Air Bag Restraint Systems Land Rover Range Rover L322

Airbag 23 illustrations ~5290 words

DESCRIPTION & OPERATION

WARNINGAccidental air bag deployment is possible. Personal injury may result. Read and follow all WARNINGS and AIR BAG SAFETY PRECAUTIONS before working on air bag system or related components.

The Supplemental Restraint System (SRS), also known as air bag system, is designed to provide increased accident protection for driver and passenger by deploying air bags and seat belt pretensioners in a collision. The air bags deploy in about 40 milliseconds after impact sensors close. The air bag system is designed to work with the 3-point seat belt system. Seat belt pretensioners deploy in conjunction with air bags.

The main components of air bag system are driver-side and passenger-side air bag modules, side air bag modules, front and rear head air bag modules, rotary coupler (clockspring), Diagnostic Control Unit (DCU), AIR BAG warning light (SRS warning light), seat belt pretensioners and buckle switches, side impact sensors, battery disconnection unit and associated wiring harness. See COMPONENT LOCATIONS .

COMPONENT LOCATIONS

Refer to illustration for component locations. (Scheme 1)& (Scheme 2).

Scheme 1

Scheme 1: COMPONENT LOCATIONS
Scheme 1: COMPONENT LOCATIONS

Scheme 2

Scheme 2
Scheme 2

SERVICING

All components of the air bag system must be replaced every 15 years.

SYSTEM OPERATION CHECK

Turn ignition switch to ON position. AIR BAG warning light should illuminate for approximately 5 seconds while air bag Diagnostic Control Unit (DCU) performs self-diagnosis. AIR BAG warning light will then go off if air bag system is functioning properly. If self-diagnosis by DCU reveals that a fault exists, AIR BAG warning light will go off for one second and then turn back on. Air bag system may not operate in the event of a crash if AIR BAG warning light is on. AIR BAG warning light will also come on if low voltage condition is present, but will go off when voltage condition is corrected.

AIR BAG SAFETY PRECAUTIONS

The following precautions should be observed when working with air bag systems

  1. Disable air bag system before servicing any air bag system, steering column, seat assembly, interior trim, electrical or seat belt pretensioner components. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. When placing a live air bag on a bench or other surface, ensure trim cover is facing up, away from surface. If air bag is stored face down, accidental deployment will propel module through air with force sufficient to cause serious injury.
  3. DO NOT expose air bag system components to temperatures in excess of 185°F (85°C).
  4. Air bag system faults can only be diagnosed using Land Rover Test Book tester. DO NOT use electrical test equipment while attempting to service air bag system. Disconnecting or probing air bag system connectors could result in accidental deployment or system damage.
  5. If air bag module or other components have been dropped, or there are cracks, dents or other defects visible, replace with NEW parts.
  6. DO NOT attempt to measure resistance across air bag module squib connector. Accidental air bag deployment is possible which could cause personal injury.
  7. After deployment, air bag surface may contain deposits of sodium azide, a toxic substance. Always wear safety glasses, rubber gloves and long-sleeved shirt during clean-up. Wash hands using mild soap and water.
  8. Never allow sodium azide to mix with water, acids or heavy metals. Harmful or explosive compounds can be produced.
  9. Never attempt to incinerate or dismantle air bag or seat belt pretensioner. After deployment, components will be very hot. Allow at least 30 minutes for cooling before handling air bag modules or pretensioners.
  10. When carrying a live air bag module, make sure to face trim cover away from your body. In event of accidental deployment, this will reduce the risk of serious injury.
  11. Never install used air bag system components from another vehicle. Always use NEW parts.
  12. Always disable air bag system before performing any electrical welding or heat drying paint on vehicle.
  13. Always use NEW bolts (special Torx bolts for air bag modules) when installing any air bag system component. Ensure bolts are always tightened to correct torque.
  14. Never install electrical or electronic equipment into air bag system electrical system. Air bag harness has a Yellow outer covering.
  15. After work is complete on air bag system, ensure system is functioning properly. See «SYSTEM OPERATION CHECK»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__system-operation-check) .

DISABLING SYSTEM

WARNINGAccidental air bag module deployment is possible. Personal injury may result. Never use radio key code (memory) savers when working on air bag system.

Remove key from ignition switch. Wait at least 2 minutes (to protect navigation system). Disconnect negative then positive battery cable. Wait at least 10 minutes before working on vehicle.

ACTIVATING SYSTEM

Ensure ignition switch is off and key is removed. Reconnect positive battery cable. Reconnect negative battery cable. Perform SYSTEM OPERATION CHECK . Start engine and turn steering wheel lock-to-lock. This allows the Dynamic Stability Control (DSC) system to relearn steering wheel position. Not following this procedure may result in a variety of warning lights being illuminated.

DISPOSAL PROCEDURES

Disposal of undeployed components may be a violation of federal, state, and local laws. If a vehicle is to be removed from service (scrapped), air bag system components should be deployed while installed in vehicle. See ON-VEHICLE DEPLOYMENT (SCRAPPED VEHICLES ONLY) . If this is impossible or if vehicle is being placed back into service, remove components and deploy outside vehicle. See OFF-VEHICLE DEPLOYMENT .

ON-VEHICLE DEPLOYMENT (SCRAPPED VEHICLES ONLY)

WARNINGAir bag modules and seat belt pretensioners are very hot after deployment. Personal injury may result. Allow components to cool for at least 30 minutes before handling.

Battery Disconnection Unit

  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. Disconnect battery disconnection unit harness connector. Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/03) to battery disconnection unit connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from vehicle and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy battery disconnection unit. Wait at least 30 minutes before disconnecting deployment tool or handling deployed battery disconnection unit. DO NOT re-use or salvage any parts from the air bag system.

Driver-side AIR Bag

On-vehicle deployment procedures are not available.

Front Head AIR Bag Module

  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove instrument panel reinforcement. See «INSTRUMENT PANEL REINFORCEMENT»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Ensure front head air bag module is securely mounted. Disconnect front head air bag module harness connector. (Scheme 3) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from vehicle and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. DO NOT re-use or salvage any parts from the air bag system.

Scheme 3

Scheme 3
Scheme 3

Passenger-side AIR Bag Module

  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Release 3 clips and remove instrument panel side garnish. Remove right lower instrument panel trim panel and lower panel. Remove glove box assembly.
  2. Ensure passenger-side air bag module is securely mounted to instrument panel. Disconnect passenger-side air bag module harness connector. Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/05) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from vehicle and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. DO NOT re-use or salvage any parts from the air bag system.

Rear Head AIR Bag Module

  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING & ACTIVATING AIR BAG SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems). Remove headliner. See «HEADLINER»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Ensure rear head air bag module is securely mounted. Disconnect rear head air bag module harness connector. Ensure Deployment Tool (LRT-86-003) is not connected to battery. (Scheme 4) Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from vehicle and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. DO NOT re-use or salvage any parts from the air bag system.

Scheme 4

Scheme 4
Scheme 4

Side AIR Bag Module

  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove 3 screws securing door trim panel to door frame.
  2. Carefully release 13 clips around trim panel. Pull trim panel horizontally from 7 clips securing upper edge to inner glass seal. Release door operating cable and move aside. Disconnect harness connectors and remove trim panel.
  3. Ensure side air bag module is securely mounted. Disconnect side air bag module harness connector. Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  4. Move at least 50 feet (15.2 m) from vehicle and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. DO NOT re-use or salvage any parts from the air bag system.

Seat Belt Buckle Pretensioner

  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Disconnect seat belt buckle pretensioner harness connector.
  2. Ensure seat belt buckle pretensioner is securely mounted. Disconnect pretensioner harness connector. Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to pretensioner connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from vehicle and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy pretensioner. Wait at least 30 minutes before disconnecting deployment tool or handling deployed pretensioner. DO NOT re-use or salvage any parts from the air bag system.

OFF-VEHICLE DEPLOYMENT

WARNINGAir bag modules and seat belt pretensioners are very hot after deployment. Personal injury may result. Allow components to cool for at least 30 minutes before handling. Seal deployed components in sturdy plastic bag before disposal.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Position Air Bag Holding Fixture (LRT-86-007/02) in vice. Ensure vice jaws grip fixture securely above bottom flange. Remove battery disconnection unit. See «BATTERY DISCONNECTION UNIT»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Securely mount battery disconnection unit to holding fixture. (Scheme 5) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/03) to disconnection unit connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from air bag module and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy disconnection unit. Wait at least 30 minutes before disconnecting deployment tool or handling deployed disconnection unit. Seal deployed disconnection unit in bag and dispose as of as normal. DO NOT re-use or salvage any parts from the air bag system.

Scheme 5

Scheme 5
Scheme 5
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Position Air Bag Holding Fixture (LRT-86-007/02) with 2 Adaptors (LRT-86-007/05) in vice. Ensure vice jaws grip fixture securely above bottom flange. Remove driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Secure 2 Adaptors (LRT-86-007/08) to studs at bottom of driver-side air module. Securely mount air bag module to holding fixture. (Scheme 6) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/05) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from air bag module and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. Seal deployed air bag module in bag and dispose as of as normal. DO NOT re-use or salvage any parts from the air bag system.

Scheme 6

Scheme 6
Scheme 6
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Position Air Bag Holding Fixture (LRT-86-007/02) with 2 Adaptors (LRT-86-007/05) in vice. Ensure vice jaws grip fixture securely above bottom flange. Remove head front air bag module. See «FRONT HEAD AIR BAG MODULE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Securely mount air bag module to holding fixture. (Scheme 7) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from air bag module and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. Seal deployed air bag module in bag and dispose as of as normal. DO NOT re-use or salvage any parts from the air bag system.

Scheme 7

Scheme 7
Scheme 7

Passenger-side AIR Bag

  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Position Air Bag Holding Fixture (LRT-86-007/02) in vice. Ensure vice jaws grip fixture securely above bottom flange. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Securely mount air bag module to holding fixture. (Scheme 8) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from air bag module and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. Seal deployed air bag module in bag and dispose as of as normal. DO NOT re-use or salvage any parts from the air bag system.

Scheme 8

Scheme 8
Scheme 8
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Position Air Bag Holding Fixture (LRT-86-007/02) with 2 Adaptors (LRT-86-007/05) in vice. Ensure vice jaws grip fixture securely above bottom flange. Remove rear head air bag module. See «REAR HEAD AIR BAG MODULE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Securely mount air bag module to holding fixture. (Scheme 9) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from air bag module and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. Seal deployed air bag module in bag and dispose as of as normal. DO NOT re-use or salvage any parts from the air bag system.

Scheme 9

Scheme 9
Scheme 9
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Position Air Bag Holding Fixture (LRT-86-007/02) in vice. Ensure vice jaws grip fixture securely above bottom flange. Remove seat belt buckle pretensioner. See «SEAT BELT BUCKLE PRETENSIONER»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Securely mount pretensioner to holding fixture. (Scheme 10) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from air bag module and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed pretensioner. Seal deployed pretensioner in bag and dispose as of as normal. DO NOT re-use or salvage any parts from the air bag system.

Scheme 10

Scheme 10
Scheme 10
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Position Air Bag Holding Fixture (LRT-86-007/02) with 2 Adaptors (LRT-86-007/05) in vice. Ensure vice jaws grip fixture securely above bottom flange. Remove side air bag module. See «SIDE AIR BAG MODULE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) under REMOVAL & INSTALLATION.
  2. Securely mount air bag module to holding fixture. (Scheme 11) Ensure Deployment Tool (LRT-86-003) is not connected to battery. Connect Deployment Tool Lead (LRT-86-003/08) to air bag module connector and deployment tool.
  3. Move at least 50 feet (15.2 m) from air bag module and ensure no one is within the deployment area. Connect deployment tool to battery. Depress deployment tool button to deploy air bag module. Wait at least 30 minutes before disconnecting deployment tool or handling deployed air bag module. Seal deployed air bag module in bag and dispose as of as normal. DO NOT re-use or salvage any parts from the air bag system.

Scheme 11

Scheme 11
Scheme 11

POST-COLLISION INSPECTION

When a vehicle has been involved in a collision, certain components of the passive restraint system must be inspected or replaced. See AIR BAG/SRS COMPONENT INSPECTION & REPLACEMENT TABLES article in the GENERAL INFORMATION section.

REMOVAL & INSTALLATION

WARNINGAccidental air bag deployment is possible. Personal injury may result. Read and follow all WARNINGS and AIR BAG SAFETY PRECAUTIONS before working on air bag system components.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. Release cover and remove nut securing positive battery cable to battery disconnection unit. (Scheme 12) Position positive battery cable aside. Release cover and remove nut securing disconnection unit to junction box. Disconnect disconnection unit harness connector and remove disconnection unit.
  3. To install, reverse removal procedure. Tighten nuts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 12

Scheme 12
Scheme 12
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Turn ignition on, depress brake pedal and move gearshift lever to "D" position. Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. Release clips and gearshift cover from center console. Carefully disconnect 4 harness connectors from gearshift cover. Remove gearshift knob and cover by pulling sharply upward. Release clips securing gearshift lever boot to center console cover and remove knob and boot.
  3. Release boot from handbrake lever grip. Release and remove handbrake lever grip. Open storage box lids, carefully release clips and remove finisher.
  4. Remove 2 screws and large storage box liner. Remove 2 screws securing ignition switch to center console. Remove 4 screws securing center console to instrument panel. Remove 2 screws and washers from base of storage box.
  5. Remove 2 screws securing center console rear closing panel, release clips and remove panel. Raise center console and disconnect harness connectors. Remove center console being careful not to damage painted and veneered surfaces.
  6. To install, reverse removal procedure. Ensure harness connectors are securely seated. Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove center console. See «CENTER CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems). Disconnect Yellow DCU harness connector. (Scheme 13) Remove 3 DCU mounting nuts and remove DCU from vehicle.
  2. To install, reverse removal procedure. Ensure harness connectors are securely seated. Tighten DCU mounting nuts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 13

Scheme 13
Scheme 13
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. Using a rod at least 2" (50 mm) long and not exceeding 1/8" (3 mm) diameter, release 2 air bag module retaining clips. (Scheme 14) Insert rods through access holes in steering wheel at right angles to the steering column. Locate secondary hole and carefully push on rod until retainer is released.
  3. Disconnect harness connectors and remove air bag module. DO NOT let air bag module hang by harness. Remove 4 Torx screws and release switch units from air bag module. Disconnect harness connectors from switch units and remove switch units.
  4. To install, reverse removal procedure. Record bar code of module, if installing NEW. Ensure harness connectors are securely seated. Tighten switch unit screws to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 14

Scheme 14
Scheme 14
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove instrument panel reinforcement. See «INSTRUMENT PANEL REINFORCEMENT»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems).
  2. Remove right and left sun visors. Remove all grab handles. Release enough door weatherstrip to release headliner. Release 4 clips securing lower center pillar trim. Release center pillar upper trim from clips and remove trim assembly. Depress clips and remove center pillar upper trim from lower trim.
  3. Remove right parcel tray and fold rear seat forward. Pull top of upper D-pillar trim panel out to release clips and set aside. Repeat procedure for left upper D-pillar. Open tailgate and remove weatherstrip. Release 4 clips securing right E-pillar trim panel and remove trim panel. Repeat for left E-pillar trim panel.
  4. Remove front and rear consoles from headliner. Carefully remove 2 screws securing center of headliner. Lower side edges of headliner for access to front head air bag module clips and fasteners. (Scheme 15)
  5. Remove 2 screws securing front head air bag module to A-pillar. Remove screw securing air bag module webbing to A-pillar. Remove screw securing air bag module rear webbing to roof. Release 4 clips and remove air bag module.
  6. To install, reverse removal procedure. Record bar code of module, if installing NEW. Ensure harness connectors are securely seated. Tighten air bag module screws to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 15

Scheme 15
Scheme 15
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Fully open sunroof, if equipped. Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. Remove bolts securing front of rear seat. Release rear seat and roll it forward. Disconnect harness connector, remove 2 nuts and remove right rear seat. Remove screw cover labeled AIRBAG from right A-pillar trim panel. Remove Torx screw from A-pillar trim, release clips and remove trim panel. Repeat for left A-pillar trim panel.
  3. Release sufficient door weatherstrip to access center pillar trim. Release 4 clips securing lower center pillar trim. Release center pillar upper trim from clips and remove trim assembly. Depress clips and remove center pillar upper trim from lower trim.
  4. Remove right parcel tray and fold rear seat forward. Pull top of upper D-pillar trim panel out to release clips and set aside. Repeat procedure for left upper D-pillar. Open tailgate and remove weatherstrip. Release 4 clips securing right E-pillar trim panel and remove trim panel. Repeat for left E-pillar trim panel.
  5. On sunroof models, remove 15 screws securing headliner to sunroof and remove clamp plate. On all models, remove right and left sun visors. Remove front and rear consoles from headliner. Remove grab handles.
  6. Remove 4 cargo net hooks. Release weatherstrip from all door openings to release headliner. On sunroof models, remove 4 screws securing headliner. On all other models, remove 2 screws securing headliner. Release 3 clips from rear of headliner and remove headliner through rear of vehicle.
  7. To install, reverse removal procedure. Ensure harness connectors are securely seated. Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove center console. See «CENTER CONSOLE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems).
  2. Remove passenger-side air bag module. See «PASSENGER-SIDE AIR BAG MODULE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems). Remove right and left center console footwell closing panels. Release 4 clips securing heater control panel to instrument panel, disconnect 5 harness connectors and remove control panel.
  3. Carefully release clips securing air suspension switch panel, disconnect harness connectors and remove panel. Remove 6 screws securing multi-information display housing to instrument panel. Release multi-information display housing and harness from instrument panel and disconnect antenna.
  4. From rear of housing, release clips securing display unit. Disconnect connector from display unit and remove unit. Remove 2 screws and remove cassette/CD unit. Remove screws, disconnect connectors and remove instrument cluster.
  5. Release and remove instrument cluster lower trim panel. Remove steering column extension dust boot. Release 4 clips securing instrument cluster harness to instrument panel. Release clip securing cassette/CD unit harness.
  6. Disconnect solar sensor connector. Identify position of remaining connectors and harnesses for reassembly, then disconnect them. Note position of foam strips in ends of instrument panel reinforcement. Remove screws and remove instrument panel reinforcement. (Scheme 16)
  7. To install, reverse removal procedure. Ensure harness connectors are securely seated. Tighten screws to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 16

Scheme 16
Scheme 16
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Release clips and remove right and left side garnish. Release 4 internal clips securing right air vent grille and apply even outward pressure until last clip is released. Remove air vent grille. Repeat fro left air vent grille.
  2. Remove screw cover labeled AIRBAG from right A-pillar trim panel. Remove Torx screw from A-pillar trim, release clips and remove trim panel. Repeat for left A-pillar trim panel. Remove 3 Torx screws securing right side vent trim panel to instrument panel. Remove screw securing rear of cup holder to inner mounting bracket.
  3. Release side vent trim from carrier and disconnect footwell light assembly. Remove side vent trim assembly.
  4. Remove 3 Torx screws securing left side vent trim panel to instrument panel. Release side vent trim from carrier and disconnect harness connector and footwell light assembly. Remove side vent trim assembly.
  5. Carefully release clips securing center grille to upper instrument panel pad. Remove 11 screws and carefully pull upper instrument panel pad rearward. (Scheme 17) Disconnect speaker connector and remove upper instrument panel pad.
  6. Remove rotary coupler. See «ROTARY COUPLER (CLOCKSPRING)»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems). Remove screw securing right center console closing panel to instrument panel. Release 2 clips securing right center console closing panel and remove closing panel. Remove 4 screws securing lower trim panel. Disconnect light assembly connector and remove lower trim panel.
  7. Remove 3 screws and remove right side trim panel. Remove 2 screws securing glove box to under side of instrument panel. Open glove box and remove 5 screws securing glove box. Disconnect light, release cable from latch and remove glove box assembly. Disconnect light, release cable from latch and remove glove box assembly.
  8. Individually release 4 internal clips securing center air vent grille to trim panel. Apply even outward pressure until last clip is released. Disconnect harness connectors, release distribution cable from ratchet assembly, then remove center air vent grille.
  9. Remove 6 screws securing front panel, release 6 clips and remove front panel. (Scheme 18) Remove 8 screws from front and 2 bolts from underside of passenger-side air bag module. (Scheme 19) Pull air bag module from instrument panel, disconnect harness connector and remove air bag module.
  10. To install, reverse removal procedure. Record bar code of module, if installing NEW. Ensure harness connectors are securely seated. Tighten air bag module bolts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove headliner. See «HEADLINER»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems).
  2. Disconnect appropriate rear head air bag module harness connector. (Scheme 20) Remove 4 screws securing air bag module and remove air bag module.
  3. To install, reverse removal procedure. Record bar code of module, if installing NEW. Ensure harness connectors are securely seated. Tighten air bag module screws to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 20

Scheme 20
Scheme 20
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Ensure front wheels are in straight-ahead position. Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. Remove steering wheel. See «STEERING WHEEL»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems) . Remove 3 Torx screws from bottom of lower steering column cover. Release steering column covers from clips securing assembly to column extension dust boot. Remove steering column covers.
  3. Remove 4 Torx screws securing rotary coupler to steering column. Release rotary coupler assembly. Disconnect 5 harness connectors and remove rotary coupler.
  4. To install, reverse removal procedure. Ensure harness connectors are securely seated. Tighten steering wheel bolt to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications) . Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Raise front seat. Remove bolt securing seat belt to front seat. Remove nut caps and remove 2 nuts securing front of seat. Move seat fully forward.
  2. Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Release seat harness multiplug from bracket located under seat, release and disconnect main harness connector. Remove 2 bolts securing rear of seat. Remove front seat.
  3. Release 2 clips securing harness to seat belt pretensioner. Disconnect pretensioner connector. Remove Torx bolt securing pretensioner to seat and remove pretensioner.
  4. To install, reverse removal procedure. Tighten nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications) . Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Remove 3 screws securing appropriate door trim panel to door frame.
  2. Carefully release 13 clips around trim panel. Ensure clip in center of trim panel is released. Pull trim panel horizontally from 7 clips securing upper edge to inner glass seal. Release door operating cable and move aside. Disconnect harness connectors and remove trim panel
  3. Disconnect side air bag module harness connector. Remove and discard 3 bolts securing side air bag module to door frame. Remove air bag module.
  4. To install, reverse removal procedure. Tighten NEW air bag module bolts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications) . Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions) . Raise appropriate front seat. Remove bolt securing seat belt to front seat. Remove nut caps and remove 2 nuts securing front of seat. Move seat fully forward.
  2. Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM. Release seat harness multiplug from bracket located under seat, release and disconnect main harness connector. Remove 2 bolts securing rear of seat. Remove front seat.
  3. Release sufficient door weatherstrip to access center pillar trim. Release 4 clips securing lower center pillar trim. Release center pillar upper trim from clips and remove trim assembly. Depress clips and remove center pillar upper trim from lower trim. Disconnect side impact sensor harness connector. Remove 2 Torx screws and remove sensor.
  4. To install, reverse removal procedure. Tighten nuts, bolts and screws to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications) . Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  1. Before proceeding, see «AIR BAG SAFETY PRECAUTIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__air-bag-safety-precautions). Ensure front wheels are in straight-ahead position. Disable air bag system. See «DISABLING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__disabling-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.
  2. Remove driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems). Disconnect heated steering wheel connector from rotary coupler, if equipped. Hold steering wheel in position and remove steering wheel retaining bolt. Ensure bottom alignment mark on steering column is aligned with mark on steering wheel. Remove steering wheel. (Scheme 21)
  3. To install, reverse removal procedure. Ensure bottom alignment mark on steering column is aligned with mark on steering wheel. Ensure harness connectors are securely seated. Tighten steering wheel bolt to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__torque-specifications). Activate air bag system. See «ACTIVATING SYSTEM»(/land-rover/range-rover/l322-2002-2005/remont/airbag/#air-bag-restraint-systems__activating-system) under DISABLING & ACTIVATING AIR BAG SYSTEM.

Scheme 21

Scheme 21
Scheme 21

DIAGNOSTICS

Air bag system diagnostic information is not available. Air bag system diagnosis is accomplished using proprietary Land Rover Test Book or T4 diagnostic system.

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Battery disconnection unit nuts18 (25)
Front seat-to-floor bracket nuts & bolts33 (45)
Passenger-side air bag module bolts16 (22)
Rear seat mounting nuts & bolts18 (25)
Seat belt lower anchor bolt35 (48)
Seat belt pretensioner mounting bolt35 (48)
Seat belt upper anchor nut23 (31)
Steering wheel retaining bolt46 (63)
INCH Lbs. (N.m)
Diagnostic control unit mounting nuts89 (10.0)
Driver-side air bag module switch screws22 (2.5)
Front head air bag module screws89 (10.0)
Side air bag module bolts80 (9.0)
Side impact sensor screws35 (4.0)
Sunroof clamping plate screws22 (2.5)
Rear head air bag module screws89 (10.0)

TORQUE SPECIFICATIONS

Air Bag System Wiring Diagram (Range Rover-1 Of 2). Scheme 22

Scheme 22: Air Bag System Wiring Diagram (Range Rover-1 Of 2)
Scheme 22: Air Bag System Wiring Diagram (Range Rover-1 Of 2)

Air Bag System Wiring Diagram (Range Rover-2 Of 2). Scheme 23

Scheme 23: Air Bag System Wiring Diagram (Range Rover-2 Of 2)
Scheme 23: Air Bag System Wiring Diagram (Range Rover-2 Of 2)
