Air Bag Deactivation Procedures Land Rover Range Rover L322

SPECIAL CARE DURING MECHANICAL REPAIRS

Note. This article applies to 2003 vehicles, except where noted.

Note. When the battery is disconnected, vehicle computer and memory system may lose data. Driveability problems may exist until computer systems have completed a relearn cycle.

In some instances, it may be necessary to remove steering column or instrument panel to gain access to blower motor housing, heater assembly, evaporator assembly, or other A/C-heater system related components. Observe manufacturer service precautions when working on a vehicle equipped with an air bag system. See appropriate manufacturer's SERVICE PRECAUTIONS.

Electrical sources should never be allowed near inflator on back of air bag module. Never probe air bag system electrical wires with analog volt-ohmmeter or test light. Always disable air bag system before servicing vehicle. See appropriate DISABLING & ACTIVATING AIR BAG SYSTEM procedure. Failure to do so could result in accidental air bag deployment and possible personal injury.

If air bag system is not fully functional for any reason, DO NOT drive vehicle until system is repaired and is again operational. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally. If air bag system is not functional, park vehicle until system is repaired and functions properly.

SYSTEM OPERATION CHECK

When ignition is turned on, SRS indicator light should come on for about 6 seconds and then go off. If indicator does not come on, or does not go off after about 6 seconds or comes on while driving, air bag system must be inspected and repaired as soon as possible.

SERVICE PRECAUTIONS

Observe these precautions when working with air bag systems and seat belt pretensioners, if equipped

1. Disable SRS before servicing any SRS, instrument panel or steering column component. Failure to do this could result in accidental air bag deployment, causing personal injury and/or vehicle damage. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures__disabling-activating-air-bag-system) .
2. WAIT at least 3 minutes after disabling air bag system. A back-up power circuit capacitor (in SRS control unit) maintains system voltage for about 3 minutes after battery is disconnected. Servicing air bag system or seat belt pretensioners before 3 minutes may cause accidental air bag deployment and possible personal injury.
3. Radio has a coded theft protection circuit. Before disconnecting battery cables get radio activation code from vehicle owner.
4. Avoid direct exposure of SRS unit or wiring harnesses to heat guns, welding or spraying equipment when painting or doing body work.
5. DO NOT attempt to modify, splice or repair SRS wiring harnesses. Ensure SRS wiring harnesses are installed so that they are not pinched or interfering with other components.
6. After an accident, all SRS components, including wiring harnesses and brackets, must be inspected. If any components are damaged or bent, they must be replaced, even if air bag did not deploy. Check steering column, knee bolster, instrument panel steering column reinforcement plate and lower brace for damage. DO NOT repair any component or wiring. If components or wiring are damaged or defective, replacement is required.
7. Whenever air bags have been activated, replace seat belt pretensioners (if equipped) and SRS unit.
8. Carefully inspect all SRS components before installation. DO NOT install any component that shows signs of being dropped or improperly handled, such as dents, cracks or other deformities.
9. DO NOT install SRS components previously installed on another vehicle. When replacing SRS components, use only NEW, manufacturer supplied components.
10. DO NOT expose air bags or seat belt pretensioner assemblies to temperatures exceeding 212°F (100°C).
11. DO NOT spill water or oil on air bags or side impact sensors.
12. Always wear safety glasses when servicing SRS or handling an air bag or seat belt pretensioner, if equipped.
13. DO NOT position yourself in front of air bag during removal, inspection or replacement.
14. DO NOT attempt to disassemble air bag assembly, cable reel, or seat belt pretensioner, if equipped. Neither component has any serviceable or reusable parts.
15. A replacement air bag assembly must be stored in its original special container until used for service. Special container must be stored in a clean, dry place, away from sources of extreme heat, sparks and high electrical energy.
16. When placing a live air bag assembly on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of air bag assembly if accidentally deployed.
17. During installation or replacement of SRS control unit, DO NOT bump, drop or strike unit or immediate area. SRS unit could be damaged and/or air bag deployment could occur.
18. After deployment, air bag assembly is very hot. WAIT 30 minutes before handling. After deployment, air bag surface may contain deposits of sodium azide and potassium nitrate, which can irritate skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up, and wash hands using mild soap and water. Follow correct disposal procedures.
19. After air bag deployment, inspect all SRS wiring harnesses for heat or other damage. Replace, DO NOT repair, any damaged harnesses. Ensure all SRS ground connections are clean and tight. Ensure SRS wiring harnesses are installed so that they are not pinched or interfere with other components.
20. DO NOT allow any electrical source near inflator on back of air bag assembly or near 3-pin connector of seat belt pretensioner.
21. During SRS component installation or replacement, be careful to not bump area around SRS unit, front impact sensors or side impact sensor using an impact wrench, hammer, etc. Air bags could accidentally deploy causing damage or injury.
22. When carrying a live air bag assembly, trim cover pad should be pointed away from body to minimize injury in case of accidental air bag deployment.
23. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove any component or in any way disable system from operating normally. If SRS is not functional, park vehicle until repairs can be made.

DISABLING & ACTIVATING AIR BAG SYSTEM

Note. To release SRS system connector lock, pull spring-loaded sleeve toward stop while holding opposite half of connector. Continue pulling connector sleeve until connector halves are separated. DO NOT pull on connector half. (Scheme 1)and (Scheme 2).

Scheme 1

Scheme 2

Disabling Air Bag System (MDX)

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable. WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect 4-pin connector between driver's air bag module and cable reel. (Scheme 1)and (Scheme 3). When disconnected, air bag connector power and ground terminals are automatically shorted together.
3. Remove glove box. Disconnect 4-pin connector between passenger's air bag module and SRS main harness. (Scheme 1)and (Scheme 4). When disconnected, air bag connector power and ground terminals are automatically shorted together.
4. Disconnect 2-pin side air bag module connectors under front seats. On driver's side, connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat.
5. Remove left and right "B" pillar trim panels. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 5) When disconnected, seat belt pretensioner connector power and ground terminals are automatically shorted together.

Scheme 3

Scheme 4

Scheme 5

Activating Air Bag System (MDX)

Note. To reconnect front SRS connector, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and lock connector.

1. Ensure ignition is OFF and negative battery cable is disconnected for at least 3 minutes. Connect 4-pin driver's air bag module connector to cable reel connector. Install access panel under steering wheel.
2. Connect 4-pin passenger's air bag module connector to SRS harness connector. Install glove box. Connect both front seat belt pretensioner 2-pin connectors to SRS main harness. Install trim panels. Connect driver's and passenger's side impact air bag module 2-pin connectors under seats.
3. Ensure ignition is off. Connect negative battery cable. Ensure air bag system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures__system-operation-check) . Reset radio anti-theft code and preset radio frequencies. The idle learn procedure must be performed so the PCM can learn engine idle characteristics. To perform idle learn procedure, go to next step. Power window control unit AUTO operation must be reset. To reset power window control unit, go to step 5 .
4. Ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are turned off. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or until engine coolant temperature reaches 194°F (90°C). Allow engine to idle for about 5 minutes with throttle fully closed and cooling fan not operating.
5. Turn ignition switch to OFF position. Turn ignition switch to ON (II) position. Lower driver's window all the way down by pushing driver's window switch to the second detent. When window reaches the bottom, hold driver's window switch in the DOWN position for 2 seconds. Raise driver's window all the way up without stopping by pulling driver's window switch to the second detent. When the window reaches the top, hold driver's window switch in the UP position for 2 seconds. If window does not work in AUTO, repeat power window control unit reset procedure.

Disabling Air Bag System (RSX)

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable and WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect 4-pin connector between driver's air bag module and cable reel. (Scheme 1)and (Scheme 3).
3. Remove glove box. Disconnect 4-pin connector between passenger's air bag module and SRS main harness. (Scheme 12)
4. Disconnect side air bag module 2-pin connectors for driver's and passenger's side impact air bag modules. On driver's side, connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat. (Scheme 8)
5. Slide front seats fully forward. Remove left and right "B" pillar lower trim panels. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 13)
6. Disconnect 2-pin connector between both front seat belt buckle tensioners and SRS main harness. Connectors are near front, center of seat. (Scheme 14)

Activating Air Bag System (RSX)

Note. To reconnect front SRS connector, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and lock connector.

1. Ensure ignition is OFF and negative battery cable is disconnected for at least 3 minutes. Connect 4-pin driver's side air bag connector to cable reel connector. Install access panel under steering wheel.
2. Connect 4-pin passenger's air bag connector to SRS harness connector. Install glove box. Connect driver's and passenger's side impact air bag module 2-pin connectors under front seats.
3. Connect both front seat belt pretensioner connectors to SRS main harness. Connect both seat belt buckle tensioner connectors to SRS main harness.
4. Ensure ignition is off. Connect negative battery cable. Ensure air bag system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures__system-operation-check) . Reset radio anti-theft code and preset radio frequencies. The idle learn procedure must be performed so the ECM can learn engine idle characteristics. To perform idle learn procedure, go to next step.
5. Ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are turned off. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or until the engine coolant temperature reaches 194°F (90°C). Allow engine to idle for about 5 minutes with throttle fully closed and cooling fan not operating.

Disabling Air Bag System (3.2CL & 3.5RL)

1. Obtain radio and navigation system anti-theft codes from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable and then positive battery cable. WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect 4-pin connector between driver's air bag module and cable reel. (Scheme 1)and (Scheme 3). When disconnected, air bag connector power and ground terminals are automatically shorted together.
3. Remove glove box. Disconnect 4-pin connector between passenger's air bag module and SRS main harness. (Scheme 1), (Scheme 6) and (Scheme 9). When disconnected, air bag connector power and ground terminals are automatically shorted together.
4. Remove left and right "B" pillar trim panels. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 7) When disconnected, seat belt pretensioner connector power and ground terminals are automatically shorted together.
5. Disconnect side air bag module 2-pin connectors for driver's and passenger's side impact air bag modules. On 3.2CL, driver's side connector is near rear, left side corner of seat. On passenger's side, connector is near rear, right side corner of seat. On 3.5RL, driver's side connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat. (Scheme 8)

Scheme 6

Scheme 7

Scheme 8

Activating Air Bag System (3.2CL & 3.5RL)

Note. To reconnect front SRS connector, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and lock connector.

1. Ensure ignition is OFF and negative and positive battery cables are disconnected for at least 3 minutes. Connect 4-pin driver's air bag module connector to cable reel connector. Install access panel under steering wheel.
2. Connect 4-pin passenger's air bag module connector to SRS harness connector. Install glove box. Connect both front seat belt pretensioner 2-pin connectors to SRS main harness. Install trim panels. Connect driver's and passenger's side impact air bag module 2-pin connectors under seats.
3. Ensure ignition is off. Connect positive battery cable and then negative battery cable. Ensure air bag system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures__system-operation-check) . Before returning the vehicle to the customer, enter navigation and radio anti-theft codes, then enter the customer's radio station presets, and set the clock.
4. Start and run engine at 3000 RPM with no loads and transmission in Park or Neutral. When radiator fan comes on, allow engine to idle for 5 minutes with A/C, headlights and rear defogger off.

Disabling Air Bag System (3.2TL)

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable. WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect 4-pin connector between driver's air bag module and cable reel. (Scheme 1)and (Scheme 3). When disconnected, air bag connector power and ground terminals are automatically shorted together.
3. Remove glove box. Disconnect 4-pin connector between passenger's air bag module and SRS main harness. (Scheme 1)and (Scheme 9). When disconnected, air bag connector power and ground terminals are automatically shorted together.
4. Disconnect 2-pin side air bag module connectors under front seats. On driver's side, connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat.
5. Slide front seats fully forward. Remove left and right "B" pillar lower trim panels. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 13)

Activating Air Bag System (3.2TL)

Note. To reconnect front SRS connector, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and lock connector.

1. Ensure ignition is OFF and negative battery cable is disconnected for 3 minutes. Connect 4-pin driver's side air bag connector to cable reel connector. Install access panel under steering wheel.
2. Connect 4-pin passenger's air bag connector to SRS harness connector. Install glove box. Connect driver's and passenger's side impact air bag module 2-pin connectors under seats. Connect both front seat belt pretensioner connectors to SRS main harness.
3. Ensure ignition is off. Connect negative battery cable. Ensure air bag system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures__system-operation-check) . Before returning the vehicle to the customer, enter navigation and radio anti-theft codes, then enter the customer's radio station presets, and set the clock.

Scheme 9

Allroad, A4, A6, A8, S4, S8 & TT

Turn ignition switch to ON position. AIR BAG indicator light should come on for about 4 seconds, and then go out. If light remains on, goes out and comes back on, or flashes continuously, air bag control unit has detected a system fault.

Observe these precautions when working with air bag systems

1. Disable air bag system before servicing any air bag system component or component located in instrument panel or steering column. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. Because of critical operating requirements of air bag system, DO NOT attempt to service or disassemble any air bag system component. If a component is faulty it must be replaced.
3. DO NOT leave air bag components unattended. Install air bag components in vehicle immediately after they are obtained.
4. NEVER point open end of a seat belt tensioner at another person.
5. Only install NEW air bag system components supplied by manufacturer. DO NOT use components previously installed in another vehicle.
6. DO NOT use air bag or seat belt pretensioner components that have been dropped from a height of more than 20 inches (50 cm) to a hard surface or have mechanical damage.
7. DO NOT allow chemical cleaners, oil or grease to contact vinyl covering on air bag.
8. DO NOT place stickers or covers on steering wheel, passenger's side instrument panel or over front seat backs. Using a seat cushion, mat or pad on front passenger's seat, may inhibit operation of seat occupied sensor and side air bags.
9. Disable SRS before performing electric welding on vehicle.
10. DO NOT expose air bag module or seat belt pretensioners to temperatures greater than 212°F (100°C).
11. DO NOT allow any electrical source near front or side air bag inflators or near seat belt tensioner connector.
12. Never use test lamp, voltmeter or ohmmeter for testing.
13. A technician must be electrostatically discharged before picking up (touching) an air bag unit or seat belt tensioner. This is accomplished by touching a suitable metal part, for example, a water pipe, a heating pipe or a metal frame.
14. When carrying a live air bag assembly, trim cover pad should be pointed away from body to minimize injury in case of accidental air bag deployment.
15. When driving or riding in an air bag-equipped vehicle, NEVER hold scan tool or other test equipment in your hands or lap while in motion. Objects between you and the air bag increase the risk of injury in an accident.
16. During a road test in an air bag-equipped vehicle, test equipment must always be fastened to and operated from the rear seat by a second technician.
17. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove any component or in any way disable system from operating normally. If SRS is not functional, park vehicle until repairs can be made.

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. To disable air bag system, ensure ignition is off and remove key. If vehicle is equipped with Audi Telematic by OnStar®, go to next step. If vehicle is not equipped with Audi Telematics by OnStar®, disconnect and shield negative battery cable.
2. On vehicles equipped with Audi Telematics by OnStar®, Telematic and Telephone Control Module emergency (back-up) battery must be switched off prior to disconnecting vehicle battery. Connect VAS 5051 tester or VAG 1551/1552 scan tool to data link connector located under left side of dash.
3. Press scan tool buttons "0" and "8" to select adaptation channel 8. Press "Q" button to confirm CHANNEL 8 ADAPTATION 0 EMERG.BATTERY ON input is displayed on scan tool. Top row of display indicates adaptation channel selected and current adaptation value currently stored: 0 = EMERG.BATTERY - SWITCHED ON; 1 = EMERG.BATTERY - SWITCHED ON, TIME REGISTER RESET; 2 = EMERG.BATTERY - SWITCHED OFF. Bottom row confirms emergency (back-up) battery status.
4. Press scan tool "0" button 4 times and "2" button one time to switch off battery. Press "Q" button to confirm input and display CHANNEL 8 ADAPTATION 2 EMERG.BATTERY OFF on scan tool. Press "Q" button again to confirm input CHANNEL 8 ADAPTATION 2 Q STORE CHANGED VALUE? on scan tool. Press "Q" button again to confirm input CHANNEL 8 ADAPTATION 2 CHANGED VALUE IS STORED on scan tool. Press right arrow button to store BATTERY OFF change and display RAPID DATA TRANSFER HELP SELECT FUNCTION XX.
5. TO ACTIVATE SYSTEM, turn ignition switch to ON position. Ensure no one is inside vehicle and connect negative battery cable. Perform a system operation check to ensure proper system operation. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
6. Input radio anti-theft security code and reset radio frequencies. Ensure radio, clock and power windows are operating properly. After reconnecting vehicle battery on vehicles equipped with Audi Telematics by OnStar®, switch on Telematic/Telephone Control Module emergency (back-up) battery. If vehicle is equipped with Audi Telematics by OnStar®, go to next step.
7. On vehicles equipped with Audi Telematics by OnStar®, connect VAS 5051 tester or VAG 1551/1552 scan tool to data link connector located under left side of dash. Press scan tool buttons "0" and "8" to select adaptation channel 8 and go to next step.
8. Press "Q" button to confirm CHANNEL 8 ADAPTATION 0 EMERG.BATTERY OFF input is displayed on scan tool. Press "0" button 5 times to switch on battery. Press "Q" button to confirm input and display CHANNEL 8 ADAPTATION 0 EMERG.BATTERY ON on scan tool. Press "Q" button again to confirm input and display CHANNEL 8 ADAPTATION 0 Q STORE CHANGED VALUE? on scan tool. Press "Q" button again to confirm input and display CHANNEL 8 ADAPTATION 0 CHANGED VALUE IS STORED on scan tool. Press right arrow button to store BATTERY ON change and display RAPID DATA TRANSFER HELP SELECT FUNCTION XX on scan tool.

1. Turn ignition switch to ON position, with engine off. SRS is operational if AIR BAG warning light comes on and then goes out after about 6 seconds with engine off.
2. If AIR BAG warning light remains on, this indicates a fault in the SRS. If AIR BAG warning light fails to illuminate when ignition is first turned on, this indicates bulb is faulty or there is a fault in the wiring circuit to the bulb.

Observe these precautions when working on SRS

1. When working around steering column and before any repairs are performed, disable SRS. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. Before straightening damaged metal or arc-welding, disable SRS and disconnect front sensors, front air bag modules, seat belt tensioners (if equipped) and side air bag modules connectors. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
3. After disabling SRS, wait at least 5 minutes before servicing vehicle. SRS control unit maintains SRS voltage for about 5 minutes after system is disabled. Servicing SRS before 5 minutes may cause accidental air bag deployment and possible personal injury.
4. Always wear safety glasses and gloves when handling a deployed air bag module. Air bag module may contain sodium hydroxide deposits, which irritates skin.
5. Handle sensors carefully. Never strike or jar sensors. All sensors and mounting bracket bolts must be tightened to specification to ensure proper sensor operation.
6. Never use any SRS component that has been dropped from a height of 2 feet or higher.
7. DO NOT repair any SRS component or wiring harness; replace only. Wiring harnesses and connectors are Orange for immediate identification.
8. To avoid air bag deployment, DO NOT use self-powered electrical test equipment on driver's or passenger's air bag modules. This equipment includes battery powered circuit testers, voltmeters and ohmmeters.
9. Always handle air bag module with trim cover away from body. Always place air bag module on workbench with trim cover up, away from loose objects. DO NOT leave air bag modules unattended.
10. Never expose SRS components to temperatures greater than 167°F (75°C).
11. Front air bag modules, belt tensioners and side air bag modules (if equipped) can only be checked while installed in vehicle and using a BMW Service Tester/DIS. Only attempt SRS inspections using specified procedures and checking devices.
12. Never expose any SRS system components to cleaning agents such as solvents, gasoline, lye, etc.

1. Before proceeding, see «SERVICE PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . Retrieve fault codes before disconnecting battery. Ensure radio and ignition is off. Disconnect and shield negative battery cable. WAIT at least 5 minutes (one minute on 735i and 745i models) for energy capacitor in SRS control unit to discharge. System is now disabled.
2. Ensure no one is inside vehicle and connect negative battery cable. System is now activated. Perform system operation check to ensure system is functioning properly and no fault codes are set. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

When ignition is turned on, SRS indicator light should come on for about 6 seconds and then go off. If indicator does not come on, or does not go off after about 6 seconds or comes on while driving, air bag system must be inspected as soon as possible.

Observe these precautions when working with air bag systems

1. Disable SRS before servicing any SRS, instrument panel or steering column component. Failure to do this could result in accidental air bag deployment, causing personal injury and/or vehicle damage. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. WAIT at least 3 minutes after disabling air bag system. A back-up power circuit capacitor (in SRS control unit) maintains system voltage for about 3 minutes after battery is disconnected. Servicing air bag system or seat belt pretensioners before 3 minutes may cause accidental air bag deployment and possible personal injury.
3. After an accident, all SRS components, including wiring harnesses and brackets, must be inspected. If any components are damaged or bent, they must be replaced, even if air bag did not deploy. Check steering column, knee bolster, instrument panel steering column reinforcement plate and lower brace for damage. DO NOT repair any component or wiring. If components or wiring are damaged or defective, replacement is required.
4. Carefully inspect all SRS components before installation. DO NOT install any component that shows signs of being dropped or improperly handled, such as dents, cracks or other deformities.
5. DO NOT install SRS components previously installed on another vehicle. When replacing SRS components, use only NEW, manufacturer supplied components.
6. DO NOT expose air bags to temperatures exceeding 200°F (93°C).
7. DO NOT spill water or oil on air bags or side impact sensors.
8. Always wear safety glasses when servicing SRS or handling an air bag or seat belt pretensioner, if equipped.
9. DO NOT attempt to disassemble air bag assembly, cable reel, or seat belt pretensioner, if equipped. Neither component has any serviceable or reusable parts.
10. Misalignment of the cable reel could cause an open in the wiring, making the SRS system and the horns inoperative. Center the cable reel whenever the following is performed: installation of steering wheel, cable reel, steering column or other steering-related adjustment or installation. DO NOT disassemble the cable reel. DO NOT apply grease to the cable reel. If the cable reel shows any signs of damage or contamination, replace it with a new one. For example, if it does not rotate smoothly.
11. A replacement air bag assembly must be stored in its original special container until used for service. Special container must be stored in a clean, dry place, away from sources of extreme heat, sparks and high electrical energy.
12. When placing a live air bag assembly on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of air bag assembly if accidentally deployed.
13. During installation or replacement of SRS control unit, DO NOT bump, drop or strike unit or immediate area. SRS unit could be damaged and/or air bag deployment could occur.
14. DO NOT position yourself in front of the air bag during removal, inspection, or replacement.
15. After deployment, air bag assembly is very hot. WAIT 30 minutes before handling. After deployment, air bag surface may contain deposits of sodium azide and potassium nitrate, which can irritate skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up, and wash hands using mild soap and water. Follow correct disposal procedures.
16. After air bag deployment, inspect all SRS wiring harnesses for heat or other damage. Replace, DO NOT repair, any damaged harnesses. Ensure all SRS ground connections are clean and tight. Ensure SRS wiring harnesses are installed so that they are not pinched or interfere with other components.
17. DO NOT allow any electrical source near inflator on back of air bag assembly or near seat belt pretensioner connector.
18. When carrying a live air bag assembly, trim cover pad should be pointed away from body to minimize injury in case of accidental air bag deployment.
19. Seats with side air bags have a SIDE AIRBAG label on the seat-back. Because component parts (seat-back cover, cushion, etc.) of seats with and without air bags are different, ensure you install only the correct replacement parts.
20. When cleaning seat, DO NOT saturate with liquid, and DO NOT spray steam on the seat.
21. DO NOT repair a torn or frayed seat-back cover. Replace the seat-back cover.
22. After a collision in which the side air bag was deployed, replace the side air bag with new parts; if the seat-back cushion is split, it must be replaced; if the seat-back frame is deformed, it must be replaced. Never put aftermarket accessories on the seat (covers, pads, seat heaters, lights, etc.).
23. Side curtain air bag inflator assembly is a long, jointed part containing an inflator, a flexible bag, an adapter pipe and a center bracket. When removing or installing side curtain air bag inflator assembly, never handle flexible bag or adapter pipe.
24. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove any component or in any way disable system from operating normally. If SRS is not functional, park vehicle until repairs can be made.

Note. To release SRS connector lock, pull spring-loaded sleeve toward stop while holding opposite half of connector. Continue pulling connector sleeve until connector halves are separated. DO NOT pull on connector half. see scheme 10and see scheme 11.

Disabling Air Bag System (Accord)

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable. WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect 4-pin connector between driver's air bag and cable reel. see scheme 10and see scheme 12.
3. Remove glove box. Disconnect 4-pin connector between passenger's air bag and SRS main harness. see scheme 10and (Scheme 10). When disconnected, air bag connector half power and ground terminals are automatically shorted together.
4. Disconnect side air bag module 2-pin connectors for driver's and passenger's side impact air bag modules. On driver's side, connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat. see scheme 14
5. On sedan models, remove left and right "B" pillar lower trim panels. On coupe models, remove rear side trim panels. On both models, disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 7) When disconnected, seat belt pretensioner connector power and ground terminals are automatically shorted together.
6. If equipped with side curtain air bag assembly, remove rear pillar trim panels. Disconnect both side curtain air bag inflator 2-pin connectors. (Scheme 11)

Activating Air Bag System (Accord)

Note. To reconnect front SRS connectors, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and connector will lock.

1. Ensure ignition is OFF and negative battery cable is disconnected for at least 3 minutes. Connect 4-pin driver's side air bag connector. Install access panel under steering wheel. Connect 4-pin passenger's air bag connector. Install glove box.
2. Connect driver's and passenger's side impact air bag module 2-pin connectors under seats. Connect both front seat belt pretensioner 2-pin connectors to SRS main harness. Connect both side curtain air bag inflator 2-pin connectors. Install trim panels.
3. Reconnect negative battery cable. Check SRS indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . Reprogram radio frequencies. Allow ECM/PCM adaptive idle speed system to learn and adjust the engine idle speed. On V6 models, go to next step. On 4-cylinder models, go to step 5 .
4. On V6 models, ensure all electrical loads (A/C, audio, rear window defogger, lights, etc.) are off. Perform PCM RESET in the CLEAR MENU using Honda PGM Tester or HDS. Turn ignition switch to ON (II) position, and wait for 2 seconds. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or until engine coolant temperature reaches 194°F (90°C). Allow engine to idle for about 5 minutes with throttle fully closed.
5. On 4-cylinder models, ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are off. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or until engine coolant temperature reaches 194°F (90°C). Allow engine to idle for about 5 minutes with throttle fully closed and cooling fans not operating.

Scheme 10

Scheme 11

Disabling Air Bag System (Civic)

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable. WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect 4-pin connector between driver's air bag and cable reel. see scheme 10and see scheme 12. When disconnected, air bag connector half power and ground terminals are automatically shorted together.
3. Remove glove box. Disconnect 4-pin connector between passenger's air bag and SRS main harness. (Scheme 12)
4. Disconnect side air bag module 2-pin connectors for driver's and passenger's side impact air bag modules. On driver's side, connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat. see scheme 14
5. Slide front seats fully forward. Remove left and right "B" pillar lower trim panels. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 13)
6. Disconnect 2-pin connector between both front seat belt buckle tensioners and SRS main harness. Connectors are near front, center of seat. (Scheme 14)

Activating Air Bag System (Civic)

Note. To reconnect front SRS connectors, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and connector will lock.

1. Ensure ignition is OFF and negative battery cable is disconnected. WAIT at least 3 minutes. Connect 4-pin driver's air bag connector. Install access panel.
2. Connect 4-pin passenger's air bag connector. Install glove box. Connect driver's and passenger's side impact air bag module 2-pin connectors under seats.
3. Connect both front seat belt pretensioner 2-pin connectors to SRS main harness. Install trim panels. Connect both seat belt buckle tensioner connectors to SRS main harness.
4. Reconnect negative battery cable. Check SRS indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . Reprogram radio frequencies. To allow ECM/PCM adaptive idle speed system to learn and adjust the engine idle speed, go to next step.
5. Ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are turned off. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or until engine coolant temperature reaches a normal operating temperature of 194°F (90°C). On Civic Hybrid, engine coolant normal operating temperature is 176-212°F (80-100°C). On all models, allow engine to idle for about 5 minutes with throttle fully closed and cooling fan not operating.

Scheme 12

Scheme 13

Scheme 14

Disabling Air Bag System (CR-V, Insight, Odyssey & S2000)

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable and then positive battery cable. WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect connector between driver's air bag and cable reel. see scheme 10and see scheme 12. When disconnected, air bag connector half power and ground terminals are automatically shorted together.
3. On CR-V, remove small access panel located above center of glove box. Disconnect 4-pin connector between passenger's air bag and SRS main harness. On Odyssey, remove glove box and disconnect 4-pin connector between passenger's air bag and SRS main harness (located on lower left of opening). On Insight and S2000, remove glove box. Disconnect 2-pin connector between passenger's air bag and SRS main harness. see scheme 10and (Scheme 15). When disconnected, air bag connector half power and ground terminals are automatically shorted together.
4. On CR-V and Odyssey, disconnect side air bag module 2-pin connectors for driver's and passenger's side impact air bag modules. On driver's side, connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat. see scheme 14
5. On CR-V, Insight and Odyssey, slide front seats fully forward. Remove left and right "B" pillar lower trim panels. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 13) On S2000, remove roll bar upper trim panel. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 16) When disconnected, seat belt pretensioner connector power and ground terminals are automatically shorted together.
6. On CR-V, disconnect 2-pin connector between both front seat belt buckle tensioners and SRS main harness. Connectors are near front, center of seat. (Scheme 14)

Note. To reconnect front SRS connectors, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and connector will lock.

Activating Air Bag System (CR-V, Insight, Odyssey & S2000)

1. Ensure ignition is OFF and both battery cables are disconnected. WAIT at least 3 minutes. Connect driver's air bag connector. Install access panel.
2. Connect passenger's air bag connector. Install glove box or access panel. Connect both front seat belt pretensioner 2-pin connectors to SRS main harness. Install trim panels. On CR-V and Odyssey, connect both side air bag module connectors. On CR-V, connect both front seat belt buckle tensioner connectors.
3. Reconnect battery cables. Check SRS indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . Reprogram radio frequencies. Perform ECM/PCM adaptive idle speed system relearn procedure to learn and adjust engine idle speed. For CR-V and Odyssey, go to next step. For Insight, go to step 5 . On Odyssey, power window control unit must also be reset. To reset power window control unit on Odyssey, go to step 6 .
4. On CR-V and Odyssey, ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are turned off. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or until engine coolant temperature reaches 194°F (90°C). Allow engine to idle for about 5 minutes with throttle fully closed and cooling fan not operating.
5. On Insight and S2000, ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are turned off. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or engine coolant temperature reaches 176-212°F (80-100°C). Allow engine to idle for about 5 minutes with throttle fully closed and with all electrical items off.
6. On Odyssey, to reset power window control unit, turn ignition switch OFF position and then back to ON (II) position. Move driver's window all the way down using driver's window switch. When window reaches the bottom, hold driver's window switch in DOWN position for 2 seconds. Move driver's window all the way up without stopping using driver's window switch. When window reaches the top, hold driver's window switch in UP position for 2 seconds. If window does not work in AUTO, repeat procedure for resetting power window control unit.

Scheme 15

Scheme 16

Disabling Air Bag System (Element)

Note. Before removing a front air bag, side air bag, or other SRS related devices, disconnecting connectors from related devices, or removing the dashboard or the steering column, disconnect the air bag connectors or the side air bag connectors to prevent accidental deployment.

1. The original radio has a coded theft protection circuit. Obtain radio theft code from owner and record frequencies for radio preset buttons before disconnecting the battery cable. Turn ignition switch to OFF position. Disconnect and isolate negative battery cable. Wait at least 3 minutes before beginning installation or replacement of SRS unit, or disconnecting connectors from SRS unit.
2. Before disconnecting SRS unit connector "A" from the SRS unit, remove lower access panel from the steering wheel, then disconnect driver's air bag 4-pin connector from the cable reel. Remove glove box, then disconnect front passenger's air bag 4-pin connector from dashboard wire harness "B". Disconnect driver's and passenger's seat belt tensioners 2-pin connector from the floor wire harness, located under each front seat.
3. Before disconnecting SRS unit connector "B" from SRS unit, disconnect driver's and passenger's side air bags 2-pin connector and both seat belt buckle tensioners 4-pin connector. Before disconnecting cable reel 4-pin connector, disconnect driver's air bag 4-pin connector. Before disconnecting floor wire harness 4-pin connector, disconnect both seat belt tensioner 2-pin connectors.

Activating Air Bag System (Element)

1. Turn ignition switch to OFF position. Disconnect negative battery cable. WAIT at least 3 minutes before beginning installation or replacement of the SRS unit, or connecting the connectors from the SRS unit. After completing repairs, ensure all SRS components have been reconnected. Reconnect negative battery cable. Check SRS indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . Enter radio theft code, then reprogram radio frequencies, set the clock and go to next step.
2. Perform ECM idle learn procedure. Ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are off. Start engine, and hold speed at 3000 RPM with no load (in Park or Neutral) until the radiator fan comes on, or until the engine coolant temperature reaches 194°F (90°C). Allow engine to idle for about 5 minutes with throttle fully closed. When procedure is completed, go to next step.
3. Ensure driver's window does not work in AUTO with ignition switch in ON position. Start engine. Lower driver's window all the way down by pushing driver's power window switch to second detent; when window reaches the bottom, hold switch in DOWN position for 2 seconds. Raise driver's window all way up without stopping by pulling driver's power window switch to second detent. When window reaches the top, hold switch in UP position for 2 seconds. If window does not work in AUTO, repeat procedure.

Disabling Air Bag System (Pilot)

1. Obtain radio anti-theft code from vehicle owner and write down preset radio frequencies. Ensure ignition is OFF. Disconnect negative battery cable. WAIT at least 3 minutes.
2. Remove access panel from under steering wheel. Disconnect 4-pin connector between driver's air bag module and cable reel. (Scheme 1)and (Scheme 3). When disconnected, air bag connector power and ground terminals are automatically shorted together.
3. Remove glove box. Disconnect 4-pin connector between passenger's air bag module and SRS main harness. (Scheme 1)and (Scheme 4). When disconnected, air bag connector power and ground terminals are automatically shorted together.
4. Disconnect 2-pin side air bag module connectors under front seats. On driver's side, connector is near front, lower left corner under seat. On passenger's side, connector is near front, lower right corner under seat.
5. Remove left and right "B" pillar trim panels. Disconnect 2-pin connector between both front seat belt pretensioners and SRS main harness. (Scheme 5) When disconnected, seat belt pretensioner connector power and ground terminals are automatically shorted together.

Activating Air Bag System (Pilot)

Note. To reconnect front SRS connector, push sleeve-side connector half toward pawl-side connector half without touching sleeve. As connector halves are pressed together, pawl will push sleeve back. When connector halves are completely connected, pawl will release spring-loaded sleeve and lock connector.

1. Ensure ignition is OFF and negative battery cable is disconnected for at least 3 minutes. Connect 4-pin driver's air bag module connector to cable reel connector. Install access panel under steering wheel.
2. Connect 4-pin passenger's air bag module connector to SRS harness connector. Install glove box. Connect both front seat belt pretensioner 2-pin connectors to SRS main harness. Install trim panels. Connect driver's and passenger's side impact air bag module 2-pin connectors under seats.
3. Ensure ignition is off. Connect negative battery cable. Ensure air bag system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . Reset radio anti-theft code and reprogram radio frequencies. The idle learn procedure must be performed so the PCM can learn engine idle characteristics. To perform idle learn procedure, go to next step.
4. Ensure all electrical loads (A/C, audio, rear defogger, lights, etc.) are turned off. Start engine, and hold it at 3000 RPM with no load (in Park or Neutral) until radiator fan comes on, or until engine coolant temperature reaches 194°F (90°C). Allow engine to idle for about 5 minutes with throttle fully closed and cooling fan not operating.

Air bag system operation is normal if the SRS indicator light in instrument cluster flashes approximately 6 times and then goes out after ignition switch is turned to ON position.

Observe these precautions when working with air bag systems

1. Be sure to proceed with air bag related service after waiting at least 30 seconds or more from the time ignition switch is turned to LOCK position and negative battery cable is disconnected. Air bag system is equipped with a back-up power source to assure air bag deployment if battery power is interrupted during an accident. The back-up power is available for approximately 150 milliseconds.
2. When troubleshooting air bag system, always check for, and record Diagnostic Trouble Codes (DTCs) before disconnecting the battery.
3. Symptoms of air bag system malfunctions are difficult to detect, DTCs become the most important source of information when troubleshooting air bag system malfunctions.
4. When negative battery cable is disconnected, clock and audio system memory will be erased. Before starting work, record contents of audio system memory. When work is finished, reset audio system and adjust clock time display.
5. Never use air bag components from another vehicle. When replacing components, replace them with new manufacturer components.
6. Never attempt to disassemble and repair air bag modules, clockspring and wiring harnesses in order to reuse them.
7. When ignition switch is in ON position, never cause a sudden shock to area around satellite sensor by a hammer, air tools, etc. Doing so could cause air bag system to unexpectedly deploy during servicing.
8. If any air bag system component has been dropped, or if there are cracks, dents or other defects in the case, bracket or connector, replace component with a new component.
9. The inflator will be quite hot immediately following deployment, wait at least 30 minutes to allow it to cool before attempting to handle it. Although not poisonous, DO NOT inhale gas from air bag deployment.
10. The air bag indicator lamp can be triggered by faults in other circuit in some cases. Therefore if the air bag indicator lamp goes on, be sure to erase the DTC codes using scan tool just after repairing or replacing the troubled parts, including the fuse.
11. After firing the air bags one time, the Supplement Restraint System Control Module (SRSCM) must be replaced.
12. Always disconnect negative battery cable when performing body welding.
13. When work on air bag system is completed, perform air bag system check. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

Note. When the negative battery cable is disconnected, clock and audio system memories will be erased. Before starting work, record contents of audio system memory.

1. Record preset radio station frequencies. Turn ignition off. Disconnect and shield negative battery cable. Be sure to proceed with air bag related service after waiting at least 30 seconds or more from the time the ignition switch is turned to the LOCK position and battery is disconnected. Air bag system back-up power source is available for approximately 150 milliseconds.
2. Ensure ignition is turned off. Reconnect negative battery cable. Check SRS indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . When the work is finished, reset the audio system and adjust the clock.

1. Turn ignition ON and verify that AIR BAG indicator light comes on for about 7 seconds, then goes off. With seat belt fastened and ignition ON, the SEAT BELT indicator light should come on and seat belt warning chime should sound for about 7 seconds, then go off. If seat belt is not fastened, the seat belt warning chime should sound and SEAT BELT indicator light will stay on for longer than 7 seconds.
2. If the AIR BAG indicator light does not come on, or after about 7 seconds does not go out or begins to flash, a SRS malfunction has been detected.
3. On G20 and Q45 models, if the SEAT BELT indicator light does not come on, or stays on longer than 7 seconds with seat belt fastened, a seat belt pretensioner malfunction has been detected.

Observe these precautions when working with air bag systems

1. Disable SRS system before servicing any SRS component, instrument panel components, steering column components or seat belt pretensioners, if equipped. Failure to do this could result in accidental activation of SRS and causing personal injury and/or vehicle damage. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. WAIT at least 3 minutes after disabling SRS before servicing vehicle. System maintains SRS system voltage for about 3 minutes. Servicing air bag system or seat belt pretensioners (if equipped) before 3 minutes could result in accidental SRS activation, causing personal injury and/or vehicle damage.
3. After repairs, ensure AIR BAG indicator light is operating properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
4. Always wear safety glasses when servicing or handling any air bag system components.
5. Air bag modules and seat belt pretensioners (if equipped) must be stored in their original special containers until installation. They must be stored in a clean, dry place, away from sources of extreme heat, sparks or high electrical energy.
6. Always place SRS components on a clean flat surface. When placing a live air bag module on a bench, always face air bag and trim cover up, away from surface. This will reduce motion of module if accidentally activated.
7. Replace air bag module if dropped or if it sustained an impact.
8. DO NOT expose air bag to temperatures greater than 194°F (90°C).
9. DO NOT expose seat belt pretensioners to temperatures greater than 176°F (80°C).
10. DO NOT allow water, oil, or grease to come in contact with air bag module.
11. If steering gear is removed, DO NOT turn steering wheel or column shaft. Rotation of SRS spiral cable under steering wheel air bag module is limited. SRS spiral cable must be aligned in neutral position (centered).
12. After deployment, air bag surface may contain deposits of sodium hydroxide, which can irritate skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up, and wash hands using mild soap and water. Follow correct disposal procedures.
13. At no time should any electrical source be allowed near inflator on back of air bag module.
14. DO NOT use old bolts after removal; replace with new ones.
15. DO NOT insert any foreign objects (screwdriver, etc.) into air bag module connector.
16. When carrying a live air bag module, trim cover should be pointed away from body to minimize injury in case of accidental air bag deployment.
17. DO NOT probe a wire through insulator; this will damage wire and eventually cause failure due to corrosion.
18. If SRS system is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove bulbs, modules, sensors or other components or in any way disable system from operating normally. If SRS system is not functional, park vehicle until repairs can be made.

Disabling Air Bag System

Record preset radio station frequencies. Turn ignition off. Disconnect and shield negative battery cable and then positive battery cable. WAIT at least 3 minutes.

Activating Air Bag System

Ensure ignition is off. Connect positive battery cable and then negative battery cable. Ensure AIR BAG and SEAT BELT indicator lights are operating properly and no system faults are indicated. See SYSTEM OPERATION CHECK .

ISUZU

Note. Rodeo air bag information also applies to Honda Passport.

Turn ignition ON and verify that AIR BAG indicator light flashes 7 times, then turns off. AIR BAG indicator light should not come on during vehicle operation. If AIR BAG indicator light does not function as described, service air bag system.

Observe these precautions when working with air bag system

1. Disable SRS system before servicing any SRS system, instrument panel or steering column component. Failure to do this could result in accidental air bag deployment, and possible personal injury and/or vehicle damage. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. WAIT at least 15 SECONDS after disabling SRS before servicing vehicle. System maintains SRS system voltage for time specified. Servicing SRS system before time has elapsed could result in accidental air bag deployment, and possible personal injury and/or vehicle damage.
3. After repairs, ensure AIR BAG indicator light is operating properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
4. Always wear safety glasses when servicing or handling an air bag.
5. Air bag modules must be stored in original special container until used for service. They must be stored in a clean, dry place, away from sources of extreme heat, sparks or high electrical energy.
6. When placing a live air bag module on a bench or other flat surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if accidentally deployed. Provide enough free space for the air bag to expand in case of an accidental deployment.
7. Any SRS component dropped from a height greater than 3 feet (91 cm) must be replaced.
8. On Rodeo and Rodeo Sport, DO NOT subject SRS components to temperatures greater than 200°F (93°C). On Ascender, DO NOT expose inflator modules to temperatures greater than 150°F (65°C).
9. NEVER use SRS components from another vehicle. DO NOT use salvaged parts for repairs to the SIR system.
10. After deployment, air bag surface may contain deposits of sodium hydroxide, which can irritate skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up, and wash hands using mild soap and water. Follow correct disposal procedures.
11. After deployment, air bag module and surrounding metal areas will be hot. To help avoid a fire or personal injury WAIT at least 10 minutes before touching components. DO NOT place the deployed SIR component near any flammable objects.
12. At no time should any electrical source be allowed near inflator on back of air bag module.
13. When carrying a live air bag module, trim cover should be pointed away from body to minimize injury in case of accidental air bag deployment.
14. When carrying inflator module DO NOT carry an undeployed inflator module by the wires or connector.
15. When storing a steering column, DO NOT rest column with air bag opening facing down and column vertical. Lay column on its side.
16. DO NOT attempt to disassemble any SRS component. SRS components are serviced as a complete unit and contain no serviceable components.
17. DO NOT use battery powered tester or ohmmeter on air bag module connectors. The current from these devices can trigger air bag deployment. DO NOT use probe type tester on SRS harness or components.
18. DO NOT probe a wire through insulator; this will damage wire and eventually cause failure due to corrosion.
19. DO NOT attempt to repair damaged SRS wiring harness. Replace harness as an assembly if damaged.
20. If SRS system is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove bulbs, modules, sensors or other components or in any way disable system from operating normally. If SRS system is not functional, park vehicle until repairs can be made.

Disabling System (Axiom, Rodeo & Rodeo Sport)

Note. When air bag fuse is removed and ignition switch is in ON position, AIR BAG indicator light will be on. This is a normal operation and does not indicate an SRS malfunction.

1. Turn ignition switch to LOCK position and remove ignition key. On Axiom, remove SRS-1 fuse from left side dash lower fuse block or disconnect negative battery cable. On Rodeo and Rodeo Sport, remove METER and SRS fuses from left side dash lower fuse block, or disconnect battery.
2. On all models, WAIT 15 SECONDS before servicing vehicle.
3. Disconnect driver's air bag Yellow 2-pin connector located at base of steering column. To disconnect, push in on sides of spring-loaded sleeve and pull on opposite connector. DO NOT pull on wiring. see scheme 21
4. Remove glove box assembly. Disconnect passenger's air bag Yellow 2-pin connector located behind glove box assembly.

Activating System (Axiom, Rodeo & Rodeo Sport)

1. Ensure ignition switch is in LOCK position, and ignition key is removed. Ensure battery is still disconnected or air bag fuse(s) is removed. Connect passenger's air bag Yellow 2-pin connector. Push in on connectors. DO NOT push on locking sleeve. see scheme 21 Install glove box assembly. Connect driver's air bag Yellow 2-pin connector.
2. Install air bag fuse(s), or connect battery. Staying well away from air bag modules, turn ignition switch to ON position, with engine off. Ensure AIR BAG indicator light operates properly, see «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures).

Supplemental Inflatable Restraint (SIR) Disabling & Enabling Zones (Ascender)

On Ascender, the Supplemental Inflatable Restraint (SIR) system has been divided into disabling and enabling zones. When performing service on or near SIR components or SIR wiring, it may be necessary to disable the SIR components in that zone. It may be necessary to disable more than one zone depending on the location of other SIR components and the area being serviced. (Scheme 17) Identify the specific zone or zones in which service will be performed and disable and enable selected zone or zones.

Scheme 17

Disabling System (Ascender)

Note. When AIR BAG or SIR fuse is removed, and ignition is in ON position, AIR BAG warning light will illuminate. This is normal operation and does not indicate SIR system malfunction.

1. Before proceeding, follow air bag service precautions. See «SERVICE PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures). Turn front wheels to straight-ahead position. Turn ignition switch to LOCK position. Remove key from ignition switch. Remove SIR fuse from underhood fuse block. Wait one minute.
2. Zone 1 To disable inflatable restraint Electronic Front Sensors (EFS) located in SIR Zone 1, remove the grille. Remove headlamp wire harness from the retaining clip and raise wire harness to gain access to the front end sensor. Loosen front end sensor retaining bolts and protective cover. Remove sensor assembly from the frame. (Scheme 18) Remove Connector Position Assurance (CPA) clip from the sensor electrical connector and disconnect sensor electrical connector.
3. Zones 2 & 6 To disable left or right front door inflatable restraint Side Impact Sensor (SIS) located in SIR Zones 2 (left) or 6 (right), remove accessory switch panel. Remove 2 trim panel retaining bolts. Release 9 trim panel fasteners from door and remove trim panel from the door. Remove CPA clip from side air bag sensor Yellow 2-pin connector located near the bottom of door. (Scheme 19) Disconnect side air bag sensor Yellow 2-pin connector located near the bottom of door.
4. Zone 3 To disable driver's air bag module and coil located in SIR Zone 3, remove left instrument panel closeout/insulator panel. Remove 4 trim panel retaining screws, release trim panel retaining clips and remove trim panel. Remove CPA clip from driver's air bag module Yellow 4-pin connector located left of steering column, near knee bolster. (Scheme 20) Disconnect driver's air bag module Yellow 4-pin connector.
5. Zone 5 To disable passenger's air bag module located in SIR Zone 5, access passenger's air bag module Yellow 4-pin connector through glove box. Remove CPA clip from passenger's air bag module Yellow 4-pin connector located behind instrument panel support. Disconnect passenger's air bag module Yellow 4-pin connector located behind instrument panel support.
6. Zone 7 To disable inflatable restraint side air bag module located in SIR Zone 7, remove CPA clip from left side air bag module Yellow 2-pin connector located under driver's seat. Disconnect left side air bag module Yellow 2-pin connector located under driver's seat.
7. Zone 8 To disable inflatable restraint Sensing and Diagnostic Module (SDM) located in SIR Zone 8, disable Zones 3, 5, 7 and 9. Disconnect Yellow component connectors.
8. Zone 9 To disable inflatable restraint side air bag module located in SIR Zone 9, remove CPA clip from right side air bag module Yellow 2-pin connector located under passenger's seat. Disconnect right side air bag module Yellow 2-pin connector located under passenger's seat.

Scheme 18

Scheme 19

Scheme 20

Activating System (Ascender)

Remove key from ignition switch. Ensure SIR fuse is still removed from fuse block. In reverse order, connect SIR component Yellow SIR connectors to vehicle harness and install CPA clips. Install SIR fuse in fuse block. Staying away from both air bags, turn ignition switch to ON position. Ensure AIR BAG warning light flashes 7 times, and then turns off. See SYSTEM OPERATION CHECK . To complete installation, reverse removal procedures.

1. To check air bag system, turn ignition switch from OFF to RUN position (engine off). If AIR BAG warning light illuminates for approximately 6 seconds, and then goes out, air bag system is functioning properly and no fault codes exist.
2. If a fault is detected in air bag system during initial system check, AIR BAG warning light will either fail to light, stay on continuously, or flash. If AIR BAG warning light flashes, indicating a fault in system, diagnose and repair system as necessary.
3. If a system fault exists and AIR BAG warning light fails to light, an audible tone will be heard, indicating AIR BAG warning light is out and service is required. The tone is a chime which sounds 5 sets of 5 beeps.

Observe these precautions when working with air bag system

1. Disable SRS before servicing any SRS or steering column component. Failure to do this could result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. DO store modules in an upright position.
3. DO keep modules dry.
4. DO carry modules with the cover side pointing away from the body.
5. DO place modules with their cover side upwards.
6. DO carefully inspect modules for damage.
7. DO stand to one side when connecting modules.
8. DO make sure all test equipment is properly calibrated and maintained.
9. DO wash your hands after handling deployed air bags.
10. DO NOT store highly flammable material together with modules or gas generators.
11. DO NOT store gas generators at temperatures exceeding 176°F (80°C).
12. DO NOT use damaged modules.
13. DO NOT store modules upside down.
14. DO NOT attempt to open a gas generator housing.
15. DO NOT expose gas generators to open flame or sources of heat.
16. DO NOT place anything on top of a module cover.
17. DO NOT touch a fired module or gas generator for at least 10 minutes.
18. DO NOT use any electrical probes on the wiring circuit.
19. Replace any air bag or seat belt pretensioner component dropped from a height greater than 12 inches (0.3 m).
20. DO NOT probe air bag module connector with ohmmeter. Ohmmeter current can cause air bag to deploy.
21. DO NOT expose air bag or seat belt pretensioner components to heat or flame, high humidity or electrical noise.
22. Never disassemble or repair system components. Replace cracked, dented or otherwise damaged system components.
23. Electronic components in seats are sensitive to impact. Handle seat with care or damage may result.
24. Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result.
25. Air bag system component repair is made by replacement only. If a component is replaced and does not correct condition, install original component and repeat diagnostic procedure.
26. The gas generant used in air bags is Sodium Azide. This material is hermetically sealed in the module and is completely consumed during deployment. No attempt should be made to open an air bag inflator as this will lead to the risk of exposure to Sodium Azide. If a gas generator is ruptured, full protective clothing should be worn when dealing with the spillage.
27. When placing a live air bag on a bench or other flat surface, always face air bag trim cover up, away from surface. This will reduce motion of module if it is accidentally deployed.
28. When carrying a live air bag module, trim cover must be pointed away from body to minimize injury in case of accidental air bag deployment.
29. After deployment, air bag surface may contain deposits of sodium hydroxide, which irritates skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up. After clean-up, wash hands using mild soap and water.
30. In the event of a fault that causes F4 10-amp battery supply fuse (located in the fuse-box at the driver's end of the fascia), the fuse must not be renewed until the Air Bag/SRS system has been deactivated. Fuses of any other value must never be used, as this can cause disarm failure.
31. Radio code saving devices MUST NOT be used when conducting work on air bag system. It must be noted that, when using these devices, the vehicle electrical system is still live and capable of activating air bag system.

Note. It is necessary to record any settings or fault codes before battery is disconnected. Obtain and record the radio anti-theft keycode and preset radio frequencies, Powertrain Control Module (PCM) fault codes, and climate control assembly settings and fault codes.

XJR & XJ8

1. To disable air bag system, turn ignition switch to LOCK position and remove key. Disconnect and isolate negative battery cable. After disconnecting negative battery cable, wait at least 15 minutes before disconnecting the Single Point Sensing (SPS) unit and at least 2 minutes before disconnecting any other Supplementary Restraint System (SRS) component.
2. To activate air bag system, ensure ignition switch is in LOCK position and key is removed. Connect negative battery cable. After repairs, ensure AIR BAG indicator light is operating properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

XK Series

1. To disable air bag system, turn ignition switch to LOCK position and remove key. Disconnect and isolate negative battery cable. After disconnecting negative battery cable, wait at least ONE MINUTE before disconnecting any other Supplementary Restraint System (SRS) component.
2. To activate air bag system, ensure ignition switch is in LOCK position and key is removed. Connect negative battery cable. After repairs, ensure AIR BAG indicator light is operating properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

J-Type

1. To disable air bag system, turn ignition switch to LOCK position and remove key. Disconnect and isolate negative battery cable. WAIT at least one MINUTE before servicing vehicle.
2. To activate air bag system, ensure ignition switch is in LOCK position and key is removed. Connect negative battery cable. After repairs, ensure AIR BAG indicator light is operating properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

X-Type

1. To disable air bag system, turn ignition switch to LOCK position and remove key. Disconnect and isolate negative battery cable. Wait ONE MINUTE for backup power supply in the RCM to deplete its stored energy. Remove driver's air bag module and connect an air bag simulator to vehicle harness. Remove passenger's air bag module and connect an air bag simulator to vehicle harness. Reconnect negative battery cable.
2. To activate air bag system, turn ignition switch to LOCK position and remove key. Disconnect and isolate negative battery cable. Wait ONE MINUTE for backup power supply in RCM to deplete its stored energy. Remove air bag simulator from vehicle and install driver's air bag module. Remove air bag simulator from vehicle and install passenger's air bag module. Turn ignition switch from OFF to RUN position, exit vehicle and close all doors. Reconnect negative battery cable. After repairs, ensure AIR BAG indicator light is operating properly and no system faults are indicated. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

Optima, Magentis (Canadian), Sedona & Sorento

Turn ignition on, with engine off. Air bag warning light in instrument cluster should flash 6 times, then turn off. If air bag warning light does not illuminate when the ignition is turned on, illuminates for 6 seconds without flashing and goes out, or remains lit with the ignition on, there is a fault in the air bag system.

Rio & Spectra

Turn ignition on, with engine off. Air bag warning light in instrument cluster should come on for 4-6 seconds and then turn off. If air bag warning light remains lit, or flashes, there is a fault in the air bag system.

Observe the following precautions when servicing SRS

1. Disable SRS before servicing any SRS or steering column component. Failure to do this could result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. Malfunction symptoms of the SRS are difficult to confirm, so Diagnostic Trouble Codes (DTCs) become the most important source of information when troubleshooting. When troubleshooting the SRS, always check for and record DTCs before disconnecting battery.
3. After turning ignition switch to LOCK position, disconnect negative battery cable. Turn headlight switch on, and wait at least 10 minutes before servicing vehicle. SRS is equipped with a back-up power source that may allow air bag to deploy within 10 minutes after disconnecting negative battery cable.
4. If any component of SRS has been dropped, or if there are cracks, dents or other defects in the case, bracket or connector, replace them with new components.
5. NEVER use air bag components from another vehicle. Replace air bag components with NEW components.
6. DO NOT probe air bag module connector with ohmmeter. Ohmmeter current can cause air bag to deploy.
7. Never disassemble or repair system components. Replace cracked, dented or otherwise damaged system components.
8. DO NOT expose air bag components to heat or flame, high humidity or electrical noise. DO NOT expose air bag modules to heat exceeding 200°F (93°C).
9. After servicing SRS, check air bag warning light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
10. Always wear safety glasses when servicing or handling an air bag module.
11. When placing a live air bag on a bench or other flat surface, always face air bag trim cover up, away from surface. This will reduce motion of module if it is accidentally deployed.
12. After deployment, air bag surface may contain chemical deposits which irritate the skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up. After clean-up, wash hands using mild soap and water.
13. After deployment, air bag modules are very hot. WAIT at least 20 minutes for components to cool.
14. Disconnect negative battery cable BEFORE welding body components.
15. Before removing steering gearbox, center front wheels and remove ignition key. This will prevent damage to SRS clockspring at the top of the steering column.
16. When carrying a live air bag module, trim cover must be pointed away from body to minimize injury in case of accidental air bag deployment.
17. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and again becomes operational. DO NOT remove bulbs, modules, sensors or other components or in any way disable system from operating normally. If SRS is not functional, park vehicle until it is repaired and functions properly.

Turn ignition switch to LOCK position. Disconnect negative battery cable. WAIT at least 30 SECONDS or more before servicing vehicle. To activate SRS, ensure ignition key switch is in LOCK position. Connect negative battery cable. Perform SYSTEM OPERATION CHECK .

To disable SRS, turn ignition switch to LOCK position. Disconnect negative battery cable and then positive battery cable. WAIT at least 10 minutes before servicing vehicle. To activate SRS, ensure ignition key is in LOCK position. Connect positive battery cable and then negative battery cable. Perform SYSTEM OPERATION CHECK .

Turn ignition switch to ON position (with engine off). Air bag indicator light should come on for about 5 seconds and then go out. If SRS warning light does not illuminate, or illuminates and does not go out, service SRS. If SRS warning light comes on for about 5 seconds, then remains on, a fault code is set in memory.

Observe the following precautions when servicing SRS

1. Disable SRS before servicing any SRS, instrument panel or steering column component. Failure to do this could result in accidental air bag and seat belt pretensioner deployment, and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. After removing key from ignition switch and disconnecting battery cables, wait at least 10 minutes. SRS has a back-up power source which is capable of deploying air bags for up to 10 minutes after disconnecting battery cables. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
3. NEVER disconnect the battery with ignition switch in ON position.
4. To prevent damage to the navigation computer hardware, WAIT at least 2 minutes after ignition switch is turned to OFF position before disconnecting negative battery cable.
5. To prevent damage to electrical components, always disconnect the battery when working on the vehicle's electrical system. The ground lead must be disconnected first and reconnected last.
6. Always ensure that battery leads are routed correctly and are not close to any potential chafing points.
7. Before attempting to service SRS, remove key from ignition and disconnect both battery cables.
8. DO NOT subject SRS components to temperatures greater than 185°F (85°C), high humidity, or electrical noise.
9. DO NOT allow oil, grease, detergents, or cleaning solutions to come in contact with air bag module and seat belt pretensioner units.
10. When placing an air bag module on a bench or other flat surface, ensure trim cover is facing up, away from surface. This will reduce motion of module if it is accidentally deployed.
11. If air bag module or other components have been dropped, or there are cracks, dents or other defects visible, replace with NEW components.
12. DO NOT attempt to measure resistance across air bag module squib connector terminals. DO NOT use powered circuit testers on air bag module connectors. Accidental air bag deployment is possible which could cause personal injury.
13. Air bag modules and seat belt pretensioner units contain sodium azide which is a poisonous and flammable gas. Contact with water, acid or heavy metals may produce harmful or explosive compounds.
14. After deployment, air bag surface will be very hot. WAIT at least 30 minutes before handling it. Always wear safety glasses, rubber gloves, and long-sleeved shirt when handling air bag or during clean up.
15. DO NOT attempt to incinerate or dismantle an undeployed air bag. SRS components DO NOT contain any serviceable parts.
16. DO NOT install components previously installed on another vehicle. Only use NEW components supplied by manufacturer.
17. SRS wiring harness has a Yellow outer covering. DO NOT attempt to modify, splice or repair any part of SRS wiring harness. DO NOT install any electrical or electronic equipment into SRS wiring harness. Ensure SRS wiring harness is routed correctly and not pinched or trapped on other components.
18. When carrying a live air bag module, trim cover must be pointed away from body to minimize injury in case of accidental air bag deployment.
19. After SRS repairs have been completed, ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
20. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and again becomes operational. DO NOT remove bulbs, modules, sensors or other components or in any way disable system from operating normally. If SRS is not functional, park vehicle until it is repaired and functions properly.

On Range Rover, remove key from ignition switch and WAIT at least 2 minutes and then disconnect negative battery cable, followed by the positive battery cable. On Discovery and Freelander, remove key from ignition switch and disconnect negative battery cable, followed by the positive battery cable. On all models, WAIT at least 10 minutes before working on vehicle.

Note. On Range Rover, after reconnecting battery, turn the steering wheel to full left and right lock (with engine running). This allows DSC system to relearn steering wheel position. Failure to do so will result in a variety of instrument warning lights being illuminated.

Ensure key is removed from ignition switch. Connect positive battery cable and then negative battery cable. Staying well away from air bag modules, turn ignition switch to ON position. Ensure AIR BAG indicator light operates properly. See SYSTEM OPERATION CHECK .

Turn ignition switch to ACC or ON position. Air bag indicator light in instrument cluster should come on for about 6 seconds, then go out. If indicator light remains on or flashes, a SRS malfunction has been detected.

Observe the following precautions when servicing SRS

1. Disable SRS before servicing any SRS, instrument panel or steering column component. Failure to do this could result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. DO NOT use any type of back-up power supply from outside vehicle to avoid memory loss in memory systems. Back-up power supplies can provide enough voltage to activate SRS components.
3. After turning ignition switch to LOCK position and disconnecting negative battery cable, wait at least 90 SECONDS before working on vehicle. SRS is equipped with a back-up power source that may allow air bag to deploy within 90 seconds after disconnecting negative battery cable.
4. In a minor collision in which air bags did not deploy, inspect front air bag sensors, steering wheel pad, front passenger's air bag assembly, side air bag assembly, curtain air bag assembly, seat belt pretensioner, air bag control module, and side air bag sensor.
5. If steering wheel pad, front or side air bag assemblies, curtain air bag assembly, air bag sensor, side air bag sensor or front air bag sensor has been dropped, or if there are cracks, dents or other defects in the case, connectors or brackets, replace the component.
6. Remove air bag sensors if an impact is likely to be applied to area close to sensors during repair.
7. Never disassemble or repair system components. Replace cracked, dented or otherwise damaged system components.
8. DO NOT expose front air bag sensors, center air bag sensor assembly, steering wheel pad, passenger's air bag, side air bags or seat belt pretensioners directly to hot air or flame.
9. DO NOT store air bag modules where they will be exposed to temperatures greater than 199°F (93°C), high humidity or electrical noise. DO NOT store seat belt pretensioners to temperatures greater than 176°F (80°C), high humidity or electrical noise.
10. Information labels are attached to air bag components. Follow all notices on labels.
11. After servicing SRS, check air bag indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
12. Always wear safety glasses when servicing or handling air bags or seat belt pretensioners.
13. When placing a live air bag module on a bench or other flat surface, always face air bag module and trim cover up, away from surface. This will reduce motion of module if it is accidentally deployed.
14. After deployment, air bag surface may contain deposits of sodium hydroxide, which irritates skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up. After clean-up, wash hands using mild soap and water.
15. After deployment, steering wheel pad is very hot. WAIT 30 minutes before touching.
16. DO NOT install components previously installed on another vehicle. Only use NEW components supplied by manufacturer.
17. When using electric welding, disconnect air bag module and seat belt pretensioner connectors.
18. When carrying a live air bag module, trim cover must be pointed away from body to minimize injury in case of accidental air bag deployment.
19. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and again becomes operational. DO NOT remove bulbs, modules, sensors or other components or in any way disable system from operating normally. If SRS is not functional, park vehicle until it is repaired and functions properly. See «SYSTEM OPERATING CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

Note. All SRS harness connectors are colored Yellow to distinguish them from other connectors.

Note. If the ignition switch is turned ON with the air bag sensor assembly connectors disconnected, or if a vehicle battery is removed with the ignition switch ON, the system will determine this condition as a failure and it will automatically call the call center. When an accidental call is made automatically, access the call center and ask them to cut off the line. To prevent accidental calls, perform the following when working on procedures related to the air bag sensor assembly or battery. Disconnect Mayday ECU and back-up battery connectors before disconnecting the air bag sensor assembly connector. Ensure that the ignition switch is in the OFF position when removing a vehicle battery. If no signal has been received from the air bag sensor assembly since the ignition switch was turned ON, a service call will be made. If good signal reception from the air bag sensor assembly after the ignition switch ON is interrupted, an emergency call will be made.

1. Obtain radio anti-theft protection code from vehicle owner and record preset radio frequencies before disconnecting battery.
2. Place front wheels in straight-ahead position. Turn ignition switch to LOCK position. Disconnect and shield negative battery cable. WAIT at least 90 SECONDS before working on vehicle.

1. Ensure ignition key is removed from switch. Connect negative battery cable.
2. Staying well away from air bag modules, turn ignition switch to ACC or ON position. Ensure AIR BAG indicator light operates properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) . If equipped with a sliding roof, go to next step.
3. When battery is disconnected sliding roof motor AUTO operation must be reset. To reset sliding roof motor, press the sliding roof switch on TILT UP side and hold it. When roof glass stops at the fully tilted-up position for one second, reset of the motor is completed. If the battery terminal is disconnected or after the jam protection function has operated, the ECU of the sliding roof motor may not detect the position of the roof glass.
4. On ES300, always reset the sliding roof motor whenever the battery is disconnected. If not reset, the AUTO operation and jam protection function will not operate. Set sliding roof glass in to the fully tilt-up position. Push and hold the sliding roof switch UP until the sliding roof tilts down a little. Check that the sliding roof tilts up/down and slides open/close in AUTO operation. If the sliding roof is not in the correct position, press and hold the sliding roof switch UP and CLOSE until 10 seconds have passed after the roof stops moving or starts the reverse operation. The reset operation will be completed. If the jam protection function does not work, reset the sliding roof drive gear (motor) again.
5. On GX470, if the AUTO operation function does not operate after reconnecting battery, reset the sliding roof motor as follows. Press sliding roof switch on TILT UP side and hold it. When the roof glass stops at the fully tilted-up position for one second, the reset of the motor is completed. If the battery terminal is disconnected or after the jam protection function has operated, the sliding roof motor ECU may not detect the position of the roof glass. If the AUTO operation function is still disabled even after the sliding roof motor is reset, the hall IC (built in the sliding roof motor assembly) for detecting the roof glass position may be malfunctioning.
6. On IS300, sliding roof motor ECU must be reinitialized after reconnecting battery. Reinitialize sliding roof by moving the sliding roof to the maximum tilted position. Release the switch, press the switch again and hold it for 10 seconds. The sliding roof operates in a cycle of TILT DOWN, SLIDE OPEN, SLIDE CLOSE and TILT UP. This completes reinitializing.

B Series Pickup & Tribute

1. Turn ignition on, with engine off (OFF to RUN). AIR BAG indicator light in instrument cluster should come on for 6 seconds and then turn off. The passenger's air bag deactivation switch will also light for about 6 seconds, and then turn off.
2. If a fault is detected in the air bag system during the system operation check, AIR BAG indicator light will either fail to light, stay on continuously, or flash. Flashing may not begin for up to 30 seconds after initial bulb check (ignition turned from OFF to RUN).
3. If an air bag system fault exists, and AIR BAG indicator light fails to light, an audible tone will be heard, indicating AIR BAG indicator light is out and service is required. The tone is a chime which sounds 5 sets of 5 beeps.

Mazda6, Millenia, MPV, MX-5 Miata & Protege

1. Turn ignition on, with engine off. AIR BAG indicator light in instrument cluster should come on for 6 seconds and then turn off.
2. If AIR BAG indicator light does not come on, stays on or flashes, a SRS fault has been detected.

Observe these precautions when working with air bag system

1. Disable air bag system before servicing any air bag system or steering column component. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. WAIT at least ONE MINUTE after disabling air bag system before servicing vehicle. Air bag system activation voltage is maintained for about ONE MINUTE after system is disabled. Failure to wait at least ONE MINUTE before servicing system may cause accidental air bag deployment and possible personal injury.
3. Because of critical system operating requirements, DO NOT service or repair any air bag system component or wiring harness. Corrections are made by component replacement only.
4. DO NOT allow water, oil or grease to contact air bag system components.
5. DO NOT repaint air bag module trim.
6. DO NOT use an ohmmeter or powered circuit tester to check resistance of air bag module, as it may cause air bag deployment.
7. After deployment, air bag surface may contain deposits of sodium hydroxide, which can irritate skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up, and wash hands using mild soap and water. Follow correct disposal procedures.
8. When carrying a live (undeployed) module, ensure trim cover is pointed away from body. This minimizes chance of injury in event of accidental air bag deployment.
9. When placing a live air bag module on a bench or other flat surface, always face trim cover up to reduce motion of module if it is accidentally deployed.
10. Air bag system clockspring MUST be aligned in neutral position, since its rotation ability is limited. DO NOT turn steering wheel or column after removal of steering gear.
11. DO NOT install components previously installed on another vehicle. Only use NEW components supplied by manufacturer.
12. DO NOT store air bag modules where they will be exposed to temperatures greater than 199°F (93°C), high humidity or electrical noise.
13. Information labels are attached to air bag components. Follow all notices on labels.
14. After servicing SRS, check air bag indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
15. Always wear safety glasses when servicing or handling air bags or seat belt pretensioners.
16. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and again becomes operational. DO NOT remove bulbs, modules, sensors or other components or in any way disable system from operating normally. If SRS is not functional, park vehicle until it is repaired and functions properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

Note. When the battery is disconnected and reconnected, some abnormal drive symptoms may occur while the vehicle relearns its adaptive strategy. The vehicle may need to be driven to relearn its strategy.

Disabling System (B Series Pickup)

Note. B Series Pickups are equipped with a passenger's air bag ON/OFF switch. Turning switch off is not a substitute for completely disabling the passenger's air bag.

1. Obtain radio anti-theft protection code from vehicle owner prior to servicing vehicle or deactivate radio anti-theft function before disconnecting vehicle battery.
2. Turn ignition switch to LOCK position and remove key. Disconnect and shield negative battery cable. Be sure to disconnect auxiliary batteries and power supplies, if equipped. WAIT at least ONE MINUTE for back-up power supply to be depleted.
3. Remove screws and position hood release handle aside. Remove screws from lower steering column opening finish panel. Pull out to release retaining clips, and remove lower steering column opening finish panel. Remove 5 bolts and remove lower steering column opening finish panel reinforcement. Disconnect clockspring electrical connector at base of steering column. Install Air Bag Simulator 105-R0012 (418-F088) to vehicle harness side of clockspring electrical connector.
4. Open glove box. Press inward on sides of glove box, and lower glove box to floor. Release tab and disconnect passenger's air bag module electrical connector. Install Air Bag Simulator 105-R0012 (418-F088) to vehicle harness at passenger's air bag assembly.

Activating System (B Series Pickup)

1. Ensure negative battery cable is disconnected. WAIT at least ONE MINUTE. Remove air bag simulator from vehicle harness at base of steering column. Connect clockspring connector to vehicle harness. Install lower steering column opening finish panel reinforcement. Install lower steering column opening finish panel and hood release handle.
2. Remove passenger's air bag simulator from vehicle harness. Connect passenger's air bag module connector to vehicle harness. Install glove box. Connect negative battery cable. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

Disabling Air Bag System (Mazda6, Millenia, MPV, MX-5 Miata, Protege & Protege5)

Note. MX-5 Miata is equipped with a passenger's air bag ON/OFF switch. Turning switch off is not a substitute for completely disabling the passenger's air bag.

1. Obtain radio anti-theft protection code from vehicle owner prior to servicing vehicle or deactivate radio anti-theft function before disconnecting vehicle battery.
2. Turn ignition switch to LOCK position. Disconnect and shield negative battery cable. WAIT at least ONE MINUTE for back-up power supply to be depleted.

Activating Air Bag System (Mazda6, Millenia, MPV, MX-5 Miata, Protege & Protege5)

Ensure ignition switch is in LOCK position and key is removed. Connect negative battery cable. Ensure AIR BAG indicator light operates properly. See SYSTEM OPERATION CHECK .

Disabling System (Tribute)

1. Obtain radio anti-theft protection code from vehicle owner prior to servicing vehicle or deactivate radio anti-theft function before disconnecting vehicle battery.
2. Turn ignition switch to LOCK position and remove key. Disconnect and shield negative battery cable. Be sure to disconnect auxiliary batteries and power supplies, if equipped. WAIT at least ONE MINUTE for back-up power supply to be depleted.
3. Remove access panel in bottom of steering wheel housing. Disconnect driver's air bag module connector. Install Air Bag Simulator (418-F468) to clockspring side of driver's air bag module electrical connector.
4. Open glove box. Press inward on sides of glove box, and lower glove box to floor. Disconnect passenger's air bag module connector at rear of glove box opening. Install Air Bag Simulator (418-F468) to vehicle harness at passenger's air bag assembly.
5. If equipped with side air bags, disconnect the passenger's side air bag connector under the front passenger's seat. Install Air Bag Simulator (418-F468) to vehicle harness at passenger's side air bag assembly. Install Air Bag Simulator (418-F470) to vehicle harness at passenger's side safety belt buckle connector.
6. Disconnect the driver's side air bag connector under the driver's seat. Install Air Bag Simulator (418-F468) to vehicle harness at driver's side air bag assembly. Install Air Bag Simulator (418-F470) to vehicle harness at driver's side safety belt buckle connector.

Activating Air Bag System (Tribute)

1. Ensure negative battery cable is disconnected. WAIT at least ONE MINUTE. If equipped with side air bags, remove air bag simulator from driver's side air bag harness. Connect driver's side air bag harness to vehicle harness. Remove air bag simulator from driver's side safety belt buckle connector. Connect driver's side safety belt buckle connector to vehicle harness. Remove air bag simulator from passenger's side air bag harness. Connect passenger's side air bag harness to vehicle harness. Remove air bag simulator from passenger's side safety belt buckle connector. Connect passenger's side safety belt buckle connector to vehicle harness.
2. Remove passenger's air bag simulator from vehicle harness. Connect passenger's air bag module connector to vehicle harness. Install glove box. Remove air bag simulator from vehicle harness at top of steering column. Connect driver's air bag module to vehicle harness. Install access cover.
3. Connect negative battery cable. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

1. Turn ignition switch to ON position. SRS MIL will illuminate for approximately 4 seconds and then go out. If vehicle is equipped with side air bags, SRS MIL will illuminate for approximately 4-20 seconds and then go out.
2. If vehicle is equipped with Seat Occupied Recognition (SOR) that includes Automatic Child Seat Recognition (ACSR), the ACSR AIRBAG OFF warning light will illuminate and then go out after approximately 4 seconds if a Mercedes-Benz Babysafe Child Seat is not installed. If a Mercedes-Benz Babysafe Child Seat is installed, AIRBAG OFF warning light will illuminate and verify the recognition of the Babysafe Child Seat.

1. Store SRS front and side air bags with opening surface pointing upward.
2. DO NOT expose to temperatures greater than 212°F (100°C).
3. Protect from any electrical current reaching the SRS air bag unit.
4. Risk of injury if SRS air bag units and ETR units are ignited accidentally or if stored with the opening end facing downward which may cause the accidentally ignited components to fly about causing injury.
5. There is a danger to persons if components are disposed of by cutting apart with cutting torches or other cutting/separation devices. A danger also exists if disposing untriggered units via refuse collection or via smelting/carbonizing companies.
6. Only allow properly trained staff to supervise, purchase, transport, store, test and/or replace any SRS components.
7. Install all SRS air bags or ETR units when they are removed from their original packaging.
8. Protect all SRS air bag or ETR units from sparks, open flame, or temperatures greater than 212°F (100°C).
9. DO NOT transport SRS air bag or ETR units in vehicle passenger's compartment, rather transport securely in their original packaging in the trunk.
10. DO NOT allow oil, grease or cleaning agents to come in contact with the SRS air bag or ETR units.
11. Perform SRS tests only with approved test equipment (such as HHT), while installed in the vehicle without occupants.
12. When reconnecting the vehicle battery or any outside electrical source, with the ignition turned ON, do not allow any occupants inside the vehicle.
13. SRS air bag or ETR units which have been dropped from a height greater than 18 inches must be replaced.
14. Prior to disposing SRS air bag or ETR units, the units must be made unusable by discharging.
15. When discharging SRS air bag and ETR unit, use specified discharge harness while maintaining a safe distance of at least 33 feet from unit being discharged.
16. When installing additional accessories, observe harness clearances near SRS sensor lines.

Turn ignition off and remove ignition key. Disconnect any outside source of electrical circuit (i.e. battery charger). Disconnect negative battery cable and shield cable end. Disconnect SRS control module connector.

Turn ignition off and remove ignition key. Reconnect SRS control module connector. Reconnect negative battery cable end. Ensure SRS MIL will illuminates properly. See SYSTEM OPERATION CHECK .

Turn ignition switch to ON or START position. SRS warning light should illuminate for about 7 seconds and then turn off and remain off for at least 5 seconds indicating that SRS system is operating properly. If SRS warning light does not illuminate as described, stays on for more than 7 seconds or illuminates while driving, SRS is malfunctioning and needs repair.

Observe the following precautions when working with SRS

1. Disable SRS before servicing any SRS or steering column component. Failure to do this may result in accidental air bag deployment and possible personal injury.
2. WAIT at least ONE MINUTE after disabling air bag system before servicing vehicle. Air bag system maintains enough voltage to deploy air bags for ONE MINUTE after disconnecting battery.
3. After servicing, check SRS warning light to verify system operation. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
4. Always wear safety glasses when servicing or handling an air bag.
5. Battery posts, terminals and related accessories contain lead and lead compounds. WASH HANDS after handling to reduce lead exposure.
6. DO NOT expose SRS-ECU, air bag module and clockspring to temperatures greater than 200°F (93°C).
7. DO NOT expose seat belt with pretensioner to temperatures greater than 194°F (90°C).
8. SRS components and seat belt pretensioner should not be subjected to heat. Remove SRS-ECU, driver's and front passenger's air bag modules, clockspring, side-air bag modules, and seat belt pretensioners before drying or baking vehicle after painting.
9. When placing a live air bag module on a bench or other surface, always face air bag module and trim cover up, away from surface. This will reduce motion of module if air bag accidentally deploys.
10. To prevent damage to driver's air bag clockspring, center front wheels before removing steering wheel or steering gear. Center front wheels and align clockspring neutral marks before installing steering wheel.
11. After air bag deploys, air bag surface may contain deposits of sodium hydroxide, which irritates skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct clean-up and disposal procedures.
12. Because of critical system operating requirements, DO NOT service or repair any SRS components, including wiring harness. Repairs are only made by replacing defective component(s).
13. DO NOT allow any electrical source near inflator on the back of air bag module. DO NOT use an ohmmeter or powered circuit tester on air bag modules.
14. When carrying a live (undeployed) air bag module, trim cover must be pointed away from body to minimize injury in case of accidental air bag deployment.
15. Make certain ignition switch is in the LOCK (OFF) position when scan tool is connected or disconnected.
16. DO NOT probe a wire through insulator, as this will damage wire and eventually cause failure due to corrosion.
17. If SRS is not fully functional for any reason, DO NOT drive vehicle until system is repaired and is fully functional. DO NOT remove bulbs, modules, sensors or other components, or in any way disable system from operating normally. If SRS is not functional, park vehicle until repairs are made.

To disable system, turn ignition switch to LOCK position. Disconnect and isolate negative battery cable. WAIT at least ONE MINUTE before servicing vehicle. To activate system, ensure ignition switch is in LOCK position and reconnect negative battery cable. Staying well away from air bag modules, turn ignition switch to ON position. Ensure AIR BAG indicator light operates properly. See SYSTEM OPERATION CHECK .

1. Turn ignition ON and verify that AIR BAG indicator light comes on for about 7 seconds, then goes off.
2. If the AIR BAG indicator light does not come on, or after about 7 seconds does not go out or begins to flash, a SRS malfunction has been detected.

Observe these precautions when working with air bag systems

1. Disable SRS before servicing any SRS or steering column component. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. WAIT at least 3 minutes after disabling SRS before servicing vehicle. SRS voltage is maintained for at least 3 minutes after system is disabled. Servicing system before waiting 3 minutes may cause accidental SRS deployment and possible personal injury.
3. Air bag will operate only when ignition switch is in ON or START position. Ignition switch should be in OFF position when working under hood or inside vehicle.
4. DO NOT attempt to repair, splice or modify SRS wiring harness. If harness is damaged, replace it with a new one.
5. When servicing vehicle, air bag module should be pointed away from technician.
6. DO NOT use a circuit tester to check air bag harness connectors. SRS wiring harness and connectors have Yellow insulation for easy identification. Keep all ground points clean.
7. Impact sensor(s), safing sensor and tunnel sensor must be installed with arrow marks facing front of vehicle. Also, check sensors for cracks, defects and rust before installation. Replace sensors as necessary.
8. If steering gear is removed, DO NOT turn steering wheel or column shaft. Rotation of SRS spiral cable under steering wheel air bag module is limited. SRS spiral cable must be aligned in neutral position (centered).
9. On vehicles equipped with passenger's side air bag module ON/OFF switch, ensure ON/OFF switch is in the same position as when vehicle was brought in for service.
10. Handle air bag modules carefully. Always place air bag modules with pad facing upward. DO NOT disassemble air bag module.
11. DO NOT use old bolts after removal; replace with new ones.
12. DO NOT insert any foreign objects (screwdriver, etc.) into air bag module connector.
13. Replace air bag module if it has been dropped or sustained an impact.
14. After servicing SRS system, perform «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
15. DO NOT expose air bag module to temperatures exceeding 194°F (90°C).
16. DO NOT expose seat belt pretensioners to temperatures exceeding 176°F (80°C).
17. DO NOT allow oil, grease or water to contact air bag module or seat belt pretensioner assembly.
18. If vehicle is damaged in a collision, check impact sensor, tunnel and safing sensors and related wiring harnesses.
19. Wear gloves when handling deployed air bag module.
20. Before discarding an air bag module or seat belt pretensioner (including scrapping a vehicle with air bag system), always deploy air bag(s) and seat belt pretensioners.
21. Always place the side curtain air bag module with the warning label facing upward.
22. DO NOT attempt to disassemble side curtain air bag module.

To disable SRS, turn ignition off. Disconnect and shield BOTH battery cables starting with negative battery cable and then positive battery cable. WAIT at least 3 minutes before working on vehicle. To activate SRS, connect battery cables. Turn ignition on. Ensure AIR BAG indicator light operates as specified. See SYSTEM OPERATION CHECK .

Turn ignition switch to ON position, with engine off. AIR BAG light on instrument panel should come on for about 3 seconds and then go off. If AIR BAG light fails to come on, remains on after 3 seconds, or comes on while driving, air bag system requires servicing. Ignition must be in ON position for at least 10 seconds to enable the triggering unit to identify all faults in the air bag system.

Observe the following precautions when servicing air bag system

1. Before servicing any air bag system or steering column component, disable air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. After disabling the air bag system, wait at least ONE MINUTE before servicing vehicle. Air bag system voltage is maintained for about ONE MINUTE after system is disabled. Failure to wait specified amount of time before servicing system may cause accidental air bag deployment and possible personal injury.
3. Because of critical operating requirements of system, DO NOT service or disassemble any air bag component. Correction is made by replacement only.
4. DO NOT allow grease, oil, cleaning solutions, or similar products to come in contact with air bags.
5. DO NOT subject air bags to temperatures greater than 194°F (90°C).
6. Replace air bag modules, crash sensors, and air bag control units that have fallen from a height of 20 inches or more.
7. DO NOT install additional trim, labels or stickers on steering wheel, or in area of passenger's side air bag.
8. DO NOT repair or modify air bag system wiring. Replace wiring harness if damaged.
9. Disable air bag system before electric-welding vehicle.
10. DO NOT route wires from other electrical equipment in the vicinity of air bag wire harness.
11. Wash hands thoroughly after handling deployed air bags.

To disable air bag system, turn ignition off. Disconnect and shield negative battery cable. WAIT at least ONE MINUTE before servicing vehicle. To activate air bag system, reconnect negative battery cable. Perform a system operation check to ensure system is functioning properly. See SYSTEM OPERATION CHECK .

Turn ignition on. AIR BAG warning light should come on for 3-4 seconds, then go out. If the light goes out and then comes back on, or does not come on at all, a fault exists in the system.

Observe these precautions when working with air bag systems

1. Disable Supplemental Restraint System (SRS) before servicing any SRS or steering column component. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. Because of critical operating requirements of system, DO NOT attempt to repair or dismantle air bag components. Corrections are made by replacement only.
3. Always wear safety glasses when servicing or handling an air bag.
4. Handle air bag and seat belt pretensioner components carefully. Avoid exposing components to impact, excessive heat, and moisture.
5. Air bag modules or seat belt pretensioners must be installed immediately after it is taken out of storage. If work is interrupted, module must be returned to storage. Air bag modules or seat belt pretensioners must never be left unattended out of storage.
6. Air bag module and seat belt pretensioner are sealed units. DO NOT attempt to dismantle or repair it.
7. When placing a live air bag module on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if accidentally deployed.
8. Disconnect and shield negative battery cable before welding any body components.
9. DO NOT splice or repair air bag wiring harness.
10. Air bags and seat belt pretensioners that have fallen onto hard surfaces must be replaced. Dropped or defective components must not be installed in vehicle.
11. After deployment, air bag surface may contain deposits of sodium hydroxide, which can irritate skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up. Wash hands using mild soap and water. Follow correct disposal procedures.
12. DO NOT subject air bag modules to temperatures greater than 275°F (135°C). DO NOT subject seat belt pretensioners to temperatures greater than 212°F (100°C).
13. Never allow any electrical source near inflator on back of air bag module.
14. DO NOT use grease, detergent or similar substances on seat belt pretensioner.
15. When carrying a live air bag module, trim cover should be pointed away from body to minimize injury in case of accidental air bag deployment.
16. Never apply grease to SRS connectors.

Note. Saab vehicles are equipped with seat belt pretensioners. The SRS controls both air bags and seat belt pretensioners.

Note. The control module has 3 backup power sources. Two of them enable the front air bags to be activated for a minimum of 150 milliseconds after the regular power supply has failed and the third backup power source keeps the processor going for 150 milliseconds after the regular power supply has failed.

To disable SRS, disconnect and shield negative battery cable. To activate system, reconnect negative battery cable. Perform a system operation check. See SYSTEM OPERATION CHECK .

Turn ignition switch to ON position. Air bag warning light should illuminate for about 6 seconds. Keep ignition switch in ON position and confirm that air bag warning light remains off for about 6 seconds after being illuminated.

Observe these precautions when working with air bag systems

1. If air bag system sensors, air bag module, air bag control module, seat belt pretensioners and/or harness are deformed or damaged, replace them with NEW manufacturer components.
2. DO NOT drop air bag system components.
3. DO NOT subject air bag system components to temperatures greater than 199°F (93°C).
4. DO NOT use air bag system components from other vehicles. ONLY use NEW manufacturer components.
5. NEVER reuse any deployed air bag system components.
6. Only use a digital circuit tester to check air bag system. An analog circuit tester may cause air bag system to activate.
7. When checking air bag system harness, use a test harness. DO NOT directly probe air bag system harness connectors with tester probes.
8. DO NOT check continuity of driver, passenger's or side air bag modules and pretensioner. Doing so could cause air bag component to activate.
9. DO NOT allow water, oil or grease to come in contact with air bag system components or connector terminals. DO NOT touch component connector terminals.
10. DO NOT disassemble driver, passenger's or side air bag modules or pretensioner. They are not repairable.
11. If any damage, opening or rust is found on the air bag system wire harness, DO NOT attempt to repair using soldering equipment. Be sure to replace faulty harness with a NEW manufacturer component.
12. Install wire harness securely with specified clips to avoid interference or tangling with other components.
13. When painting or performing body panel repairs on the front of the vehicle, including the front wheel apron, front fender and front side of frame, remove air bag system front sub sensors and wire harness.
14. When painting or performing body panel repairs on the either side of the vehicle, including the side sill, center pillar and front or rear doors, remove air bag system side sensors and wire harness.
15. A removed front seat with a side air bag must be kept more than 8" (200 mm) away from walls or other objects.
16. When storing a removed air bag module, DO NOT place any objects on top of it or pile air bag modules on top of each other. If the air bag module activates with an object on top of it or with pad side down, a serious accident may result.
17. After removal, place air bag component with pad facing up, on a clean, dry and flat surface away from sources of heat, light, moisture and dust.

Note. Air bag system has a back-up power supply. If the air bag system is serviced within 20 seconds after the battery cable is disconnected the air bag system may be activated.

To disable air bag system, turn ignition switch to OFF position. Disconnect and shield negative battery cable and WAIT for more than 20 seconds before starting repair procedures. To activate system, ensure ignition switch is in OFF position. Reconnect negative battery cable. Perform a system operation check. See SYSTEM OPERATION CHECK .

Turn ignition switch to ON position. On Aerio and XL-7, if system is functioning normally, AIR BAG indicator should flash 6 times. On Grand Vitara and Vitara, if system is functioning normally, AIR BAG indicator should flash 7 times. On all models, if air bag warning light does not come on, stays on steady or keeps flashing after flashing 6 or 7 times, there is a fault in the air bag system.

Observe the following precautions when servicing SRS

1. Disable air bag system before servicing any air bag or steering column component. Failure to disable air bag could result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. Never power up air bag system when SDM is not rigidly attached to the vehicle. Failure to follow procedures could result in possible air bag system activation, personal injury or unnecessary air bag system repairs.
3. Always wear safety glasses when servicing or handling an air bag.
4. The air bag module and seat belt pretensioner immediately after deployment/activation are very hot. Wait for at least 30 minutes for components to cool off before proceeding the work.
5. DO NOT apply water, oil or anything else to deployed air bag module or to seat belt pretensioner.
6. After an air bag module has been deployed, the surface of the air bag may contain a powdery residue. This powder consists primarily of cornstarch (used to lubricate the bag as it inflates) and by-products of the chemical reaction. During many service procedures, wear gloves and safety glasses. Wash your hands with mild soap and water after completing the work.
7. Handle air bag module(s) carefully. Always place air bag module(s) with pad facing upward. DO NOT disassemble air bag module.
8. If the air bag system and another vehicle system both need repair, the air bag system must be repaired first to avoid unintended air bag deployment.
9. DO NOT modify steering wheel, dashboard, or any other air bag system component. Modifications can adversely affect air bag system performance and lead to personal injury.
10. Never use air bag parts from another vehicle. Replace air bag parts with new parts.
11. Remove air bag modules and SDM if repairing the vehicle requires exposing the vehicle to temperatures over 200°F (93°C). Never expose air bag system components directly to hot air or flames.
12. NEVER expose air bag system components directly to hot air (drying or baking the vehicle after painting) or flames.
13. If painting vehicle, DO NOT expose air bag harness or connectors to paint mist.
14. Store live air bag modules at temperatures below 150°F (65°C) with low humidity, and away from electrical noise.
15. When placing a live air bag on a bench or other surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if it is accidentally deployed.
16. Replace any air bag components that have been dropped from a height of 3 feet (90 cm) or more. Replace seat belt pretensioner (retractor assembly) if it is dropped from a height of one foot (30 cm) or more.
17. NEVER attempt disassembly or repair of air bag components or seat belt pretensioners. Components are not repairable and must be replaced if damaged.
18. When servicing vehicle if shocks (as from a hammer or mallet) may be applied near air bag system sensors or other components, remove those components first.
19. DO NOT allow any electrical source near inflator on the back of air bag module. To avoid deployment when troubleshooting the air bag system, DO NOT use electrical test equipment such as a battery powered or AC powered voltmeter, ohmmeter or any type of electrical equipment other than that specified. DO NOT use a non-powered probe type tester.
20. DO NOT apply power to the air bag system unless all components are connected or a diagnostic procedure requests it, as this will set a diagnostic trouble code.
21. When using electric welding equipment, always disconnect driver's and passenger's air bag module connectors.
22. Never use air bag components from another vehicle.
23. Air bag wire harness can be identified easily because it is covered with a Yellow protection tube and is included in floor harness. Be very careful when handling it.
24. Replace air bag wire harness when an open, short or other damage to wire harness, connector or terminal is found. Replace wire harness, connectors and terminals as an assembly. When installing it, ensure that the air bag wire harness is not caught or does not interfere with other parts.
25. Ensure air bag system grounding points are clean and grounds are securely fastened for optimum metal-to-metal contact. Poor grounding can cause intermittent problems that are difficult to diagnose.

Note. With AIR BAG fuse removed and ignition on, AIR BAG warning light will be on. This is normal and does not indicate an air bag system malfunction.

Disabling Air Bag System (Aerio)

1. Turn steering wheel so that front wheels are pointing straight ahead. Disconnect negative battery cable. Turn ignition switch to LOCK position and remove key. Remove AIR BAG fuse located in fuse box above left kick panel. (Scheme 21)
2. Release driver's side Yellow connector lock slider and disconnect connector. Pull out glove box while pushing stopper from both right and left sides. Release passenger's side Yellow connector lock slider and disconnect connector.

Scheme 21

Activating Air Bag System (Aerio)

1. Confirm that negative battery cable is disconnected. Turn ignition switch to LOCK position and remove ignition key. Connect driver's side Yellow connector of air bag contact coil and combination switch assembly by pushing connector in until a click is heard. Connect passenger's side Yellow connector of passenger's air bag module by pushing connector in until a click is heard. Ensure all other air bag components are properly installed and connected.
2. Install glove box. Install AIR BAG fuse in fuse box. (Scheme 21) Connect negative battery cable. Turn ignition switch to ON position and verify that AIR BAG warning lamp flashes 6 times and then turns OFF. If it does not operate as described, perform Air Bag Diagnostic System Check.

Disabling Air Bag System (Grand Vitara, Vitara & XL-7)

1. Technical service work must be started at least 90 seconds after the ignition switch is turned to the LOCK position and the negative battery cable is disconnected. Otherwise, the system may be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
2. Ensure wheels are in straight-ahead position. Turn ignition switch to LOCK position. Remove ignition key.
3. Remove AIR BAG fuse. On Grand Vitara, Vitara and XL-7, there is a single fuse located in the air bag harness, behind lower left edge of driver's side knee bolster. (Scheme 22)
4. On Grand Vitara, Vitara and XL-7, locate Yellow 2-pin connector behind lower edge of driver's side knee bolster (below steering column). Disconnect Yellow 2-pin connector for driver's air bag module. (Scheme 22)
5. On all models, pull out glove box while pushing in both right and left sides. Release locking lever and disconnect Yellow connector for passenger's air bag module (located in glove box opening). (Scheme 23)

Activating Air Bag System (Grand Vitara, Vitara & XL-7)

1. Ensure ignition switch is in LOCK position. Remove ignition key. Ensure AIR BAG fuse is removed.
2. Reconnect driver's air bag module and passenger's air bag module connectors. Install AIR BAG fuse. Perform «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

Scheme 22

Scheme 23

TOYOTA

Note. When ignition switch is in ON or ACC position and SRS warning light remains on or flashes, the air bag sensor assembly has detected a malfunction code. If, after about 6 seconds, SRS warning light sometimes lights up or SRS warning light lights up even when ignition switch is OFF, a short in the SRS warning light circuit can be considered likely.

Turn ignition switch to ACC or ON position. SRS warning light should come on for about 6 seconds, then go out. If air bag warning light does not operate as specified, service air bag system.

Observe the following precautions when servicing SRS

1. Disable SRS before servicing any SRS, instrument panel or steering column component. Failure to do this could result in accidental air bag deployment and possible personal injury. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. DO NOT use any type of back-up power supply from outside vehicle to avoid memory loss in memory systems. Back-up power supplies can provide enough voltage to activate SRS components.
3. After turning ignition switch to LOCK position and disconnecting negative battery cable, wait at least 90 SECONDS before working on vehicle. SRS is equipped with a back-up power source that may allow air bag to deploy within 90 seconds after disconnecting negative battery cable.
4. In a minor collision in which air bags did not deploy, inspect front air bag sensors, steering wheel pad, front passenger's air bag assembly, side air bag assembly, curtain air bag assembly, seat belt pretensioner, air bag control module, and side air bag sensor.
5. If steering wheel pad, front or side air bag assemblies, curtain air bag assembly, air bag sensor, side air bag sensor or front air bag sensor has been dropped, or if there are cracks, dents or other defects in the case, connectors or brackets, replace the component.
6. Remove air bag sensors if an impact is likely to be applied to area close to sensors during repair.
7. Never disassemble or repair system components. Replace cracked, dented or otherwise damaged system components.
8. DO NOT expose front air bag sensors, center air bag sensor assembly, steering wheel pad, passenger's air bag, side air bags or seat belt pretensioners directly to hot air or flame.
9. DO NOT store air bag modules where they will be exposed to temperatures greater than 199°F (93°C), high humidity or electrical noise. DO NOT store seat belt pretensioners in temperatures greater than 176°F (80°C), high humidity or electrical noise.
10. Information labels are attached to air bag components. Follow all notices on labels.
11. After servicing SRS, check air bag indicator light to ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
12. Always wear safety glasses when servicing or handling air bags or seat belt pretensioners.
13. When placing a live air bag on a bench or other flat surface, always face air bag and trim cover up, away from surface. This will reduce motion of module if it is accidentally deployed.
14. After deployment, air bag surface may contain deposits of sodium hydroxide, which irritates skin. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up. After clean-up, wash hands using mild soap and water.
15. After deployment, steering wheel pad is very hot. WAIT 30 minutes before touching.
16. DO NOT install components previously installed on another vehicle. Only use NEW components supplied by manufacturer.
17. When using electric welding, disconnect air bag module and seat belt pretensioner connectors.
18. When carrying a live air bag module, trim cover must be pointed away from body to minimize injury in case of accidental air bag deployment.
19. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and again becomes operational. DO NOT remove bulbs, modules, sensors or other components or in any way disable system from operating normally. If SRS is not functional, park vehicle until it is repaired and functions properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
20. Malfunction symptoms of SRS are difficult to be confirmed, so Diagnostic Trouble Codes (DTCs) become the most important source of information when troubleshooting. When troubleshooting SRS malfunction, always check for and record any DTCs before disconnecting the battery.

Note. All air bag system harness connectors are colored Yellow to distinguish them from other connectors.

Note. SRS is equipped with a back-up power source so that if work is started within 90 seconds from disconnecting negative battery cable, SRS may be deployed.

1. Obtain radio anti-theft protection code from owner prior to servicing vehicle or deactivate radio anti-theft function before disconnecting vehicle battery.
2. Place front wheels in straight-ahead position. Turn ignition switch to LOCK position. Disconnect and shield negative battery cable. WAIT at least 90 SECONDS before working on vehicle.

1. Ensure ignition key is removed from switch. Connect negative battery cable.
2. Staying well away from air bag modules, turn ignition switch to ACC or ON position. Ensure AIR BAG indicator light operates properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

Cabrio, EuroVan, Golf, GTI, Jetta, New Beetle & Passat

Turn ignition switch to ON position. AIR BAG indicator light should come on for about 4 seconds, and then go out. If light remains on, goes out and comes back on, or flashes continuously, air bag control unit has detected a system fault.

Observe these precautions when working with air bag systems

1. Disable air bag system before servicing any air bag system component or component located in instrument panel or steering column. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
2. Because of critical operating requirements of air bag system, DO NOT attempt to service or disassemble any air bag system component. If a component is faulty it must be replaced.
3. DO NOT leave air bag components unattended. Install air bag components in vehicle immediately after they are obtained.
4. NEVER point open end of a seat belt tensioner at another person.
5. Only install NEW air bag system components supplied by manufacturer. DO NOT use components previously installed in another vehicle.
6. DO NOT use air bag or seat belt pretensioner components that have been dropped on hard surface or have mechanical damage.
7. DO NOT allow chemical cleaners, oil or grease to contact vinyl covering on air bag.
8. DO NOT place stickers or covers on steering wheel, passenger's side instrument panel or over front seat backs. Using a seat cushion, mat or pad on front passenger's seat, may inhibit operation of seat occupied sensor and side air bags.
9. Disable SRS before performing electric welding on vehicle.
10. DO NOT expose air bag module or seat belt pretensioners to temperatures greater than 212°F (100°C).
11. DO NOT allow any electrical source near front or side air bag inflators or near seat belt tensioner connector.
12. Before picking up or touching an air bag unit ensure technician has been electrostatically discharged by touching a suitable metal part, for example, a water pipe, a heating pipe or a metal frame.
13. Install a new air bag component as soon as component is removed from the packaging. If work is interrupted or delayed for any reason, place air bag component back in its original packaging.
14. DO NOT leave any undeployed air bag component unattended if work is interrupted.
15. NEVER use test lamp, voltmeter or ohmmeter for testing.
16. Air bag components which have dropped onto a hard surface from a height of 19.7" (50 cm) or more, or show signs of damage MUST NOT be installed in the vehicle. Always replace any air bag system component that has been mechanically damaged (example: dented or cracked).
17. Air bag components which have not been activated should be marked and returned to the manufacturer for disposal (use air bag unit transport container). The storage and transportation of air bag units must comply with the regulations for explosive substances.
18. Only install original seat covers that have been authorized for use with side air bags (recognizable by AIRBAG label). DO NOT install commercially available loose fitting seat covers. When installing a backrest cover ensure that the cover seam is straight in the area of the side air bag. Replace all seat cover clips. Only use original seat cover clips. For safety reasons always replace the seat cover if it is damaged in area of the side air bag, e.g. torn, burn holes, etc.
19. When carrying a live air bag assembly, trim cover pad should be pointed away from body to minimize injury in case of accidental air bag deployment.
20. If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired. DO NOT remove any component or in any way disable system from operating normally. If SRS is not functional, park vehicle until repairs can be made.

1. Obtain radio anti-theft code (if equipped) from vehicle owner and write down preset radio frequencies. To disable air bag system, ensure ignition is off and key is removed. Disconnect and shield negative battery cable.
2. To activate system, turn ignition switch to ON position. Ensure no one is inside vehicle and connect negative battery cable. Perform system operation check to ensure proper system operation. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

1. Check that the Supplementary Restraint System (SRS) indicator light is not defective by turning ignition key to ON position. SRS indicator light will illuminate and go out after approximately 7 seconds for all models except the C70 Convertible, which is 3 seconds or the S40 and V40 models, which is 10 seconds. Ensure SRS indicator light in combined instrument panel is not constantly illuminated. Repair SRS fault if SRS light is constantly illuminated.
2. If vehicle is equipped with Roll Over Protection (ROP) system, when the ignition is turned to ON position the ROP light should illuminate for approximately 5 seconds and then go out.

1. On XC90 equipped with Supplemental Restraint System (SRS) Module include Roll Over Protection (ROP). The SRS control module must not be removed, moved to another position or worked on unless power supply is disconnected. If power supply is disconnected, air bags and seat belt tensioners may deploy. SRS module is located between the parking brake and gear selector lever in center console. NEVER install car accessories on or near SRS Module.
2. C70 Convertible is equipped with a Roll Over Protection (ROP) system. The ROP roll-over bar is raised by a spring with a force sufficient to cause injury. It is important that no one is standing above the roll-over bar when it is deployed. The roll-over bar operating range is approximately 20" (50 cm), which is also the safety distance from the bar. No repairs are permitted on the roll-over bar cassette. If there is a fault in the roll-over bar, the whole cassette should be replaced.
3. Air bag modules/pyrotechnical seat belt tensioners must never be taken apart, repaired or transferred to another vehicle.
4. Under no circumstances use an ohmmeter or other live measuring instrument to take readings on a disconnected non deployed air bag or pyrotechnical seat belt tensioner. This could deploy the air bag or pyrotechnical seat belt tensioner.
5. Never take a resistance reading across air bags or seat belt tensioners if a DTC is stored for too high or low igniter resistance. Special tools with the same resistance as the air bag or seat belt tensioner must be used for fault-tracing.
6. When storing or transporting air bag modules/pyrotechnical seat belt tensioners, they should be handled in accordance with national statutory regulations.
7. Battery must not be connected when the steering wheel air bag module connector is disconnected. If battery must be connected, install special tool (998-8695) to SRS steering wheel air bag module connector. This is to prevent vehicle SRS On-Board Diagnostic (OBD) system setting a Diagnostic Trouble Code (DTC). If ignition switch is turned to ON position with air bag module connector disconnected, an open circuit DTC will be set. DTCs must be cleared.
8. DO NOT turn steering wheel when contact reel is locked. The contact reel locking pin will break off.
9. DO NOT open any SRS component.
10. The inflatable curtain must never be unscrewed, repaired or moved to another vehicle. DO NOT remove, loosen or tighten any mounting screws.
11. DO NOT fold or twist inflatable curtain during removal or installation. The inflatable curtain module must be handled with both hands, with one hand holding gas generator. The inflatable curtain module must be kept level. Avoid twisting or bending the inflatable curtain module as much as possible.
12. Any SRS component must be returned if there is any visible damage.
13. DO NOT position or install accessories or any other components in the area near SRS components. Failure to observe this instruction may cause SRS component to fail.
14. The SRS system must always be worked on by a qualified technician.
15. When removing a non deployed steering wheel module, module should be placed with metal side (rear) facing downwards somewhere where it will not be handled carelessly (in the luggage compartment for example).
16. When the air bag is deployed powder is spread throughout the car. The chemical reaction that creates the gas can also produce certain by-products such as calcium chloride. When decontaminating a car with a deployed air bag wear gloves, protective goggles, overalls and a face mask. Exposure to the powder can cause the following problems: Eye Contact Symptoms may include burning or grittiness. Flush immediately, using copious amounts of water for AT LEAST 15 minutes. See a doctor if the symptoms persist. Skin Contact Symptoms may include a burning sensation. Wash thoroughly using a mild soap solution and water. Open Wounds Wounds may be aggravated. Avoid exposure and carefully clean thoroughly.

S40 & V40

1. To disable air bag system, make a note of radio code if anti-theft coded radio is installed. Turn ignition switch to OFF position and remove key. Disconnect and isolate battery negative cable. Wait 3 minutes before starting work.
2. To activate air bag system, ensure nobody is in the vehicle when battery is connected. This is a safety precaution in case an air bag module activates when the power is connected. When all components have been reinstalled, turn ignition switch to ON position (II). Connect battery negative cable. Perform system operation check to ensure proper system operation. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

S60, V70, XC70, XC90 & S80 - Built After Chassis Number 29668

Note. Before disconnecting negative battery cable, if the Malfunction Indicator Light (MIL) illuminates, record any Diagnostic Trouble Codes (DTCs) for the engine management system. Whenever possible, repair any DTCS before disconnecting negative battery cable.

1. To disable air bag system, make a note of radio code if anti-theft coded radio installed. Turn ignition switch to OFF position (0) and wait at least 5 minutes before disconnecting negative battery cable. This allows sufficient time for information to be stored in the control modules. Disconnect negative battery cable and WAIT at least 10 SECONDS before starting work. DO NOT disconnect positive battery cable in the engine compartment.
2. To activate air bag system, ensure nobody is in the vehicle when battery is connected. This is a safety precaution in case an air bag module activates when the power is connected. When all components have been reinstalled, turn ignition switch to ON position (II). Connect negative battery cable. Perform system operation check to ensure proper system operation. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .
3. After reconnecting negative battery cable the Upper Electronic Module (UEM) must be initialized. Initialize the central locking, interior lighting and sun roof by unlocking vehicle using a remote control, ignition key or VADIS vehicle communication. If vehicle is equipped with Manual Climate Control (MCC) or Standard Climate Control (SCC), the blower fan speed must recalibrated if the battery has been disconnected.
4. Turn ignition to ON position. Turn blower fan switch to maximum and then turn blower fan switch to minimum. The calibration is complete. To calibrate sun roof, close sun roof and operate sun roof switch so that sun roof is in tilt position. Release switch and press the button again for at least 5 seconds. Release the switch and the calibration is complete. To calibrate the engine control module after battery has been disconnected and reconnected, may require driving vehicle for a few minutes before engine runs normally.

S60, V70, XC70, XC90 & S80 - Built Before Chassis Number 29668

1. To disable air bag system, make a note of radio code if anti-theft coded radio is installed. Turn ignition switch to OFF position and remove key. Disconnect and isolate negative battery cable. Wait 3 minutes before starting work.
2. To activate air bag system, ensure nobody is in the vehicle when battery is connected. This is a safety precaution in case an air bag module activates when the power is connected. When all components have been reinstalled, turn ignition switch to ON position (II). Connect negative battery cable. Perform system operation check to ensure proper system operation. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/restraints/#air-bag-deactivation-procedures) .

See also:
• DISABLING & ACTIVATING AIR BAG SYSTEM
• SYSTEM OPERATION CHECK
• DISABLING & ACTIVATING AIR BAG SYSTEM
