Fuses & Circuit Breakers Land Rover Range Rover III рестайлинг

IDENTIFICATION

CAUTION

When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle.

ENGINE COMPARTMENT

Note. Some fuses are located in the engine compartment, including the glow plug fuses (located adjacent to the battery) and engine management fuses (located in the electronic control box).

PASSENGER COMPARTMENT

Note. The passenger compartment fuse box is fitted behind the lower glove box; to access the fuses, open the glove box, then release the left-hand support stay as shown (see upper inset). This allows the glove box to open to the service position. Remove the fuse box cover by pressing down on the catches (1) while pulling the cover rearwards. The solid arrow in the illustration indicates the location of the fuse removal tool. (Scheme 1)

Scheme 1

Scheme 1: PASSENGER COMPARTMENT

Scheme 2

Fuse No.	Amps	Fuse Function
1	5A	Instruments, Passenger Airbag Disable Indicator
2	5A	Heated Rear Window, Rear Blower, Heated Seats - Rear, Cigar Lighter/Front Accessory Socket, Trailer Socket
3	5A	Airbag Dcu, Occupancy Sensor
4	5A	Exterior Lamps, Instrument Illumination, Approach Lamps
5	7.5A	Diagnostics, Transmission
6	5A	Rear View Mirror, Parking Distance Control, TPMS
7	5A	Air Suspension
8		Spare
9	5A	Brake Lamps, Exterior Lamps, Instrument Illumination, Cruise Control, Steering Wheel Audio Controls, Dynamic Stability Control (DSC)
10	20A	Climatic Seats
11	30A	Central Locking, External Mirrors, Electric Window - Driver's
12	10A	Air Conditioning, Heated Seats - Front
13	10A	Lumbar Pumps, Analogue Clock
14	5A	Transit Relay - Transit Only
15	5A	Central Locking, Diagnostic Socket, Power Assisted Steering
16	5A	TPMS
17	5A	Approach Lamps
18	10A	Immobilisation
19		Spare
20	30A	Seat Memory, Electric Seat Switches, Steering Column Adjust
21	30A	Electric Seat Switches
22	5A	Telephone
23		Spare
24	30A	Central Locking, Exterior Mirrors, Electric Window - Front Passenger's
25	5A	Immobilisation
26	30A	Windshield Wipers
27	20A	Glove Box Lamp, Interior Lamps, Body Control Unit (BCU)
28	30A	Headlamp Washers
29	10A	Heated Steering Wheel
30	5A	Alternator
31	5A	Engine Management, Immobilisation
32	5A	Active Front Lighting System (AFS)
33	5A	Transmission, Centre Console Switches, Electronic Differential
34	7.5A	Air Conditioning, Blower, Heated Front Screen, Heated/Cooled Seats
35	5A	Hill Descent Control (HDC), Dynamic Stability Control, Steering Angle Sensor
36	5A	Electronic Parking Brake (EPB)
37		Spare
38	5A	Anti-lock Braking System (ABS), Yaw Rate Sensor
39	5A	Immobilisation
40	5A	Cd Autochanger
41	5A	Rain Sensor, Rear Window Wash/Wipe, Headlamp Wash/Wipe
42	5A	Vanity Mirror Illumination
43	5A	Alarm, Interior Mirror (Infra Red), Glove Box Lock Control
44		Spare
45	5A	Instruments
46	5A	Instruments
47	15A	Heated Screen Washers, Heated Wiper Blades
48	15A	Active Front Lighting System (AFS) - LH
49	30A	Navigation System, On-board Computer, On-board Monitor, Audio System
50		Spare
51	5A	Interior Illumination
52	20A	Heated/Cooled Seats - Front
53	15A	Active Front Lighting System (AFS) - RH
54		Spare
55	25A	Anti-lock Braking System, Dynamic Stability Control
56	25A	Heated Seats - Rear
57	20A	Air Suspension
58	20A	Sunroof
59	20A	Auxiliary Heater (Diesel Models Only), Independent Heater
60	30A	Central Locking, Electric Windows - Rear

Passenger Compartment Fuse Box

REAR CARGO AREA

Note. Rear cargo area fuse box is located on right side of cargo area behind access hatch.

Scheme 3

Scheme 3: REAR CARGO AREA

Fuse No.	Amps	Fuse Function
1	15A	Trailer Socket
2		Spare
3		Spare
4	20A	Accessory Socket - Rear
5	20A	Rear Screen Wiper
6	30A	Electronic Parking Brake (EPB)
7		Spare
8	30A	Rear Rear Window
9	30A	Audio System Amplifier
10	10A	Rear Seat Entertainment, Vehicle Information Communication System
11	10A	Telephone, Navigation, Message Centre, Television, Radio, Headphones
12	5A	Rear View Camera
13	5A	Air Suspension
14	15A	Rear Blower Motor
15	10A	Taildoor
16	5A	Remote Control Receiver, Glove Box Switch
17	20A	Cigar Lighter - Front, Accessory Socket - Rear
18	20A	Cigar Lighter - Rear, Accessory Socket - Front
19		Spare
20	20A	Trailer Socket

Rear Cargo Area Fuse Box
