Scheme 1
LUBRICATION SPECIFICATIONS
| Material | Condition | Specification |
|---|---|---|
| Engine Oil (1) | Ambient Temperature From -22°F (-30°C) To Over 95°F (35°C) | SAE 5W-30 |
| Engine Oil (1) | Ambient Temperature From -22°F (-30°C) To 122°F (50°C) | SAE 5W-40 Or SAE 5W-50 |
| Engine Oil (1) | Ambient Temperature From 14°F (-10°C) To 104°F (40°C) | SAE 10W-30 |
| Engine Oil (1) | Ambient Temperature From 14°F (-10°C) To 122°F (50°C) | SAE 10W-40 |
| Brake Fluid | All | DOT 4 |
| Engine Coolant | Protects Against Frost Down To -33°F (-36°C) | 50/50 Mixture DistilledWater & Ethylene Glycol |
| Main Gearbox, Automatic | All | ATF DEXRON III |
| Main Gearbox, Manual | All | ATF DEXRON III |
| Transfer Gearbox | All | MIL-L-2105 MIL-L-2105B,C,D |
| Final Drive Units, SwivelPin Housings | All | MIL-L-2105 MIL-L-2105B,C,D |
| Power Steering Fluid | All | ATF DEXRON III |
| Battery Terminals | All | Petroleum Jelly |
| Door Locks | All | FUCHS RENOCAL FN745 |
| (1) Energy conserving oils are recommended, API classification SG", "SH". | ||
| (1) | Energy conserving oils are recommended, API classification SG", "SH". |
LUBRICATION SPECIFICATIONS
FLUID CAPACITIES
| Item | Condition | Specification (1) |
|---|---|---|
| Engine Oil | Drained | 7.0 Qts. (6.6L) |
| Engine Coolant | Drained | 12.0 Qts. (11.3L) |
| Automatic Gearbox | Capacity | 11.6 Qts. (11L) |
| Transfer Box | Capacity | 2.4 Qts. (2.3L) |
| Front Differential | Capacity | 1.8 Qts. (1.7L) |
| Rear Differential | Capacity | 1.8 Qts. (1.7L) |
| Washer Reservoir | Capacity | 6.3 Qts. (6.0L) |
| Fuel Tank | Full Capacity | 24.6 Gal. (93.0L) |
| (1) Capacities are recommended or calculated levels. Always use dipstick (if available) to measure level. | ||
| (1) | Capacities are recommended or calculated levels. Always use dipstick (if available) to measure level. |
FLUID CAPACITIES
WHEEL TIGHTENING
Tighten all wheel lug nuts to 80 ft. lbs. (108 N.m).
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
SUPPLEMENTAL RESTRAINT SYSTEM - AIR BAG
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in ACCESSORIES/SAFETY EQUIPMENT. |
Modification to the air bag system component or wiring can adversely affect system performance and possibly cause injury.
| CAUTION | The Diagnostic Energy Reserve Module (DERM) can maintain enough voltage to cause a deployment of the inflator module for up to 10 minutes after the ignition switch is turned off and the battery is disconnected. Many of the service procedures require disconnection of the inflator module to avoid an accidental deployment. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
AIR CONDITIONING SERVICING
| WARNING | Avoid breathing R-134a refrigerant and PAG lubricant vapors, exposure may irritate eyes, nose and throat. To remove R-134a from system use R-134a recycling equipment that meets SAE J2210 specifications. If accidental system discharge occurs, ventilate work area before resuming service. |
| WARNING | R-134a service equipment or vehicle A/C systems SHOULD NOT be pressure tested or leak tested with compressed air. Some mixtures of air/R134a have shown to be combustible at elevated pressures. These mixtures are dangerous and may cause fire and/or explosions. See AIR CONDITIONING SERVICE article in GENERAL INFORMATION section. |
ANTI-LOCK BRAKE SYSTEM
| CAUTION | The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals. |
On models equipped with anti-lock brake systems, ALWAYS observe the following cautions
- DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
- DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
- Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.
REPLACING BLOWN FUSES
| CAUTION | Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload. |
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
| CAUTION | To prevent catalytic converter overheating, DO NOT allow engine to idle for more than 20 minutes. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component. |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
METHANOL GASOLINE
| CAUTION | Fuel that is more than 5% methanol should not be used in this vehicle. It can corrode metal parts in the fuel system, and damage plastic and rubber parts. Even at 5% methanol or less, solvents and corrosion preventers must be used with this fuel to avoid these problems. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
SPARK PLUGS
Note. Allow engine to cool before removing spark plugs from aluminum cylinder heads.
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
NEW VEHICLE LIMITED WARRANTY
Everything covered for 3 years or 42,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle which have proven defective during material and workmanship in normal use (tires excluded). Warranty repairs (parts and labor) will be made by the dealer at no charge using new or remanufactured parts by the dealer.
CORROSION COVERAGE
Body sheet metal panels are covered against rust or corrosion for 6 years regardless of mileage.
EMISSIONS "DEFECT" & "PERFORMANCE" WARRANTIES (EXCEPT CALIFORNIA)
The Emissions Defect Warranty and the Emissions Performance Warranty begin on the date the vehicle is first delivered or put into use and continues for a period of 3 years or 42,000 miles, whichever occurs first.
Defect Warranty ensures that vehicle meets applicable EPA regulations and that vehicle's emission control system is free from defects in materials and workmanship.
The Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a Federally required state or local emissions test.
Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.
Under the Defect Warranty and the Performance Warranty, if a catalytic converter or vehicle (powertrain) control module is found to be defective, the parts are covered for a period of 8 years or 80,000 miles, whichever occurs first.
EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)
If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure that vehicle passes the inspection. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
EMISSION "DEFECT" WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Warranty begins at warranty start date and lasts for a period of 3 years or 50,000 miles, whichever occurs first.
Some emission-related parts are warranted for 7 years or 70,000 miles, whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.
FUSE BLOCK LOCATIONS
There are two fuse block locations. One fuse block is located in the dashboard on the passenger side. The other fuse box is located in the engine compartment.
Scheme 2
Scheme 3
MAIN FUSE BLOCK IDENTIFICATION
Note. (Scheme 2)
Fuse Identification
- 1 - 10 Amp Instrument Pack, Clock, Radio, Center Console
- 2 - 30 Amp RH Rear Window, Seat Heaters
- 3 - 5 Amp Automatic Gearbox ECU
- 4 - 30 Amp Transfer Box ECU
- 5 - Not Used
- 6 - 10 Amp Rear Window Mirror Dip, Automatic Gearbox ECU, Sun Visor Illumination, Transfer Box ECU
- 7 - 10 Amp Airbag SRS
- 8 - 30 Amp Car Phone, Aerial Amplifier, Cigar Lighter, Radio, Heating, Ventilation & Air Conditioning
- 9 - 20 Amp Front Audio System Amplifiers, Front Doors
- 10 - 30 Amp RH Seat
- 11 - Not Used Insert Fuse - 5 Amp Or More To Select Transfer Neutral
- 12 - 30 Amp Heated Rear Screen & LH Rear Window
- 13 - 20 Amp Shift Interlock Solenoid, Key Inhibit Solenoid, Sunroof
- 14 - 20 Amp Rear Central Door Locking, Fuel Flap Solenoid, Trailer Socket, Tailgate Central Door Locking
- 15 - 20 Amp Courtesy Lights, Handset Receiver, Load Space Light, Rear Wiper, Sub-Woofer, Rear Audio System Amplifiers
- 16 - Not Used
- 17 - 10 Amp Brake Switch, Heating, Ventilation & Air Conditioning, Air Suspension Switches
- 18 - Not Used
- 19 - Not Used
- 20 - 30 Amp LH Seat
- 21 - Not Used
- 22 - 30 Amp LH & RH Front Doors (Windows Only)
ENGINE COMPARTMENT FUSE BOX IDENTIFICATION
Note. (Scheme 3)
- 23 - 10 Amp Air Bag SRS
- 24 - 5 Amp ABS & Air Suspension
- 25 - 20 Amp Front Wiper System
- 26 - 20 Amp Engine Management System
- 27 - 30 Amp ABS
- 28 - 10 Amp Not Used
- 29 - 20 Amp Not Used
- 30 - 30 Amp Heated Front Screen
- 31 - 30 Amp Air Conditioning
- 32 - 30 Amp Heated Front Screen
- 33 - 5 Amp Diagnostics
- 34 - 25 Amp Heater Blower
- 35 - 5 Amp Not Used
- 36 - 30 Amp Air Conditioning
- 37 - 20 Amp Engine Management System (EMS)
- 38 - 10 Amp Headlight Wash
- 39 - 10 Amp Fuel Pump
- 40 - 30 Amp Not Used
- 41 - 20 Amp Horn
- 42 - 10 Amp Heating & Ventilation
- 43 - 25 Amp Heater Blower
- 44 - 10 Amp Air Suspension
Maxi Fuse Identification
- Maxi 1 - 60 Amp ( 1 )
- Maxi 2 - 30 Amp Air Suspension
- Maxi 3 - 40 Amp Heating & Ventilation
- Maxi 4 - 60 Amp ( 1 )
- Maxi 5 - 60 Amp ( 1 )
Note. ( 1 ) - Failure of one of these fuses will result in the message center displaying various messages simultaneously. DO NOT attempt to replace the fuse; contact a Land Rover Dealer.
