Full Frame and Body Mounting: Specifications Land Rover Range Rover III facelift

Frames, Subframes & Crossmembers 6 illustrations ~134 words

SPECIFICATIONS

DescriptionNm
Transmission support crossmember damper90
Transmission support crossmember to chassis bolts68
Transmission support insulator through-bolt115
Exhaust hanger bolt45

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-522601) .
  2. Raise and support the vehicle.
  3. Remove the exhaust system. Refer to «Exhaust System»(ref-522600-S14109741142013011500000) .
  4. Remove the RH heat shield. Remove the 7 nuts.
  5. Remove the LH heat shield. Remove the 5 nuts.
  6. Remove the LH exhaust hanger. Remove the nut.
  7. Remove the transmission support insulator nut, bolt and damper. Support the transmission.
  8. Release the catalyst monitor sensor wiring harness. Release the 4 clips.
  9. With assistance, remove the transmission support crossmember. Remove the 4 bolts and washers. Noting fitted position, remove the 4 spacers. Noting fitted position, remove the 2 transmission support insulator buffers.
  10. Remove the transmission support crossmember damper. Remove the nut and bolt.
