Maintenance Schedules Land Rover Range Rover Sport L320

TORQUE SPECIFICATIONS

Scheme 1

1. Brake fluid reservoir (LH drive illustrated - RH drive on opposite side)
2. Engine oil filler cap
3. Dynamic Response fluid reservoir
4. Engine oil level indicator
5. Windshield washer fluid reservoir
6. Coolant expansion tank
7. Power steering fluid reservoir

Seats and Safety Belts

Front seat frame fixings - Every 2 years or 30, 00 miles (48, 00 km)

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Carefully remove the trim panels covering the seat frame fixing Torx screws.
2. Check that the front seat frame fixing Torx screws are secure and that the seat frames show no signs of movement.
3. Install the trim panels on completion. Rear seat frame front fixings - Every 2 years or 30, 00 miles (48, 00 km)
4. Check that the rear seat frame front fixings are secure and that the seat frames show no signs of movement. Rear seat frame rear fixings - Every 2 years or 30, 00 miles (48, 00 km)
5. Fold the seat cushions forwards and check that the rear seat frame rear fixings are secure and that the seat frames show no signs of movement.
6. Fold the seat cushions back on completion. Front seat controls
7. Check operation of all seat controls. Safety belts - Every 2 years or 30, 00 miles (48, 00 km)
8. Fully extend each safety belt and check that it returns unassisted; repeat for all belts.
9. Check entire length of safety belt webbing for signs of fraying or damage; repeat for all belts.
10. Connect each safety belt to the correct buckle, check safety belt buckle and tongue are secure; check that buckle releases tongue correctly.
11. Check all safety belt and buckle mountings and fixings for security.
12. Check front safety belt height adjusters for correct operation.

LAMPS, HORNS AND WARNING INDICATORS

1. Check side, head, fog, reversing and tail lamps for correct operation.
2. Check operation of headlamp automatic levelling system - if installed.
3. Check turn signals and hazard warning lamps for correct operation.
4. Check brake (stop) lamps for correct operation.
5. Check all exterior lamp lenses for clarity and condition; pay particular attention to headlamp and fog lamp lenses for stone chips or damage.
6. Check horn for loud, clear sound.
7. Switch on headlamps and check that side/headlamp reminder warning sounds when door is opened.
8. Check operation of interior courtesy lamps.
9. Check operation of all instrument pack warning and indicator lamps.

Scheme 6

1. Check all wiper blades for condition and signs of splits or damage.
2. Check security of wiper arms.
3. Operate front and rear screen washers, check that jets are clear and correctly aimed.
4. Operate front and rear wipers at all speeds and check for smooth, smear free operation.

CHECK HIGH/LOW GEAR ENGAGEMENT

1. Select LOW range gear, drive vehicle forwards 3 to 4 vehicle lengths, stop vehicle and select HIGH range gear - gears must engage smoothly.

POLLEN FILTER

1. Replace pollen filter. For additional information, refer to: «POLLEN FILTER»(/land-rover/range-rover-sport/l320-2005-2009/remont/schedule/#maintenance-schedules__pollen-filter) .

CORROSION/COSMETIC INSPECTION

1. Carry out the annual corrosion/cosmetic inspection using the Annual Corrosion Inspection Sheet.

WHEELS AND TIRES

1. Check that tires comply with manufacturer's specification. For additional information, refer to: «WHEELS AND TIRES»(/land-rover/range-rover-sport/l320-2005-2009/remont/schedule/#maintenance-schedules__wheels-and-tires) .
2. Check/adjust tire pressures including spare. For additional information, refer to: «WHEELS AND TIRES»(/land-rover/range-rover-sport/l320-2005-2009/remont/schedule/#maintenance-schedules__wheels-and-tires) .
3. Vehicle fitted with Uni-directional tires: Mark the wheel to stud relationship of each road wheel and note location of each road wheel to its respective hub.
4. Loosen road wheel nuts. Raise vehicle to a wheel free condition. For additional information, refer to: «LIFTING»(/land-rover/range-rover-sport/l320-2005-2009/remont/hoistjack/#jacking-and-lifting) .
5. Remove the road wheels.
6. Visually check tires for condition, lumps or bulges. Check tread depth across the width of the tire and around the circumference; make sure that remaining tread depth does not contravene local legislative requirements. NOTE: Do not install wheels at this stage.

BRAKING SYSTEM

Scheme 7

1. Inspect front brake pads for wear. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical-hydraulic/#front-disc-brake__specifications) .
2. Inspect rear brake pads for wear. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical-hydraulic/#rear-disc-brake__specifications) .
3. Check brake calipers for signs of fluid leaks.
4. Check brake discs for condition.
5. Check all brake booster and brake system pipes and hoses for condition, chafing and leaks.
6. Clean road wheel hub spigots and apply grease, Land Rover Part Number RYL 105020 to the wheel mating surface of each spigot.
7. Vehicles fitted with Uni-directional tires: Install road wheels on their respective hubs ensuring that stud to wheel relationship is maintained.
8. Vehicles fitted with NON uni-directional tires: Install wheels on the opposite side of the vehicle but make sure that they are on the same axle as they were originally installed.
9. Install road wheel nuts and tighten to 140 Nm (103 lb-ft). CAUTION: When vehicles are operating under arduous conditions, the following service item must be carried out every 2 years or 30, 00 miles (48, 00 km).
10. Every 3 years or 45, 00 miles (72, 00 km): Replace brake fluid. For additional information, refer to: «BRAKE SYSTEM BLEEDING VEHICLES WITH: STANDARD BRAKES»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#brake-system-general-information__brake-system-bleeding-vehicles-with-standard) . «Brake System Pressure Bleeding Vehicles With: Standard Brakes»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#brake-system-general-information__brake-system-pressure-bleeding-vehicles-with) .
11. Every 6 years or 90, 00 miles (144, 00 km): Replace all flexible brake hoses.

Electric Parking Brake

1. Check the adjustment of the electric parking brake. For additional information, refer to: «PARKING BRAKE SHOE AND LINING ADJUSTMENT»(/land-rover/range-rover-sport/l320-2005-2009/remont/parking-brake-system/#parking-brake-and-actuation__parking-brake-shoe-and-lining-adjustment) .
2. Vehicles operating under arduous conditions: Check the condition of the electric parking brake system.

ROAD WHEEL SPEED SENSORS

1. Inspect the road wheel speed sensor harnesses for damage.

RADIATOR AND COOLING FAN

1. Vehicles operating under arduous conditions: Visually check radiator for external obstructions, check cooling fan blades for damage.

AIR SUSPENSION

1. Every 5 years or 75, 00 miles (120, 00 km) - Vehicles operating under arduous conditions: Replace air suspension compressor filter. For additional information, refer to: «AIR SUSPENSION AIR FILTER»(/land-rover/range-rover-sport/l320-2005-2009/remont/electronic-suspension/#vehicle-dynamic-suspension) .

DOOR LOCKS AND HINGES

1. Check operation of all door locks, bonnet lock and fuel filler flap.
2. Lubricate all door check straps, bonnet catch and fuel filler flap catch.

COOLING SYSTEM

1. Check specific gravity of coolant using a hydrometer. NOTE: A suitable hydrometer is available from the Equipment Program under Part Number 511 3302 001 00.
2. Top-up cooling system if necessary. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__specifications) V8 S/C 4.2L Petrol/ «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-44l-petrol__specifications) V8 4.4L Petrol. CAUTION: Anti-freeze concentration must be maintained at 50%.

Scheme 8

1. Check the level of coolant in the expansion tank. With the engine cold, the coolant level must be to the 'UPPER LEVEL' indicator mark above the 'COLD FILL RANGE' text on the side of the expansion tank. Ignore any coolant which may be visible in the top section of the tank.
2. If topping-up is required, remove expansion tank filler cap and top-up coolant level to the 'UPPER LEVEL' indicator mark. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__specifications) V8 S/C 4.2L Petrol/ «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-44l-petrol__specifications) 8 4.4L Petrol CAUTION: Always top-up with a 50% mixture of anti-freeze and water.
3. Install expansion tank filler cap, tighten cap until ratchet is heard to 'click'.

Coolant - Replace

1. Every 10 years or 150, 00 miles (240, 00 km): Replace the coolant. For additional information, refer to: «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-system-draining-filling-and-bleeding) V8 S/C 4.2L Petrol/ «Cooling System Draining, Filling and Bleeding»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-44l-petrol__cooling-system-draining-filling-and-bleeding) V8 4.4L Petrol.

IGNITION SYSTEM

1. Every 12 months or 15, 00 miles (24, 00 km) Vehicles using LEADED fuel or those fitted with COPPER spark plugs: Replace spark plugs. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-sc-42l-petrol__specifications) V8 S/C 4.2L Petrol/ «SPARK PLUGS»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-sc-42l-petrol) V8 S/C 4.2L Petrol. Refer to «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-44l-petrol__specifications) V8 4.4L Petrol. Refer to «SPARK PLUGS»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-44l-petrol) V8 4.4L Petrol.
2. Every 3 years or 45, 00 miles (72, 00 km) - Vehicles operating under arduous conditions: Replace spark plugs. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-sc-42l-petrol__specifications) V8 S/C 4.2L Petrol/ Refer to «SPARK PLUGS»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-sc-42l-petrol) V8 S/C 4.2L Petrol. Refer to «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-44l-petrol__specifications) V8 4.4L Petrol. Refer to «SPARK PLUGS»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-44l-petrol) V8 4.4L Petrol.
3. Every 7 years or 105, 00 miles (168, 00 km) - 4.4 liter and 4.2 Liter Supercharged V8 engines: Replace spark plugs. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-44l-petrol__specifications) V8 4.4L Petrol. Refer to «SPARK PLUGS»(/land-rover/range-rover-sport/l320-2005-2009/remont/ignition-system/#engine-ignition-v8-44l-petrol) V8 4.4L Petrol.

AIR FILTERING

1. Every 4 years or 60, 00 miles (96, 00 km) - 4.4 Liter engine: Replace the air filter element. For additional information, refer to: «Air Cleaner Element»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-v8-44l-petrol) .
2. Every 3 years or 45, 00 miles (72, 00km) - 4.2 Liter Supercharged engine: Replace the air filter element. For additional information, refer to: «Air Cleaner Element»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-42l-petrol) .

ANCILLARY DRIVE BELT

1. Check the condition of the ancillary drive belt.
2. Remove all traces of mud and dirt from the drive belt and pulleys.
3. Check the drive belt for signs of splitting and wear. CAUTION: When vehicles are operating under arduous conditions, the following service items must be carried out every 5 years or 75, 00 miles (120, 00 km).
4. Every 7 years or 105, 00 miles (168, 00 km) - Vehicles with Dynamic Response installed: Replace the ancillary drive belt. For additional information, refer to: «Accessory Drive Belt»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) V8 S/C 4.2L Petrol.
5. Every 10 years or 150, 00 miles (240, 00 km) - Vehicles without Dynamic Response installed: Replace the ancillary drive belt. For additional information, refer to: «Accessory Drive Belt»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-44l-petrol) V8 4.4L Petrol.

Scheme 9

1. Remove the brake fluid reservoir cover.
2. Check the fluid level in the brake fluid reservoir, the level must be to the 'MAX' mark on the reservoir; top-up if necessary.
3. Clean the area around the reservoir filler cap, remove cap.
4. If necessary, top-up using the recommended fluid to the 'MAX' mark on the reservoir. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#brake-system-general-information__specifications) .
5. Install the reservoir filler cap.
6. Install the brake fluid reservoir cover.

Scheme 10

1. Check that the fluid level is to the mid-way mark between the 'MAX' and 'MIN' marks on the fluid reservoir, top-up if necessary.
2. Clean the area around the reservoir filler cap, remove cap.
3. If necessary, top-up using the recommended fluid to the mid-way mark on the reservoir. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/manual-power-steering/#power-steering__specifications) . CAUTION: Do not fill reservoir above the 'MAX' mark.
4. Install the reservoir filler cap.

Windshield washer reservoir

1. Remove the windshield washer reservoir filler cap.
2. Top-up the reservoir using a mixture of an approved windshield washer fluid and water until the level is to the bottom of the gauze filter in the reservoir filler neck.
3. Install the reservoir filler cap.

Dynamic Response reservoir

1. Check that the fluid level is to the mid-way mark between the 'MAX' and 'MIN' marks on the fluid reservoir, top-up if necessary.
2. Clean the area around the reservoir filler cap, remove cap.
3. If necessary, top-up using the recommended fluid to the mid-way mark on the reservoir.

ENGINE OIL AND FILTER

1. Renew engine oil and filter - 4.2 liter supercharged engine. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#engine-v8-sc-42l-petrol__specifications) / «Engine Oil Draining and Filling»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#engine-v8-sc-42l-petrol) .
2. Renew engine oil and filter - 4.4 liter engine. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#engine-v8-44l-petrol__specifications) / «Engine Oil Draining and Filling»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#engine-v8-sc-42l-petrol)

AUTOMATIC TRANSMISSION

1. Every 10 years or 150, 00 miles (240, 00 km): Renew automatic transmission fluid - 4.4 liter engine. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/automatic-trans/#automatic-transmissiontransaxle-v8-44l-petrol__specifications) / «TRANSMISSION FLUID DRAIN AND REFILL»(/land-rover/range-rover-sport/l320-2005-2009/remont/automatic-trans/#automatic-transmissiontransaxle-v8-sc-42l-petrol__transmission-fluid-drain-and-refill) Renew automatic transmission fluid - 4.2 Liter supercharged engine. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/automatic-trans/#automatic-transmissiontransaxle-v8-sc-42l-petrol__specifications) / «TRANSMISSION FLUID DRAIN AND REFILL»(/land-rover/range-rover-sport/l320-2005-2009/remont/automatic-trans/#automatic-transmissiontransaxle-v8-sc-42l-petrol__transmission-fluid-drain-and-refill) .

TRANSFER CASE

1. Every 5 years or 75, 00 miles (120, 00 km): Renew transfer case oil.

DIFFERENTIAL ASSEMBLIES

1. Every 10 years or 150, 00 miles (240, 00 km): Renew front differential oil. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__specifications) / «Differential Draining and Filling»(/land-rover/range-rover-sport/l320-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling) .
2. Every 5 years or 75, 00 miles (120, 00 km): Renew rear 'Electronic Torque Managed (ETM)' differential oil. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/differentials-drive-axles/#rear-drive-axledifferential__specifications) / «Differential Draining and Filling»(/land-rover/range-rover-sport/l320-2005-2009/remont/differentials-drive-axles/#front-drive-axledifferential__differential-draining-and-filling)
3. Every 10 years or 150, 00 miles (240, 00 km): Renew rear 'OPEN' differential oil. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/differentials-drive-axles/#rear-drive-axledifferential__specifications) / «Differential Draining and Filling»(/land-rover/range-rover-sport/l320-2005-2009/remont/differentials-drive-axles/#rear-drive-axledifferential__differential-draining-and-filling)

SUSPENSION AND BODY MOUNTINGS

1. Check for free play in all suspension and body mounting rubbers.
2. Check condition of suspension rubber boots and gaiters.
3. Lift the vehicle so that front wheels are clear of ground/ramp to enable insertion of a suitable lever (e.g. a 1200mm long steel tube). Check the lower ball joints for free play by placing the lever between the ground/ramp and the tire, and lifting the wheel assembly with the lever. A second person will be required to check simultaneously for any ball joint lift. If free play (knock) is noted in the ball joint, replacement is required.

REMOVABLE TOW BAR

1. Check condition of removable tow bar. For additional information, refer to: «TOW BAR MOUNTING CHECK»(/land-rover/range-rover-sport/l320-2005-2009/remont/frames-subframes-crossmembers/#full-frame-and-body-mounting__tow-bar-mounting-check) .

FUEL SYSTEM

1. Check fuel system pipes, hoses and unions for chafing, leaks and corrosion.

ELECTRICAL HARNESSES

1. Check all electrical harnesses for chafing.

OIL/FLUID LEAKS

1. Check for oil/fluid leaks.

EXHAUST SYSTEM

1. Check exhaust system for leaks, security and damage.

POWER STEERING

1. Check power steering rod ball joint fixings, gaiters and condition of ball joints and dust covers.
2. Check power steering pipes, hoses and unions for chafing, leaks and corrosion. NOTE: M14 tie rod end nuts do not require checking.
3. Check torque of the tie rod end nuts - M12 nuts tighten to 76 Nm (56 lb.ft).

FAULT LAMP(S)

1. If fault lamp(s) are illuminated, test the associated system using approved Land Rover diagnostic equipment and report findings.

ROAD TEST

1. Carry out road test of vehicle. For additional information, refer to: «ROAD/ROLLER TESTING»(/land-rover/range-rover-sport/l320-2005-2009/remont/oem-general-information/#general-information__roadroller-testing) .

GENERAL

1. Endorse Service Record.
2. Report any unusual features of vehicle condition and any additional work required.

ADDITIONAL ITEMS THAT MAY REQUIRE ATTENTION

It is recommended that

1. Every 6 years: All brake fluid hydraulic seals are replaced. NOTE: This is in addition to the maintenance requirement that flexible brake hoses MUST be replaced at this service interval.
2. After 50 miles (80 km) continuous use in severe off-road conditions i.e. wading, deep mud and abrasive grit/slurry: The electric parking brake should be cleaned and inspected.
3. After 50 miles (80 km) continuous use in severe off-road conditions i.e. wading, deep mud and abrasive grit/slurry: The ancillary drive belt should be cleaned and inspected.
4. Vehicles with air suspension: Vehicles used extensively in arduous or off road conditions will require the compressor air inlet filter to be renewed more frequently.
5. Vehicles used in dusty or field conditions or deep wading: More frequent attention to the air cleaner will be required.

TORQUE SPECIFICATIONS

UNDER BONNET VIEW - 2.7 LITER

1. Brake fluid reservoir (RH drive illustrated - LH drive on opposite side)
2. Engine oil filler cap
3. Dynamic Response fluid reservoir
4. Engine oil level indicator
5. Windshield washer reservoir
6. Coolant expansion tank
7. Power steering fluid reservoir

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Carefully remove the trim panels covering the seat frame fixing Torx screws.
2. Check that the front seat frame fixing Torx screws are secure and that the seat frames show no signs of movement.
3. Reinstall the trim panels on completion.
4. Check that the rear seat frame front fixings are secure and that the seat frames show no signs of movement.
5. Fold the seat cushions forwards and check that the rear seat frame rear fixings are secure and that the seat frames show no signs of movement.
6. Fold the seat cushions back on completion.
7. Check operation of all seat controls.
8. Fully extend each safety belt and check that it returns unassisted; repeat for all belts.
9. Check entire length of safety belt webbing for signs of fraying or damage; repeat for all belts.
10. Connect each safety belt to the correct buckle, check safety belt buckle and tongue are secure; check that buckle releases tongue correctly.
11. Check all safety belt and buckle mountings and fixings for security.
12. Check front safety belt height adjusters for correct operation.

1. Check side, head, fog, reversing and tail lamps for correct operation.
2. Check operation of headlamp automatic levelling system - if installed.
3. Check turn signals and hazard warning lamps for correct operation.
4. Check brake (stop) lamps for correct operation.
5. Check all exterior lamp lenses for clarity and condition; pay particular attention to headlamp and fog lamp lenses for stone chips or damage.
6. Check horn for loud, clear sound.
7. Switch on headlamps and check that side/headlamp reminder warning sounds when door is opened.
8. Check operation of interior courtesy lamps.
9. Check operation of all instrument pack warning and indicator lamps.

Scheme 15

1. Check all wiper blades for condition and signs of splits or damage.
2. Check security of wiper arms.
3. Operate front and rear screen washers, check that jets are clear and correctly aimed.
4. Operate front and rear wipers at all speeds and check for smooth, smear free operation.

1. Select LOW range gear, drive vehicle forwards 3 to 4 vehicle lengths, stop vehicle and select HIGH range gear - gears must engage smoothly.

1. Replace pollen filter. For additional information, refer to: «POLLEN FILTER»(/land-rover/range-rover-sport/l320-2005-2009/remont/schedule/#maintenance-schedules__pollen-filter) .

1. Carry out the annual corrosion/cosmetic inspection using the Annual Corrosion Inspection Sheet.

1. Check that tires comply with manufacturer's specification. For additional information, refer to: «WHEELS AND TIRES»(/land-rover/range-rover-sport/l320-2005-2009/remont/schedule/#maintenance-schedules__wheels-and-tires) .
2. Check/adjust tire pressures including spare. For additional information, refer to: «WHEELS AND TIRES»(/land-rover/range-rover-sport/l320-2005-2009/remont/schedule/#maintenance-schedules__wheels-and-tires) .
3. Vehicles fitted with Uni-directional tires: Mark the wheel to stud relationship of each road wheel and note location of each road wheel to its respective hub.
4. Loosen road wheel nuts. Raise vehicle to a wheel free condition. For additional information, refer to: «LIFTING»(/land-rover/range-rover-sport/l320-2005-2009/remont/hoistjack/#jacking-and-lifting) .
5. Remove the road wheels.
6. Visually check tires for condition, lumps or bulges. Check tread depth across the width of the tire and around the circumference; make sure that remaining tread depth does not contravene local legislative requirements. NOTE: Do not install wheels at this stage.

Scheme 16

1. Inspect front brake pads for wear. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical-hydraulic/#front-disc-brake__specifications) .
2. Inspect rear brake pads for wear. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical-hydraulic/#rear-disc-brake__specifications) .
3. Check brake calipers for signs of fluid leaks.
4. Check brake discs for condition.
5. Check all brake booster and brake system pipes and hoses for condition, chafing and leaks.
6. Clean road wheel hub spigots and apply grease, Land Rover Part Number RYL 105020 to the wheel mating surface of each spigot.
7. Vehicles fitted with Uni-directional tires: Install road wheels to their respective hubs ensuring that stud to wheel relationship is maintained.
8. Vehicles fitted with NON uni-directional tires: Install wheels on the opposite side of the vehicle but make sure that they are on the same axle as they were originally fitted.
9. Install road wheel nuts and tighten to 140 Nm (103 lb-ft). CAUTION: When vehicles are operating under arduous conditions, the following service item must be carried out every 2 years or 30, 00 miles (48, 00 km).
10. Every 3 years or 45, 00 miles (72, 00 km): Replace brake fluid. For additional information, refer to: «BRAKE SYSTEM BLEEDING VEHICLES WITH: STANDARD BRAKES»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#brake-system-general-information__brake-system-bleeding-vehicles-with-standard) .
11. Every 6 years or 90, 00 miles (144, 00 km): Replace all flexible brake hoses.

1. Check the adjustment of the electric parking brake. For additional information, refer to: «PARKING BRAKE SHOE AND LINING ADJUSTMENT»(/land-rover/range-rover-sport/l320-2005-2009/remont/parking-brake-system/#parking-brake-and-actuation__parking-brake-shoe-and-lining-adjustment) .
2. Vehicles operating under arduous conditions: Check the condition of the electric parking brake system.

1. Inspect the road wheel speed sensor harnesses for damage.

FUEL FILTER ELEMENT

1. Every 2 years or 30, 00 miles (48, 00 km): Replace fuel filter element.

FUEL SEDIMENTOR

1. Drain the fuel sedimentor.

RADIATOR/INTERCOOLER AND COOLING FAN

1. Visually check the radiator/intercooler for external obstructions, check cooling fan blades for damage.
2. Remove any debris from the intercooler using a low pressure hose.

1. Every 5 years or 75, 00 miles (120, 00 km) - Vehicles operating under arduous conditions: Replace the air suspension compressor filter. For additional information, refer to: «AIR SUSPENSION AIR FILTER»(/land-rover/range-rover-sport/l320-2005-2009/remont/electronic-suspension/#vehicle-dynamic-suspension) .

1. Check operation of all door locks, bonnet lock and fuel filler flap.
2. Lubricate all door check straps, bonnet catch and fuel filler flap catch.

Scheme 17

1. Check specific gravity of coolant using a hydrometer. NOTE: A suitable hydrometer is available from the Equipment Program under Part Number 511 3302 001 00.
2. Top-up cooling system if necessary. CAUTION: Anti-freeze concentration must be maintained at 50%.

Cooling system - Check/Top-up

1. Check the level of coolant in the expansion tank. With the engine cold, the coolant level must be to the 'UPPER LEVEL' indicator mark above the 'COLD FILL RANGE' text on the side of the expansion tank. Ignore any coolant which may be visible in the top section of the tank.
2. If topping-up is required, remove expansion tank filler cap and top-up coolant level to the 'UPPER LEVEL' indicator mark. CAUTION: Always top-up with a 50% mixture of anti-freeze and water.
3. Install expansion tank filler cap, tighten cap until ratchet is heard to 'click'.

1. Every 10 years or 150, 00 miles (240, 00 km): Replace the coolant.

1. Every 3 years or 45, 00 miles (72, 00 km): Replace the air cleaner element.

1. Check the condition of the ancillary drive belt.
2. Remove all traces of mud and dirt from the drive belt and pulleys.
3. Check the drive belt for signs of splitting and wear. CAUTION: When vehicles are operating under arduous conditions, the following service item must be carried out every 3 years or 45, 00 miles (72, 00 km).
4. Every 7 years or 105, 00 miles (168, 00 km): Replace the ancillary drive belt.

CAMSHAFT TIMING BELT AND HIGH PRESSURE FUEL PUMP DRIVE BELT

1. Every 7 years or 105, 00 miles (168, 00 km): Replace camshaft timing belt. Replace High pressure fuel pump drive belt.

FLUID LEVELS

Brake/clutch fluid reservoir

Scheme 18

1. Remove the brake/clutch fluid reservoir cover.
2. Check the fluid level in the brake/clutch fluid reservoir, the level must be to the 'MAX' mark on the reservoir; top-up if necessary.
3. Clean the area around the reservoir filler cap, remove the cap.
4. If necessary, top-up using the recommended fluid to the 'MAX' mark on the reservoir. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#brake-system-general-information__specifications) .
5. Install the reservoir filler cap.
6. Install the brake/clutch fluid reservoir cover.

Scheme 19

1. Check that the fluid level is to the mid-way mark between the 'MAX' and 'MIN' marks on the fluid reservoir, top-up if necessary.
2. Clean the area around the reservoir filler cap, remove the cap.
3. If necessary, top-up using the recommended fluid to the mid-way mark on the reservoir. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/l320-2005-2009/remont/manual-power-steering/#power-steering__specifications) . CAUTION: Do not fill reservoir above the 'MAX' mark.
4. Refit the reservoir filler cap.

Scheme 20

1. Remove the windshield washer reservoir filler cap.
2. Top-up the reservoir using a mixture of an approved windshield washer fluid and water until the level is to the bottom of the gauze filter in the reservoir filler neck.
3. Install the reservoir filler cap.

1. Check that the fluid level is to the mid-way mark between the 'MAX' and 'MIN' marks on the fluid reservoir, top up if necessary.
2. Clean the area around the reservoir filler cap, remove the cap.
3. If necessary, top-up using the recommended fluid.

1. Renew engine oil and filter.

1. Every 10 years or 150, 00 miles (240, 00 km): Renew automatic transmission fluid.

1. Every 5 years or 75, 00 miles (120, 00 km): Renew transfer case oil.

1. Every 10 years or 150, 00 miles (240, 00 km): Renew front differential oil.
2. Every 5 years or 75, 00 miles (120, 00 km): Renew rear 'Electronic Torque Managed (ETM)' differential oil.
3. Every 10 years or 150, 00 miles (240, 00 km): Renew rear 'OPEN' differential oil.

1. Check for free play in all suspension and body mounting rubbers.
2. Check condition of suspension rubber boots and gaiters.
3. Lift the vehicle so that front wheels are clear of ground/ramp to enable insertion of a suitable lever (e.g. a 1200mm long steel tube). Check the lower ball joints for free play by placing the lever between the ground/ramp and the tire, and lifting the wheel assembly with the lever. A second person will be required to check simultaneously for any ball joint lift. If free play (knock) is noted in the ball joint, replacement is required.

1. Check condition of removable tow bar. For additional information, refer to: «TOW BAR MOUNTING CHECK»(/land-rover/range-rover-sport/l320-2005-2009/remont/frames-subframes-crossmembers/#full-frame-and-body-mounting__tow-bar-mounting-check) .

1. Check fuel system pipes, hoses and unions for chafing, leaks and corrosion.

1. Check all electrical harnesses for chafing.

1. Check for oil/fluid leaks.

1. Check exhaust system for leaks, security and damage.

1. Check power steering rod ball joint fixings, gaiters and condition of ball joints and dust covers.
2. Check power steering pipes, hoses and unions for chafing, leaks and corrosion. NOTE: M14 tie rod end nuts do not require checking.
3. Check torque of the tie rod end nuts - M12 nuts tighten to 76 Nm (56 lb.ft).

CLUTCH

1. Check clutch pipes and unions for chafing, leaks and corrosion.

1. If fault lamp(s) are illuminated, test the associated system using approved Land Rover diagnostic equipment and report findings.

1. Carry out road test of vehicle. For additional information, refer to: «ROAD/ROLLER TESTING»(/land-rover/range-rover-sport/l320-2005-2009/remont/oem-general-information/#general-information__roadroller-testing) .

1. Endorse Service Record.
2. Report any unusual features of vehicle condition and any additional work required.

It is recommended that

1. Every 6 years: All brake fluid hydraulic seals are replaced. NOTE: This is in addition to the maintenance requirement that flexible brake hoses MUST be replaced at this service interval.
2. After 50 miles (80 km) continuous use in severe off-road conditions i.e. wading, deep mud and abrasive grit/slurry: The electric parking brake should be cleaned and inspected.
3. After 50 miles (80 km) continuous use in severe off-road conditions i.e. wading, deep mud and abrasive grit/slurry: The ancillary drive belt should be cleaned and inspected.
4. Vehicles fitted with air suspension: Vehicles used extensively in arduous or off road conditions will require the compressor air inlet filter to be renewed more frequently.
5. Vehicles used in dusty or field conditions or deep wading: More frequent attention to the air cleaner will be required.
6. Vehicles used in areas where fuel quality is poor: Where vehicles are used in these areas, the fuel sedimentor may require draining at more frequent intervals.

See also:
• LIFTING
• Specifications
• Specifications
• BRAKE SYSTEM BLEEDING VEHICLES WITH: STANDARD BRAKES
• Brake System Pressure Bleeding Vehicles With: Standard Brakes
• PARKING BRAKE SHOE AND LINING ADJUSTMENT
• AIR SUSPENSION AIR FILTER
• Specifications
• Specifications
• Cooling System Draining, Filling and Bleeding
• Cooling System Draining, Filling and Bleeding
• Specifications
• SPARK PLUGS
• Specifications
• SPARK PLUGS
• Air Cleaner Element
• Air Cleaner Element
• Accessory Drive Belt
• Accessory Drive Belt
• Specifications
• Specifications
• Specifications
• Engine Oil Draining and Filling
• Specifications
• Specifications
• TRANSMISSION FLUID DRAIN AND REFILL
• Specifications
• Specifications
• Differential Draining and Filling
• Specifications
• Differential Draining and Filling
• TOW BAR MOUNTING CHECK
• ROAD/ROLLER TESTING
• POLLEN FILTER
• WHEELS AND TIRES
