Driving Aids - Removal & Installation Land Rover Range Rover L322

Scheme 1

1. Using a jack, raise vehicle and support with stands. WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.
2. Remove 5 nuts securing road wheel, remove wheel. CAUTION: Never use high pressure cleaning equipment on a wheel with a TPM sensor fitted.
3. Remove tire from rim. CAUTION: To avoid damage to TPM sensor, break tire bead from rim 180 degrees from valve stem.
4. Remove valve from wheel and collect washer.
5. Carefully remove TPM sensor from rim. CAUTION: If a tire sealing fluid has been used the TPM sensor must be replaced. CAUTION: If sensor has been removed, the complete valve must be replaced.

Scheme 2

1. Clean TPM sensor filter surface (on underside of sensor). CAUTION: If the TPM sensor filter is dirty the sensor must be replaced. CAUTION: Do not use compressed air to clean TPM sensors. Do not clean sensors with solvents or any cleaning agent of any source, use a clean dry cloth only.
2. Fit Torx bolt and adapter to TPM sensor, finger tighten bolt.
3. Carefully fit TPM sensor to rim, fit washer and valve, tighten valve to 3.5 Nm (2.6 lbf.ft). CAUTION: Do not exceed these torque figures as damage to sensor will occur if overtightened.
4. Insert brace supplied with valve into adapter.
5. Ensure sensor is pushed fully home to the rim and tighten Torx bolt to 3.5 Nm (2.6 lbf.ft). CAUTION: Do not exceed these torque figures as damage to sensor will occur if overtightened.
6. Remove brace from adapter.
7. Fit tire and balance wheel.
8. Fit road wheel and tighten nuts to 140 Nm (103 lbf.ft).
9. Remove stands and lower jack.
10. An initialization process must be carried out after the following: A tire pressure has been adjusted A TPM sensor has been replaced A wheel has changed position, e.g. swapped axles or the spare fitted as a road wheel
11. To initialize the TPM system, turn ignition key to position 'II', depress and hold TPM button, until SET TIRE PRESSURE message appears on the instrument pack message center (approximately 4 seconds). The system is now initialized. NOTE: Some vehicles may display a re-arranged message TIRE PRESSURE SET, this also acknowledges that the system is initialized.

Scheme 3

1. Remove front wheel arch liner. See «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)
2. Disconnect multiplug and release antenna from securing bracket.

Refit

1. Fit antenna in securing bracket and connect multiplug.
2. Fit wheel arch liner. See «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)

Scheme 4

1. Using jack Raise vehicle and support with stands. WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.
2. Remove 5 nuts securing road wheel, remove wheel.
3. Remove 2 bolts securing antenna, disconnect multiplug and remove antenna.

1. Position and fit bolts to secure antenna.
2. Connect multiplug to antenna.
3. Fit road wheel and tighten nuts to 140 Nm (103 lbf.ft).
4. Remove stands and lower jack.

86.54.05 Electronic control unit (ECU)-tire pressure monitoring (TPM)

If the ECU is to be replaced then Testbook/T4 must be connected and correct procedures adhered to, prior to battery disconnection.

Scheme 5

1. Remove the Body Control Unit (BCU). See «86.55.75 BODY CONTROL UNIT (BCU)»(/land-rover/range-rover/l322-2002-2005/remont/accessories-control-systems/#control-units-and-relays__865575-body-control-unit-bcu)
2. Release tire pressure monitoring ECU from holder, disconnect multiplug and remove ECU.

1. Position ECU, connect multiplug and fit ECU to holder.
2. Fit BCU. See «86.55.75 BODY CONTROL UNIT (BCU)»(/land-rover/range-rover/l322-2002-2005/remont/accessories-control-systems/#control-units-and-relays__865575-body-control-unit-bcu)
3. Configure new ECU using testbook\T4.

86.54.10 Electronic control unit (ECU)-parking aid

If the ECU is to be replaced then Testbook/T4 must be connected and correct procedures adhered to, prior to battery disconnection.

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed. Refer to ELECTRICAL PRECAUTIONS

Scheme 6

Scheme 7

1. Disconnect battery earth lead.
2. Remove access panel from load space RH trim casing.
3. Remove warning triangle.
4. Remove cable tie securing harness.
5. Release 2 straps securing harness.
6. Remove 3 bolts securing fuse box to body.
7. Disconnect 3 multiplugs from parking aid ECU.
8. Remove 2 nuts securing parking aid ECU and remove ECU.

1. Fit parking aid ECU and secure with nuts.
2. Connect multiplugs to parking aid ECU.
3. Align fuse box and tighten bolts to 6 Nm (4.4 lbf.ft).
4. Align and secure harness.
5. Fit and secure warning triangle.
6. Fit access panel.
7. Connect battery earth lead.
8. Configure new ECU using testbook\T4.

Scheme 8

1. Release park distance control sensor from rear bumper and disconnect multiplug. Remove sensor assembly.
2. Remove and collect finisher from the rear parking distance sensor.

1. Fit finisher to rear parking distance sensor.
2. Position rear parking sensor to the rear bumper and connect multiplug.
3. fit and secure rear parking distance sensor to bumper.

Scheme 9

Scheme 10

1. Remove center console closing panel. See «76.25.31 CLOSING PANEL -- CENTER CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
2. Remove 4 screws and 1 trim stud securing closing panel.
3. Release closing panel and disconnect multiplugs from sounder.
4. Remove sounder.

1. Fit sounder.
2. Position panel, connect multiplugs, locate and secure with screws and stud.
3. Fit center console closing panel. See «76.25.31 CLOSING PANEL -- CENTER CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

Scheme 11

1. Remove access panel from load space RH trim casing.
2. Disconnect multiplug from instrument pack sounder.
3. Remove nut securing sounder and remove sounder.

1. Fit sounder and tighten nut to 10 Nm (7 lbf.ft).
2. Connect multiplug to instrument pack sounder.
3. Fit access panel

Scheme 12

1. Remove front bumper. See «76.22.72 BUMPER -- ASSEMBLY -FRONT»(ref-208059-S28552961812005120200000)
2. Remove parking sensor from bumper, release clips and remove sensor from finisher.

1. Fit sensor to finisher, align sensor to bumper and secure clips.
2. Fit front bumper. See «76.22.72 BUMPER -- ASSEMBLY-FRONT»(ref-208059-S28552961812005120200000)

Scheme 13

Scheme 14

1. Remove screw securing bumper extension to wheel arch liner.
2. Ease lower edge of wheel arch liner aside for access, from rear of bumper release parking sensor.
3. Disconnect multiplug.
4. Release clips and remove finisher from sensor.

1. Fit sensor to finisher, connect harness multiplug.
2. Fit sensor to bumper and secure clips.
3. fit wheel arc liner and with secure with screw.

Scheme 15

Scheme 16

1. Remove upper tailgate spoiler. See «76.10.91 SPOILER -- TAILGATE»(ref-208059-S26385576422005120200000)
2. Remove screw and release 2 clips securing rear view camera to spoiler. Remove camera.
3. Drill out pop rivet, release adhesive pads and remove camera bracket.

1. Fit camera bracket and secure with pop rivet and adhesive pads.
2. Fit camera and secure with clips and screw.
3. Fit upper tailgate spoiler. See «76.10.91 SPOILER -- TAILGATE»(ref-208059-S26385576422005120200000)

Scheme 17

1. Remove lower finisher from passenger side of fascia. See «76.46.14 FINISHER -- LOWER - PASSENGERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
2. Remove 6 Torx screws securing venture cam charger to finisher. Remove charger.

1. Fit venture cam charger to finisher and secure with Torx screws.
2. Fit lower finisher to passenger side of fascia. See «76.46.14 FINISHER -- LOWER - PASSENGERS SIDE»(/land-rover/range-rover/l322-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
