| Description | Nm |
|---|---|
| Seat frame fixing Torx screws | 40 |
| Seat belt fixing Torx screws | 40 |
| Road wheel nuts | 140 |
TORQUE SPECIFICATIONS
| CAUTION | Unless stated otherwise, the following operations must be carried out at every indicated service interval. |
Scheme 1
- A. Engine oil filler cap
- B. Brake fluid reservoir - LHD illustrated, RHD on opposite side
- C. Coolant expansion tank
- D. Power steering fluid reservoir
- E. Windshield washer fluid reservoir
Scheme 2
- A. Brake fluid reservoir - RHD illustrated, LHD on opposite side
- B. Engine oil filler cap
- C. Coolant expansion tank
- D. Power steering fluid reservoir
- E. Windshield washer fluid reservoir
MAINTENANCE OPERATIONS
Seats and Safety Belts
Note: The following procedures should only be completed when carrying out Service Inspection 1 and Service Inspection 2.
Scheme 3
1. Check front seat fixings are secured to the floor and that the seat frames show no signs of movement.
Scheme 4
2. Check that the rear seat frame front fixings are secure and that the seat frames show no signs of movement.
Scheme 5
3. Release the catch and fold the rear seats forwards, check that the rear seat frame rear fixings are secured to the floor and that the seat frames show no signs of movement.
4. Check rear seat catch locking bars are secured to the floor and show no signs of movement.
5. Fold the rear seats back on completion.
6. Check operation of all seat controls.
7. Fully extend each safety belt and check that it returns unassisted; repeat for all belts.
8. Check entire length of safety belt webbing for signs of fraying or damage; repeat for all belts.
9. Connect each safety belt to the correct buckle, check safety belt buckle and tongue are secure; check that buckle releases tongue correctly.
10. Check all safety belt and buckle mountings and fixings for security.
11. Check front safety belt height adjusters for correct operation.
