SPECIFICATIONS

DescriptionNm
Low tire pressure module bolts1.5

TORQUE SPECIFICATIONS

INSPECTION AND VERIFICATION

  1. Verify the customer concern.
  2. Visually inspect for obvious signs of mechanical or electrical damage.
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step
  4. If the cause is not visually evident, verify the symptom and refer to the Symptom Chart.

LOW TIRE PRESSURE MODULE

Note. If the tire pressure module is to be replaced then T4 must be connected and the correct procedures adhered to, prior to battery disconnection.

Scheme 1

Scheme 1: LOW TIRE PRESSURE MODULE

Scheme 2

Scheme 2

Scheme 3

Scheme 3
  1. Disconnect the battery ground cable. For additional information, refer to: SPECIFICATIONS .
  2. Remove the LH A-pillar upper trim panel. For additional information, refer to: A-PILLAR TRIM PANEL (Removal and Installation).
  3. Remove the LH B-pillar upper trim panel. For additional information, refer to: B-PILLAR UPPER TRIM PANEL (Removal and Installation).
  4. Remove the LH C-pillar upper trim panel. For additional information, refer to: C-PILLAR UPPER TRIM PANEL (Removal and Installation).
  5. Remove the LH sun visor. Remove the cover. Remove the 2 screws. Disconnect the electrical connector.
  6. Remove the sun visor retaining clip. Release the screw cover. Remove the screw.
  7. Remove the LH passenger assist handles. Carefully release the 6 screw covers. Remove the 6 screws.
  8. Release the LH side of the headliner. Release the 6 clips.
  9. Remove the low tire pressure module. Disconnect the 2 electrical connectors. Remove the 2 bolts.
