SPECIFICATIONS
| Item | Specification |
|---|
| Air conditioning (A/C) compressor oil type | Sanden SP-10 PAG oil |
| A/C compressor oil - vehicles fitted with 2 zone | 110 cm 3 |
| A/C compressor oil - vehicles fitted with 4 zone | 200 cm 3 |
| Item | Specification |
|---|
| Refrigerant type | R134A |
| Refrigerant - vehicles fitted with 2 zone | 750 grammes |
| Refrigerant - vehicles fitted with 4 zone | 930 grammes |
| Description | Nm |
|---|
| A/C compressor mounting bolts | 25 |
| A/C compressor manifold and tube retaining bolt | 9 |
| A/C line to bulkhead bolts | 6 |
| Thermostatic expansion valve (TXV) to refrigerant line clamp bolts | 5 |
| A/C line to compressor bolt | 22 |
| A/C line to condenser | 10 |
| A/C liquid line to front evaporator bolts - vehicles fitted with 4 zone | 9 |
| A/C suction lines to front evaporator bolts - vehicles fitted with 4 zone | 18 |
| A/C lines to rear evaporator bolts - vehicles fitted with 4 zone | 9 |
Scheme 16
Scheme 16: AIR CONDITIONING
| Item Number | Description |
|---|
| 1 | Condenser |
| 2 | High pressure servicing connection |
| 3 | Refrigerant pressure sensor |
| 4 | Low pressure servicing connection |
| 5 | Thermostatic expansion valve |
| 6 | Evaporator |
| 7 | Air conditioning (A/C) compressor |
| 8 | Receiver drier module |
Scheme 17
| Item Number | Description |
|---|
| 1 | Condenser |
| 2 | Low pressure servicing connection |
| 3 | Refrigerant pressure sensor (reference) |
| 4 | Thermostatic expansion valve |
| 5 | Evaporator |
| 6 | High pressure servicing connection |
| 7 | Air conditioning (A/C) compressor |
| 8 | Receiver drier module |
