Contents Wiring diagrams Section: Frames, Subframes & Crossmembers All sections

Full Frame and Body Mounting Land Rover Range Rover Sport L320

Frames, Subframes & Crossmembers 46 illustrations ~1749 words

SPECIFICATIONS

DescriptionNm
HO2s harness bracket bolt10
Transmission support crossmember nuts and bolts90
Transmission support insulator through-bolt175
Transmission undershield bolts10
*Integrated-body frame to body bolts133

TORQUE SPECIFICATIONS

* New bolts must be installed

TOW BAR MOUNTING CHECK

SPECIAL TOOLS Tool Illustration Tool Name Tool Number Tow Bar Gauge JLR-501-201

Scheme 1

Scheme 1: TOW BAR MOUNTING CHECK
Scheme 1: TOW BAR MOUNTING CHECK

Scheme 2

Scheme 2
Scheme 2
  1. Pre test: Check the detachable tow bar locking pin is moving freely without sticking.
  2. Insert the tow bar into the chassis following the owners handbook instruction.
  3. Hold the special tool JLR-501-201 against the tow bar as shown, failure to follow this instruction may result in an incorrect measurement.
  4. Install the special tool as shown.
  5. Check the position of the tow bar release handle against the special tool, and observe the following: If the tow bar release handle points to the red area of the special tool, go to Step 6. If the tow bar release handle points outside of the red area of the special tool, then the tow bar mounting is correct and no further action is required.
  6. Install a new tow bar and check the tow bar mounting following Steps 3 - 5. If the tow bar release handle points to the red area of the special tool, install a new rear crossmember. See «REAR CROSSMEMBER»(/land-rover/range-rover-sport/l320-2009-2013/remont/frames-subframes-crossmembers/#full-frame-and-body-mounting) .

REMOVAL

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Some illustrations may show the engine removed for clarity.

Scheme 3

Scheme 3: REMOVAL
Scheme 3: REMOVAL

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Remove the battery for access. Refer to «BATTERY»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-mounting-and-cables) .
  2. Refer to «AIR CLEANER LH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  3. Refer to «AIR CLEANER RH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  4. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/land-rover/range-rover-sport/l320-2009-2013/remont/ac-compressor/#climate-control-system-general-information__air-conditioning-ac-system-recovery-evacuation) .
  5. Refer to «COOLANT EXPANSION TANK - V8 5.0L PETROL, 5.0L»(/land-rover/range-rover-sport/l320-2009-2013/remont/cooling-fan/#engine-cooling) .
  6. Remove and discard the 2 O-ring seals.
  7. Remove and discard the O-ring seal.
  8. Discard the O-ring seal.
  9. Refer to «AUXILIARY BATTERY TRAY»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-mounting-and-cables) .
  10. Remove and discard the bolt.
  11. Raise and support the vehicle.
  12. Refer to «FRONT BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  13. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  14. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  15. Remove the fuel filler cap.
  16. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  17. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  18. Lower the vehicle.
  19. Remove and discard the 10 body mount bolts. Remove the 10 spacing washers.
  20. Using an assistant raise and support the body. Remove the body mounts.

Scheme 34

Scheme 34: INSTALLATION
Scheme 34: INSTALLATION

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. Using an assistant install the body to the integrated body frame. Install the body mounts. With assistance align the body and integrated body frame mounts. Install the bolts, but do not tighten fully at this stage.
  2. Remove the tie down straps securing the body.
  3. TORQUE: 133 Nm
  4. TORQUE: 45 Nm
  5. TORQUE: 45 Nm
  6. TORQUE: 45 Nm
  7. TORQUE: 45 Nm
  8. TORQUE: 25 Nm
  9. TORQUE: 12 Nm
  10. TORQUE: 12 Nm
  11. TORQUE: 12 Nm
  12. Install the fuel filler cap.
  13. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  14. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  15. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  16. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  17. TORQUE: 25 Nm
  18. TORQUE: 12 Nm
  19. TORQUE: 20 Nm
  20. TORQUE: 20 Nm
  21. TORQUE: 12 Nm Install new O-ring seals.
  22. TORQUE: 12 Nm Install new O-ring seals.
  23. TORQUE: 12 Nm Install new O-ring seals.
  24. TORQUE: 8 Nm
  25. TORQUE: 10 Nm
  26. Refer to «COOLANT EXPANSION TANK - V8 5.0L PETROL, 5.0L»(/land-rover/range-rover-sport/l320-2009-2013/remont/cooling-fan/#engine-cooling) .
  27. TORQUE: 10 Nm
  28. Refer to «FRONT BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  29. Refer to «REAR BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  30. Refer to «AIR CLEANER LH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  31. Refer to «AIR CLEANER RH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  32. TORQUE: 10 Nm
  33. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/land-rover/range-rover-sport/l320-2009-2013/remont/ac-compressor/#climate-control-system-general-information__air-conditioning-ac-system-recovery-evacuation) .
  34. Refer to «BATTERY»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-mounting-and-cables) .
  35. Check and top-up the coolant Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - V8 5.0L PETROL»(/land-rover/range-rover-sport/l320-2009-2013/remont/cooling-fan/#engine-cooling) .
  36. Bleed the braking system. Refer to «BRAKE SYSTEM BLEEDING - VEHICLES WITH: STANDARD BRAKES»(/land-rover/range-rover-sport/l320-2009-2013/remont/anti-locktraction-control/#brake-system-general-information__brake-system-bleeding-vehicles-with-standard) .

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Some illustrations may show the engine removed for clarity.

Scheme 38

Scheme 38
Scheme 38
  1. Remove the battery for access. Refer to «BATTERY»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-mounting-and-cables) .
  2. Refer to «AIR CLEANER LH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  3. Refer to «AIR CLEANER RH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  4. Refer to «COOLANT EXPANSION TANK - V8 S/C 5.0L PETROL, 5.0L»(/land-rover/range-rover-sport/l320-2009-2013/remont/cooling-fan/#engine-cooling) .
  5. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/land-rover/range-rover-sport/l320-2009-2013/remont/ac-compressor/#climate-control-system-general-information__air-conditioning-ac-system-recovery-evacuation) .
  6. Remove and discard the 2 O-ring seals.
  7. Remove and discard the O-ring seal.
  8. Discard the O-ring seal.
  9. Refer to «AUXILIARY BATTERY TRAY»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-mounting-and-cables) .
  10. Remove and discard the bolt.
  11. Raise and support the vehicle.
  12. Refer to «FRONT BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  13. See figure CAUTION: Before disconnecting or removing the components, make sure the area around the joint faces and connections are clean. Plug open connections to prevent contamination. CAUTION: If brake fluid is spilled on the paintwork, the affected area must be immediately washed down with cold water. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  14. See figure CAUTION: Before disconnecting or removing the components, make sure the area around the joint faces and connections are clean. Plug open connections to prevent contamination. CAUTION: If brake fluid is spilled on the paintwork, the affected area must be immediately washed down with cold water. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  15. Refer to «REAR BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  16. Remove the fuel filler cap.
  17. See figure CAUTION: Before disconnecting or removing the components, make sure the area around the joint faces and connections are clean. Plug open connections to prevent contamination. CAUTION: If brake fluid is spilled on the paintwork, the affected area must be immediately washed down with cold water. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  18. Position an absorbent cloth to collect fluid spillage. Disconnect the line union. Remove the clip.
  19. Lower the vehicle.
  20. Remove and discard the 10 body mount bolts. Remove the 10 spacing washers.
  21. Using an assistant raise and support the body. Remove the body mounts.

Scheme 39

Scheme 39
Scheme 39
  1. Using an assistant install the body to the integrated body frame. Install the body mounts. With assistance align the body and integrated body frame mounts. Install the bolts, but do not tighten fully at this stage.
  2. Remove the tie down straps securing the body.
  3. TORQUE: 133 Nm
  4. Raise the vehicle on the lift.
  5. TORQUE: 45 Nm
  6. TORQUE: 45 Nm
  7. TORQUE: 45 Nm
  8. TORQUE: 45 Nm
  9. TORQUE: 25 Nm
  10. TORQUE: 12 Nm
  11. TORQUE: 12 Nm
  12. TORQUE: 12 Nm
  13. Install the fuel filler cap.
  14. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  15. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  16. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  17. TORQUE: 16 Nm Clean the component mating faces. Secure the clip.
  18. TORQUE: 25 Nm
  19. TORQUE: 12 Nm
  20. TORQUE: 20 Nm
  21. TORQUE: 20 Nm
  22. TORQUE: 12 Nm Install new O-ring seals.
  23. TORQUE: 12 Nm Install new O-ring seals.
  24. TORQUE: 12 Nm Install new O-ring seals.
  25. TORQUE: 8 Nm
  26. TORQUE: 10 Nm
  27. See figure CAUTION: Be prepared to collect escaping coolant. Refer to «COOLANT EXPANSION TANK - V8 S/C 5.0L PETROL, 5.0L»(/land-rover/range-rover-sport/l320-2009-2013/remont/cooling-fan/#engine-cooling) .
  28. TORQUE: 10 Nm
  29. Refer to «FRONT BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  30. Refer to «REAR BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  31. Refer to «AIR CLEANER LH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  32. Refer to «AIR CLEANER RH»(/land-rover/range-rover-sport/l320-2009-2013/remont/mechanical/#intake-air-distribution-and-filtering-v8-50l-petrol) .
  33. TORQUE: 10 Nm
  34. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/land-rover/range-rover-sport/l320-2009-2013/remont/ac-compressor/#climate-control-system-general-information__air-conditioning-ac-system-recovery-evacuation) .
  35. Refer to «BATTERY»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-mounting-and-cables) .
  36. Check and top-up the coolant. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING - V8 S/C 5.0L PETROL»(/land-rover/range-rover-sport/l320-2009-2013/remont/cooling-fan/#engine-cooling) .
  37. Bleed the braking system. Refer to «BRAKE SYSTEM BLEEDING - VEHICLES WITH: HIGH PERFORMANCE BRAKES»(/land-rover/range-rover-sport/l320-2009-2013/remont/anti-locktraction-control/#brake-system-general-information__brake-system-bleeding-vehicles-with-high) .

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. Raise and support the vehicle.
  2. Disconnect both battery cables. Refer to «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-charging-system-general-information) .
  3. Disconnect the battery positive cable.
  4. Remove the rear bumper cover. Refer to «REAR BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  5. Remove the spare wheel and tire.
  6. Remove both rear body mount dampers.
  7. Remove both rear body mass dampers.
  8. Remove the rear bumper cover lower brackets. Remove the 2 scrivets.
  9. Remove the rear bumper foam pads.
  10. Remove the bracket. Remove the 2 nuts.
  11. Remove the bracket. Remove the bolt.
  12. Using suitable tools, remove and discard the 4 rear body mass damper brackets. Item Description - Mig weld. (Right-hand is symmetrically opposite to left-hand).
  13. Using suitable tools, remove and discard the rear crossmember. Item Description - Mig weld. (Right-hand is symmetrically opposite to left-hand).

Scheme 45

Scheme 45
Scheme 45
  1. To install, reverse the removal procedure. For additional information: Welding. For additional information, refer to: «BODY REPAIRS»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#body-repairs-general-information) . Corrosion protection. For additional information, refer to: «CORROSION PROTECTION - DESCRIPTION & OPERATION»(/land-rover/range-rover-sport/l320-2009-2013/remont/body-cab-control-systems/#body-repairs-corrosion-protection) . Tolerance checks. For additional information, refer to: «BODY AND FRAME»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#body-repairs-vehicle-specific-information-and-tolerance) .
  2. Install the rear bumper foam pads.
  3. Install the rear bumper cover lower brackets. Secure the 2 scrivets.
  4. Install the stiffener inside the chassis.
  5. Install the bracket. Tighten the bolt to 175 Nm.
  6. Remove the bracket. Tighten the M14 nut to 175 Nm. Tighten the M10 nut to 45 Nm.
  7. Remove the spare wheel and tire. Tighten the M8 bolts to 25 Nm. Tighten the M10 bolts to 40 Nm
  8. Install both rear body mount dampers. Tighten the bolts to 45 Nm.
  9. Install the spare wheel and tire.
  10. Install the rear bumper cover. For additional information, refer to: «REAR BUMPER COVER»(/land-rover/range-rover-sport/l320-2009-2013/remont/exterior-body-panels/#bumpers) .
  11. Connect the battery positive cable. Tighten the battery terminal to 5 Nm.
  12. Connect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-mounting-and-cables__specifications) .

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Removal steps in this procedure may contain installation details.

Scheme 46

Scheme 46: REMOVAL
Scheme 46: REMOVAL
  1. Raise and support the vehicle.

INSTALLATION

  1. TORQUE: 115 Nm
  2. TORQUE: 175 Nm
  3. TORQUE: 10 Nm
  4. TORQUE: 10 Nm
  5. Lower the vehicle.
