Specifications & Drive Belt Routing Land Rover Range Rover L322

Accessory Drive Belts 15 illustrations ~1049 words

ENGINE IDENTIFICATION

ApplicationEngine
Range Rover
2003-044.4L

ENGINE IDENTIFICATION

COMPONENT LOCATIONS

For component locations and cooling system flow (Scheme 1)

Scheme 1

Scheme 1: COMPONENT LOCATIONS
Scheme 1: COMPONENT LOCATIONS

DRAINING & REFILLING COOLING SYSTEM

WARNINGDO NOT remove expansion tank pressure cap when engine is hot. Serious injury such as scalding can be caused by escaping steam or hot coolant.

CHECK & TOP-UP

  1. Check coolant level, top-up to MAX mark if necessary. With engine cold, remove expansion tank filler cap.
  2. Top-up with recommended mixture of coolant and anti-freeze until float is at its highest position in the filler neck. (Scheme 2)
  3. Check anti-freeze concentration. Check "O" rings on filler cap for condition, replace if necessary. Install expansion tank filler cap.

Scheme 2

Scheme 2
Scheme 2

Drain

  1. Position vehicle on lift. Set heater controls to maximum. Disconnect battery ground lead. See «DISCONNECTING & RECONNECTING BATTERY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__disconnecting-reconnecting-battery).
  2. Remove coolant expansion tank cap. Remove undertray. See «UNDERTRAY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing) under REMOVAL & INSTALLATION.
  3. Position container beneath radiator to collect coolant. Install tube to drain tap, open tap and allow coolant to drain. (Scheme 3) Position container beneath engine to collect coolant. Remove cylinder block drain plug and allow coolant to drain. (Scheme 4) Discard sealing washer. Remove container.

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Refill

  1. Close radiator drain tap and remove tube. Using a NEW sealing washer, fit cylinder block drain plug and tighten to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__torque-specifications). Connect battery ground lead.
  2. Remove bleed screw from expansion tank. (Scheme 5) Fill cooling system, keeping coolant to neck of expansion tank until a steady stream of coolant is emitted from bleed screw hole. Install and tighten bleed screw.
  3. Install coolant expansion tank cap. Run engine until normal operating temperature is reached. Turn engine off and allow to cool. Check for leaks and fill expansion tank to MAX mark. (Scheme 2)
  4. Clean coolant from body and surrounding area. Install undertray. See «UNDERTRAY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing) under REMOVAL & INSTALLATION.

Scheme 5

Scheme 5
Scheme 5

BELT ADJUSTMENT

Note. If reinstalling original belt, mark direction of rotation on belt for installation reference before removing.

ApplicationSpecification
All Models(1)
(1) No adjustment is necessary, drive belt tension is maintained by automatic belt tensioners.
(1)No adjustment is necessary, drive belt tension is maintained by automatic belt tensioners.

BELT ADJUSTMENT

Routing Illustrations

Note. Serpentine belts are adjusted by belt tensioners. (Scheme 6), (Scheme 7) and (Scheme 8).

Scheme 6

Scheme 6: Routing Illustrations
Scheme 6: Routing Illustrations

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Disconnecting & Reconnecting Battery

WARNINGVehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see SERVICE PRECAUTIONS (or AIR BAG SAFETY PRECAUTIONS) and DISABLING & ACTIVATING AIR BAG SYSTEM in appropriate AIR BAG RESTRAINT SYSTEMS article.
CAUTIONIt is imperative that the key is removed from the ignition before disconnecting the battery. Never disconnect the battery with the ignition switched on.
CAUTIONWAIT at least 2 minutes before battery is disconnected after turning ignition to OFF position. Failure to do so could result in Navigation computer hardware damage and/or an incorrect fuel gauge reading.
CAUTIONTo prevent damage to electrical components, always disconnect the battery when working on the vehicle's electrical system.
CAUTIONAfter reconnecting the battery, the steering wheel must be turned to full left and right lock (with engine running). This allows the DSC system to relearn the steering wheel position. Failure to do so will result in a variety of instrument warning lights being illuminated.
CAUTIONAlways ensure that battery leads are routed correctly and are not close to any potential chafing points.
  1. Turn ignition to OFF position and remove key from ignition switch before disconnecting battery. A time of at least 2 minutes must also elapse before disconnection. Failure to do so could result in: Navigation computer hardware damage. Incorrect fuel gauge reading.
  2. Before disconnecting the battery, disable the alarm system and switch off all electrical equipment. If the radio is to be serviced, ensure radio security code has been deactivated.
  3. The ground lead must be disconnected first and reconnected last. Ensure battery leads are routed correctly and are not close to any potential chafing points.
  4. After reconnecting the battery, the steering wheel must be turned to full left and right lock (with engine running). This allows the DSC system to relearn the steering wheel position. Failure to do so will result in a variety of instrument warning lights being illuminated.

THERMOSTAT

Note. The thermostat heater is serviced with the thermostat and must not be removed.

Removal

  1. Raise and support vehicle. Disconnect battery ground lead. See «DISCONNECTING & RECONNECTING BATTERY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__disconnecting-reconnecting-battery).
  2. Drain cooling system. See «DRAIN & REFILL»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing) under DRAINING & REFILLING COOLING SYSTEM. Remove engine acoustic cover. Remove air intake hose.
  3. Disconnect vacuum pipes from air intake pipe. Release 2 clips and disconnect air intake pipe from throttle body. Remove air intake pipe. Remove seal from air intake pipe, at MAF sensor connection end.
  4. Remove clips from air intake pipe. Disconnect thermostat heater connector. (Scheme 9) Release clip and disconnect radiator bottom hose from thermostat housing. Remove 4 bolts and remove thermostat housing from coolant pump. (Scheme 10) Discard seal.

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Installation

  1. Clean mating face of thermostat housing and coolant pump. Install NEW seal to thermostat housing. Install thermostat housing and tighten bolts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__torque-specifications) .
  2. Connect radiator bottom hose to thermostat housing and secure with clip. Connect thermostat heater connector. Connect air intake hose.
  3. Install seal to MAF sensor. Lubricate air intake pipe mating face of throttle body seal and MAF sensor seal to aid refit. Install clips to air intake pipe. Install and secure air intake pipe. Connect vacuum pipes to air intake pipe.
  4. Install engine acoustic cover. Connect battery ground lead. See «DISCONNECTING & RECONNECTING BATTERY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__disconnecting-reconnecting-battery) .
  5. Fill cooling system. See «DRAIN & REFILL»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing) under DRAINING & REFILLING COOLING SYSTEM.

Removal & Installation

  1. Raise and support vehicle. Release clips and remove towing eye finisher. (Scheme 11) Remove 6 screws securing air dam to undertray. Remove 2 screws securing air dam support brackets to bumper. Carefully ease air dam aside for access and remove 4 screws.
  2. Remove 2 screws securing left inner edge of wheel arch liner to undertray, repeat on right side. Remove 6 remaining screws securing undertray, release panel and remove. Further dismantling is not necessary if component is removed for access only. Remove 6 screw retaining clips from undertray. To install, reverse removal procedure.

Scheme 11

Scheme 11
Scheme 11
  1. Raise and support vehicle. Disconnect battery ground lead. See «DISCONNECTING & RECONNECTING BATTERY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__disconnecting-reconnecting-battery).
  2. Remove undertray. See «UNDERTRAY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing). Release 3 coolant hoses from clips on fan cowl. Remove screw securing fan cowl to radiator. (Scheme 12)
  3. Disconnect harness multiplug and release cooling fan multiplug from mounting. (Scheme 13) Using flat wrenches LRT-12-214 and LRT-12-215, loosen viscous coupling lock nut and remove fan assembly from coolant pump. (Scheme 14)
  4. Remove scrivets securing fan cowl. Release cowl from mountings and remove cowl and fan assembly. (Scheme 15) Place viscous coupling and fan on to work bench.
  5. Do not carry out further dismantling if component is removed for access to other components. To remove fan, remove 4 bolts and remove coupling from fan.

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Clean coupling and fan mating faces. Install viscous coupling to fan and tighten 4 bolts to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__torque-specifications) .
  2. Carefully install fan and cowl assembly, secure the cowl to mountings. Install fan assembly to coolant pump. Using flat wrenches LRT-12-214 and LRT-12-215, tighten viscous coupling lock nut to specification. See «TORQUE SPECIFICATIONS»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__torque-specifications) .
  3. Install cooling fan harness and connector to fan cowl. Install screw securing fan cowl to radiator. Secure 3 coolant hoses to clips on fan cowl. Install undertray. See «UNDERTRAY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing) . Connect battery ground lead. See «DISCONNECTING & RECONNECTING BATTERY»(/land-rover/range-rover/l322-2002-2005/remont/accessory-drive-belts/#specifications-drive-belt-routing__disconnecting-reconnecting-battery) .

COOLING SYSTEM SPECIFICATIONS

ApplicationSpecification
Coolant Replacement Interval(1)
Coolant Capacity - Refill13.7 Qts. (13.0 L)
Coolant Capacity - Fill From Dry18.4 Qts. (17.4 L)
Expansion Tank Cap Pressure15 psi (1.0 bar)
Serpentine Drive Belt Inspection Interval (2)12 Months Or 15,000 Miles
Thermostat Initial Opening185°F (85°C)
(1) Inspect coolant level every week and replace every 48 months or 60,000 miles. Use an ethylene glycol based anti-freeze (containing no methanol) with non-phosphate corrosion inhibitors suitable for use in aluminum engines. Use a 50 percent mixture. DO NOT allow mixture to exceed 60 percent or fall below 25 percent. (2) Inspect serpentine drive belt every 12 months or 15,000 miles, whichever comes first. Replace drive belt as necessary. Manufacturer does not have a specified replacement time interval.
(1)Inspect coolant level every week and replace every 48 months or 60,000 miles. Use an ethylene glycol based anti-freeze (containing no methanol) with non-phosphate corrosion inhibitors suitable for use in aluminum engines. Use a 50 percent mixture. DO NOT allow mixture to exceed 60 percent or fall below 25 percent.
(2)Inspect serpentine drive belt every 12 months or 15,000 miles, whichever comes first. Replace drive belt as necessary. Manufacturer does not have a specified replacement time interval.

COOLING SYSTEM SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Cylinder Block Drain Plug18 (25)
Multiplug-To-Bell Housing Bolt18 (25)
Viscous Fan Assembly-To-Water Pump41 (56)
Viscous Fan Coupling Nuts33 (45)
Water Pump Pulley Bolts16 (22)
Water Pump-To-Engine Bolts16 (22)
INCH Lbs. (N.m)
Coolant Manifold-To-Cylinder Heads Bolts84 (10)
Coolant Pump Bolts84 (10)
Coolant Pump Pulley Bolts84 (10)
Engine Harness-To-Coolant Manifold Bolt84 (10)
Coolant Gallery Sealing Plate-To-Cylinder Block Bolts84 (10)
Radiator Drain Plug (Range Rover)53 (6)
Secondary Air Injection Pipe Bolts84 (10)
Thermostat Housing Bolts84 (10)
Viscous Fan Coupling-To-Unit Bolts84 (10)

TORQUE SPECIFICATIONS
