SPECIFICATIONS
| Description | Nm |
|---|---|
| Camshaft position (CMP) sensor(s) retaining bolt | 10 |
| Crankshaft position (CKP) sensor retaining bolt | 10 |
| Heated oxygen sensor(s) (HO2S) | 48 |
| Catalyst monitor sensor(s) | 48 |
| Knock sensor(s) (KS) retaining bolt | 20 |
| Fuel rail pressure (FRP) sensor | 32 |
| Manifold absolute pressure and temperature (MAPT) sensor | 5 |
| Engine oil level sensor retaining bolts | 12 |
| Variable valve timing (VVT) oil control solenoid(s) retaining bolts | 10 |
| Engine control module (ECM) cover retaining bolt | 9 |
| ECM bracket retaining nut | 9 |
TORQUE SPECIFICATIONS
Scheme 1
| Item Number | Description |
|---|---|
| 1 | MAFT (mass air flow and temperature) sensor |
| 2 | MAP (manifold absolute pressure) sensor |
| 3 | Knock sensors |
| 4 | CKP (crankshaft position) sensor |
| 5 | MAFT sensor |
| 6 | ECT (engine coolant temperature) sensor (ECT 2) |
| 7 | CMP (camshaft position) sensors |
| 8 | Electronic throttle |
| 9 | CMP sensors |
Scheme 2
| Item Number | Description |
|---|---|
| 1 | ECM (engine control module) |
| 2 | ECT sensor (ECT 1) |
| 3 | Upstream HO2S (heated oxygen sensor) |
| 4 | Downstream HO2S |
| 5 | Downstream HO2S |
| 6 | Upstream HO2S |
| 7 | MAPT (manifold absolute pressure and temperature) sensor |
Scheme 3
| Item Number | Description |
|---|---|
| 1 | AAT (ambient air temperature) sensor |
| 2 | APP (accelerator pedal position) sensor |
