Air Conditioning - Recovery, Removal & Installation Land Rover Range Rover III

Automatic HVAC System 52 illustrations ~3761 words

Scheme 1

Scheme 1: Refrigerant recovery
Scheme 1: Refrigerant recovery
  1. Recover refrigerant. WARNING: Servicing must only be carried out by personnel familiar with both the vehicle system and the charging and testing equipment. All operations must be carried out in a well ventilated area away from open flame and heat sources. NOTE: Receiver drier need only be changed under the following circumstances. There is dirt in the refrigerant circuit (e.g. compressor seizure). The system is leaking and refrigerant has been lost to atmosphere. Refrigerant circuit has been open more than 24 hours due to repair.
  2. Remove dust caps from high and low pressure connectors.
  3. Connect high and low pressure hoses to appropriate connections.
  4. Open valves on connectors.
  5. Turn valves on refrigerant station to correct positions.
  6. Turn process switch to correct position.
  7. Turn Main switch to 'ON'.
  8. Allow station to recover refrigerant from system. WARNING: Refrigerant must always be recycled before re-use to ensure that the purity of the refrigerant is high enough for safe use in the air conditioning system. Recycling should always be carried out with equipment which is design certified by Underwriter Laboratory Inc. for compliance with SAE J1991. Other equipment may not recycle refrigerant to the required level of purity. A R134a Refrigerant Recovery Recycling Recharging Station must not be used with any other type of refrigerant. Refrigerant R134a from domestic and commercial sources must not be used in motor vehicle air conditioning systems.
  9. Close valves on refrigerant station.
  10. Turn Main switch to 'OFF'.
  11. Close valves on connectors.
  12. Disconnect high and low pressure connectors.
  13. Fit dust caps to connectors.
  14. Open tap at rear of station to drain refrigerant oil.
  15. Measure and record quantity of refrigerant oil recovered from system.
  16. Close tap at rear of station.

Evacuation

  1. Remove dust caps from high and low pressure connectors.
  2. Connect high and low pressure hoses to appropriate connections.
  3. Open valves on connectors.
  4. Turn valves on refrigerant station to correct positions.
  5. Turn Process switch to correct position.
  6. Turn Main switch to 'ON'.
  7. Allow station to evacuate system.

Recharging

  1. Recharge A/C system. CAUTION: The system must be evacuated immediately before recharging commences. Delay between evacuation and recharging is not permitted.
  2. Close valves on refrigerant station.
  3. Close valve on oil charger.
  4. Disconnect yellow hose from refrigerant station.
  5. Remove lid from oil charger.
  6. Pour same quantity of refrigerant oil into oil charger as collected during recovery. If the following components have been removed, add the following additional quantity of lubricating oil: Condenser = 30 cm 3 Desiccant bag = 30 cm 3 Evaporator = 20 cm 3 Pipe/hose = 10 cm 3
  7. Fit lid to oil charger.
  8. Connect yellow hose to refrigerant station.
  9. Open valve on oil charger.
  10. Move pointer on refrigerant gauge to mark position of refrigerant drop.
  11. Slowly open correct valve on refrigerant station and allow vacuum to pull refrigerant into system.
  12. Close valve on refrigerant station when correct amount of refrigerant has been drawn into air conditioning system.
  13. Turn Main switch to 'OFF'.
  14. Close valves on connectors.
  15. Disconnect high and low pressure connectors.

82.10.02 Drive belt -compressor-Td6

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 2

Scheme 2: Remove
Scheme 2: Remove
  1. Disconnect battery earth lead.
  2. Remove undertray.
  3. Using a 16 mm spanner, rotate tensioner clockwise and remove drive belt from compressor.
  4. Remove compressor drive belt.

Refit

  1. Ensure pulleys are clean and damage free.
  2. Fit compressor drive belt to crankshaft pulley, hold back tensioner and fit belt to compressor. Release tensioner and ensure belt is correctly aligned.
  3. Fit undertray.
  4. Connect battery earth lead.

82.10.02 Drive belt-compressor-V8

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 3

Scheme 3: Remove
Scheme 3: Remove

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Raise vehicle on lift.
  2. Disconnect battery earth lead.
  3. Remove undertray.
  4. Loosen 2 ancillary drive belt tensioner bolts.
  5. Rotate tensioner to release tension from drive belt.
  6. Release ancillary drive belt from tensioner pulley.
  7. Release ancillary drive belt from crankshaft pulley.
  8. Loosen 2 bolts securing compressor drive belt tensioner.
  9. Release compressor drive belt from tensioner pulley.
  10. Remove compressor drive belt from crankshaft pulley and compressor pulley.

Scheme 7

Scheme 7: Refit
Scheme 7: Refit

Scheme 8

Scheme 8
Scheme 8
  1. Ensure drive belt pulleys are clean and damage free.
  2. Fit compressor drive belt to compressor pulley and crankshaft pulley. NOTE: Make sure compressor drive belt is fully seated in pulley grooves.
  3. Fit compressor drive belt to tensioner.
  4. Rotate tensioner to fully tension compressor drive belt.
  5. Tighten 2 bolts securing compressor drive belt tensioner to 25 Nm (18 lbf.ft).
  6. Fit ancillary drive belt to all pulleys except tensioner pulley.
  7. Fit ancillary drive belt to tensioner pulley. Ensure ancillary drive belt is aligned to all pulleys.
  8. Rotate tensioner to fully tension ancillary drive belt.
  9. Tighten tensioner bolts to 30 Nm (22 lbf.ft).
  10. Fit undertray.
  11. connect battery earth lead.

Scheme 9

Scheme 9: Remove
Scheme 9: Remove

Scheme 10

Scheme 10
Scheme 10
  1. Remove compressor drive belt. «82.10.02 DRIVE BELT-COMPRESSOR-TD6»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation__821002-drive-belt-compressor-td6)
  2. Remove Allen bolt securing pulley arm to spring tensioner, withdraw arm assembly.
  3. Remove 2 bolts securing tensioner to mounting, noting fitted position remove tensioner.
  1. Position tensioner, fit bolts and tighten to 25 Nm (18 lbf.ft).
  2. Fit tensioner arm assembly and tighten Allen bolt to 10 Nm (7 lbf.ft).
  3. Fit compressor drive belt. «82.10.02 DRIVE BELT-COMPRESSOR-TD6»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation__821002-drive-belt-compressor-td6)

82.10.05 Tensioner -compressor drive belt-V8

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 11

Scheme 11: Remove
Scheme 11: Remove

Scheme 12

Scheme 12
Scheme 12
  1. Position vehicle on lift.
  2. Disconnect battery earth lead.
  3. Remove undertray.
  4. Loosen 2 compressor drive belt tensioner securing bolts.
  5. Remove 2 bolts securing compressor drive belt tensioner and remove tensioner.
  1. Position compressor drive belt tensioner, fit 2 bolts and tighten to 25 Nm (18 lbf.ft).
  2. Rotate tensioner to fully tension compressor drive belt. NOTE: Make sure compressor drive belt is fully seated in pulley grooves.
  3. Tighten 2 bolts securing compressor drive belt tensioner to 25 Nm (18 lbf.ft).
  4. Fit undertray.
  5. connect battery earth lead.

82.10.20 Compressor-Td6

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 13

Scheme 13: Remove
Scheme 13: Remove

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Raise front of vehicle. WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.
  2. Disconnect battery earth lead.
  3. Recover refrigerant from A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation) NOTE: Receiver drier need only be changed under the following circumstances. There is dirt in the refrigerant circuit (e.g. compressor seizure). The system is leaking and refrigerant has been lost to atmosphere. Refrigerant circuit has been open more than 24 hours due to repair.
  4. Remove turbocharger intake duct.
  5. Remove viscous coupling. «COUPLING UNIT -- VISCOUS FAN»(/land-rover/range-rover/iii-2002-2005/remont/cooling-system-mechanical/#cooling-system__coupling-unit-viscous-fan)
  6. Remove compressor drive belt. «82.10.02 DRIVE BELT-COMPRESSOR-TD6»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation__821002-drive-belt-compressor-td6)
  7. Remove Allen bolt securing pulley arm to spring tensioner, withdraw arm assembly.
  8. Remove 2 bolts securing A/C pipes to compressor. Release pipes from compressor. CAUTION: Always fit plugs to open connections to prevent contamination.
  9. Remove and discard 'O' rings from A/C pipes.
  10. Remove bolt securing intercooler hose support bracket to compressor and move aside.
  11. Disconnect multiplug from compressor.
  12. Remove bolt securing compressor earth lead, move lead aside.
  13. Remove bolt securing rear of compressor to mounting, release compressor from dowels and remove from vehicle.
  1. If a new compressor is being installed, drain the required amount of refrigerant oil from the new compressor. «AIR CONDITIONING SYSTEM PRECAUTIONS»(/land-rover/range-rover/iii-2002-2005/remont/oem-general-information/#general-information)
  2. Ensure mating faces of A/C pipes and compressor are clean.
  3. Clean compressor and mounting bracket mating faces.
  4. Ensure rear bolt is fitted to compressor, locate compressor onto dowels and finger tighten bolt.
  5. Fit bolt and intercooler support bracket to compressor.
  6. Fit bolt and secure compressor earth lead.
  7. Evenly and progressively tighten compressor mounting bolts to 25 Nm (18 lbf.ft).
  8. Lubricate new 'O' rings with clean refrigerant oil and fit to evaporator pipes
  9. Position A/C pipes to compressor, fit bolts and tighten to 22 Nm (16 lbf.ft).
  10. Connect multiplug to compressor.
  11. Fit tensioner arm assembly and tighten Allen bolt to 10 Nm (7 lbf.ft).
  12. Fit compressor drive belt. «82.10.02 DRIVE BELT-COMPRESSOR-TD6»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation__821002-drive-belt-compressor-td6)
  13. Fit viscous coupling. «COUPLING UNIT -- VISCOUS FAN»(/land-rover/range-rover/iii-2002-2005/remont/cooling-system-mechanical/#cooling-system__coupling-unit-viscous-fan)
  14. Fit turbocharger intake duct.
  15. Recharge A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  16. Connect battery earth lead.
  17. remove stands and lower vehicle.

82.10.20 Compressor-V8

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 17

Scheme 17: Remove
Scheme 17: Remove

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Position vehicle on lift.
  2. Disconnect battery earth lead.
  3. Recover refrigerant from A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation) Receiver drier need only be changed under the following circumstances. There is dirt in the refrigerant circuit (e.g. compressor seizure). The system is leaking and refrigerant has been lost to atmosphere. Refrigerant circuit has been open more than 24 hours due to repair.
  4. Remove air intake pipe. «HOSE -- AIR FLOW METER TO THROTTLE BODY»(/land-rover/range-rover/iii-2002-2005/remont/removal-installation/#engine-management-removal-installation)
  5. Remove A/C compressor drive belt. «82.10.02 DRIVE BELT-COMPRESSOR-V8»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation__821002-drive-belt-compressor-v8)
  6. Remove 2 bolts securing A/C compressor drive belt adjusting plate to sump.
  7. Position A/C tensioner toward crankshaft pulley to aid removal of A/C compressor.
  8. Disconnect multiplug from A/C compressor.
  9. Remove bolt securing rear of A/C compressor to mounting.
  10. Remove 2 Allen bolts securing A/C pipes to A/C compressor. Release pipes from A/C compressor. CAUTION: Always fit plugs to open connections to prevent contamination.
  11. Remove and discard 'O' rings from A/C pipes.
  12. Remove 2 bolts securing A/C compressor to mounting. NOTE: Top securing bolt needs to stay located into compressor on removal and installation.
  13. Remove A\C compressor
  1. If a new compressor is being installed, drain the required amount of refrigerant oil from the new compressor. «AIR CONDITIONING SYSTEM PRECAUTIONS»(/land-rover/range-rover/iii-2002-2005/remont/oem-general-information/#general-information)
  2. Ensure mating faces of A/C pipes and A/C compressor are clean.
  3. Clean A/C compressor and mounting bracket mating faces.
  4. Fit A/C compressor to mounting bracket. Fit 3 securing bolts. NOTE: Top securing bolt needs to stay located into compressor on removal and installation.
  5. Evenly and progressively tighten A/C compressor mounting bolts to 25 Nm (18 lbf.ft).
  6. Lubricate new 'O' rings with clean refrigerant oil and fit to evaporator pipes
  7. Position A/C pipes to A/C compressor, fit bolts and tighten to 22 Nm (16 lbf.ft).
  8. Connect multiplug to A/C compressor.
  9. Tighten 2 bolts securing compressor drive belt tensioner to 25 Nm (18 lbf.ft).
  10. Fit A/C compressor drive belt. «82.10.02 DRIVE BELT-COMPRESSOR-V8»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation__821002-drive-belt-compressor-v8)
  11. Fit air intake pipe. «HOSE -- AIR FLOW METER TO THROTTLE BODY»(/land-rover/range-rover/iii-2002-2005/remont/removal-installation/#engine-management-removal-installation)
  12. Recharge A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  13. Connect battery earth lead.

82.15.01 Motor-condenser fan

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 21

Scheme 21: Remove
Scheme 21: Remove

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Disconnect battery earth lead.
  2. Remove front bumper. «76.22.72 BUMPER -- ASSEMBLY -FRONT»(ref-208059-S28552961812005120200000)
  3. Release 4 cable ties securing washer hose to armature and move hose aside.
  4. Disconnect horn multiplugs.
  5. Remove 2 screws securing armature extension and remove extension from armature.
  6. Remove 3 bolts securing LH bumper support bracket. Repeat for RH bracket and remove.
  7. Remove screw and scrivet securing LH air intake deflector, repeat operation on RH. Remove deflectors.
  8. Remove 8 nuts and 4 bolts securing armature. Cut 2 cable ties and release harness, remove armature. NOTE: Do not carry out further dismantling if component is removed for access only.
  9. Disconnect multiplug from condenser cooling fan motor.
  10. Depress clips and remove condenser fan cowl.
  11. Depress 7 clips securing fan guard and remove from cowl.
  12. Hold fan assembly, rotate nut anti clockwise and remove fan from motor.
  13. Release fan motor harness from cowl.
  14. Remove 3 Torx screws securing fan motor to condenser cowl, remove motor.
  1. Position fan and motor assembly to fan cowl, fit and tighten bolts to 5 Nm (3.7 lbf.ft).
  2. Secure cooling fan harness in clips on fan cowl.
  3. Position fan to motor and align lugs. Hold fan, rotate center nut clockwise to secure.
  4. Position fan guard and secure clips.
  5. Position condenser fan cowl to mounting and secure clips.
  6. Connect fan motor multiplug.
  7. Position armature to body fit nuts and bolts, tighten bolts to 10 Nm (7 lbf.ft), tighten nuts to 45 Nm (33 lbf.ft).
  8. Secure harness with cable ties.
  9. Fit and secure bumper support brackets, tighten bolts to 3 Nm (2.2 lbf.ft), fit scrivets.
  10. Fit and secure air deflectors.
  11. Fit and secure armature extension.
  12. Connect horn multiplugs.
  13. Position hose to armature and secure with new cable ties.
  14. Fit front bumper. «76.22.72 BUMPER -- ASSEMBLY -FRONT»(ref-208059-S28552961812005120200000)
  15. Connect battery earth lead.

82.15.07 Condenser

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 30

Scheme 30: Remove
Scheme 30: Remove

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Disconnect battery earth lead.
  2. Recover refrigerant from A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  3. Remove viscous coupling. «COUPLING UNIT -- VISCOUS FAN»(/land-rover/range-rover/iii-2002-2005/remont/cooling-system-mechanical/#cooling-system__coupling-unit-viscous-fan)
  4. Remove radiator assembly retaining bolts from bonnet locking platform.
  5. Ease radiator assembly rearward, release and remove radiator retaining clips.
  6. Remove 2 Allen screws securing A/C pipes to condenser, disconnect pipes and discard 'O' rings. CAUTION: Before disconnecting or removing components, ensure the immediate area around joint faces and connections are clean. Plug open connections to prevent contamination.
  7. Remove Torx screw securing condenser to mounting.
  8. Carefully remove condenser.
  1. Fit and secure condenser with Torx screw.
  2. Position radiator to mounting, fit and secure retaining clips.
  3. Position and secure radiator assembly to bonnet locking platform.
  4. Lubricate new 'O' rings with clean refrigerant oil, fit one seal to each condenser pipe.
  5. Fit A/C pipes to condenser, fit bolts and tighten to 9 Nm (7 lbf.ft).
  6. Fit viscous coupling. «COUPLING UNIT -- VISCOUS FAN»(/land-rover/range-rover/iii-2002-2005/remont/cooling-system-mechanical/#cooling-system__coupling-unit-viscous-fan)
  7. Recharge A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  8. Connect battery earth lead.

82.17.05 Drier desiccant bag

Note. The desiccant bag/receiver drier need only be changed under the following circumstances

  1. There is dirt in the refrigerant circuit (e.g. compressor seizure).
  2. The system is leaking and refrigerant has been lost to atmosphere.
  3. Refrigerant circuit has been open more than 24 hours due to repair.

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 33

Scheme 33: Remove
Scheme 33: Remove

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Disconnect battery earth lead.
  2. Recover refrigerant from A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  3. Remove viscous coupling. «COUPLING UNIT -- VISCOUS FAN»(/land-rover/range-rover/iii-2002-2005/remont/cooling-system-mechanical/#cooling-system__coupling-unit-viscous-fan)
  4. Remove radiator assembly retaining bolts from bonnet locking platform.
  5. Ease radiator assembly rearward, release and remove radiator retaining clips.
  6. Remove desiccant bag cover from condenser. CAUTION: Before disconnecting or removing components, ensure the immediate area around joint faces and connections are clean. Plug open connections to prevent contamination.
  7. Fit a 5 mm bolt to desiccant bag plug, depress plug and remove circlip.
  8. Withdraw plug, carefully remove and discard desiccant bag from condenser.
  9. Remove and discard 'O' rings.
  1. Clean condenser opening and plug.
  2. Fit desiccant bag.
  3. Lubricate new 'O' rings with clean refrigerant oil, fit and secure plug with circlip. Remove bolt from plug.
  4. Fit desiccant bag cover.
  5. Position radiator to mounting, fit and secure retaining clips.
  6. Position and secure radiator assembly to bonnet locking platform.
  7. Fit viscous coupling. «COUPLING UNIT -- VISCOUS FAN»(/land-rover/range-rover/iii-2002-2005/remont/cooling-system-mechanical/#cooling-system__coupling-unit-viscous-fan)
  8. Recharge A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  9. Connect battery earth lead.

82.20.38 Sensor-refrigerant pressure

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 36

Scheme 36: Remove
Scheme 36: Remove
  1. Disconnect battery earth lead.
  2. Recover refrigerant from A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  3. Release multiplug from refrigerant pressure sensor. WARNING: Under no circumstances should refrigerant hoses be disconnected without first discharging the system.
  4. Remove refrigerant pressure sensor from air conditioning (A/C) pipe mounting. Use two spanners to avoid straining A/C pipe mounting. CAUTION: Immediately cap all A/C pipes to prevent ingress of dirt and moisture into the system.
  5. Discard 'O' ring.
  1. Clean refrigerant pressure switch and surrounding area.
  2. Fit new 'O' ring to sensor and tighten to 10 Nm (7 lbf.ft).
  3. Fit multiplug to sensor.
  4. Recharge air conditioning system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  5. Connect battery earth lead.

Scheme 37

Scheme 37: Remove
Scheme 37: Remove
  1. Make the SRS system safe. «SRS COMPONENT REPLACEMENT POLICY»(/land-rover/range-rover/iii-2002-2005/remont/oem-general-information/#general-information__srs-component-replacement-policy)
  2. Remove fascia carrier. «76.46.22 FASCIA -- CARRIER»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764622-fascia-carrier)
  3. Release and remove solar sensor.
  1. Fit solar sensor.
  2. Fit fascia carrier. «76.46.22 FASCIA -- CARRIER»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764622-fascia-carrier)

Scheme 38

Scheme 38: Remove
Scheme 38: Remove
  1. Remove heating control assembly. «80.10.02 CONTROLS -- HEATER (ECU)»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation__801002-controls-heater-ecu)
  2. Disconnect multiplug from air temperature sensor.
  3. Remove sensor from heating assembly.
  1. Fit sensor to heater assembly and connect multiplug.
  2. Fit heating control assembly. «80.10.02 CONTROLS -- HEATER (ECU)»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation__801002-controls-heater-ecu)

82.20.95 Sensor-evaporator temperature-LHD

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Remove

  1. Set heater control to de-mist. CAUTION: Failure to comply will result in damage to footwell vent flap.
  2. Disconnect battery earth lead.
  3. Remove glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  4. Noting fitted position, disconnect 8 multiplugs from fuse box.
  5. Remove 4 Torx screws securing the fuse box, position the fuse box aside.
  6. Remove screw securing footwell heating duct to fuse box mounting bracket. Remove duct.
  7. Remove 4 Torx screws and spring clip from RH heating duct elbow. Remove elbow. CAUTION: Contain spring clip prior to release.
  8. Disconnect multiplug from evaporator sensor, release harness and remove sensor.
  1. Carefully fit sensor and secure grommet.
  2. Connect multiplug and secure harness.
  3. Position and secure heating duct elbow.
  4. Position and secure footwell heating duct.
  5. Position fuse box and secure with screws.
  6. Connect multiplugs to fuse box.
  7. Fit glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  8. Connect battery earth lead.

82.20.95 Sensor-evaporator temperature-RHD

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

  1. Set heater control to de-mist. CAUTION: Failure to comply will result in damage to footwell vent flap.
  2. Disconnect battery earth lead.
  3. Remove closing panel. «76.46.27 CLOSING PANEL - PASSENGER SIDE»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  4. Remove shroud. «76.46.05 SHROUD - LOWER - FASCIA»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764605-shroud-lower-fascia)
  5. Remove screw securing footwell heating duct to carrier. Remove duct.
  6. Remove 4 Torx screws and spring clip from RH heating duct elbow. Remove elbow. CAUTION: Contain spring clip prior to release.
  7. Disconnect multiplug from evaporator sensor, release harness and remove sensor.
  1. Carefully fit sensor and secure grommet.
  2. Connect multiplug to sensor and secure harness.
  3. Position and secure heating duct elbow.
  4. Position and secure footwell heating duct.
  5. Fit shroud. «76.46.05 SHROUD - LOWER - FASCIA»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764605-shroud-lower-fascia)
  6. Fit closing panel. «76.46.27 CLOSING PANEL - PASSENGER SIDE»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings)

82.25.01 Valve-thermostatic expansion (TXV)-LHD

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 39

Scheme 39: Remove
Scheme 39: Remove

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. Disconnect battery earth lead.
  2. Remove air intake plenum. «80.15.62 PLENUM - AIR INTAKE»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  3. Recover refrigerant from A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  4. Remove glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  5. Noting fitted position, disconnect 8 multiplugs from fuse box.
  6. Remove 4 Torx screws securing the fuse box, position the fuse box aside.
  7. Remove screw securing footwell heating duct to carrier. Remove duct.
  8. Release evaporator sensor harness from TXV cover.
  9. Remove 4 Torx screws securing TXV cover and position aside.
  10. Remove 2 Allen bolts securing A/C pipes to bulkhead, release pipes and discard 'O' rings.
  11. Remove 2 Allen bolts securing A/C pipes to TXV, remove clamps, release pipes and discard 'O' rings.
  12. Remove TXV.
  13. Plug all connections.
  1. Clean mating faces and seal recesses on evaporator, TXV and A/C pipes.
  2. Lubricate new 'O' rings with clean refrigerant oil and fit to A/C pipes.
  3. Position TXV to A/C pipes, fit clamps, fit bolts and tighten to 6 Nm (4. 4 lbf.ft).
  4. Position A/C pipes to bulkhead, fit bolts and tighten to 6 Nm (4.4 lbf.ft).
  5. Fit and secure TXV cover.
  6. Position and secure footwell heating duct.
  7. Secure evaporator sensor harness.
  8. Position fuse box and secure with screws.
  9. Connect multiplugs to fuse box.
  10. Fit glove box. «76.52.03 GLOVE BOX»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings)
  11. Recharge A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  12. Fit air intake plenum. «80.15.62 PLENUM - AIR INTAKE»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  13. Connect battery earth lead.

82.25.01 Valve-thermostatic expansion (TXV)-RHD

Before disconnecting the battery, ensure all text and cautions in the battery disconnection section are observed.

Scheme 45

Scheme 45: Remove
Scheme 45: Remove

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47
  1. Disconnect battery earth lead.
  2. Remove air intake plenum. «80.15.62 PLENUM - AIR INTAKE»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  3. Recover refrigerant from A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  4. Remove drivers side footwell closing panel.
  5. Remove shroud. «76.46.05 SHROUD - LOWER - FASCIA»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764605-shroud-lower-fascia)
  6. Remove screw securing footwell heating duct, remove duct.
  7. Release evaporator sensor harness from TXV cover.
  8. Remove 4 Torx screws securing TXV cover and position aside.
  9. Remove 2 Allen bolts securing A/C pipes to bulkhead, release pipes and discard 'O' rings.
  10. Remove 2 Allen bolts securing A/C pipes to TXV, remove clamps, release pipes and discard 'O' rings.
  11. Remove TXV.
  12. Plug all connections.
  1. Clean mating faces and seal recesses on TXV and A/C pipes.
  2. Lubricate new 'O' rings with clean refrigerant oil and fit to A/C pipes.
  3. Position TXV to A/C pipes, fit clamps, fit bolts and tighten to 6 Nm (4. 4 lbf.ft).
  4. Position A/C pipes to bulkhead, fit bolts and tighten to 6 Nm (4.4 lbf.ft).
  5. Fit and secure TXV cover.
  6. Secure evaporator sensor harness.
  7. Position and secure footwell heating duct.
  8. Fit shroud. «76.46.05 SHROUD - LOWER - FASCIA»(/land-rover/range-rover/iii-2002-2005/remont/exteriorinterior-trim/#interior-fittings__764605-shroud-lower-fascia)
  9. Fit footwell closing panel.
  10. Recharge A/C system. «82.30.02 REFRIGERANT RECOVERY-RECYCLING AND RECHARGE»(/land-rover/range-rover/iii-2002-2005/remont/automatic-hvac-system/#air-conditioning-recovery-removal-installation)
  11. Fit air intake plenum. «80.15.62 PLENUM - AIR INTAKE»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  12. Connect battery earth lead.

Scheme 48

Scheme 48: Remove
Scheme 48: Remove

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52
  1. Remove HEVAC assembly. «80.20.01.99 HEATER UNIT HEVAC - REMOVE FOR ACCESS & REFIT»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)
  2. Position HEVAC assembly upside down.
  3. Remove 2 Torx screws securing LH heating duct elbow to HEVAC assembly. Remove elbow.
  4. Remove 4 Torx screws and spring clip from RH heating duct elbow. Remove elbow.
  5. Disconnect multiplug from evaporator sensor, release harness and remove sensor.
  6. Disconnect multiplug and remove rear air vent motor.
  7. Remove 4 Torx screws securing TXV cover and position aside.
  8. Remove 7 Torx screws and 3 spring clips from lower HEVAC access panel.
  9. Release 2 clips and remove access panel.
  10. Remove 2 Allen bolts securing A/C pipes to TXV, remove clamps, release pipes and discard 'O' rings.
  11. Remove TXV.
  12. Remove evaporator assembly.
  1. Clean mating faces and seal recesses on evaporator, TXV and A/C pipes.
  2. Lubricate new 'O' rings with clean refrigerant oil and fit to A/C pipes.
  3. Fit evaporator assembly.
  4. Position TXV to A/C pipes, fit clamps, fit bolts and tighten to 6 Nm (4.4 lbf.ft).
  5. Fit and secure access panel.
  6. Fit and secure TXV cover.
  7. Fit motor to heating assembly and connect multiplug.
  8. Carefully fit sensor and secure grommet.
  9. Connect multiplug to sensor and secure harness.
  10. Position RH heating duct elbow to HEVAC assembly, secure with clip and screws.
  11. Position LH heating duct elbow to HEVAC assembly and secure with screws.
  12. Fit HEVAC assembly to fascia. «80.20.01.99 HEATER UNIT HEVAC - REMOVE FOR ACCESS & REFIT»(/land-rover/range-rover/iii-2002-2005/remont/heater/#heating-and-ventilation-removal-installation)

More articles — HVAC
