Air Distribution and Filtering Land Rover Range Rover Sport L320

Automatic HVAC System 8 illustrations ~532 words
Item NumberDescription
1Side window ducts
2Windshield duct
3Windshield vent
4Instrument panel register duct
5Side window vent
6Instrument panel register
7Cabin air filter
8Front passenger footwell duct
9Second row footwell duct
10Second row register
11Second row register duct
12Driver footwell duct
13Driver lap register
14Driver lap register duct
15Heater outlet manifold
16Windshield duct

Note. left-hand drive (LHD) installation shown, right-hand drive (RHD) similar

GENERAL

The air distribution and filtering system controls the distribution and quality of air supplied to the vehicle interior. The system consists of

  1. Air ducts.
  2. Air registers and vents.
  3. A cabin air filter.

AIR DUCTS

The air ducts distribute the air from the heater to the various registers and air vents around the vehicle interior. The air ducts for the instrument panel registers, the driver lap register and the second row registers are connected to the heater outlet manifold on top of the heater. The air ducts for the front and second row footwells are connected direct to outlet ports on the heater. The air ducts for the windshield vents and the side window vents form part of the structure of the instrument panel.

AIR REGISTERS AND VENTS

The air registers allow occupants to control the flow and direction of air from the air ducts. The driver lap register has moveable vanes to regulate the flow and direction of the air. The instrument panel and second row registers each have a thumbwheel to regulate flow, and moveable vanes to control direction.

The air vents are fixed outlets either integrated into the end of the air duct or installed in the trim panel connected to the air duct.

CABIN AIR FILTER

The cabin air filter is a combined pollen and odor filter installed in the air inlet duct. The filter removes particulates and unpleasant odors from the fresh and recirculated air entering the blower.

No data available.

PRINCIPLES OF OPERATION

For a detailed description of the air distribution and filtering system and operation, refer to Air Distribution and Filtering .

INSPECTION AND VERIFICATION

  1. Verify the customer concern.
  2. Visually inspect for obvious mechanical faults. Mechanical Air ducts (blocked/damaged) Air registers/vents (blocked/damaged) Pollen filter (blocked/contaminated)
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

DTC INDEX

For a list of Diagnostic Trouble Codes (DTCs) that could be logged on this vehicle, please refer to Diagnostic Trouble Code (Dtc) Index (Dtc: Climate Control Module (Hvac))

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 8

Scheme 8: REMOVAL

Scheme 9

Scheme 9

INSTALLATION

  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 10

Scheme 10: REMOVAL

Scheme 11

Scheme 11
  1. To install, reverse the removal procedure.

Scheme 12

Scheme 12: REMOVAL

Scheme 13

Scheme 13
  1. Open the glove compartment to the service condition. Release the glove compartment latch stops.
  2. Remove the pollen filter housing cover.
  3. Remove the pollen filter.
  1. To install, reverse the removal procedure. Clean the component mating faces.

Scheme 14

Scheme 14: REMOVAL

Scheme 15

Scheme 15
  1. Remove the A-pillar mouldings. Refer to «A-Pillar Moulding LH»(/land-rover/range-rover-sport/l320-2009-2013/remont/exteriorinterior-trim/#exterior-trim-and-ornamentation) .
  2. Remove the windshield wiper arms. Refer to «Front Wiper Pivot Arm»(/land-rover/range-rover-sport/l320-2009-2013/remont/wiperwasher-systems/#wipers-and-washers) .
  3. Release the hood seal from the plenum chamber.
  4. Remove the plenum chamber panel. Release the 8 clips.
  5. Remove the clips from the plenum chamber panel.
  1. To install, reverse the removal procedure.
