Seating Land Rover Range Rover Sport I

SPECIFICATIONS

TORQUE SPECIFICATIONS

COMPONENT LOCATION

Note. RH drive shown, LH drive similar

Scheme 1

OVERVIEW

Seat Configuration

Scheme 2

The driver's seat has the option of an 8-way power adjustment, with or without memory functionality, or a 6-way manual adjustment. The front passenger seat has the option of a 6 way power adjustment or a 4-way, non-height, manual adjustment. On vehicles from 2008MY, the passenger seat is also available with an 8-way power adjustment.

The second row of seats are designed as a 60/40 split, flip and fold configuration.

All seats are available in a fabric, duragrain or leather finish depending on model specification.

POWER OPERATED FRONT SEATS (NON-MEMORY)

Note. The following operations require the ignition switch to be in position I or II.

Note. 8-way memory switch pack shown.

Scheme 3

Forward/Backward adjustment

Push and hold the switch forwards or backwards to move the seat to the desired position.

Seat back adjustment

Twist the switch forwards or backwards until the desired seat back angle is achieved.

Seat cushion height adjustment

Push the switch up or down to raise or lower the cushion.

Scheme 4

The seat motors are a permanent magnet motor type coupled to a rack and pinion assembly. Should the motor seize or stick, an internal thermal cut-out switch will trip to remove voltage from the motor. Two pins within each of the seat switch packs control the seat motors. Both pins are connected to ground. Operating the switch applies voltage to one of the pins while the other pin remains connected to ground. Operating the switch in the opposite direction reverses power and ground path to the motor allowing the motor to run in the opposite direction.

Lumbar Adjustment

The lumbar pump inflates a bladder in the backrest which provides extra support for the seat occupant.

Lumbar Adjustment Switch Location

Scheme 5

Adjustment is achieved by operation of a rocker switch located on the outside of the seat, on the upper face of the side cushion trim. The switch is connected to an air pump, which inflates a lumbar bladder to provide the required lumbar adjustment. The air pump will operate for as long as the switch is operated in the inflate position. When the switch is operated in the deflate position, the switch operates a deflate solenoid to allow the air to escape from the bladder. The lumbar bladder is protected from over inflation by a pressure relief valve.

DRIVERS MEMORY SEAT

Note. 6-way switch pack shown.

Scheme 6

The memory control module can store up to three different driver seating, mirror and electric steering column (where fitted) positions for each key (up to 3 keys). The three-numbered memory and single memory store switches control memory storage and recall operations. Each switch is a momentary action push switch.

All seat adjustments are available whilst the ignition key is in position I or II or for a 10 minutes period from when either the driver door status is changed or the ignition key status changes from position I to position 0 (key in).

Note. This does not include lazy entry (refer to the lazy entry section for more information).

The mirror adjustment is only enabled when the ignition key is in position I or II.

Memory Recall

Memory recall has three memory positions stored for the seats, exterior mirrors and electric steering column (where fitted). The switches for this function are located on driver's seat outer side trim panel. Pressing the appropriate numbered memory switch allows the seat to start moving to the position appropriate to that memory.

The following procedure will store a memory position

1. Ensure the ignition key is in position I or II
2. Ensure reverse gear is not engaged
3. Manually adjust the seat to the desired position, using the seat switches
4. Press and release the 'memory store' switch
5. Press and release the desired numbered memory switch within 5 seconds

With the ignition key in position II, a single chime will be emitted from the instrument cluster to indicate that the store operation has been successful.

When a memory recall is initiated, to limit the overall current consumption, only two-seat axis will move towards their intended position at any one time. To minimize current load as the motors start, the initiation of each axis is phased with a 100ms delay between each motor starting.

The cushion slide and backrest will move first, followed by the cushion height and tilt. If the vehicle is stationary, the memory recall will operate in a 'one-touch' mode, whereby the switch can be released and the seat will continue to move to the memory position. If, however, the vehicle is in motion when the switch is released, then the system will operate in manual mode. This means that when the switch is released, the seat will stop moving. In order to reach the intended memory position, the switch must not be released until all movement has stopped. The instrument cluster will emit a double chime to indicate that the recall operation has been successfully completed.

If any of the seat adjustment or memory switches are activated during a 'one touch' memory recall, the recall will be overridden and the seat will begin to move in the direction corresponding to the switch that has been pressed.

Both mirrors move simultaneously about the vertical axis first (left/right), and then, once all vertical axis movements are complete, about the horizontal axis (up/down). To minimize the number of mirror drives required, a method of sharing is implemented, which dictates that all movement about one axis is complete before movement about the other axis commences.

Mirror movement coincides with the following switch request table (the table below shows module pins of connector C2383)

Lazy Entry

Pressing the unlock button on the remote transmitter will initiate a memory recall. This feature is known as 'lazy entry'. If the seat movement, memory switch or the lock button on the remote transmitter is pressed, then the 'lazy entry' feature will stop immediately.

The memory settings are stored within Electronic Erasable Programmable Read Only Memory (EEPROM) of the memory control module each time the ignition switch is cycled from position II to position I. These are the positional values that a lazy entry request uses when the remote unlock button for that particular key is next pressed.

The lazy entry feature can be activated or deactivated via the setting menu of the high line instrument cluster. This provides the driver with the option to enable or disable lazy entry as required.

For additional information, refer to: Information And Message Center information.

Immediate Adjustment

Pressing one of the manual adjustment switches will initiate the corresponding motor for that axis until the switch is released.

Only two seat motors can be driven at any one time. However, due to the sharing of relays, there are certain combinations of motors that cannot be driven together. The following table indicates which axis can and cannot be operated at the same time

If two axis are being driven and a third axis is requested to move, the third switch request is ignored until either of the two axis switches, already active, are released. The third axis movement may only be initiated providing the switch has been released and re-selected.

Seat adjustment can be initiated simultaneously with any mirror movement.

REVERSE GEAR MIRROR POSITION

To give the driver a clear view of the curbs when reversing, the exterior door mirror's can be dipped when reverse gear is selected. The level of mirror dipping is set to a predetermined amount when the vehicle leaves the factory but has the ability to be customer programmed.

The following procedure will store a reverse gear mirror position

1. Ensure the ignition key is in position I or II
2. Perform a memory recall procedure
3. Ensure reverse gear is engaged
4. Manually adjust the mirrors to the desired position
5. Press and release the 'memory store' switch
6. Press and release the desired numbered memory switch
7. Reverse gear mirror dip setting will be stored for that particular memory setting.

A single chime will be emitted from the instrument cluster to indicate that the store operation has been successful and 'Mirror Dip Stored' message will be displayed in the message center.

Once this sequence has been completed, the stored mirror position will be the position that the mirrors move to when reverse gear is next selected.

Storing a memory position with reverse gear selected only affects reverse gear mirror positions, the remainder of the memory position's remain unchanged.

To protect against an accidental setting, the mirror position will only be stored if a mirror adjustment has been made since reverse gear was selected. If there is no reverse gear mirror position stored, then a default setting, stored in the memory control module, is adopted.

There are three memory settings per key. For each of these settings there is a reverse gear mirror position store. This equates to a possible nine reverse gear mirror position settings. Personalisation memory setting relates to the 3 most recent ignition keys.

Scheme 7

The reverse gear mirror position feature can be activated or deactivated via the customer personalization feature of the high line instrument cluster. This provides the driver with the option to enable or disable reverse gear mirror position as required.

For additional information, refer to: Information And Message Center information.

Information regarding the reverse gear mirror status, for both manual and automatic transmissions, is transmitted as a message on the Local Interconnect Network (LIN) bus.

When the reverse gear mirror position feature is toggled 'OFF', all 3-memory settings associated with that personalization memory will return to the default reverse gear mirror settings.

Note. Reverse gear status is only available with the ignition in position II.

When reverse gear is de-selected, the mirror position immediately prior to reverse selection will be resumed, unless a memory recall has been requested whilst reverse has been selected, in which case the mirrors will move to the requested memory position when reverse is de-selected.

On vehicles fitted with the ZF automatic transmission there is a delay of 0.5 second following the selection of reverse gear, prior to the reverse mirror position being recalled. This is to prevent any movement of the mirrors as the gear selector is moved through the reverse position on the way to, and from, the park position.

STEERING COLUMN ADJUST (WHERE FITTED)

The memory control module controls the electric adjustable steering column in a rake (up and down) and reach (in and out). The steering column can be adjusted for rake and reach by operating the rotary joystick control switch on the LH side of the steering column.

Scheme 8

To adjust the steering column

1. Turn the switch to the 'Column' or 'Auto' position
2. Move the switch forwards or backwards to adjust the reach
3. Move the switch up or down to adjust the rake.

Entry/Exit Mode

Entry/Exit mode provides automatic movement of the steering column and driver's seat to allow easier entry to or exit from the vehicle.

Entry/Exit mode is selected by setting the steering column adjustment switch to the 'AUTO' position.

Note. If the adjustment switch is moved away from 'AUTO' whilst the steering column is tilted away, the steering column will move back to it's memorized position when the key is next inserted in the ignition. Entry/Exit mode will then be cancelled.

Note. If the adjustment switch is moved during entry/exit operation, steering column movement will stop.

Exit

When the ignition key is removed, the steering column will move to the uppermost rake and innermost reach positions and the driver's seat will move slightly rearwards and lower.

Entry

When the key is inserted in the ignition the steering column and seat will return to their previous positions. If, however, the memorized driver position has been changed (using the seat memory switches or another key transmitter), the steering wheel and seat will move to the new position.

Steering Column Control

Adjustment of the steering column is achieved by a single DC motor. Each adjustment movement is transmitted through a solenoid actuated clutch; one clutch for reach movement and one for rake movement.

When engaged, a clutch can be released only if the system is unstressed. As the clutches are mounted on the same motor spindle, the sequence for position adjustment is as follows

1. Engage the selected clutch by powering the appropriate solenoid
2. After a time period (approximately 0.1 of a second), the motor is powered in the desired direction
3. When the motor reaches the stop position the solenoid and motor is released/unpowered. The clutch remains engaged under stress
4. After a time period (approximately 0.1 of a second), the motor is powered in the opposite direction to enable the clutch to disengage when the stress is released.

Simultaneous rake and reach movements are not possible since the motor must reverse direction as soon as the first axis has reached it's required position.

Steering column rake and reach is controlled via potentiometer feedback.

AUDIBLE AND VISUAL CONFIRMATIONS

An audible confirmation is generated by the instrument cluster to provide confirmation to the driver that the requested operation has been successfully completed. The following operations support an audible confirmation

In addition to audible confirmation there is also a visual confirmation via the instrument cluster message center.

For additional information, refer to: Information And Message Center information.

MEMORY CONTROL MODULE

Note. Memory control module location (LHD shown, RHD similar)

Scheme 9

The memory control module, located under the driver's seat, relies upon a number of inputs to control various outputs. As with all electronic control modules, the unit needs information regarding the current operating conditions of the engine and other related systems before it can make calculations, which determine the appropriate outputs.

All memory values are stored in the non-volatile memory, EEPROM. The current motor positions, which are monitored by the control modules integral Hall sensors, are stored in the EEPROM. If a loss of power occurs, upon power reconnection the current motor position are recalled from the memory and adopted as the current positions. This will allow the relative memory positions to be retained without any need to re-calibrate. The memory control module checks the integrity of all data stored in the EEPROM each time it exit's stand-by mode. In the event that the data is corrupt, the control module adopts the default values for all of the programming options. All memory positions are deemed as invalid and the software will perform as if there are no memory positions stored. Following the procedure for storing a memory position again will reset the relevant memory and allow full functionality.

Stall Detection

Seat, steering column (where fitted) and mirror motors are deemed to have stalled if there is no change in the inputs that are received from the corresponding feedback sensors for 200ms (seat), 1000ms (mirror & steering column) while that axis is being driven.

If a stall condition is detected then the drive to that axis is cancelled for the remainder of that memory operation (memory recall) or until the switch is re-selected (manual movement).

If the motor movement has stopped due to loss of sensor feedback, either stall or sensor failure, then that axis may be activated again, to move past the stall position, by re-selecting the appropriate switch. This allows control of the motor to be maintained if sensor feedback is lost.

Upon re-selection of movement, if sensor pulses are detected then the motor will continue to be driven until the switch is released or another stall condition is detected. If sensor feedback is not detected then the motor is only driven for 0.5 second and then stops until the switch is released and then pressed again, when a further 0.5 second of activation is permitted, and so on.

For all seat motor and steering column manual movements, whenever a motor is driven and a stall occurs, the memory control module records the position at which the stall occurred. If movement occurs beyond a stall position, then that position is erased from the control modules memory. This will always allow movement past a previously recorded stall position once movement has been registered beyond that position. This is the case for both manual and memory movement.

Initialization

When a replacement memory control module is fitted to a seat it should be initialized so that the control module can learn the seats and steering column maximum and minimum adjustment values. This is achieved by

1. adjusting all seat movement axis from one end of travel to the other; slide, recline, height and tilt
2. adjusting all steering column movement from one end of travel to the other; rake and reach.

Battery Monitor

If the battery voltage drops below 10.5 Volts, then the memory control module ignores all requests for a memory recall, including lazy entry, or easy entry/exit until the battery voltage has reached 11.5 Volts. This will conserve as much power in the vehicle battery as possible to enable engine cranking.

Stand-by Mode

The memory control module supports a stand-by mode to keep power consumption to a minimum.

The control module will enter stand-by mode upon receipt of a LIN bus 'SLEEP' message from the Central Junction Box (CJB). Alternatively, a time period of 3 seconds after the LIN bus network has remained quiet provided there are no motors being driven at that time and there are no valid switch requests.

If there is a failure with the LIN bus network then the seat will be operational in 'inch mode' only.

If the control module is being prevented from entering stand-by mode due to motor movement, memory recall or switch operation, then it will enter stand-by mode when the current function has terminated.

Note. In the case of a memory recall, all memory recall operations should be carried out before entering stand-by mode, not just the current motor movement.

The control module will exit stand-by mode if there is any LIN bus activity. When the control module exits stand-by mode it must verify the 'System Enable Status' in order to recognize when it should respond to a switch request.

Scheme 10

Front Seats

Front Seat Heater Switches

Scheme 11

The heated front seat system is available on both manual and electric seats and is controlled by the Automatic Temperature Control (ATC) module.

When the front seat heater switch is operated, power is supplied to the heater elements in the seat, causing the seat to heat up. The ATC module senses seat temperature via the sensor in the cushion and regulates voltage to the seat heater elements to maintain a constant temperature.

For additional information, refer to: Control Components - LHD/RHD information.

Rear Seat Heaters

Rear Seat Heater Switches

Scheme 12

The RH and LH rear seats support three integral heating elements, squab, backrest and bolster. The optional rear child booster seat also supports an integral seat-heating element.

Note. The rear center seat is not available with seat heating.

The rear seat heaters are enabled when the ignition switch is in position II, and operate at one of two temperature settings. With the first press of a rear seat heater switch the relative rear seat heat control module (RH or LH) adopts the higher temperature setting, supplies a power feed to the related rear seat heater elements and illuminates two amber LED's in the switch. At the second press of the switch the control module adopts the lower temperature setting and extinguishes one of the LED's. At the third press of the switch the control module de-energizes the heater elements and extinguishes the second LED. The seat heaters remain on until selected off or the ignition is turned off.

The rear seat heat control modules receive an input from a temperature sensor in RH and LH rear seats, and regulate the power feed to the heater elements to control the seat temperature at the appropriate temperature setting between 35 and 45 °C (95 and 113 °F). The actual temperature settings vary with the type of seat covering, to allow for the differing heat conduction properties of the different seat covering materials.

DIAGNOSTICS

The exchange of information between a Land Rover approved diagnostic system and the memory control module is via the CJB, which are interconnected via the hi-speed Controller Area Network (CAN) bus and Local Interconnect Network (LIN) bus. There is a non-volatile memory (EEPROM) for saving detected errors. Its contents are not lost when the power supply is disconnected. Only a Land Rover approved diagnostic system can erase the error memory.

CONTROL DIAGRAM

Note. A = Hardwired; O = LIN bus

Scheme 13

The diagnosis of the seats can be separated into three main areas, seat movement, memory and seat heating.

Seat heating is controlled by the automatic temperature control module, so there will be some cross-over with the climate control section as far as diagnostic trouble codes (DTCs) are concerned.

There are a number of linked systems, such as the mirror and steering column movement which will also be covered in this section.

For information on the description and operation of the systems, refer to the relevant section of the service information.

INSPECTION AND VERIFICATION

1. Verify the customer concern.
2. Visually inspect for obvious mechanical or electrical faults. It is not unusual for foreign objects to find their way into the runners and frames of the seats. Visual Inspection Mechanical Electrical Seat runners Seat frames Seat movement switch condition and installation Seat heater switch condition and installation Seat motor(s) condition and installation Steering column switch condition and installation Steering column condition and installation Door mirror switch condition and installation Door mirror condition and installation Battery condition and state of charge Fuses Harnesses and connectors Seat movement switch (es) Seat heater switch (es) Seat heater elements Seat motor(s) Seat module(s) Memory control module(s) Steering column switch Steering column motor Door mirror switch (es) Door mirror motor(s) Ignition switch Battery junction box (BJB) Central junction box (CJB) Local interconnect network (LIN) circuit
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. Use the approved diagnostic system or a scan tool to retrieve any DTCs before moving onto the symptom chart or DTC index. Because the DTCs are stored in more than one module, a complete vehicle read is recommended. Make sure that all DTCs are cleared following rectification.

SYMPTOM CHART

Note. References to seat movement refer to either front seat.

DTC INDEX

Note. Generic scan tools may not read the codes listed, or may read only 5-digit codes. Match the 5 digits from the scan tool to the first 5 digits of the 7-digit code listed to identify the fault (the last 2 digits give extra information read by the manufacturer-approved diagnostic system).

Note. For a full list of seat heating function DTCs, refer to Climate Control System information. For additional DTCs, refer to Module Communications Network information.

REMOVAL

Note. Left-hand shown, right-hand similar.

Note. The Torx bolts can be re-used.

Scheme 14

Scheme 15

1. Release the rear seat. Fold the LH seat cushion forward. Remove the 7 Torx bolts. Fold down the rear seat backrest. Disconnect the electrical connector.
2. With assistance, remove the rear seat assembly.
3. Remove the rear seat cushion side trim. Release the seat heater control module. Remove the Torx screw. Release the 6 clips.
4. Remove the seat frame trim. Release the 4 clips.

INSTALLATION

1. Install the seat frame trim. Carefully secure the clips.
2. Install the rear seat cushion side trim. Carefully secure the clips. Fit and tighten the Torx screw. Install the seat heater control module.
3. With assistance, install the rear seat assembly. Position the seat on the dowels.
4. Secure the rear seat. Return the seat backrest to the upright position. Tighten the Torx bolts to 40 Nm (30 lb.ft). Fold the seat cushion rearwards. Connect and secure the electrical connector.

Scheme 16

Scheme 17

Scheme 18

1. Make the SRS system safe. For additional information, refer to: «Standard Workshop Practices»(/land-rover/range-rover-sport/i-2005-2009/remont/oem-general-information/#general-information) information.
2. Release the front seat. Remove the bolt covers. Remove the 5 Torx bolts.
3. Release the safety belt lower anchor from the seat. Remove the bolt cover. Passenger side, disconnect the electrical connector. Remove and discard the Torx bolt.
4. With assistance, remove the front seat. Protect the rocker panel. Remove the bolt. Disconnect the 2 electrical connectors. Release the 2 wiring harness clips.

1. With assistance, install the front seat. Connect the electrical connectors. Secure the wiring harness clips.
2. Attach the safety belt lower anchor to the seat. Tighten the new Torx bolt to 40 Nm (30 lb.ft). Passenger side, connect the electrical connector. Install the bolt cover.
3. Secure the front seat. Tighten the Torx bolts to 40 Nm (30 lb.ft). Install the bolt covers.
4. Connect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-and-charging-system-general-information__specifications) information.

Scheme 19

Scheme 20

Scheme 21

1. Raise the seat base for access.
2. Remove the drive cable. Disconnect the seat motor electrical connector.
3. Remove the 2 clips.
4. Remove the front seat track motor.

1. Install the front seat track motor. Install the drive cable. Install the 2 clips.
2. Install the drive cable. Connect the seat motor electrical connector.

Scheme 22

1. Remove the front seat backrest cover. For additional information, refer to: «Front Seat Backrest Cover»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
2. Remove the front seat backrest pad.
3. Remove the front seat recliner motor. Disconnect the electrical connector. Remove the Torx bolt. Remove the front seat backrest shaft clip. Remove the front seat backrest shaft.

1. Install the front seat recliner motor. Install the front seat backrest shaft. Install the front seat backrest shaft clip. Tighten the Torx bolt to 10 Nm (7 lb.ft). Connect the electrical connector.
2. Install the front seat backrest pad.
3. Install the front seat backrest cover. For additional information, refer to: «Front Seat Backrest Cover»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .

Scheme 23

Scheme 24

1. Remove the front seat cushion assembly. For additional information, refer to: «Front Seat Cushion»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
2. Release the front seat cushion cover. Release the 13 clips.
3. Remove the front seat cushion cover. Remove the 12 hog rings.

1. Install the front seat cushion cover. Install the hog rings. Attach the cover and secure with the clips.
2. Install the front seat cushion assembly. For additional information, refer to: «Front Seat Cushion»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .

Scheme 25

1. Remove the front seat cushion cover. For additional information, refer to: «Front Seat Cushion Cover»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
2. Remove the front seat cushion heater mat.

1. Install the front seat cushion heater mat.
2. Install the front seat cushion cover. For additional information, refer to: «Front Seat Cushion Cover»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .

Note. This procedure shows the removal and installation of both the LH and the RH covers.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Fold the seat cushion forward.
2. Release the rear LH seat cushion cover. Release the clip.
3. Remove the rear LH seat cushion cover. Remove the 21 hog rings.
4. Release the rear RH seat cushion cover. Release the clip.
5. Remove the rear RH seat cushion cover. Remove the 10 hog rings.

1. Install the rear seat cushion cover. Install the hog rings. Attach the retaining clip.
2. Fold the seat cushion rearwards.

Note. Front seat height adjustment motor is supplied as part of the front seat frame assembly.

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. Remove the front safety belt buckle. For additional information, refer to: «Front Safety Belt Buckle»(/land-rover/range-rover-sport/i-2005-2009/remont/passive-restraints/#safety-belt-system) information.
2. Remove the front seat cushion assembly. For additional information, refer to: «Front Seat Cushion»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
3. Remove the front seat backrest assembly. Release and disconnect the 2 electrical connectors. Remove the 4 Torx bolts.
4. Remove the front seat electrical connector bracket. Remove the 4 screws.
5. Remove the front seat tilt motor. Release the 3 wiring harness clips. Remove the 4 Torx bolts.
6. Remove the front seat position sensor. Remove the 2 nuts.
7. Remove the front seat height adjustment motor. Disconnect the electrical connector. Remove the 8 nuts.

1. Install the front seat height adjustment motor. Tighten the nuts to 25 Nm (18 lb.ft). Connect the electrical connector.
2. Install the front seat position sensor. Tighten the nuts to 4 Nm (3 lb.ft).
3. Install the front seat tilt motor. Tighten the Torx bolts to 10 Nm (7 lb.ft). Attach the wiring harness.
4. Install the front seat electrical connector bracket. Tighten the screws.
5. Install the front seat backrest assembly. Tighten the Torx bolts to 25 Nm (18 lb.ft). Connect and secure the electrical connectors.
6. Install the front seat cushion assembly. For additional information, refer to: «Front Seat Cushion»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
7. Install the front safety belt buckle. For additional information, refer to: «Front Safety Belt Buckle»(/land-rover/range-rover-sport/i-2005-2009/remont/passive-restraints/#safety-belt-system) information.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Make the SRS system safe. For additional information, refer to: «Standard Workshop Practices»(/land-rover/range-rover-sport/i-2005-2009/remont/oem-general-information/#general-information) information.
2. Remove the front safety belt buckle. For additional information, refer to: «Front Safety Belt Buckle»(/land-rover/range-rover-sport/i-2005-2009/remont/passive-restraints/#safety-belt-system) information.
3. Remove the front seat cushion side trim. Remove the 2 screws. Release from the 3 clips.
4. Remove the front seat backrest hinge cover. Remove the 2 screws. Release from the clip.
5. Remove the front seat backrest assembly. Release the retaining clips and disconnect the three electrical connectors. Remove the 4 Torx bolts.
6. Remove the front seat head restraint. Release the front seat head restraint latch.
7. Remove the seat armrest.
8. Remove the front seat lumbar adjustment knob. Pull sharply to release from lumbar mechanism.
9. Release the front seat backrest cover. Release the 5 clips. Release the tension straps.
10. Remove the front seat backrest cushion and cover from the front seat frame. Remove the 3 hog rings.

1. Install the front sear backrest cover. Install the hog rings. Install the clips. Attach the tension straps.
2. Install the front seat lumbar adjustment knob. Push firmly to secure to the lumbar mechanism.
3. Install the seat armrest. Tighten the Torx bolt to 10 Nm (7 lb.ft). Install the bolt cover.
4. Install the front seat head restraint.
5. Install the front seat backrest assembly. Tighten the Torx bolts to 25 Nm (18 lb.ft). Connect and secure the electrical connectors.
6. Install the front seat backrest hinge cover. Tighten the screws. Fit the clip.
7. Install the front seat cushion side trim. Position and secure in the clips. Install the screws.
8. Install the front safety belt buckle. For additional information, refer to: «Front Safety Belt Buckle»(/land-rover/range-rover-sport/i-2005-2009/remont/passive-restraints/#safety-belt-system) information.

Note. This procedure shows the removal of both the LH and RH covers.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. LH seat only: Remove the safety belt retractor cover and guide. Remove the 2 screws.
2. Remove the rear seat release handle.
3. Remove the rear seat release handle finisher. Remove the screw.
4. Remove the rear seat head restraint. Depress the 2 retaining clips.
5. Remove the rear seat head restraint retaining clips.
6. Release the rear LH seat backrest cover. Release the 10 clips.
7. Remove the rear LH seat backrest cover. Remove the 41 hog rings.
8. Release the rear RH seat backrest cover. Release the 9 clips.
9. Remove the rear RH seat backrest cover. Remove the 24 hog rings.

1. Install the rear seat backrest cover. Install the hog rings. Attach the clips.
2. Install the rear seat head restraint retaining clips.
3. Install the rear seat head restraint.
4. Install the rear seat release handle finisher. Tighten the screw.
5. Install the rear seat release handle.
6. Install the safety belt guide and retractor cover. Attach the safety belt guide and retractor cover. Tighten the screws.

Note. In this procedure the cushion is removed as an assembly. There is a separate procedure showing removal of the cushion cover.

Scheme 46

1. Remove the front seat cushion assembly. Release and disconnect the 2 electrical connectors. Remove the 4 Torx bolts.

1. Install the front seat cushion assembly. Tighten the Torx bolts to 25 Nm (18 lb.ft). Connect and secure the electrical connectors.

Note. The front seat track motor is supplied as part of the front seat lower frame assembly.

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. Remove the front seat. For additional information, refer to: «Front Seat»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
2. Remove the front seat cushion side trim. Remove the 2 Torx screws. Release from the 4 clips.
3. Release the seat control switch. Remove the 2 screws. Remove the 2 clips.
4. Remove the front seat base trim. Remove the screw. Release the 2 clips.
5. Remove the front seat base. Remove the 6 nuts.
6. Remove the front seat track motor. Disconnect the electrical connector. Release the electrical connector. Remove the 8 nuts.
7. Remove the front seat track motor assembly from the seat rails. Remove the 4 bolts. Release the flexi drive from the seat rails.

Scheme 51

1. Make sure the seat rails are installed as a matched pair as supplied. Make sure the seat rails are correctly aligned.
2. Install the front seat track motor assembly to the seat rails. Install the 4 bolts. Tighten the nuts to 10 Nm (7 lb.ft).
3. Install the front seat track motor. Tighten the nuts to 22 Nm (16 lb.ft). Connect the electrical connector. Secure the electrical connector.
4. Install the front seat base. Tighten the nuts to 22 Nm (16 lb.ft).
5. Install the front seat base trim. Secure in the clips. Tighten the screw.
6. Install the front seat cushion side trim. Secure in the clips. Tighten the screws.
7. Install the seat control switch. Secure in the clips. Tighten the screws.
8. Install the front seat. For additional information, refer to: «Front Seat»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Remove the drivers side seat slides. For additional information, refer to: «Seat Track - Vehicles With: Power Seats»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
2. Remove the front seat cushion base. For additional information, refer to: «Front Seat Cushion»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) .
3. TORQUE: 25 Nm
4. Secure the seat base using the 4 tie straps supplied, as shown. Using the seat height adjuster, lower the seat base to its lowest position.
5. Release the arm from the height adjuster. Remove the Torx bolt.
6. Drill out the 4 rivets.

1. To install, reverse the removal procedure.

See also:
• Information And Message Center
• Control Components - LHD/RHD
• Climate Control System
• Module Communications Network
• Standard Workshop Practices
• Specifications
• Front Safety Belt Buckle
• Front Seat Backrest Cover
