Automatic Transmission/transaxle External Controls Land Rover Range Rover Sport L320

SPECIFICATIONS

GENERAL SPECIFICATION

TORQUE SPECIFICATIONS

COMPONENT LOCATION

INTRODUCTION

The external controls for the transmission consist of a selector lever assembly, a selector cable and two paddle switches (standard fit on supercharger (SC) vehicles, optional fit on all other vehicles).

The selector cable transmits the position of the selector lever to the transmission.

Where fitted, the paddle switches can be used to inititiate gear changes, with the selector lever in either the D or M/S position, causing a change of operating mode from automatic gear selection to manual gear selection.

The selector lever position is displayed on the selector lever position display and the M/S (manual/sport) display. The selector lever position and current forward gear are also displayed in the instrument cluster. Refer to TRANSMISSION DESCRIPTION .

SELECTOR LEVER ASSEMBLY

The selector lever assembly is located in the floor console and is secured to the transmission tunnel closure plate. The selector lever assembly comprises a moulded plastic housing which provides for the location of the selector components.

The lever is connected to a crosspiece which allows for the selection of P, R, N, D in a forward and backward direction and selection between D and M/S in a left/right direction.

When M/S (sport) mode is selected the lever can be moved in a forward or backward direction to select + or - for manual (CommandShift ® ) operation. If left in sport mode, all gear changes are performed automatically.

If manual (CommandShift ® ) mode is selected, all gear changes are based on inputs received by the transmission control module (TCM) from manual +/- Hall effect sensors located in the selector lever assembly.

The selector lever assembly houses the following components

1. PCB (printed circuit board)
2. Shift Interlock solenoid
3. Park and Neutral locking levers.

The selector lever positions are as follows

1. P (park) : no torque transmitted to the drive wheels and prevents the vehicle from moving by locking the transmission
2. R (reverse) : selects reverse gear - only to be selected when the vehicle is stationary and the engine is at idle
3. N (neutral) : no torque transmitted to the drive wheels - allows the vehicle to roll, so ensure the electronic parking brake (EPB) is applied before leaving the vehicle in this state
4. D (drive) : this position uses all six forward gears in automatic operation
5. M/S : this position engages the sport mode, which uses all six forward gears as in D, but will upshift at higher engine speeds improving acceleration
6. + and - : initiates upshifts and downshifts respectively, allowing the transmission to be used as a sequential manual transmission (CommandShift ® mode) with six forward gears

The selector lever position is displayed to the driver on the selector lever position display, M/S display and in the instrument cluster.

MANUAL/SPORT AND +/- COMMANDSHIFT® SENSORS

The PCB in the selector lever assembly contains Hall effect sensors to activate the M/S mode and provide the +/- signals.

When the selector lever is moved to the M/S position, the lower magnet located in the selector lever is moved close to the M/S Hall effect sensor on the PCB. This provides a signal for the transmission control module (TCM), which initiates sport mode.

When the selector lever is moved to the + or - position, the magnet is moved close to one of the Hall effect sensors positioned either side of the M/S Hall effect sensor. When an input from either the + or - sensor is received, manual CommandShift ® mode is initiated by the transmission control module (TCM). A spring moves the selector lever back to the center position when released. When the selector lever is moved back to the D position, the transmission control module (TCM) returns to normal automatic operation.

SELECTOR LEVER POSITION AND MANUAL/SPORT DISPLAYS

The displays are incorporated into the switch pack and finisher on the selector lever assembly. The selector lever position display is located on the right-hand (RH) side of the selector lever and the M/S display is located on the left-hand (LH) side of the selector lever. The two displays are connected to the PCB of the selector lever assembly. An light emitting diode (LED) is installed under the P, R, N and D of the selector lever position display and the M/S of the M/S display. The position of the selector lever is sensed by the PCB, which illuminates the related light emitting diode (LED) in the displays.

P, R, N, D POSITION SWITCH

The P, R, N, D position switch is located within the Mechatronic valve block in the transmission. The switch is operated by movement of the selector lever to the P, R, N or D positions via the selector cable, which is connected between the selector lever and the transmission selector shaft.

The switch is electrically connected to the transmission control module (TCM), which outputs a common power supply to each of the four switch contacts. This power supply is also used by the two speed sensors and the fluid temperature sensor in the transmission. Each of the four switch contacts have a separate output to the transmission control module (TCM), which enables the transmission control module (TCM) to detect the position of the selector lever.

SHIFT INTERLOCK SOLENOID

The shift interlock solenoid is located on the side of the selector lever assembly. The solenoid is connected to two locking levers, which engage with the base of the selector lever and lock it in the P and N positions when the solenoid is de-energized. Operation of the solenoid is controlled by the transmission control module (TCM).

When the ignition is on and the brake pedal is pressed, the transmission control module (TCM) energizes the solenoid and the selector lever can be moved from the P or N position. This prevents the selector lever from being moved to the D or R position unintentionally, and the application of the brakes prevents the vehicle 'creeping' when the transmission engages gear.

Movement of the selector lever from the P or N positions is prevented if the transmission control module (TCM) senses the engine speed is above 2500 rev/min, even if the brake pedal is pressed.

The selector lever is locked in the N position during the transfer box changing range from high to low or vice versa.

If there is a vehicle electrical failure, or failure of the interlock solenoid or associated wiring, it is possible to move the selector lever from the P position by removing the selector lever, and the switch pack and finisher, and lifting the white tab on the rear of the selector lever assembly. While holding the tab in this position, the selector lever can be moved from the P position.

SELECTOR CABLE

The selector cable is used as a mechanical connection between the selector lever and the transmission. Movement of the selector lever between the P, R, N and D positions moves the cable. Movement of the cable is prevented when the selector lever is in the M/S position.

A seal is installed on the cable where it passes through the mounting plate. The outer cable is attached to a bracket on the transmission. The inner cable is connected to a lever attached to the transmission selector shaft.

Movement of the selector lever between the P, R, N and D positions moves the inner cable, which moves the lever. The lever transforms the linear movement of the cable into rotary movement of the selector shaft, which operates the P, R, N, D position switch and a spool valve in the Mechatronic valve block.

PADDLE SWITCHES (WHERE FITTED)

Two gear change 'paddle' switches are fitted at the rear of the steering wheel and allow the driver to operate the transmission as a semi-automatic manual gearbox using the CommandShift ® feature.

Each paddle switch has three connections; ground, illumination pulse width modulation (PWM) supply and ground switch signal. The paddle switches are hardwired to the steering wheel audio switches. Operation of the paddle switch completes a ground path to the audio switch assembly. The audio switch assembly converts the completed ground signal into a local interconnect network (LIN) bus signal, which is passed via the clockspring to the central junction box (CJB). The central junction box (CJB) converts the signal into a high speed controller area network (CAN) bus signal to the transmission control module (TCM).

Pulling the left-hand (LH) (-) paddle provides down changes and pulling the right-hand (RH) (+) paddle provides up changes. The first operation of either paddle, after sport mode is selected, puts the transmission into permanent manual CommandShift ® mode. Moving the selector lever back to the D position returns the transmission to conventional automatic operation.

Temporary operation of manual CommandShift ® mode can be activated with the selector lever in the D position. Operation of either the upshift or downshift paddle activates the manual mode operation. If the selector lever is in D, CommandShift ® mode will cancel after a time period or can be cancelled by pressing and holding the + paddle for approximately 1.2 seconds.

CONTROL DIAGRAM

Note. A = Hardwired; D = High speed controller area network (CAN) bus; O = local interconnect network (LIN) bus.

PRINCIPLES OF OPERATION

For a detailed description of the automatic transmission/transaxle external controls system and operation, refer to the relevant Description and Operation information. Refer to EXTERNAL CONTROLS .

INSPECTION & VERIFICATION

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

1. Verify the customer concern.
2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION Mechanical Electrical Check for correct gear selector lever cable adjustment. Visibly worn or damaged components Loose or missing fastners Fuses Loose or corroded electrical connectors
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the cause is not visually evident, check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

DTC INDEX

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to GENERAL or GENERAL .

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 75

Scheme 76

Scheme 77

1. Refer to «FLOOR CONSOLE UPPER SECTION»(/land-rover/range-rover-sport/l320-2009-2013/remont/gauges-instrument-panels/#instrument-panel-and-console) .
2. Torque: 10 Nm

INSTALLATION

1. To install, reverse the removal procedure.

SELECTOR LEVER PRINTED CIRCUIT BOARD

No data available.
