Engine Cooling - v8 S/c 4.2l Petrol Land Rover Range Rover Sport L320

Cooling System (mechanical) 29 illustrations ~4070 words

SPECIFICATIONS

ItemSpecification
* Anti-freezeHavoline Extended Life Coolant (XLC) or any ethylene glycol based anti-freeze containing no methanol with only Organic Acid Technology (OAT) corrosion inhibitors
Anti-freeze concentration - Will provide frost protection to -40°C (-40°F)50%
Specific gravity of coolant at 20°C (68°F), to protect against frost down to -40°C (-40°F)1.068
Amount of anti-freeze to use for 50% concentration6.0 litres (10.5 pints) (6.3 US quarts)

FLUIDS

CAUTIONNo other anti-freeze should be used with Havoline Extended Life Coolant.
ItemCapacity
Cooling system12.0 litres (21 pints) (12.6 US quarts)

CAPACITY

ItemSpecification
Cooling system typePressurised, thermostatically controlled with remote header tank
RadiatorCross flow with integral transmission fluid cooler
Charge air cooler radiatorCross flow
Expansion tankRemote - fitted with a bleed screw and low coolant level sensor
Pressure cap rating110 kPa (1.1 bar) (16 lbf/in 2 )
Thermostat
Starts to open88°C (190°F)
Fully open95°C (203°F)
Cooling fanEngine driven, viscous coupled with electronic control
Cooling fan diameter470 mm (18.5 in)
Direction of rotationCounter clockwise when viewed from front of engine
Coolant pumpCentrifugal flow impellor, belt driven from crankshaft
Charge air cooler coolant pumpElectrical coolant pump

GENERAL SPECIFICATIONS

DescriptionNm
Coolant pump bolts10
Coolant pump pulley bolts10
Coolant expansion tank bolt10
Vacuum pump bolts10
Radiator bolts25
Air Conditioning (A/C) condenser bolt6
Radiator access panel bolts10
Cooling fan to viscous coupling bolts10
Cooling fan assembly65
Thermostat housing bolts10
Coolant manifold Torx screws10
Coolant hose support bracket bolt6
A/C pipe securing bolts10
Coolant bleed screw(s)3

TORQUE SPECIFICATIONS

COOLING SYSTEM COMPONENT LAYOUT - SHEET 1 OF 2

ItemPart NumberDescription
1Coolant outlet assembly
2Hose, electric coolant pump to intercoolers
3Hose, radiator to thermostat assembly
4Electric coolant pump
5Engine oil cooler plate
6Hose, oil cooler to air blast cooler
7Hose, air blast cooler to oil cooler
8Air blast engine oil cooler
9Shroud, lower
10Engine cooling fan
11Radiator assembly
12Shroud, upper
13Hose, engine to radiator

Scheme 36

Scheme 36: COOLING SYSTEM COMPONENT LAYOUT - SHEET 2 OF 2
Scheme 36: COOLING SYSTEM COMPONENT LAYOUT - SHEET 2 OF 2
ItemPart NumberDescription
1Coolant outlet assembly
2Coolant inlet housing
3Hose, coolant outlet assembly to expansion tank
4Hose, heater feed and return
5Hose, heater feed and return
6Electric throttle housing
7Engine coolant pump
8Engine block
9Engine cooling fan
10Expansion tank
11Shroud, lower
12Radiator assembly
13Shroud, upper
14Hose, expansion tank to coolant outlet assembly

GENERAL

The cooling system employed is of the pressure relief by-pass type, which allows coolant to circulate around the engine and the heater circuit while the thermostat main valve is closed. The primary function of the cooling system is to maintain the engine within an optimum temperature range under changing ambient and engine operating conditions. Secondary functions are to provide heating for the passenger compartment and cooling for the transmission fluid and engine oil.

The cooling system comprises

  1. A cooling module including common radiator, condenser, transmission oil cooler with additional charge air radiator
  2. A passenger compartment heater matrix
  3. An engine driven coolant pump
  4. An electric coolant pump
  5. A thermostat
  6. An expansion tank
  7. An electro-viscous cooling fan
  8. Transmission oil pipes
  9. Engine oil coolers
  10. Connecting hoses and pipes.

ENGINE COOLING SYSTEM

A centrifugal pump mounted on the front of the engine and driven by an ancillary drive 'polyvee' belt circulates the coolant. The engine driven coolant pump circulates coolant through the cylinder block and cylinder heads via a chamber located in the 'vee' of the engine. Having passed through the engine the coolant returns to the thermostat housing. The coolant then progresses down the 'top hose' to the heater pipe. The heater pipes lead to the bulkhead and return to the engine side of the thermostat.

The engine contains a normal thermostat, which is positioned such that the wax's temperature is controlled by both the coolant from the radiator and the bypass. This results in the thermostat being able to vary its opening temperature dependant on ambient conditions. The thermostat housing also contains a sprung loaded valve, which limits the amount flow using the bypass. This means that the engine can run without coolant flowing through the bypass temporarily, to improve heater performance.

The engine radiator is a cross flow type with an aluminium matrix and has a drain tap on the lower right-hand rear face. There is an additional charge air radiator, located in front of the engine radiator, to support the water charge air coolers on the engine.

Scheme 37

Scheme 37: ENGINE COOLING SYSTEM
Scheme 37: ENGINE COOLING SYSTEM
ItemPart NumberDescription
1Charge air radiator

The coolant for the charge air cooling is driven by an electric pump at constant speed and is mounted on the engine radiator end tank. This circuit shares the engine coolant via a vortex connection, in the engine to radiator hose. The lower engine radiator mountings are located part way up the end tanks. The mountings are fitted with rubber bushes, which sit on the upper chassis rails. The radiator upper is mounted by pins, which are pushed through rubber bushes mounted in the Front End Carrier (FEC) above the radiator. The radiator also incorporates two connections for the transmission oil pipes.

The top and bottom hoses are mounted to the inlet and outlet sides of the thermostat housing.

The expansion tank is fitted forward of the LH suspension turret in the engine compartment. The expansion tank allows for the expansion of the coolant as the engine gets hot and also supplies the engine with coolant as the coolant in the engine contracts. The tank also allows any air trapped in the coolant to be removed.

The liquid cooled transmission fluid cooler is mounted in the cold side radiator end tank. It is positioned in the middle of the LH end tank.

There are two engine oil coolers working in parallel. The first engine oil cooler is fed coolant from the bottom hose. Coolant is diverted from between the radiator and the thermostat, directed to the cooler and then returned to the bottom hose. The second engine oil cooler is cooled by air and is mounted in front of the RH front wheel.

For additional airflow through the radiator matrix, particularly when the vehicle is stationary, there is an engine driven electro-viscous unit. This unit functions as a normal viscous fan, but with electronic control over the level engagement of the clutch. The Engine Control Module (ECM), which determines the required fan speed, controls the level of clutch engagement. The ECM determines engagement based on the coolant, ambient and transmission oil temperatures and air conditioning (A/C) system pressure. The fan is mounted using a left hand thread.

The viscous fan unit is electronically controlled by the ECM to optimise fan speed for all operating conditions.

Note. If the electrical connections to the viscous fan are disconnected the fan will 'idle' and overheating may result. The ECM stores the appropriate fault codes in this case.

Scheme 38

Scheme 38: Cooling System Coolant Flow
Scheme 38: Cooling System Coolant Flow

When the engine is running the coolant pump is driven by the ancillary drive belt. This forces coolant to circulate around the engine and heater, while the thermostat and bypass valve are shut. As the temperature and pressure increases the bypass valve is forced open allowing coolant to circulate through the bypass valve. When the temperature reaches 82°C (180°F) the main thermostat begins to open allowing coolant to circulate through the main radiator. As the thermostat progressively opens (fully open at 95°C (203°F)), the bypass valve progressively closes forcing any coolant through the heater or radiator. Once coolant is allowed to circulate through the radiator, the transmission fluid and the engine oil coolers begin to receive coolant flow.

The increased coolant volume, created by heat expansion, is directed to the expansion tank through a bleed hose from the top of the radiator. The expansion tank has an outlet hose, which is connected into the coolant circuit. This outlet hose returns the coolant to the system when the engine cools.

Coolant flows through the radiator from the top right hand tank to the bottom left hand tank and is cooled by air passing through the matrix. The temperature of the cooling system is monitored by the ECM via the Engine Coolant temperature (ECT) sensor located in the cylinder head. The ECM uses signals from this sensor to control the cooling fan operation and adjust fuelling according to engine temperature.

For additional information, refer to: Electronic Engine Controls .

To control the cooling fan, the ECM sends a Pulse Width Modulated (PWM) signal to the cooling fan module (integral to the ECM). The frequency of the PWM signal is used by the cooling fan module to determine the output voltage supplied to the fan motor.

The ECM varies the duty cycle of the PWM signal between 0 and 100% to vary the fan speed. If the PWM signal is outside the 0 to 100% range, the cooling fan module interprets the signal as an open or short circuit and runs the fans at maximum speed to ensure the engine and gearbox do not overheat.

The ECM operates the fan in response to inputs from the ECT sensor, the transmission oil temperature sensor, the A/C switch and the A/C pressure sensor.

For additional information, refer to: AIR CONDITIONING .

The speed of the cooling fan is also influenced by vehicle road speed. The ECM adjusts the speed of the cooling fans, to compensate for the ram effect of vehicle speed, using the Controller Area Network (CAN) road speed signal received from the Anti-lock Braking System (ABS) module.

INSPECTION AND VERIFICATION

  1. Verify the customer concern.
  2. Visually inspect for obvious mechanical or electrical faults. VISUAL INSPECTION Mechanical Electrical Coolant leaks Coolant Hoses Coolant expansion tank Radiator Heater core Accessory drive belt Viscous fan Fuses Wiring harness Loose or corroded connector(s) Engine coolant temperature (ECT) sensor
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. Use the approved diagnostic system or a scan tool to retrieve any diagnostic trouble codes (DTCs) before moving onto the symptom chart or DTC index. Make sure that all DTCs are cleared following rectification

SYMPTOM CHART

SymptomPossible causeAction
Coolant lossHoses Hose connections Radiator Water pump Heater core Gaskets Engine casting cracks Engine block core plugsCarry out a visual inspection . If there are no obvious leaks, carry out a pressure test using your workshop tester. Rectify as necessary.
OverheatingLow/Contaminated coolant Thermostat Viscous fan ECT sensor Restricted air flow over the radiatorCheck the coolant level and condition. Check the thermostat and rectify as necessary. Carry out a COOLING SYSTEM PRESSURE TEST . Refer to the relevanat service information. Check the viscous fan operation, make sure the viscous fan rotates freely. Check for obstructions to the air flow over the radiator.
Engine not reaching normal temperatureThermostat Viscous fanCheck the thermostat operation. Check the viscous fan operation, make sure the viscous fan is not seized.

DTC INDEX

Note. Generic scan tools may not read the codes listed, or may read only 5-digit codes. Match the 5 digits from the scan tool to the first 5 digits of the 7-digit code listed to identify the fault (the last 2 digits give extra information read by the manufacturer-approved diagnostic system).

DTCDescriptionPossible causesAction
P011623Engine Coolant Temperature Sensor 1 Circuit Range/PerformanceLow coolant level Engine thermostat failure ECT sensor sensing circuit intermittent high resistance ECT sensor failureCheck the coolant level and the thermostat operation (stuck open). Refer to the guided diagnostic routine for this code on the approved diagnostic system.
P011624Engine Coolant Temperature Sensor 1 Circuit Range/PerformanceLow coolant level Engine coolant thermostat failure ECT sensor sensing circuit intermittent high resistance ECT sensor failureCheck the coolant level and the thermostat operation (stuck closed). Refer to the guided diagnostic routine for this code on the approved diagnostic system.
P011629Engine Coolant Temperature Sensor 1 Circuit Range/PerformanceLow coolant level Engine coolant thermostat failure ECT sensor sensing circuit intermittent high resistance ECT sensor failureCheck the coolant level and the thermostat operation. Refer to the guided diagnostic routine for this code on the approved diagnostic system.
P011700Engine Coolant Temperature Sensor 1 Circuit LowECT sensor disconnected Engine coolant temperature (ECT) sensor sensing circuit high resistance, short circuit to power ECT sensor failureRefer to the guided diagnostic routine for this code on the approved diagnostic system.
P011800Engine Coolant Temperature Sensor 1 Circuit HighEngine overheat condition/cooling fan failure ECT sensor wiring short circuit to ground ECT sensor failureCheck the coolant level and the thermostat operation (stuck closed). Check for cooling fan DTCs. Refer to the guided diagnostic routine for this code on the approved diagnostic system.

COOLING SYSTEM DRAINING, FILLING AND BLEEDING

WARNINGSince injury such as scalding could be caused by escaping steam or coolant, do not remove the filler cap from the coolant expansion tank while the system is hot.

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Position the vehicle on a lift.
  2. Set the heater controls to maximum.
  3. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  4. Remove the engine cover. For additional information, refer to: «ENGINE COVER V8 S/C 4.2L PETROL»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-omamentation) .
  5. Remove the coolant expansion tank cap.
  6. Remove the front RH and LH splash shields. Remove the 4 clips.
  7. Remove the radiator access panel. Remove the 4 bolts.
  8. Position a container to collect the fluid.
  9. Disconnect the charge air radiator lower hose. Release the clip. Allow the coolant to drain.
  10. Disconnect the radiator lower hose. Release the clip. Allow the coolant to drain. Remove the container.
  11. Connect the lower hoses to the radiators. Secure the clips.
  12. Connect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  13. Connect exhaust extraction hoses to the tail pipes.
  14. Refill and bleed the cooling system. Remove the coolant expansion tank cap. Loosen the coolant expansion tank bleed screw. Add coolant to the expansion tank as required, until the upper level mark is achieved.
  15. Set the heating system to MAX heat, the blower motor to MAX speed and the air distribution to the instrument panel registers. Loosen the coolant bleed screw adjacent to the charge air cooler. Turn the ignition key to position II. When coolant runs from the bleed point bubble-free, tighten the bleed screw.
  16. Start the engine and allow to idle. When coolant runs from the expansion tank bleed point bubble-free, tighten the bleed screw. Top-up the expansion tank to the upper level mark. Install the coolant expansion tank cap. Increase the engine speed to 2000 RPM, and maintain, until no air is seen returning to the expansion tank.
  17. Switch the engine off and allow to cool.
  18. Check for leaks and then fill the coolant expansion tank to the MAX mark.
  19. Install the engine cover. For additional information, refer to: «ENGINE COVER V8 S/C 4.2L PETROL»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-omamentation) .
  20. Clean any spilt coolant from the vehicle.
  21. Install the radiator access panel. Tighten the 4 bolts to 10 Nm (7 lb.ft).
  22. Install the splash shields.
  23. Disconnect the exhaust extraction hoses from the tail pipes.

COOLING SYSTEM DRAINING AND VACUUM FILLING

WARNINGTo avoid having scalding hot coolant or steam blowing out of the cooling system, use extreme care when removing the coolant pressure cap from a hot cooling system. Wait until the engine has cooled, then wrap a thick cloth around the coolant pressure cap and turn it slowly until the pressure begins to release. Step back while the pressure is released from the system. When certain all the pressure has been released (still with a cloth) turn and remove the coolant pressure cap from the coolant expansion tank. Failure to follow these instructions may result in personal injury.
CAUTIONThe engine cooling system must be maintained with the correct concentration and type of anti-freeze solution to prevent corrosion and frost damage. Failure to follow this instruction may result in damage to the vehicle. Engine coolant will damage the paint finished surfaces. If spilt, immediately remove the coolant and clean the area with water.

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Set the heater controls to maximum HOT.
  2. Remove the coolant expansion tank cap.
  3. Raise and support the vehicle.
  4. Remove the front LH splash shield. Remove the 4 clips.
  5. Remove the radiator access panel. Remove the 4 bolts.
  6. Position a container to collect the fluid.
  7. Disconnect the charge air radiator lower hose. Release the clip. Allow the coolant to drain.
  8. Disconnect the radiator lower hose. Release the clip. Allow the coolant to drain.
  9. Connect the lower hoses to the radiators. Secure the clips. Remove the container.
  10. Prepare a sufficient amount of coolant to the specified concentration.
  11. Install the cooling system vacuum refill adaptor to the expansion tank.
  12. Install the vacuum filler gauge to the cooling system vacuum refill adaptor.
  13. Install the venturi tube assembly to the vacuum filler gauge.
  14. Connect a regulated compressed air supply to the venturi tube assembly.
  15. Position the coolant pick-up pipe into a container of clean coolant.
  16. Position the evacuated air hose into a container.
  17. Open the air supply valve.
  18. Open the coolant supply valve for 2 seconds to prime the coolant supply hose.
  19. Apply air pressure progressively until the arrow on the vacuum filler gauge reaches the green segment.
  20. Close the air supply valve.
  21. Allow one minute to check the vacuum is held. Disconnect the compressed air supply.
  22. Open the coolant supply valve and allow the coolant to be drawn into the system.
  23. Remove the vacuum filler gauge and cooling system vacuum refill adaptor assembly.
  24. Check and top-up the coolant if required.
  25. Install the coolant expansion tank cap.
  26. Start and run the engine until normal operating temperature is reached.
  27. Switch the engine off and allow to cool.
  28. Clean any spilt coolant from the vehicle.
  29. Install the radiator access panel. Tighten the bolts to 10 Nm (7 lb.ft). Tighten the bolts to 62 Nm (46 lb.ft).
  30. Install the front LH splash shield. Install the 4 clips.
  31. Check for leaks and then fill the coolant expansion tank to the MAX mark.

COOLING SYSTEM PRESSURE TEST

Note. The following procedure will enable the cooling system to be pressure tested for condition and leaks. Stage 1 will check the expansion tank cap register seal and the cap for leaks. Stage 2 will check the entire cooling system.

Note. It will be necessary to use the cooling system test kit, Part Number LR-218, which is available under the equipment programme.

Scheme 47

Scheme 47: COOLING SYSTEM PRESSURE TEST
Scheme 47: COOLING SYSTEM PRESSURE TEST
  1. Examine the coolant hoses for signs of cracking, distortion and security of the hose connections.
  2. Disconnect the coolant expansion tank bleed hose. Release the clip.
  3. Install the 'T' piece adaptor (part of the cooling system test kit) between the coolant expansion tank and the coolant bleed hose. Secure with the 2 clips.
  4. Install the coolant pressure pump assembly. Connect to the 'T' piece.
  5. Pressurize the cooling system. Slowly pressurize the cooling system to 1.0 bar (100 kPa) (14.5 psi). Check the pressure remains above 0.9 bar (90 kPa) (13 psi) after waiting for 30 seconds. During the pressure drop check, listen for a hissing noise from the expansion tank cap.
  6. Depressurize the cooling system. Disconnect the 'T' piece. Connect the coolant expansion tank bleed hose. Secure the clip.
  7. Remove the coolant expansion tank cap.
  8. Install adaptor K83 to the coolant expansion tank. Clean the component mating faces. Lubricate the seal.
  9. Install the coolant pressure pump assembly. Slowly pressurize the cooling system to 1.5 bar (150kPa) (22 psi), check the pressure over a 5 minute period. A small pressure decay of approximately 0.15 bar (15 »kPa) (1 psi) over the first minute is normal, as the air in the expansion tank cools. If the pressure continues to drop after the initial tolerance, there is a coolant leak.
  10. Depressurize and remove the pressure pump and gauge. Install the coolant expansion tank cap.

Scheme 48

Scheme 48: REMOVAL
Scheme 48: REMOVAL

Scheme 49

Scheme 49
Scheme 49
  1. Remove the LH headlamp assembly. For additional information, refer to: «HEADLAMP ASSEMBLY»(/land-rover/range-rover-sport/l320-2005-2009/remont/exterior-lights/#exterior-lighting__headlamp-assembly) .
  2. Release the windshield washer reservoir filler neck.
  3. Release the coolant expansion tank. Remove the 2 bolts.
  4. Release the power steering fluid reservoir.
  5. Disconnect the 2 hoses from the coolant expansion tank. Position an absorbent cloth to collect fluid spillage. Position a container to collect the fluid. Clamp the hoses Release the 2 clips.
  6. Remove the coolant expansion tank. Disconnect the coolant low level sensor electrical connector.
  7. Remove the coolant low level sensor. Remove the coolant expansion tank support bracket.

INSTALLATION

  1. Install the bracket.
  2. Install the coolant low level sensor.
  3. Install the coolant expansion tank. Connect the coolant low level sensor electrical connector.
  4. Connect the coolant hoses to the expansion tank. Secure with the clips.
  5. Top-up the coolant. Loosen the coolant expansion tank bleed screw. Fill the coolant expansion tank until coolant emerges from the cooling system air bleed screw. Remove the hose clamps. Tighten the bleed screw to 8 Nm (6 lb.ft).
  6. Secure the coolant expansion tank. Tighten the bolts to 10 Nm (7 lb.ft).
  7. Check and top-up the coolant. Install the coolant expansion tank pressure cap.
  8. Secure the power steering fluid reservoir. Attach to the mounting bracket.
  9. Secure the windshield washer reservoir filler neck. Locate in clip.
  10. Install the LH headlamp assembly. For additional information, refer to: «HEADLAMP ASSEMBLY»(/land-rover/range-rover-sport/l320-2005-2009/remont/exterior-lights/#exterior-lighting__headlamp-assembly) .

COOLING FAN

SPECIAL TOOL(S) Viscous coupling spanner 303-1142 Viscous coupling pulley retaining tool 303-1143

Scheme 50

Scheme 50: COOLING FAN
Scheme 50: COOLING FAN

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52: REMOVAL
Scheme 52: REMOVAL

Scheme 53

Scheme 53
Scheme 53
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the cooling fan shroud.
  3. Disconnect the cooling fan control electrical connector.
  4. Using the special tools, remove the cooling fan. Remove the cooling fan assembly.
  5. Remove the viscous coupling from the cooling fan. Remove the 4 bolts.
  1. To install, reverse the removal procedure. Install the cooling fan to the viscous coupling, tighten the bolts to 10 Nm (7 lb.ft). Tighten the cooling fan assembly to 65 Nm (48 lb.ft).

Scheme 54

Scheme 54: REMOVAL
Scheme 54: REMOVAL

Scheme 55

Scheme 55
Scheme 55
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the cooling fan belt. For additional information, refer to: Cooling Fan Belt (303-05, Removal and Installation).
  3. Drain the cooling system. For additional information, refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-system-draining-filling-and-bleeding) .
  4. Remove the coolant hose support bracket. Remove the 2 bolts. Release the 2 coolant hoses.
  5. Disconnect the coolant manifold to radiator hose. Remove the clip.
  6. Disconnect the thermostat housing to radiator hose. Release the clip.
  7. Disconnect the coolant manifold to coolant reservoir hose. Release the clip.
  8. Disconnect the coolant manifold bleed hose. Release the clip.
  9. Disconnect the engine coolant temperature (ECT) sensor electrical connector. Release the clip.
  10. Disconnect the cylinder block coolant hose. Release the clip.
  11. Release the coolant manifold. Remove the 4 Torx screws. Position the wiring harness brackets aside. Remove and discard the 2 O-ring seals.
  12. Disconnect the coolant manifold rear hose. Rotate the coolant manifold. Release the clip.
  13. Remove the coolant manifold.
  14. Remove the ECT sensor. Remove the clip. Remove and discard the O-ring seal.
  15. Remove the thermostat housing. Remove the 3 bolts. Discard the O-ring seal.
  1. Install the thermostat housing. Clean the components. Install a new O-ring seal. Tighten the bolts to 10 Nm (7 lb.ft).
  2. Install the ECT sensor. Clean the component mating faces. Install a new O-ring seal. Secure with the clip.
  3. Install the coolant manifold. Clean the components. Install new O-ring seals. Connect the rear hose and secure with the clip. Connect the cylinder block hose and secure with the clip. Attach the wiring harness bracket. Tighten the Torx screws to 10 Nm (7 lb.ft).
  4. Connect the remaining coolant hoses. Secure with the clips.
  5. Connect the ECT sensor electrical connector.
  6. Install the coolant hose support bracket. Tighten the bolts to 6 Nm (4 lb.ft). Secure the coolant hoses.
  7. Install the cooling fan belt. For additional information, refer to: «Cooling Fan Belt»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  8. Connect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  9. Refill and bleed the cooling system. For additional information, refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-system-draining-filling-and-bleeding) .

Scheme 56

Scheme 56: REMOVAL
Scheme 56: REMOVAL
  1. Release the power steering fluid reservoir from the bracket.
  2. Release the windshield washer reservoir filler neck.
  3. Reposition the coolant expansion tank. Remove the 2 bolts.
  4. Remove the engine coolant level switch. Disconnect the engine coolant level switch electrical connector.
  1. Install the engine coolant level switch. Connect the engine coolant level switch electrical connector.
  2. Secure the coolant expansion tank. Tighten the bolts to 10 Nm (7 lb.ft).
  3. Secure the windshield washer reservoir filler neck.
  4. Secure the power steering fluid reservoir to the bracket.

Scheme 57

Scheme 57: REMOVAL
Scheme 57: REMOVAL

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Recover the A/C refrigerant. For additional information, refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/land-rover/range-rover-sport/l320-2005-2009/remont/hvac/#climate-control-system-general-information__air-conditioning-ac-system-recovery-evacuation) .
  3. Remove the air cleaner assembly. For additional information, refer to: «Air Cleaner»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-42l-petrol) .
  4. Remove the cooling fan drive pulley. For additional information, refer to: «COOLING FAN»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-fan) .
  5. Drain the cooling system. For additional information, refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-system-draining-filling-and-bleeding) .
  6. Remove the radiator grille. For additional information, refer to: «RADIATOR GRILLE»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-omamentation) .
  7. Remove the auxiliary coolant pump. For additional information, refer to: «Coolant Pump»(/land-rover/range-rover-sport/l320-2005-2009/remont/blowers-superchargers-turbochargers/#supercharger-cooling) .
  8. Disconnect the A/C pipes. Remove the 2 bolts. Discard the O-ring seals.
  9. Disconnect the 2 upper radiator hoses. Carefully release the clips.
  10. Release the power steering fluid reservoir and position aside. Tie the reservoir aside.
  11. Release the windshield washer reservoir filler neck.
  12. Remove the coolant expansion tank. Remove the 2 bolts. Release the spigot and lug. Disconnect the coolant low level sensor electrical connector.
  13. Remove the auxiliary coolant pump mounting bracket. Remove the peg. Release the clip.
  14. Release and remove the cooling fan lower shroud from the cooling pack. Release the 2 clips.
  15. Disconnect the transmission cooler hoses. Position a container to collect the fluid. Release the 2 clips.
  16. Remove the radiator securing pegs.
  17. Release the breather hose and tie aside.
  18. Release the power steering fluid cooler. Release the 3 clips. Tie the line aside.
  19. Release the bumper air ducting. Remove the 2 screws.
  20. With assistance, remove the radiator assembly. Protect the elements from damage. Remove the 2 radiator retaining bolts. With assistance, remove the radiator.
  1. With assistance, install the radiator assembly. With assistance, install the radiator assembly. Align the radiator. Remove the element protection. Tighten the bolts to 25 Nm (18 lb.ft).
  2. Secure the bumper air ducting. Tighten the screws.
  3. Install the power steering fluid cooler. Secure in the 3 clips.
  4. Install the radiator securing pegs.
  5. Connect the upper radiator hoses. Position and secure in the clips.
  6. Install the transmission cooler hoses.
  7. Install the radiator upper hoses. Install the clip.
  8. Secure the coolant expansion tank. Connect the coolant low level indicator electrical connector. Locate the lug and spigot. Tighten the 2 bolts to 10 Nm (7 lb.ft).
  9. Install the power steering fluid reservoir.
  10. Install the windshield washer reservoir filler neck.
  11. Connect the A/C pipes. Install new O-ring seals. Tighten the bolts to 10 Nm (7 lb.ft).
  12. Connect the coolant hoses to the expansion tank. Secure the clips.
  13. Install the auxiliary coolant pump mounting bracket. Secure the clip. Install the securing peg.
  14. Install the auxiliary coolant pump. For additional information, refer to: «Coolant Pump»(/land-rover/range-rover-sport/l320-2005-2009/remont/blowers-superchargers-turbochargers/#supercharger-cooling) .
  15. Install the radiator grille. For additional information, refer to: «RADIATOR GRILLE»(/land-rover/range-rover-sport/l320-2005-2009/remont/exteriorinterior-trim/#exterior-trim-and-omamentation) .
  16. Install the cooling fan drive pulley. For additional information, refer to: «COOLING FAN»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-fan) .
  17. Install the air cleaner assembly. For additional information, refer to: «Air Cleaner»(/land-rover/range-rover-sport/l320-2005-2009/remont/mechanical/#intake-air-distribution-and-filtering-v8-sc-42l-petrol) .
  18. Fill the A/C system. For additional information, refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(/land-rover/range-rover-sport/l320-2005-2009/remont/hvac/#climate-control-system-general-information__air-conditioning-ac-system-recovery-evacuation) .
  19. Connect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  20. Refill the cooling system. For additional information, refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-system-draining-filling-and-bleeding) .
  21. Check automatic transmission fluid level. For additional information, refer to: «Transmission Fluid Level Check»(/land-rover/range-rover-sport/l320-2005-2009/remont/automatic-trans/#automatic-transmissiontransaxle-v8-sc-42l-petrol__transmission-fluid-level-check) .

Scheme 63

Scheme 63: REMOVAL
Scheme 63: REMOVAL
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the engine cover. For additional information, refer to: Engine Cover - V8 S/C 4.2L Petrol (501-05 Interior Trim and Ornamentation, Removal and Installation).
  3. Remove the fan cowl. For additional information, refer to: «COOLING FAN SHROUD»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-44l-petrol) .
  4. Remove the thermostat housing. Position a container to collect the fluid. Disconnect the thermostat housing coolant hose. Remove the 3 bolts. Remove and discard the seal.
  5. Remove the thermostat. Position the thermostat housing in a vice. Release and remove the thermostat.
  1. To install, reverse the removal procedure. Clean the component mating faces. Install a new thermostat seal. Tighten the bolts to 10 Nm (7 lb.ft).
  2. Top-up and bleed the coolant.
  3. If required, carry out a long drive cycle. For additional information, refer to: «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(/land-rover/range-rover-sport/l320-2005-2009/remont/engine-control-systems/#electronic-engine-controls-v8-sc-42l-petrol__powertrain-control-module-pcm-long-drive) .

Scheme 64

Scheme 64: REMOVAL
Scheme 64: REMOVAL
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Position the vehicle on a lift.
  3. Drain the cooling system. For additional information, refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-system-draining-filling-and-bleeding) .
  4. Disconnect the coolant hose for access. Release the clip.
  5. Loosen the 3 coolant pump pulley bolts.
  6. Remove the accessory drive belt. For additional information, refer to: «Accessory Drive Belt»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  7. Remove the coolant pump drive pulley. Remove the 3 bolts.
  8. Remove the coolant pump. Remove the 5 bolts. Discard the gasket.
  1. Install the coolant pump. Clean the component mating faces. Install a new gasket. Install the bolts and tighten to 10 Nm (7 lb.ft).
  2. Install the coolant pump drive pulley. Install, and lightly tighten the bolts.
  3. Install the accessory drive belt. For additional information, refer to: «Accessory Drive Belt»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  4. Tighten the coolant pump pulley retaining bolts. Tighten the bolts to 10 Nm (7 lb.ft).
  5. Connect and secure the coolant hose. Clean the component mating faces.
  6. Connect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/l320-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  7. Refill the cooling system. For additional information, refer to: «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(/land-rover/range-rover-sport/l320-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-system-draining-filling-and-bleeding) .

More articles — Engine
