OVERVIEW
Two variants of driver and passenger seat are available
- Low line seat with 8-way adjustment finished in Blenheim leather
- High line seat with 10-way adjustment finished in Oxford leather
Scheme 2
| Item Number | Description |
|---|---|
| A | Low line front seat |
| B | High line front seat |
The front seats are fitted with the seat belt bolted to the seat rail. The frames are common to both variants and are equipped with the following
- Seat control switches
- Cushion front height adjustment
- Cushion rear height adjustment
- Cushion front tilt adjustment (high line only)
- Backrest adjustment
- Head restraint adjustment
- Lumbar adjustment
- Seat forward and rearward adjustment
- Side air bag module
- Backrest heating
- Cushion heating
- Seat climatic control (available as an option on the high line version)
| WARNING | Prior to removal of the front seats and before disconnecting the front seat wiring harness electrical connectors (which includes the side air bag module electrical connectors), the battery ground cable should be disconnected and a period of at least 1 minute allowed to elapse. The same amount of care should be taken when handling and storing the front seats, as would be taken when handling and storing air bag modules. |
Both variants of the front seats are fitted with a manually adjustable folding armrest on the inboard side of the seat. The memory recall functions are also available on higher specification vehicles.
The driver and passenger front seats, although almost identical, have some unique components. The front driver seat has a seat position sensor and the front passenger seat, for North American Specification (NAS) vehicles, has a seat occupant classification system, where as Rest Of the World (ROW) vehicles, except Australia, has a seat occupancy detection system. In both instances the components form an integral part of the Supplemental Restraint System (SRS). Refer to Air Bag and Safety Belt Pretensioner Supplemental Restraint System (SRS) .
The rear bench seats are designed to fold forward to increase the rear load space. a 60:40 split gives the owner increased flexibility when loading the vehicle with large objects. All rear seats are equipped with 3-point seat belts and adjustable head restraints. High line specification vehicles are also fitted with seat cushion heaters in both outboard seats.
