ENGINE MOUNT RH Land Rover Range Rover III facelift

Engine (4.2L) 4 illustrations ~130 words

ENGINE MOUNT RH

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Viscous coupling spanner 303-1142 Viscous coupling pulley retaining tool 303-1143

Scheme 186

Scheme 186: ENGINE MOUNT RH
Scheme 186: ENGINE MOUNT RH

Scheme 187

Scheme 187
Scheme 187

Scheme 188

Scheme 188: REMOVAL
Scheme 188: REMOVAL

Scheme 189

Scheme 189
Scheme 189
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-522601) .
  2. Raise and support the vehicle.
  3. Remove the air intake resonator. Refer to «Intake Air Resonator»(ref-522607-S24405156362013011500000) .
  4. Remove the coolant expansion tank. Refer to «Coolant Expansion Tank»(ref-522611-S14835446732013011500000) .
  5. Using the special tools, release the cooling fan.
  6. Remove the engine undershield. Refer to «Engine Undershield»(ref-522604-S24326226122013011500000) .
  7. Remove the engine compartment RH heat shield. Remove the 2 nuts. Remove the 2 screws.
  8. Release the engine mount. Support the engine. Remove the nut.
  9. Remove the engine mount. Using a transmission jack, raise the engine clear of the engine mount. Remove the 2 bolts.
