Safety Belt System Land Rover Range Rover Sport I

SPECIFICATIONS

TORQUE SPECIFICATIONS

Scheme 1

GENERAL

A three point safety belt is installed at each seat position. Except in NAS (north American specification) markets, all of the safety belts have an ELR (emergency locking retractor). In NAS markets, only the driver seat is fitted with an ELR; all of the passenger safety belts have an ALR (automatic locking retractor).

Both types of retractor incorporate a liftshaft locking system with webbing sensor and car sensor activating mechanisms. The webbing sensor activates the locking system if the webbing is subjected to a sharp pull. The car sensor activates the locking system if the vehicle is subjected to sudden deceleration or a severe tilt angle.

The ALR has a mode of operation where the retractor will take up slack in the webbing, but not allow any slack to be paid out. This mode of operation can be used to secure a child seat.

1. To engage the ALR child seat mode of operation: Pull the webbing out of the retractor to its full extent.
2. To cancel the ALR child seat mode of operation: Allow the retractor to fully rewind the webbing.

A safety belt warning indicator is installed in the instrument cluster to remind the front seat occupants to fasten their safety belts. On NAS vehicles, when the ignition switch is turned to position II, the warning indicator illuminates if the safety belt of an occupied front seat is not fastened. The warning indicator remains illuminated until the safety belt of each occupied front seat is fastened, or the ignition is switched off. In all markets except NAS, a belt minder function provides a more intrusive reminder to fasten the front safety belts.

FRONT SAFETY BELTS

The retractor of each front safety belt is attached to the related B pillar. The webbing runs from the retractor through an upper mounting, attached to a shoulder height adjuster on the B pillar, to an anchor point on the front seat.

On NAS vehicles, a tension sensor is integrated into the anchor point of the passenger front safety belt. The tension sensor is part of the occupant classification system.

For additional information, refer to: Air Bag And Safety Belt Pretensioner Supplemental Restraint System (SRS) information.

The retractor for each front safety belt incorporates a load limiter that allows the retractor reel to partially unwind when the load on the webbing exceeds a predetermined limit.

The buckle for each front safety belt is attached to a pretensioner secured to the inboard side of the related front seat frame. Each buckle incorporates a safety belt buckle sensor that provides a status input to the restraints control module (RCM), which uses the input to determine the air bag and pretensioner activation strategies. The RCM also relays the status of the safety belts to the instrument cluster on the high speed controller area network (CAN) bus.

Belt Minder Function (Where Fitted)

The belt minder function provides warnings to the driver if the appropriate front safety belts are not fastened when driving. The belt minder function is controlled by the instrument cluster using

1. Medium speed CAN bus messages, from the RCM, to monitor the status of the front safety belts.
2. An input from the occupant detection system to monitor the status of the front passenger seat. For additional information, refer to: «Air Bag And Safety Belt Pretensioner Supplemental Restraint System (SRS)»(/land-rover/range-rover-sport/i-2005-2009/remont/airbag/#supplemental-restraint-system) information.

When the ignition switch is turned to position II, the instrument cluster illuminates the safety belt warning indicator until one of the front safety belts is fastened or the belt minder function is triggered. The belt minder function is triggered when the ignition switch is in position II and the following conditions coexist

1. The belt minder function is enabled.
2. Vehicle speed is 8 km/h (5 mph) or more.
3. The vehicle is not in reverse.
4. The driver safety belt or, if the front passenger seat is occupied, the front passenger safety belt, is unfastened.

When the belt minder is triggered, the instrument cluster generates the following warnings for 10 seconds.

1. Flashes the safety belt warning indicator at 2 Hz.
2. Sounds a repeating chime in sequence with the flashing safety belt warning indicator.

After 10 seconds, the repeating chime is discontinued and the safety belt warning indicator changes from flashing to continuously illuminated. While the trigger conditions still coexist, the warnings are repeated every 30 seconds until one of the following occurs

1. 5 minutes has elapsed from when the warnings were first triggered.
2. The safety belt of each occupied front seat is fastened.
3. The ignition switch is turned to position 0.
4. The vehicle speed decreases to 5 km/h (3 mph).

The belt minder function can be enabled and disabled using the driver safety belt switch. The instrument cluster changes the state of the belt minder function if, within 60 seconds of first turning the ignition switch to position II, the driver safety belt is fastened and unfastened nine times. Successful completion of the change is indicated by a single chime and the safety belt warning indicator flashing five times, at 2 Hz. The belt minder function can also be enabled and disabled using T4.

Safety Belt Warning Indicator

SECOND ROW SAFETY BELTS

The retractor of each outboard second row safety belt is attached to the body immediately behind the D pillar. The webbing runs from the retractor, through an upper mounting on the D pillar, to an anchor point at the front of the related wheel arch.

The retractor for the center second row safety belt is installed in the top of the seat back. The webbing runs from the retractor, over the top of the seat, to an anchor point at the base of the seat frame.

The buckles for the second row safety belts are attached to the related seat frame.

PRINCIPLE OF OPERATION

For a detailed description of the seatbelt system and operation, refer to the relevant Description And Operation section of the service information. REFER to: Safety Belt System .

SAFETY INFORMATION

Note. Do not to use a cellular phone or to have a cellular phone in close proximity when working on the SRS system or components

Power supply depletion

Before beginning any work on the SRS system or related components

1. Remove the ignition key
2. Disconnect the battery leads, ground first
3. Wait 2 minutes for the power circuit to discharge

There are comprehensive instructions on the correct procedures for SRS system repairs, refer to the relevant service information.

INSPECTION AND VERIFICATION

Note. Check and rectify basic faults before beginning diagnostic routines including pinpoint tests

1. Verify the customer concern by operating the seatbelt
2. Visually inspect for obvious signs of mechanical or electrical damage Visual Inspection Mechanical Electrical Check for the installation of non-standard accessories which may affect or obstruct the function of the seatbelt system Frayed or damaged webbing Missing or damaged button stop Pretensioner(s) Buckles/Stalks Fuses Wiring harness fault Correct engagement of electrical connectors Loose or corroded connections Warning lamp bulb(s) Impact sensor(s) Buckle sensor(s) Pretensioner(s) Belt tension sensor(s) Restraints control module
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step
4. If the cause is not visually evident, carry out the test methods described below, alternatively check for diagnostic trouble codes and refer to the relevant diagnostic trouble code index

For a complete list of all diagnostic trouble codes that could be logged on this vehicle, please refer to

REFER to: Air Bag Supplemental Restraint System (SRS) information.

SYMPTOM CHART FOR SEATBELT ROWS 1, 2 AND 3

INERTIA REEL SEATBELTS

The vehicle is equipped with (two row one), (three row two), and (two row three (seven seat versions only)) inertia reel seatbelts

These seatbelts are "dual sensitive" which means that they have

1. Car sense system - A vehicle motion sensor, which locks the seatbelt webbing under braking, cornering, on steep hills and in adverse camber conditions, when parked on a steep incline or driveway or two wheels on a high curb
2. Webb sense system - A webbing motion sensor, which locks when the seatbelt webbing is extracted suddenly

The seatbelts in the following positions are equipped with an automatic locking retractor function

The automatic locking retractor function is a feature to secure a child seat or heavy load to the seat

SEATBELT LOCKING TEST

With the vehicle stationary and on level ground take firm hold of the seatbelt webbing (on the tongue side of the upper seatbelt anchor) and withdraw sharply, the retractor should lock . Preventing further webbing release (repeat this test 3 times) . Any seatbelt retractor which fails to lock must not be used and a new seatbelt must be installed .

DTC INDEX

Information not available at this time.

PINPOINT TEST A: BACKLOCK

PINPOINT TEST B: WEBBING - TRAPPED IN SEAT

PINPOINT TEST C: SEATBELT RETRACTOR - WEBBING GUIDE LOOSE

PINPOINT TEST D: TWIST IN WEBBING

PINPOINT TEST E: INTERFERENCE - WEBBING ROUTING

1. E1: INTERFERENCE - WEBBING ROUTING Refer to the removal and installation section of this service information, remove any trim panels required to expose the D loop (anchor point) Remove obstructions and foreign objects ensure the webbing does not catch or rub Confirm the seatbelt does not contact the wiring harness Check for correct operation twice Does the webbing move freely then retract correctly? Yes : Refer to the removal and installation section of this service information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required No : GO to Pinpoint Test «F»(/land-rover/range-rover-sport/i-2005-2009/remont/passive-restraints/#safety-belt-system__pinpoint-test-f-seatbelt-retractor) .

PINPOINT TEST F: SEATBELT RETRACTOR - INCORRECT INSTALLATION

1. F1: SEATBELT RETRACTOR - INCORRECT INSTALLATION Refer to the removal and installation section of this service information, remove any trim panels required to expose the D loop (anchor point) and the seatbelt retractor Refer to the removal and installation section of this service information, correctly reinstall the seatbelt retractor ensure that the locating "T bar" and "anti rotation pins" are correctly located Check for correct operation twice Does the webbing move freely then retract correctly? Yes : Refer to the removal and installation section of this service information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required No : Replace as required. Refer to the warranty policy and procedures manual, or determine if any prior approval program is in operation, prior to the installation of a new module/component

PINPOINT TEST G: D-LOOP NOT ROTATING CORRECTLY

1. G1: D-LOOP NOT ROTATING CORRECTLY Refer to the removal and installation section of this service information, remove any trim panels required to expose the D loop (anchor point) and the seatbelt retractor Ensure there are no obstructions and the webbing does not catch or rub, the D loop (anchor point) rotates correctly and if installed the confirm the height adjuster operates correctly Check for correct operation twice Does the webbing move freely then retract correctly? Yes : Refer to the removal and installation section of this service information, reinstall any trim panels, ensure there are no obstructions and the webbing does not catch or rub. No further action required No : Replace as required. Refer to the warranty policy and procedures manual, or determine if any prior approval program is in operation, prior to the installation of a new module/component

PINPOINT TEST H: MINI BUTTON - MISSING/DAMAGED

1. H1: MINI BUTTON - MISSING/DAMAGED NOTE: This test applies to the rear center seatbelt retractor installed in the seat back Refer to the removal and installation section of this service information, remove the seat cushion and the plastic escutcheon at the top of the seat back (where the webbing exits to expose the lower anchor fixing point of the center seatbelt) Remove the lower anchorage of the seatbelt With the seat back correctly latched, allow up to 20mm webbing to retract, then extract the webbing Is the mini-button (webbing travel limit stop) correctly installed to the webbing and in good condition? Yes : Feed the mini-button back through the plastic escutcheon if required. Correctly reinstall the escutcheon to the seat back, extract the webbing then allow to retract, ensure the mini-button comes to rest outside the escutcheon stop No : Replace as required. Refer to the warranty policy and procedures manual, or determine if any prior approval program is in operation, prior to the installation of a new module/component

PINPOINT TEST I: SEATBELT BUCKLE - NOT LATCHING/JAMMED

1. I1: SEATBELT BUCKLE - NOT LATCHING/JAMMED CAUTION: Do not insert any objects or tools into the buckle head Visually inspect the buckle head for evidence of damage. If damaged replace as required Depress the buckle release (red button) and (Using a torch) carry out visual inspection for any evidence of debris/material or foreign objects in the buckle head If required remove the pretensioner from the vehicle. Remove the seat. Remove the pretensioner from the seat frame Do not insert any objects or tools buckle head With the buckle removed invert and attempt to shake out any debris Attempt to latch the tongue in the buckle Does the seatbelt buckle operate correctly Yes : Reinstall any components, no further action required No : Replace the pretensioner, Refer to removal and installation section of this service information.

REMOVAL

1. Position the front seat fully forwards.
2. Remove the scuff plate trim panel. For additional information, refer to: «Scuff Plate Trim Panel»(/land-rover/range-rover-sport/i-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-omamentation) information.
3. Release the safety belt upper anchor. Remove and discard the Torx bolt.
4. Remove the safety belt retractor assembly. Remove and discard the Torx bolt.

INSTALLATION

1. Install the front safety belt retractor. Tighten the Torx bolt to 40 Nm (30 lb.ft).
2. Attach the safety belt upper anchor. Tighten the Torx bolt to 40 Nm (30 lb.ft).
3. Install the scuff plate trim panel. For additional information, refer to: «Scuff Plate Trim Panel»(/land-rover/range-rover-sport/i-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-omamentation) information.

1. Release the safety belt retractor cover and guide Remove the 2 screws. Remove the safety belt guide. Remove the retractor cover.
2. Remove the safety belt lower anchor. Raise the seat cushion. Remove and discard the nut.
3. Remove the safety belt retractor assembly. Remove and discard the Torx bolt.

1. Install the safety belt retractor assembly. Tighten the new Torx bolt to 40 Nm (30 lb.ft).
2. Install the safety belt guide and retractor cover. Attach the safety belt guide and retractor cover. Tighten the screws.
3. Install the safety belt lower anchor. Tighten the new nut to 40 Nm (30 lb.ft). Lower the seat cushion.

Note. Left-hand shown, right-hand similar.

Scheme 2

1. Remove the D-pillar upper trim panel. For additional information, refer to: «D-Pillar Trim Panel»(/land-rover/range-rover-sport/i-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-omamentation) information.
2. Release the safety belt upper anchor. Remove and discard the Torx bolt.
3. Remove the second row safety belt retractor. Remove and discard the Torx bolt.

1. Install the second row safety belt retractor. Tighten the Torx bolt to 40 Nm (30 lb.ft).
2. Install the safety belt upper anchor. Tighten the Torx bolt to 40 Nm (30 lb.ft).
3. Install the D-pillar upper trim panel. For additional information, refer to: «D-Pillar Trim Panel»(/land-rover/range-rover-sport/i-2005-2009/remont/exteriorinterior-trim/#interior-trim-and-omamentation) information.

Scheme 3

1. Disconnect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-and-charging-system-general-information__specifications) information.
2. Make the SRS system safe. For additional information, refer to: «Standard Workshop Practices»(/land-rover/range-rover-sport/i-2005-2009/remont/oem-general-information/#general-information) information.
3. Remove the front seat. For additional information, refer to: «Front Seat»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) information.
4. Remove the seat backrest hinge cover. Remove the 2 screws.
5. Remove the front safety belt buckle. Remove the Torx bolt. Disconnect the 2 electrical connectors. Release the wiring harness.

1. Install the front safety belt buckle. Tighten the Torx bolt to 40 Nm (30 lb.ft). Connect the electrical connectors. Attach the wiring harness.
2. Install the seat backrest hinge cover. Tighten the screws.
3. Install the front seat. For additional information, refer to: «Front Seat»(/land-rover/range-rover-sport/i-2005-2009/remont/seats/#seating) information.
4. Connect the battery ground cable. For additional information, refer to: «Specifications»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-and-charging-system-general-information__specifications) information.

1. Remove the safety belt buckle. Raise the seat cushion. Release the retaining strap. Remove the Torx bolt. Release the tension spring.

1. Install the safety belt buckle. Attach the tension spring. Tighten the Torx bolt to 25 Nm (18 lb.ft). Attach the retaining strap. Lower the seat cushion.

Scheme 4

Scheme 5

Scheme 6

1. Release the RH rear seat. Fold the seat cushion forward. Remove and discard the 4 Torx bolts. Fold down the rear seat backrest.
2. Remove the RH rear seat.
3. Remove the rear seat cushion side finisher. Remove the screw.
4. Remove the safety belt buckle. Raise the seat cushion. Release the retaining strap. Remove and discard the bolt.

1. Install the safety belt buckle. Tighten the Torx bolt to 40 Nm (30 lb.ft). Attach the retaining strap. Lower the seat cushion.
2. Install the rear seat cushion side finisher. Tighten the screw.
3. Install the RH rear seat. Position the seat on the dowels.
4. Secure the RH rear seat. Return the seat backrest to the upright position. Tighten the new bolts to 40 Nm (30 lb.ft). Fold the seat cushion rearwards.

Scheme 7

Scheme 8

1. Release the RH rear seat. Fold the seat cushion forward. Remove and discard the 4 Torx bolts. Fold down the rear seat backrest.
2. Remove the RH rear seat.
3. Remove the rear seat cushion side finisher. Raise the seat cushion. Remove the screw.
4. Remove the safety belt buckle. Release the retaining strap. Remove and discard the bolt.

1. Install the safety belt buckle. Tighten the Torx bolt to 40 Nm (30 lb.ft). Attach the retaining strap. Lower the seat cushion.
2. Install the rear seat cushion side finisher. Tighten the screw.
3. Install the RH rear seat. Position the seat on the dowels.
4. Secure the RH rear seat. Return the seat backrest to the upright position. Tighten the new bolts to 40 Nm (30 lb.ft). Fold the seat cushion rearwards.
