Wipers and Washers - Removal & Installation Land Rover Range Rover III

Wiper/washer Systems 22 illustrations ~1192 words

Scheme 1

Scheme 1: Remove
Scheme 1: Remove
  1. Remove LH front wheel arch liner. «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)
  2. Position container to catch windscreen washer fluid.
  3. Release filler neck from washer bottle and discard seal.
  4. Noting fitted position, disconnect multiplugs and hoses from washer pumps.
  5. Disconnect multiplug from washer reservoir low level sensor.
  6. Release vent pipe from reservoir.
  7. Remove 2 bolts securing reservoir to body and release reservoir from front mounting.
  8. Remove washer pumps from reservoir and discard seals.

Refit

  1. Clean washer pumps and reservoir recesses.
  2. Fit new seals to pumps and fit to reservoir.
  3. Position reservoir to body, fit bolts and tighten to 3 Nm (2.2 lbf.ft).
  4. Connect vent pipe.
  5. Connect multiplug to low level sensor.
  6. Connect multiplugs and hoses to pumps.
  7. Clean filler neck and reservoir recess.
  8. Fit new seal to filler neck and connect to reservoir.
  9. Refill reservoir.
  10. Fit wheel arch liner. «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)

Scheme 2

Scheme 2: Remove
Scheme 2: Remove

Scheme 3

Scheme 3
Scheme 3
  1. Turn steering wheel to full lock.
  2. Raise vehicle on lift.
  3. Remove screw securing bumper extension to wheel arch liner.
  4. Ease lower edge of wheel arch liner aside for access, from rear of bumper release level sensor from washer reservoir.
  5. Disconnect multiplug from level sensor and remove sensor.
  1. Connect low level sensor to multiplug and fit to reservoir.
  2. Position wheel arch liner and secure with screw.
  3. Lower vehicle ramp.
  4. Position steering wheel straight ahead.

Scheme 4

Scheme 4: Remove
Scheme 4: Remove
  1. Remove LH front wheel arch liner. «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)
  2. Position container to catch windscreen washer fluid.
  3. Disconnect multiplug and hose from windscreen washer pump.
  4. Remove washer pump from reservoir and remove and discard pump seal.
  1. Clean washer pump and reservoir recess.
  2. Fit new seal to pump and fit to reservoir.
  3. Connect hose and multiplug to pump.
  4. Refill reservoir.
  5. Fit wheel arch liner. «76.10.48 LINER -- FRONT WHEEL ARCH»(ref-208059-S38087232582005120200000)

Scheme 5

Scheme 5: Remove
Scheme 5: Remove
  1. Remove interior mirror. «INTERIOR MIRROR»(/land-rover/range-rover/iii-2002-2005/remont/mirrors/#interior-mirror)
  2. Remove 2 clips securing rain sensor and remove sensor from windscreen.
  1. Fit rain sensor to windscreen and secure with clips.
  2. Fit interior mirror. «INTERIOR MIRROR»(/land-rover/range-rover/iii-2002-2005/remont/mirrors/#interior-mirror)
  3. Configure a new sensor using TestBook/T4.

Scheme 6

Scheme 6: Remove
Scheme 6: Remove
  1. Open bonnet for access.
  2. Remove nut cover on wiper arm and remove nut.
  3. Remove wiper arm from spindle. NOTE: Do not carry out further dismantling if component is removed for access only.
  4. Remove wiper blade. «84.15.06 BLADE - WIPER - FRONT SCREEN»(/land-rover/range-rover/iii-2002-2005/remont/wiperwasher-systems/#wipers-and-washers-removal-installation)

Scheme 7

Scheme 7: Refit
Scheme 7: Refit

Scheme 8

Scheme 8
Scheme 8
  1. Fit wiper blade. «84.15.06 BLADE - WIPER - FRONT SCREEN»(/land-rover/range-rover/iii-2002-2005/remont/wiperwasher-systems/#wipers-and-washers-removal-installation)
  2. Fit wiper arm assembly to spindle, fit and finger tighten nut. Position LRT-84-001 to windscreen between points 'A' and 'B' on wiper arm, align face of wiper arm to 86°.
  3. While maintaining the 86° angle, set the respective wiper arms to the dimensions shown. Passenger side 'C' = 58 mm (2.283). Drivers side 'D' = 40.5 mm (1.594).
  4. Measurement must be taken from lip of the plenum glass seal to the lip of the wiper blade adjacent to wiper arm/blade pivot.
  5. Tighten wiper arm nut to 34 Nm (25 lbf.ft).
  6. Fit nut cover.
  7. Close bonnet.

Scheme 9

Scheme 9: Remove
Scheme 9: Remove
  1. Lift wiper arm from screen.
  2. Release wiper arm lock.
  3. Release wiper blade from arm.
  1. Position new blade to wiper arm.
  2. Push blade into engagement with arm, and check blade is retained.
  3. Lower arm onto screen.

Scheme 10

Scheme 10: Remove
Scheme 10: Remove
  1. Remove windscreen lower finisher. «76.43.41 LOWER FINISHER -- WINDSCREEN»(ref-208059-S08213552562005120200000)
  2. Remove air intake plenum.
  3. Disconnect multiplug from wiper motor.
  4. Remove 5 Torx bolts securing wiper linkage and remove assembly.
  1. Position wiper motor assembly, fit bolts and tighten to 10 Nm (7 lbf.ft).
  2. Connect multiplug to wiper motor.
  3. Fit air intake plenum.
  4. Fit windscreen finisher. «76.43.41 LOWER FINISHER -- WINDSCREEN»(ref-208059-S08213552562005120200000)

84.15.12 Motor - wiper

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 11

Scheme 11: Remove
Scheme 11: Remove
  1. Disconnect battery earth lead.
  2. Noting fitted position, remove nut securing windscreen wiper linkage and release linkage from motor.
  3. Remove 3 bolts securing mounting plate to wiper motor.
  4. Disconnect multiplug from motor.
  5. Remove motor.
  1. Position wiper motor to bracket, fit bolts and tighten to 10 Nm (7 lbf.ft)
  2. Connect multiplug to motor.
  3. Connect battery earth lead.
  4. Turn ignition key to position ll, ensure wiper motor is in park, turn ignition off.
  5. Disconnect battery earth lead.
  6. Position wiper linkage to motor, fit nut and tighten to 25 Nm (7 lbf.ft) CAUTION: Ensure wiper motor is timed with wiper linkage.
  7. Connect battery earth lead.

Scheme 12

Scheme 12: Remove
Scheme 12: Remove

Scheme 13

Scheme 13
Scheme 13
  1. Remove battery.
  2. Release clips securing ECU cover to bulkhead. Remove cover.
  3. Disconnect relay and multiplug from bulkhead fuse box.
  1. Connect relay to bulkhead fuse box mounting.
  2. Fit and secure ECU cover.
  3. Fit battery.

Scheme 14

Scheme 14: Remove
Scheme 14: Remove
  1. Raise nut cover, remove nut and release wiper arm.
  1. Fit wiper arm to spindle, align blade to glass and tighten nut to 6 Nm (4.4 lbf.ft).
  2. Fit wiper arm fixing cover.

Scheme 15

Scheme 15: Remove
Scheme 15: Remove
  1. Remove pin securing headlamp wiper blade and release blade from wiper arm.
  1. Fit wiper blade to wiper arm and secure with pin.

Scheme 16

Scheme 16: Remove
Scheme 16: Remove

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Remove front bumper assembly. «76.22.72 BUMPER -- ASSEMBLY -FRONT»(ref-208059-S28552961812005120200000)
  2. Remove headlamp assembly. «86.40.55 HEADLAMP ASSEMBLY»(/land-rover/range-rover/iii-2002-2005/remont/exterior-lights/#lighting-removal-installation__864055-headlamp-assembly)
  3. Disconnect multiplug and hose from headlamp wiper motor.
  4. Release harness from front panel.
  5. Remove 3 bolts securing bumper support bracket and remove bracket.
  6. Remove 2 bolts securing wiper motor retaining bracket, remove bracket and motor assembly.
  7. Remove 2 screws and release wiper motor from bracket.
  1. Position wiper motor to bracket and secure with screws.
  2. Fit motor assembly, fit and tighten bolts to 10 Nm (7 lbf.ft).
  3. Fit bumper support bracket, fit and tighten bolts to 10 Nm (7 lbf.ft).
  4. Secure harness to front panel, connect multiplug and hose to motor.
  5. Fit headlamp assembly. «86.40.55 HEADLAMP ASSEMBLY»(/land-rover/range-rover/iii-2002-2005/remont/exterior-lights/#lighting-removal-installation__864055-headlamp-assembly)
  6. Fit front bumper assembly. «76.22.72 BUMPER -- ASSEMBLY -FRONT»(ref-208059-S28552961812005120200000)

Scheme 19

Scheme 19: Remove
Scheme 19: Remove

Scheme 20

Scheme 20
Scheme 20
  1. Remove upper tailgate finisher.
  2. Remove 3 bolts securing spoiler to tailgate.
  3. Close tailgate.
  4. Move spoiler aside for access.
  5. Raise nut cover on wiper arm and remove nut.
  6. Remove rear wiper arm.
  1. Fit wiper arm to spindle, align blade to glass and tighten nut to 13 Nm (10 lbf.ft).
  2. Close nut cover.
  3. Fit and secure spoiler to tailgate, tighten bolts to 10 Nm (7 lbf.ft).
  4. Fit upper tailgate finisher.

Scheme 21

Scheme 21: Remove
Scheme 21: Remove
  1. Position rear wiper arm for access.
  2. Lift wiper arm from screen.
  3. Release wiper arm lock.
  4. Release wiper blade from arm.
  1. Position new blade to wiper arm.
  2. Push blade into engagement with arm, and check blade is retained.
  3. Lower arm onto screen.
  4. Return wiper to park position.

Scheme 22

Scheme 22: Remove
Scheme 22: Remove
  1. Remove rear wiper arm. «84.35.01 Arm - wiper - tailgate»(/land-rover/range-rover/iii-2002-2005/remont/wiperwasher-systems/#wipers-and-washers-removal-installation)
  2. Disconnect washer hose from wiper motor.
  3. Disconnect multiplugs from wiper motor.
  4. Remove 3 Torx screws securing rear wiper motor to tailgate.
  5. Release motor from glass seal, remove motor assembly.
  6. Remove seal from glass. NOTE: Do not carry out further dismantling if component is removed for access only.
  7. Remove compression limiters from wiper motor rubber mountings, release and collect mounting rubbers.
  1. Fit mounting rubbers and insert compression limiters.
  2. Fit new glass seal.
  3. Position wiper motor assembly to tailgate, fit and tighten Torx screws to 10 Nm (7 lbf.ft).
  4. Connect multiplugs.
  5. Connect washer hose to wiper motor.
  6. Fit wiper arm. «84.35.01 Arm - wiper - tailgate»(/land-rover/range-rover/iii-2002-2005/remont/wiperwasher-systems/#wipers-and-washers-removal-installation)
