAL

Scheme 58

Scheme 58
Scheme 58
  1. Fold the rear seat fully forwards. Release the rear seat backrest catch.
  2. Remove the rear seat backrest inner hinge cover. Remove the 3 screws.
  3. Remove the rear seat backrest inner hinge. Remove the 4 bolts. Discard the 2 lower bolts.
  4. Remove the rear safety belt buckle. Remove and discard the bolt.
  1. Install the rear safety belt buckle. Install the new bolt and tighten to 25 Nm (18 lb.ft).
  2. Install the rear seat backrest inner hinge. Install the 2 upper bolts. Install the 2 new lower bolts. Tighten the bolts to 25 Nm (18 lb.ft).
  3. Install the rear seat backrest inner hinge cover. Install the 3 screws.
  4. Fold the rear seat fully rearwards. Secure the rear seat backrest catch.

Scheme 59

Scheme 59: REMOVAL
Scheme 59: REMOVAL
  1. Remove the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
  2. Remove the rear seat backrest cover. Refer to «Rear Seat Backrest Cover»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
  3. Remove the rear center safety belt retractor. Remove and discard the bolt.
  1. Install the rear center safety belt retractor. Install the new bolt and tighten to 25 Nm (18 lb.ft).
  2. Install the rear seat backrest cover. Refer to «Rear Seat Backrest Cover»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
  3. Install the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .

Scheme 60

Scheme 60: REMOVAL
Scheme 60: REMOVAL

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. Remove the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .
  2. Remove the rear seat backrest inner hinge cover. Remove the 3 screws.
  3. Remove the rear seat backrest outer hinge cover. Remove the 2 screws.
  4. Remove the rear seat base lower trim panel. Remove the 6 clips. Reposition the rear seat hinge plates for access.
  5. Release the rear seat cushion cover from the rear seat base.
  6. Reposition the rear seat cushion and seat cushion cover for access.
  7. Remove the LH rear safety belt buckle. Remove and discard the bolt.
  1. Install the LH rear safety belt buckle. Install the new bolt and tighten to 25 Nm (18 lb.ft).
  2. Reposition the rear seat cushion and seat cushion cover for access.
  3. Secure the rear seat cushion cover to the rear seat base.
  4. Install the rear seat base lower trim panel. Install the 6 clips. Reposition the rear seat hinge plates for access.
  5. Install the rear seat backrest outer hinge cover. Remove the 2 screws. Install the 2 screws.
  6. Install the rear seat backrest inner hinge cover. Install the 3 screws.
  7. Install the rear seat. Refer to «Rear Seat»(/land-rover/range-rover/l322-2005-2009/remont/seats/#seating) .

Scheme 63

Scheme 63: REMOVAL
Scheme 63: REMOVAL
  1. Remove the C-pillar trim panel. Refer to «C-Pillar Upper Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Release the safety belt upper anchor. Remove and discard the bolt.
  3. Remove the rear safety belt. Remove and discard the bolt. Release the rear safety belt retractor.
  1. Install the rear safety belt. Secure the safety belt retractor. Install the new bolt and tighten to 31 Nm (23 lb.ft).
  2. Secure the safety belt upper anchor. Install the new bolt and tighten to 31 Nm (23 lb.ft).
  3. Install the C-Pillar trim panel. Refer to «C-Pillar Upper Trim Panel»(/land-rover/range-rover/l322-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
