Interior Fittings Land Rover Range Rover L322

Exterior/interior Trim 97 illustrations ~5767 words

Scheme 1

Scheme 1: Remove
Scheme 1: Remove
  1. Release sun visor from retaining clip.
  2. Carefully release and remove trim from mounting.
  3. Remove 3 Torx screws securing visor.
  4. Disconnect multiplug and remove visor.
  5. Remove screw securing sun visor clip to roof and remove clip.

Refit

  1. Fit sun visor clip and secure with screw.
  2. Position sun visor and connect multiplug.
  3. Fit sun visor to roof and secure with screws.
  4. Fit sun visor to clip.
  5. Fit trim to mounting.

Scheme 2

Scheme 2: Remove
Scheme 2: Remove

Scheme 3

Scheme 3
Scheme 3
  1. Release and remove mirror finishers.
  2. Rotate mirror stem at its base to release from windscreen.
  3. Models fitted with rain sensor: Disconnect multiplug from rain sensor.
  4. Disconnect multiplug from mirror and remove the mirror.
  1. Position mirror and connect multiplug.
  2. Models fitted with rain sensor: Connect multiplug to rain sensor.
  3. Fit mirror to location and rotate to secure.
  4. Fit and secure mirror finishers.

Scheme 4

Scheme 4: Remove
Scheme 4: Remove

Scheme 5

Scheme 5
Scheme 5
  1. Release 'D' post upper finisher. «76.13.30 TRIM FINISHER - 'D' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove 'D' post lower trim. «76.13.31 TRIM FINISHER - 'D' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove Allen screw securing load space securing ring to load space floor, release and remove securing ring assembly.
  4. Release and remove seat anchor escutcheon
  5. Remove access panel.
  6. Release 2 turn buckles.
  7. Remove 3 scrivets and release trim casing.
  8. Disconnect multiplugs from interior light and accessory power socket.
  9. Remove the quarter trim
  1. Position trim casing and connect multiplugs.
  2. Fit scrivets and turn buckles to secure trim.
  3. Fit access panel.
  4. Fit seat anchor escutcheon.
  5. Position luggage space securing ring to body, locate peg. Fit and tighten bolt to25 Nm (18 lbf.ft).
  6. Fit 'D' post lower trim. «76.13.31 TRIM FINISHER - 'D' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  7. Fit 'D' post upper finisher. «76.13.30 TRIM FINISHER - 'D' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 6

Scheme 6: Remove
Scheme 6: Remove
  1. Remove carpet retainer. «76.49.17 RETAINER - FRONT CARPET»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764917-retainer-front-carpet)
  2. Release 4 clips securing inner edge of footrest pad to finisher, roll pad clockwise and remove.
  3. Remove bolt securing footrest finisher to body.
  4. Lift bonnet lock release handle and withdraw finisher from clips. Pull horizontal and rearward to remove.
  1. Fit finisher to 'A' post and secure with clips.
  2. Fit bolt securing footrest finisher to body and tighten to 3 Nm (2.2 lbf.ft).
  3. Fit footrest pad and secure clips.
  4. Fit carpet retainer. «76.49.17 RETAINER - FRONT CARPET»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764917-retainer-front-carpet)

76.13.26 Trim finisher - 'A' post - upper

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 7

Scheme 7: Remove
Scheme 7: Remove
  1. Make the SRS system safe. «SUPPLEMENTARY RESTRAINT SYSTEM (SRS) PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/oem-general-information/#general-information__supplementary-restraint-system-srs-precautions)
  2. Release door aperture seal.
  3. Remove cover from screw.
  4. Remove Torx screw securing 'A' post trim.
  5. Release 3 clips securing 'A' post trim and remove trim. CAUTION: The airbag is mounted directly under this finisher, extreme care is necessary.
  6. Remove retaining clips from trim.
  1. Fit retaining clips to trim.
  2. Fit 'A' post trim and tighten screw to 2 N.m (1.5 lbf.ft).
  3. Fit screw cover.
  4. Fit seal to door aperture.
  5. Connect battery leads, earth lead last.

Scheme 8

Scheme 8: Remove
Scheme 8: Remove
  1. Remove carpet retainer. «76.49.17 RETAINER - FRONT CARPET»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764917-retainer-front-carpet)
  2. Release sufficient door aperture seal to access lower trim finisher.
  3. Release and remove finisher horizontally from 2 retaining clips. NOTE: Do not carry out further dismantling if component is removed for access only.
  4. Check condition of finisher retaining clips in body, replace if damaged.
  1. Fit retaining clips to body.
  2. Fit and secure finisher.
  3. Secure door aperture seal.
  4. Fit carpet retainer. «76.49.17 RETAINER - FRONT CARPET»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764917-retainer-front-carpet)

76.13.28 Trim finisher - 'B' post - upper

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 9

Scheme 9: Remove
Scheme 9: Remove
  1. Make the SRS system safe. «SUPPLEMENTARY RESTRAINT SYSTEM (SRS) PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/oem-general-information/#general-information__supplementary-restraint-system-srs-precautions)
  2. Remove front seat. «FRONT SEAT»(/land-rover/range-rover/l322-2002-2005/remont/seats/#seats)
  3. Release door aperture seal from 'B' and 'C' posts.
  4. Release 4 fixings securing 'B' post lower finisher.
  5. Release 'B' post upper finisher from fixings and remove finisher assembly.
  6. Remove and discard fixings from finisher.
  7. Depress clips and remove 'B' post upper finisher from lower finisher.
  1. Fit upper 'B' post finisher to lower finisher.
  2. Fit new fixings to finisher.
  3. Fit finisher assembly to upper fixings, position seat belt and secure lower finisher to 'B' post.
  4. Fit door aperture seals.
  5. Fit front seat. «FRONT SEAT»(/land-rover/range-rover/l322-2002-2005/remont/seats/#seats)
  6. Connect battery leads, earth lead last.

Scheme 10

Scheme 10: Remove
Scheme 10: Remove
  1. Remove lower 'D' post finisher. «76.13.31 TRIM FINISHER - 'D' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove and discard Torx bolt from lower seat belt anchor.
  3. Release upper 'D' post finisher from seat belt webbing and remove finisher.
  1. Pass seat belt through upper 'D' post finisher, fit belt and tighten Torx bolt to 50 Nm (37 lbf.ft).
  2. Fit finisher. «76.13.31 TRIM FINISHER - 'D' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 11

Scheme 11: Remove
Scheme 11: Remove

Scheme 12

Scheme 12
Scheme 12
  1. Remove parcel tray.
  2. Release rear seat squab and fold seat forward.
  3. Remove sufficient 'D' post door aperture seal to access upper trim finisher.
  4. Release 'D' post upper finisher from upper clips.
  5. Remove 2 Torx screws securing top edge of lower trim finisher. Release pegs at lower edge and remove.
  1. Fit lower trim finisher and secure with Torx screws.
  2. Fit 'D' post upper finisher.
  3. Check operation of rear seat belt.
  4. Secure seal to door aperture.
  5. Position seat in upright position.
  6. Fit parcel tray.

Scheme 13

Scheme 13: Remove
Scheme 13: Remove

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Open tailgate.
  2. Re lease aperture seal.
  3. Release 4 fixings securing 'E' post finisher and carefully release finisher.
  4. If fitted: Disconnect speaker multiplug.
  5. Remove finisher. Do not carry out further dismantling if component is removed for access only.
  6. If fitted: Remove 3 Torx screws securing speaker and remove the speaker.
  7. Remove fixings from finisher.
  1. Fit new fixings to finisher.
  2. If fitted: Fit speaker to finisher and secure with screws.
  3. If fitted: Connect speaker multiplug.
  4. Fit finisher and secure fixings.
  5. Fit seal to aperture.

Scheme 16

Scheme 16: Remove
Scheme 16: Remove

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Remove center console finisher. «76.25.07 FINISHER - CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove both center console closing panels. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove 2 Torx screws securing large cubby box liner, remove liner.
  4. Remove 2 Torx screws securing ignition switch to center console.
  5. Remove 4 Torx screws securing center console to fascia.
  6. Remove 2 Torx screws and collect washers from base of large cubby box.
  7. Remove 2 screws securing center console rear closing panel. Release clips and remove panel.
  8. If fitted: Disconnect 2 multiplugs from AVIO module.
  9. Raise rear of center console, disconnect 3 multiplugs from center console and collect air duct adaptor.
  10. Disconnect 3 Lucar connectors from accessory power socket.
  11. Carefully remove center console. CAUTION: Care must be taken to protect painted and veneered surfaces.
  1. Position center console and connect multiplugs to rear of console. Fit air duct adaptor and align center console to mountings.
  2. Secure center console with screws.
  3. If fitted: Connect multiplugs to AVIO module.
  4. Fit rear closing panel and secure with clips and screws.
  5. Position ignition switch and secure with screws.
  6. Fit cubby box and secure with Torx screws.
  7. Fit both center console closing panels. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Fit center console finisher. «76.25.07 FINISHER - CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 21

Scheme 21: Remove
Scheme 21: Remove

Scheme 22

Scheme 22
Scheme 22
  1. Open spectacle holder, remove 2 screws securing console and release console from headlining.
  2. Disconnect multiplugs from switches and lamp. Remove console assembly. NOTE: Do not carry out further dismantling if component is removed for access only.
  3. Remove lamp from console.
  4. Remove switches from console.
  5. Remove 2 retaining clips from console.
  1. Fit retaining clips to console.
  2. Fit switches to console.
  3. Fit lamp to console.
  4. Position front console and connect multiplugs.
  5. Fit console to headlining and secure with screws.
  6. Close holder.

Scheme 23

Scheme 23: Remove
Scheme 23: Remove

Scheme 24

Scheme 24
Scheme 24
  1. Remove gear selector cover. «76.25.09 COVER - AUTOMATIC TRANSMISSION SELECTOR»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Release gaiter from handbrake lever grip.
  3. Release and remove handbrake lever grip.
  4. Open cubby box lids, carefully release clips and remove finisher.
  5. Remove 6 Torx screws securing finisher to center console, fully apply handbrake.
  6. Release finisher from clips, raise and disconnect 3 Lucar connectors from accessory power socket.
  7. Disconnect multiplug from closing panel lamp assembly.
  8. Remove center console finisher. NOTE: Do not carry out further dismantling if component is removed for access only.
  9. Remove 2 Torx screws securing accessory socket and remove socket.
  10. Remove 4 Torx screws securing cubby box and remove box.
  11. Remove 3 Torx screws securing cup holder and remove cup holder.
  12. Remove handbrake lever gaiter.
  1. Fit cup holder and secure with Torx screws.
  2. Fit cubby box and secure with Torx screws.
  3. Fit accessory socket and secure with Torx screws.
  4. Fit handbrake lever gaiter.
  5. Position center console finisher and connect Lucars.
  6. Connect multiplug to closing panel lamp assembly.
  7. Fit finisher and secure with Torx screws.
  8. Fit handbrake lever grip and secure gaiter.
  9. Fit and secure small cubby box finisher.
  10. Close cubby box lids.
  11. Fit gear selector cover. «76.25.09 COVER - AUTOMATIC TRANSMISSION SELECTOR»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 25

Scheme 25: Remove
Scheme 25: Remove
  1. Carefully release rear console from headlining.
  2. If fitted: Disconnect multiplug from infrared headphone transmitter module.
  3. Disconnect multiplug from interior lamp.
  4. Disconnect multiplug from ultrasonic sensor and remove console assembly. NOTE: Do not carry out further dismantling if component is removed for access only.
  5. Carefully release and remove ultrasonic sensor and module.
  6. Remove lamp from console.
  7. If fitted: Release clips and remove infrared headphone transmitter module.
  1. If fitted: Fit and secure infrared headphone transmitter module.
  2. Fit lamp to console.
  3. Fit module and ultrasonic sensor to console.
  4. Position console assembly and connect multiplugs.
  5. Fit rear console to headlining.

Scheme 26

Scheme 26: Remove
Scheme 26: Remove
  1. Turn ignition key to position II, depress brake pedal and move gear lever to 'D' drive, turn ignition off.
  2. Release clips and gear selector cover from center console.
  3. Carefully disconnect 4 multiplugs from gear selector panel.
  4. Remove gear lever knob and cover by pulling sharply upward.
  5. Release clips securing gear lever gaiter to center console cover, remove knob and gaiter.
  1. Position cover and connect multiplugs, secure cover to center console.
  2. Fit gear lever knob to gear lever.
  3. Fit gaiter to center console and secure with clips.
  4. Turn ignition key to position II, return lever to Park, turn ignition off.

Scheme 27

Scheme 27: Remove
Scheme 27: Remove
  1. Remove screw securing closing panel to fascia.
  2. Release 2 clips securing closing panel and remove from lower fascia. NOTE: Do not carry out further dismantling if component is removed for access only.
  3. Remove 6 screws securing trim finisher to closing panel. Remove finisher.
  4. Remove damper.
  5. Remove 2 trim clips.
  1. Fit trim clips to finisher.
  2. Fit damper.
  3. Fit trim finisher to closing panel and secure with screws.
  4. Fit closing panel and tighten screw, secure to clips.

Scheme 28

Scheme 28: Remove
Scheme 28: Remove
  1. Remove heating control assembly. «80.10.02 CONTROLS -- HEATER (ECU)»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation__801002-controls-heater-ecu)
  2. Carefully release clips securing air suspension switch panel, disconnect multiplug and remove the panel.
  1. Position air suspension switch panel, connect multiplug and secure panel to carrier.
  2. Fit heating control assembly. «80.10.02 CONTROLS -- HEATER (ECU)»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation__801002-controls-heater-ecu)

Scheme 29

Scheme 29: Remove
Scheme 29: Remove

Scheme 30

Scheme 30
Scheme 30
  1. Remove drivers side upper trim finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove passenger side upper trim finisher. «76.46.13 FINISHER - UPPER - PASSENGER'S SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Carefully release clips securing center grille to top rail. Remove grille.
  4. Remove 11 Torx screws securing top rail to fascia, carefully pull top rail rearward and release.
  5. Disconnect speaker multiplug and remove top rail. NOTE: Do not carry out further dismantling if component is removed for access only.
  6. Remove 4 Torx screws securing speaker to top rail and remove speaker.
  7. Remove 4 Torx screws securing instrument pack finisher, remove finisher.
  1. Fit instrument pack finisher to top rail and secure with Torx screws.
  2. Fit speaker and secure with screws.
  3. Position top rail, connect speaker multiplug. Secure rail with Torx screws.
  4. Position and secure center grille.
  5. Fit drivers side upper trim finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  6. Fit passenger side upper finisher. «76.46.13 FINISHER - UPPER - PASSENGER'S SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

76.46.05 Shroud - lower - fascia

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 31

Scheme 31: Remove
Scheme 31: Remove
  1. Remove rotary coupler.
  2. Remove glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove center air vent. «80.15.24 VENTILATOR(S) -- CENTRE»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  4. Remove drivers side upper trim finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  5. Remove drivers side lower trim finisher. «76.46.15 FINISHER - LOWER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  6. Remove 6 Torx screws securing lower fascia shroud.
  7. Carefully release 7 clips securing shroud to carrier assembly. Remove shroud. NOTE: Do not carry out further dismantling if component is removed for access only.
  8. Remove 7 trim fasteners from shroud.
  9. Remove 4 retaining clips from shroud.
  1. Fit clips to shroud.
  2. Fit fasteners to shroud.
  3. Position shroud to carrier, fit and secure with clips and screws.
  4. Fit drivers side lower trim finisher. «76.46.15 FINISHER - LOWER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  5. Fit drivers side upper trim finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  6. Fit center air vent. «80.15.24 VENTILATOR(S) -- CENTRE»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  7. Fit glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Fit rotary coupler.

Scheme 32

Scheme 32: Remove
Scheme 32: Remove
  1. Release sufficient door aperture seal to access closing panel.
  2. Release 3 clips securing end closing panel to fascia and carefully remove panel. NOTE: Do not carry out further dismantling if component is removed for access only.
  3. Remove 3 retaining clips from closing panel.
  1. Fit retaining clips to closing panel.
  2. Position closing panel to fascia, align and secure clips.
  3. Fit seal to door aperture

Scheme 33

Scheme 33: Remove
Scheme 33: Remove
  1. Remove fascia end closing panel. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove face level air vent. «80.15.04 FRESH AIR VENT -- FACE LEVEL»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  3. Remove 'A' post upper trim finisher. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)
  4. Remove 3 Torx screws securing upper finisher to fascia.
  5. Release upper finisher from fascia and disconnect switch multiplug.
  6. Disconnect footwell lamp multiplug.
  7. Remove upper finisher. NOTE: Do not carry out further dismantling if component is removed for access only.
  8. Remove switch assembly from finisher.
  9. Depress clips and remove footwell lamp assembly from finisher.
  1. Fit footwell lamp assembly to finisher.
  2. Fit switch assembly to finisher.
  3. Connect multiplugs.
  4. Fit finisher to fascia and secure with screws.
  5. Fit face level air vents. «80.15.04 FRESH AIR VENT -- FACE LEVEL»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  6. Fit fascia end closing panels. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  7. Fit 'A' post finisher. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)

Scheme 34

Scheme 34: Remove
Scheme 34: Remove
  1. Remove 'A' post upper trim finisher. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)
  2. Remove fascia end closing panel. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove face level air vent. «80.15.04 FRESH AIR VENT -- FACE LEVEL»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  4. Remove 3 Torx screws securing upper finisher to fascia.
  5. Remove screw securing rear of cup holder to inner mounting bracket.
  6. Release finisher from carrier and disconnect footwell lamp assembly multiplug.
  7. Remove upper finisher. NOTE: Do not carry out further dismantling if component is removed for access only.
  8. Depress 3 clips and remove passenger cup holder from finisher.
  9. Depress clips and remove footwell lamp assembly from finisher.
  1. Fit footwell lamp assembly to finisher.
  2. Fit cup holder to finisher and secure clips.
  3. Position finisher and connect lamp multiplug.
  4. Fit finisher to fascia and secure with screws.
  5. Fit and tighten screw securing cup holder to mounting bracket.
  6. Fit face level air vent. «80.15.04 FRESH AIR VENT -- FACE LEVEL»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  7. Fit fascia end closing panel. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Fit 'A' post finisher. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)

Scheme 35

Scheme 35: Remove
Scheme 35: Remove

Scheme 36

Scheme 36
Scheme 36
  1. Remove fascia end closing panel. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove RH lower 'A' post finisher. «76.13.27 TRIM FINISHER - 'A' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove passenger side footwell closing panel. «76.46.27 CLOSING PANEL - PASSENGER SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  4. If fitted: Release and remove venture cam.
  5. Remove cover from lower finisher for access to Torx screw.
  6. Remove 3 Torx screws securing upper finisher to fascia.
  7. If fitted: Disconnect venture Cam multiplug and cable.
  8. Remove finisher.
  9. Remove clips from finisher.
  1. Fit clips to finisher.
  2. If fitted: Connect venture cam multiplug and cable.
  3. Fit finisher to fascia and secure with screws.
  4. Fit blanking plug to finisher.
  5. If fitted: Fit and secure venture cam.
  6. Fit passenger side footwell closing panel. «76.46.27 CLOSING PANEL - PASSENGER SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  7. Fit lower 'A' post finisher. «76.13.27 TRIM FINISHER - 'A' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Fit fascia end closing panel. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 37

Scheme 37: Remove
Scheme 37: Remove
  1. Remove fascia end closing panel. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove closing panel. «76.46.27 CLOSING PANEL - PASSENGER SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove LH lower 'A' post finisher. «76.13.24 FOOT REST FINISHER - LHD»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  4. Remove cover from lower finisher for access to Torx screw.
  5. Remove 3 Torx screws securing upper finisher to fascia.
  6. Disconnect on board diagnostics port multiplug, if fitted
  7. Remove finisher.
  8. Remove clips from finisher.
  1. Fit clips to finisher.
  2. Connect on board diagnostics port multiplug.
  3. Fit finisher to fascia and secure with screws.
  4. Fit blanking plug to finisher.
  5. Fit LH lower 'A' post finisher. «76.13.24 FOOT REST FINISHER - LHD»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  6. Fit closing panel. «76.46.27 CLOSING PANEL - PASSENGER SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  7. Fit fascia end closing panel. «76.46.11 CLOSING PANEL - FASCIA END»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

76.46.22 Fascia - carrier

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Note. Ensure the harness routing is noted when removing the carrier. This will help to ensure that the harness is correctly fitted/routed when refitting the carrier.

Scheme 38

Scheme 38: Remove
Scheme 38: Remove

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Make the SRS system safe. «SUPPLEMENTARY RESTRAINT SYSTEM (SRS) PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/oem-general-information/#general-information__supplementary-restraint-system-srs-precautions)
  2. Remove center console. «76.25.01 CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove passenger airbag. «PASSENGER-SIDE AIR BAG MODULE»(ref-170462-S27106631002005011000000)
  4. Remove air suspension control panel. «76.25.41 SWITCH PANEL - AIR SUSPENSION»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  5. Remove footwell closing panels. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  6. Remove cassette/CD unit. «AUDIO SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/entertainment-systems/#audio-system)
  7. Remove instrument pack. «88.20.01.99 INSTRUMENT PACK»(/land-rover/range-rover/l322-2002-2005/remont/gauges-instrument-panels/#instruments-removal-installation)
  8. Release and remove instrument pack lower finisher.
  9. Release and remove steering column extension gaiter.
  10. Release 4 clips securing instrument pack harness to carrier.
  11. Release clip securing cassette/CD unit harness.
  12. Disconnect solar sensor multiplug.
  13. Release clip securing harness to drivers side footwell duct.
  14. Identify position of harness for reassembly.
  15. Note position for refit and remove foam strip from ends of carrier.
  16. Remove 10 Torx screws securing fascia carrier and remove carrier. NOTE: Do not carry out further dismantling if component is removed for access only.
  17. Remove 3 Torx screws securing drivers side footwell duct and remove duct.
  18. Remove 3 Torx screws securing LH demister duct and remove duct.
  19. Remove 3 Torx screws securing RH demister duct and remove duct.
  20. Remove 3 Torx screws securing drivers side face level vent duct and remove duct.
  21. Remove 2 remaining Torx screws securing passenger side face level vent duct and remove duct.
  22. Release and remove solar sensor.
  23. Remove 6 Torx screws securing heater control mounting and remove mounting.
  24. Remove 3 Torx screws securing drink holder bracket and remove bracket.
  25. Remove 4 instrument lower finisher securing sacks.
  26. Remove 6 passenger airbag cover plastic retaining nuts.
  27. Remove 2 side finisher retaining sacks.
  28. Remove 64 speed nuts from fascia carrier.
  1. Fit speed nuts to fascia carrier.
  2. Fit side finisher retaining sacks.
  3. Fit airbag cover retaining nuts.
  4. Fit instrument finisher retaining sacks.
  5. Fit drinks holder bracket and secure with screws.
  6. Fit heater control mounting and secure with screws.
  7. Fit Solar Sensor.
  8. Fit face level vent ducts and secure with screws.
  9. Fit demister ducts and secure with screws.
  10. Fit footwell duct and secure with screws.
  11. With assistance, fit fascia carrier. Ensure harness is routed correctly and carrier has engaged with locations on bulkhead.
  12. Fit and tighten screws securing fascia carrier.
  13. Fit foam strips to carrier.
  14. Fit clip securing harness to footwell duct.
  15. Fit clip securing cassette/CD harness.
  16. Connect solar sensor multiplug.
  17. Fit clip securing instrument pack harness.
  18. Fit and secure steering column gaiter.
  19. Fit instrument pack lower finisher.
  20. Fit instrument pack. «88.20.01.99 INSTRUMENT PACK»(/land-rover/range-rover/l322-2002-2005/remont/gauges-instrument-panels/#instruments-removal-installation)
  21. Fit cassette/CD unit. «AUDIO SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/entertainment-systems/#audio-system)
  22. Fit footwell closing panels. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  23. Fit air suspension control panel. «76.25.41 SWITCH PANEL - AIR SUSPENSION»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  24. Fit passenger airbag. «PASSENGER-SIDE AIR BAG MODULE»(ref-170462-S27106631002005011000000)
  25. Fit center console. «76.25.01 CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

76.46.23.99 Fascia - remove for access & refit

This procedure shows how to position the fascia aside for access. The fascia is released from the passenger side and swung aside for access, with the main harness still attached to the fascia.

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 52

Scheme 52: Remove
Scheme 52: Remove

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81
  1. Make the SRS system safe. «SUPPLEMENTARY RESTRAINT SYSTEM (SRS) PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/oem-general-information/#general-information__supplementary-restraint-system-srs-precautions)
  2. Drain coolant. «DRAINING & REFILLING COOLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/cooling-system-mechanical/#cooling-system)
  3. Recover refrigerant from A/C system. «AIR CONDITIONING - RECOVERY, REMOVAL & INSTALLATION»(/land-rover/range-rover/l322-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  4. Remove air intake plenum. «80.15.62 PLENUM -- AIR INTAKE»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  5. Remove front seats. «FRONT SEAT»(/land-rover/range-rover/l322-2002-2005/remont/seats/#seats)
  6. Remove heater control panel. «80.10.02 CONTROLS -- HEATER (ECU)»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation__801002-controls-heater-ecu)
  7. Remove air suspension control panel. «76.25.41 SWITCH PANEL - AIR SUSPENSION»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Remove handbrake lever assembly.
  9. Remove footwell closing panels. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  10. Release and remove air ducts from HEVAC assembly.
  11. LHD only: Remove drivers footrest. «76.13.24 FOOT REST FINISHER - LHD»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  12. Remove 'A' post lower finisher. «76.13.27 TRIM FINISHER - 'A' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  13. Remove 'A' post upper finishers. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)
  14. Remove drivers side fascia finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  15. Remove passenger side fascia finisher. «76.46.13 FINISHER - UPPER - PASSENGER'S SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  16. Remove gearshift selector assembly. «GEARSHIFT SELECTOR ASSEMBLY LEVER»(/land-rover/range-rover/l322-2002-2005/remont/automatic-trans/#removal-installation-automatic-transmission-zf5hp24)
  17. Remove 4 nuts securing selector carrier to body and remove.
  18. Cover studs to prevent damage to fascia on removal.
  19. Remove 4 bolts securing handbrake mounting bracket to body and remove bracket.
  20. Remove 4 bolts securing center console support bracket to body and remove bracket.
  21. Noting fitted position, remove Torx bolt from clamp securing steering column lower shaft to intermediate shaft.
  22. Remove 2 nuts securing steering support bearing to body, release bearing and disconnect shaft.
  23. Noting fitted position, remove nut and disconnect arm from wiper motor.
  24. Remove 3 bolts securing wiper motor to mounting bracket, collect motor and move aside for access.
  25. Remove 2 bolts securing fascia to bulkhead.
  26. Remove 2 Allen bolts securing A/C pipes to bulkhead, disconnect pipes and discard 'O' rings. CAUTION: Immediately cap all A/C pipes to prevent ingress of dirt and moisture into the system.
  27. Position container to collect coolant.
  28. Release clips and disconnect coolant hoses from heater matrix at bulkhead.
  29. Remove 3 nuts securing heater assembly to bulkhead.
  30. Remove 4 nuts and 2 bolts securing fascia assembly to body.
  31. Cover fascia lower brackets to protect carpet from damage.
  32. Disconnect 2 multiplugs and release harness clip from 'A' post, adjacent to top rail. Repeat on opposite side. Tape disconnected leads to windscreen.
  33. Withdraw fascia sufficiently to disconnect 'A' post airbag multiplugs.
  34. Passenger side only: Release 2 additional 'A' post harness clips.
  35. Remove transfer box ECU. «TRANSFER CASE»(/land-rover/range-rover/l322-2002-2005/remont/transfer-case/#transfer-case)
  36. Disconnect positive feed from bulkhead fuse box.
  37. Disconnect relay and multiplug from bulkhead fuse box.
  38. Release harness from bulkhead and position aside.
  39. Disconnect 2 multiplugs from fuel burning heater, if fitted.
  40. Disconnect harness from side repeater lamp, release harness grommet from inner wing and withdraw harness.
  41. Remove both front wheel arch liners. «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)
  42. Release harness from clips on inner wing.
  43. Remove 10 Allen screws securing 'E' box cover and remove cover.
  44. Remove 2 bolts securing 'E' box to suspension turret, move aside for access.
  45. Release air intake duct from inner wing and remove.
  46. Remove nuts and disconnect harness earth headers.
  47. Remove front bumper. «76.22.72 BUMPER -- ASSEMBLY -FRONT»(ref-208059-S28552961812005120200000)
  48. Disconnect hose from rear washer pump.
  49. Release 4 cable ties securing washer hose to armature and move hose aside.
  50. Disconnect horn multiplugs.
  51. Remove indicator lamp. «86.40.29 LAMP ASSEMBLY -- SIDE & INDICATOR»(/land-rover/range-rover/l322-2002-2005/remont/exterior-lights/#lighting-removal-installation__864029-lamp-assembly-side)
  52. Disconnect headlamp multiplug.
  53. Note fitted position of ride height sensor cable ties, remove cable ties and disconnect multiplug.
  54. Disconnect multiplugs from radiator pack.
  55. Disconnect multiplug from ABS sensor.
  56. Disconnect multiplug from A/C switch.
  57. Disconnect multiplug from A/C compressor.
  58. Disconnect multiplug from PAS rack pinion sensor.
  59. Remove screw securing light check control module to 'A' post.
  60. Move light check module aside.
  61. Remove bolt securing door harness connector block to 'A' post and disconnect multiplug.
  62. Remove nut securing earth header to 'A' post and release header.
  63. Raise carpet and remove 3 scrivets securing harness closing panel to body, release and remove panel.
  64. Release clips securing harness connector block to BCU carrier.
  65. Remove 2 nuts and move BCU carrier aside.
  66. Release main harness from channel and reposition carpet.
  67. With assistance, withdraw harness through bulkhead and rotate fascia assembly for access. CAUTION: Ensure evaporator drain tubes are not damaged when moving fascia.
  68. Support fascia on suitably protected axle stands avoiding damage to carpet and trim.
  1. With assistance position harness and fascia assembly to bulkhead.
  2. Connect airbag and 'A' post multiplugs.
  3. Raise carpet, position main harness, fit and secure closing panel with scrivets.
  4. Fit carpet.
  5. Fit and secure BCU carrier.
  6. Fit and secure 'A' post earth header.
  7. Connect door harness multiplug and secure with bolt.
  8. Fit and secure light check module.
  9. Position harness, connect multiplugs to radiator pack, A/C pressure switch, A/C compressor, ABS and ride height sensor. Ensure the ride height sensor harness and cable ties are correctly fitted.
  10. Connect multiplug to PAS rack pinion sensor.
  11. Connect horn and headlamp multiplugs.
  12. Fit side and flasher lamp assembly. «86.40.29 LAMP ASSEMBLY -- SIDE & INDICATOR»(/land-rover/range-rover/l322-2002-2005/remont/exterior-lights/#lighting-removal-installation__864029-lamp-assembly-side)
  13. Connect rear screen washer tube.
  14. Fit rear screen washer hose to armature and secure with cable ties.
  15. Fit front bumper. «76.22.72 BUMPER -- ASSEMBLY -FRONT»(ref-208059-S28552961812005120200000)
  16. Fit 'E' box to mounting bracket and tighten bolts to 3 Nm (2.2 lbf.ft).
  17. Fit 'E' box cover and tighten Allen screws to 2 Nm (1.5 lbf.ft).
  18. Secure harness to inner wing.
  19. Fit and secure both front wheel arch liners. «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)
  20. Position harness, fit and secure side repeater lamp.
  21. Position harness, fit and secure FBH multiplugs.
  22. Connect relay to bulkhead fuse box mounting.
  23. Connect positive feed to bulkhead fuse box.
  24. Fit transfer box ECU. «TRANSFER CASE»(/land-rover/range-rover/l322-2002-2005/remont/transfer-case/#transfer-case)
  25. Secure fascia to bulkhead, fit nuts and bolts, tighten to 25 Nm (18 lbf.ft).
  26. Secure 'A' post harness with clips.
  27. Fit nuts securing HEVAC to bulkhead, tighten to 10 Nm (7 lbf.ft).
  28. Fit coolant hoses and secure with clips.
  29. Lubricate new 'O' rings with clean refrigerant oil and fit to pipe/hose assembly.
  30. Connect A/C pipes to bulkhead, fit bolts and tighten to 25 Nm (18 lbf.ft).
  31. Fit bolts securing fascia to bulkhead and tighten to 25 Nm (18 lbf.ft).
  32. Position wiper motor to bracket, fit bolts and tighten to 10 Nm (7 lbf.ft)
  33. Position wiper linkage to motor, fit nut and tighten to 25 Nm (18 lbf.ft)
  34. Connect steering column assembly, fit nuts to support bearing and tighten to 25 Nm (18 lbf.ft).
  35. Fit Torx bolt to steering clamp and tighten to 25 Nm (18 lbf.ft).
  36. Fit center console support bracket and tighten bolts to 10 Nm (7 lbf.ft).
  37. Fit handbrake mounting bracket to body, fit bolts and tighten to 25 Nm (18 lbf.ft).
  38. Fit selector carrier and tighten nuts to 25 Nm (18 lbf.ft).
  39. Fit gearshift selector assembly. «GEARSHIFT SELECTOR ASSEMBLY LEVER»(/land-rover/range-rover/l322-2002-2005/remont/automatic-trans/#removal-installation-automatic-transmission-zf5hp24)
  40. Fit passenger side upper finisher. «76.46.13 FINISHER - UPPER - PASSENGER'S SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  41. Fit drivers side upper trim finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  42. Fit 'A' post upper finishers. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)
  43. Fit lower 'A' post finisher. «76.13.27 TRIM FINISHER - 'A' POST - LOWER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  44. Fit drivers footrest. «76.13.24 FOOT REST FINISHER - LHD»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  45. Fit and secure ducts to heater assembly.
  46. Fit center console closing panel. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  47. Fit handbrake lever assembly.
  48. Fit air suspension switch panel. «76.25.41 SWITCH PANEL - AIR SUSPENSION»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  49. Fit heater control panel. «80.10.02 CONTROLS -- HEATER (ECU)»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation__801002-controls-heater-ecu)
  50. Fit front seats. «FRONT SEAT»(/land-rover/range-rover/l322-2002-2005/remont/seats/#seats)
  51. Fit air intake plenum. «80.15.62 PLENUM -- AIR INTAKE»(/land-rover/range-rover/l322-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  52. Recharge A/C system. «AIR CONDITIONING - RECOVERY, REMOVAL & INSTALLATION»(/land-rover/range-rover/l322-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  53. Refill cooling system. «DRAINING & REFILLING COOLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/cooling-system-mechanical/#cooling-system)
  54. Connect battery earth lead.

Scheme 82

Scheme 82: Remove
Scheme 82: Remove
  1. Remove closing panel from passenger side of the center console. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove 4 screws securing closing panel.
  3. Disconnect multiplug from closing panel lamp assembly.
  4. Remove passenger side footwell closing panel.
  5. Release lamp assembly from closing panel.
  1. Fit lamp assembly to closing panel.
  2. Connect multiplug to closing panel lamp assembly.
  3. Fit closing panel and secure with screws.
  4. Fit center console closing panel. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 83

Scheme 83: Remove
Scheme 83: Remove

Scheme 84

Scheme 84
Scheme 84
  1. Remove closing panel from drivers side of the center console. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove 4 screws and 1 trim stud securing closing panel.
  3. Release closing panel, disconnect multiplugs from sounder and footwell lamp assembly, remove panel.
  4. Remove sounder, lamp and speed nut from panel.
  1. Fit sounder, lamp and speed nut to panel.
  2. Position panel, connect multiplugs, locate and secure with screws and stud.
  3. Fit center console closing panel. «76.25.31 CLOSING PANEL - CENTRE CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

76.49.08 Carpet - front

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 85

Scheme 85: Remove
Scheme 85: Remove
  1. Remove fascia «76.46.23.99 FASCIA - REMOVE FOR ACCESS & REFIT»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__76462399-fascia-remove-for-access)
  2. Remove throttle pedal assembly.
  3. Remove 4 bolts securing center fascia support brackets. Remove brackets.
  4. Withdraw throttle pedal harness through carpet.
  5. With assistance, support fascia and remove carpet.
  1. Fit carpet.
  2. Feed throttle pedal harness through carpet.
  3. Position center fascia support brackets, fit bolts and tighten to 25 Nm (18 lbf.ft).
  4. Fit throttle pedal assembly.
  5. Fit fascia. «76.46.23.99 FASCIA - REMOVE FOR ACCESS & REFIT»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__76462399-fascia-remove-for-access)

76.49.17 Retainer - front carpet

This procedure is also applicable to the rear carpet retainer.

Scheme 86

Scheme 86: Remove
Scheme 86: Remove
  1. Using a trim removal tool, release 7 clips securing treadplate carpet retainer to sill.
  2. Remove treadplate. NOTE: Do not carry out further dismantling if component is removed for access only.
  3. Remove 4 clips from treadplate.
  1. Fit clips to treadplate.
  2. Position and secure treadplate to sill.

Scheme 87

Scheme 87: Remove
Scheme 87: Remove

Scheme 88

Scheme 88
Scheme 88
  1. Remove lower tailgate finisher. «76.43.99 FINISHER -- TAILGATE -- LOWER»(ref-208059-S02822206862005120200000)
  2. Carefully release 7 clips securing tailgate finisher to body. Remove finisher. NOTE: Do not carry out further dismantling if component is removed for access only.
  3. Remove 7 clips from tailgate finisher.
  4. Remove 7 clips securing acoustic pad to finisher, remove pad.
  1. Fit acoustic pad and secure with clips.
  2. Fit trim clips to finisher.
  3. Align finisher to tailgate and secure clips.
  4. Fit tailgate finisher. «76.43.99 FINISHER -- TAILGATE -- LOWER»(ref-208059-S02822206862005120200000)

Scheme 89

Scheme 89: Remove
Scheme 89: Remove

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92
  1. Remove upper finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove lower finisher. «76.46.14 FINISHER - LOWER - PASSENGERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  3. Remove 2 Torx screws securing glove box from underside of fascia.
  4. Open glove box.
  5. Remove 5 Torx screws securing glove box.
  6. Disconnect multiplug from lamp.
  7. Release cable from glove box latch.
  8. If fitted: Remove 2 Torx screws securing CD multi-changer to glove box.
  9. If fitted: Withdraw CD multi-changer from glove box and disconnect link lead and both multiplugs. Remove the CD multi-changer.
  10. Remove glove box assembly. NOTE: Do not carry out further dismantling if component is removed for access only.
  11. Remove fuse puller.
  12. Remove clips from glove box.
  13. Remove fuse box cover.
  14. Remove lamp.
  15. Remove 2 Torx screws securing latch to glove box.
  16. Remove latch fixing plate and release latch from glove box.
  1. Position latch and fixing plate to glove box, secure with screws.
  2. Fit lamp assembly to glove box.
  3. Fit fuse box cover.
  4. Fit clips to glove box.
  5. Fit fuse puller.
  6. Position glove box to fascia.
  7. If fitted: Position CD multi-changer to glove box, connect link lead and multiplugs.
  8. If fitted: Fit CD multi-changer to glove box and secure with Torx screws.
  9. Connect cable to glove box latch.
  10. Connect multiplug to lamp assembly.
  11. Secure glove box with screws.
  12. Close glove box.
  13. Fit lower trim finisher. «76.46.14 FINISHER - LOWER - PASSENGERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  14. Fit upper finisher. «76.46.12 FINISHER - UPPER - DRIVERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 93

Scheme 93: Remove
Scheme 93: Remove
  1. Remove glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  2. Remove 2 Torx screws securing latch to glove box.
  3. Remove latch fixing plate and release latch from glove box.
  1. Position latch and fixing plate to glove box, secure with screws.
  2. Fit glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 94

Scheme 94: Remove
Scheme 94: Remove
  1. Release covers from grab handle retaining screws.
  2. Remove 2 screws securing grab handle and remove handle.
  3. Remove grab handle support plate.
  1. Fit grab handle support plate.
  2. Fit grab handle and secure with screws.
  3. Fit screw covers.

76.64.15 Headlining

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 95

Scheme 95: Remove
Scheme 95: Remove

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97
  1. Models fitted with sunshine roof: Open sunshine roof.
  2. Make the SRS system safe. «SUPPLEMENTARY RESTRAINT SYSTEM (SRS) PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/oem-general-information/#general-information__supplementary-restraint-system-srs-precautions)
  3. Remove RH rear seat. «REAR SEATS»(/land-rover/range-rover/l322-2002-2005/remont/seats/#seats)
  4. Remove 'A' post upper finishers. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)
  5. Remove 'B' post upper finishers. «76.13.28 TRIM FINISHER - 'B' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761328-trim-finisher-b-post)
  6. Remove 'D' post upper finishers. «76.13.30 TRIM FINISHER - 'D' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  7. Remove 'E' post finishers. «76.13.32 TRIM FINISHER - 'E' POST»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Models fitted with sunshine roof: Remove 15 Torx screws securing headlining to sun roof and remove clamp plate.
  9. Remove sun visors. «>76.10.47 SUN VISOR»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  10. Remove front console from headlining. «76.25.02 CONSOLE - HEADLINING - FRONT»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  11. Remove rear console from headlining. «76.25.02 CONSOLE - HEADLINING - FRONT»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  12. Remove grab handles. «76.58.30 HANDLE - GRAB»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  13. Open flap, remove 4 screws securing cargo net upper anchor finishers and remove finishers.
  14. Remove seals from door aperture flanges to release headlining.
  15. Remove 2 screws securing headlining.
  16. Models fitted with sunshine roof: Remove 4 screws securing headlining.
  17. Carefully release 3 clips securing rear edge of headlining.
  18. With assistance, carefully lower and remove headlining from rear of vehicle.
  1. Fit headlining and secure with screws.
  2. Secure clips at headlining rear edge.
  3. Fit luggage net anchor finishers and secure with screws.
  4. Fit aperture seals.
  5. Fit grab handles. «76.58.30 HANDLE - GRAB»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  6. Fit rear console. «76.25.02 CONSOLE - HEADLINING - FRONT»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  7. Fit front console. «76.25.02 CONSOLE - HEADLINING - FRONT»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Fit sun visors. «76.10.47 SUN VISOR»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  9. Models fitted with sunshine roof: Fit and align clamping plate and tighten screws securing headlining to sunshine roof to 2.5 Nm (1.9 lbf.ft).
  10. Fit 'E' post finishers. «76.13.32 TRIM FINISHER - 'E' POST»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  11. Fit 'D' post upper finishers. «76.13.30 TRIM FINISHER - 'D' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  12. Fit 'B' post upper finishers. «76.13.28 TRIM FINISHER - 'B' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761328-trim-finisher-b-post)
  13. Fit 'A' post upper finishers. «76.13.26 TRIM FINISHER - 'A' POST - UPPER»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings__761326-trim-finisher-a-post)
  14. Fit rear seat. «REAR SEATS»(/land-rover/range-rover/l322-2002-2005/remont/seats/#seats)
  15. Models fitted with sunshine roof: Close sunshine roof.
  16. Connect battery earth lead.

More articles — Body & Frame
