Generator and Regulator Land Rover Range Rover Sport L320

Charging System 4 illustrations ~428 words

SPECIFICATIONS

DescriptionNm
Generator retaining bolts47
Battery positive cable retaining nut12

COMPONENT LOCATION

Note. Installation on supercharged engine shown, installation on naturally aspirated engine similar.

INTRODUCTION

On 5.0L vehicles (naturally aspirated and supercharged), the electrical charging system consists of a 150 A output generator with an integral voltage regulator. The output from the generator is set by the voltage regulator under the control of the engine control module (ECM).

The generator produces power for the vehicle electrical system and maintains the battery in a charged state.

The generator is located at the front right side of the engine and attached directly to the cylinder block and the sump body. A terminal post on the generator provides the connection point for the battery positive cable. A single pin electrical connector on the rear cover provides the interface for a local interconnect network (LIN) bus connection with the engine control module (ECM). A pulley on the front of the generator is driven at approximately three times engine speed by the accessory drive belt. Accessory Drive. Refer to Accessory Drive

When the engine is running the generator produces an alternating current, which is converted to a direct current internally.

CONTROL DIAGRAM

Item NumberDescription
1400 A megafuse
2Generator
3ECM (engine control module)
4Instrument cluster
5CJB (central junction box)
6Battery monitoring sensor
7Battery

Note. A = Hardwired; D = High speed controller area network (CAN); N = Medium speed controller area network (CAN); O = local interconnect network (LIN) bus

PRINCIPLES OF OPERATION

The output voltage required from the generator is calculated by the battery monitoring system. For additional information, refer to Battery, Mounting and Cables (414-01 Battery, Mounting and Cables, Description and Operation).

The battery monitoring system signals the required voltage to the engine control module (ECM) via the central junction box (CJB) and the instrument cluster. The engine control module (ECM) then transmits the required voltage on the local interconnect network (LIN) bus connection with the voltage regulator in the generator. The output from the generator is supplied to the battery through the main battery positive cable.

The engine control module (ECM) will over-ride the voltage value requested by the battery monitoring system if it detects a fault in the generator. The engine control module (ECM) also signals the instrument cluster to display a warning message if it detects a fault with the generator.

For further information. Refer to Charging System .

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 30

Scheme 30: REMOVAL

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33
  1. Disconnect the battery ground cable. Refer to «Specifications»(/land-rover/range-rover-sport/l320-2009-2013/remont/charging-system/#battery-charging-system-general-information__specifications) .
  2. Raise and support the vehicle.
  3. Torque: 62 Nm
  4. Torque: 47 Nm
  5. Torque: 12 Nm

INSTALLATION

  1. To install, reverse the removal procedure.
