Accessory Drive - v8 S/c 4.2l Petrol Land Rover Range Rover Sport I

Cooling System (mechanical) 9 illustrations ~879 words

SPECIFICATIONS

DescriptionNm
Cooling fan drive belt tensioner pulley retaining bolt25
Cooling fan drive belt tensioner retaining bolt40
Cooling fan drive hub bearing retaining bolts10
Cooling fan drive pulley bolts25
Accessory drive belt idler pulley bolt40
Accessory drive belt tensioner retaining bolt40

TORQUE SPECIFICATIONS

Scheme 65

Scheme 65: COMPONENT LOCATIONS
Scheme 65: COMPONENT LOCATIONS
ItemPart NumberDescription
APrimary accessory drive
BSecondary accessory drive
1Coolant pump
2Primary accessory drive belt
3Primary tensioner assembly
4A/C compressor
5Power steering pump
6Crankshaft pulley
7Generator
8Dynamic Response pump pulley
9Deflection pulley
10Supercharger pulley
11Secondary accessory drive belt
12Secondary tensioner assembly
13Engine cooling fan pulley

GENERAL

A single six-ribbed belt drives all the primary engine mounted accessories and a secondary double-sided eight-ribbed belt drives the engine driven cooling fan and the supercharger.

Both the primary and secondary belts are crankshaft driven via the torsional vibration damper. An automatic tensioner, located on the LH accessory-mounting bracket, keeps the belt at the correct tension. A deflection pulley on the RH accessory-mounting bracket increases the wrap angle around the generator pulley.

The torsional vibration damper incorporates compressed rubber between its inner and outer diameters to absorb vibration and shock loads.

The automatic tensioner consists of a deflection pulley on the end of a spring loaded pivot arm. The pivot arm can be turned counter-clockwise (viewed from the front of the engine) for removal and installation of the belt.

OVERVIEW

There are two accessory drive belts on the supercharged engine and this section covers basic checks for both.

For ease of identification, the two belts are referred to as primary and secondary drive belts.

For additional information on the description and operation of the system, refer to the relevant information.

INSPECTION AND VERIFICATION

  1. Verify the customer concern.
  2. Visually inspect for obvious mechanical faults. SYMPTOM CHART Mechanical Primary drive belt condition (cracking/damage/contamination) Secondary drive belt condition (cracking/damage/contamination) Belt tension Pulley alignment Coolant pump Primary tensioner assembly Air conditioning compressor Power steering pump Crankshaft pulley Generator Dynamic response pump pulley Deflection pulley Supercharger pulley Secondary tensioner assembly Cooling fan pulley
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step. CAUTION: If the engine is run without the accessory drive belts connected to eliminate driven components, diagnostic trouble codes, (DTCs) may be set which must be cleared before the vehicle is returned to the owner. The engine should not be run for more than 2-3 minutes with the belts disconnected. Failure to follow this instruction may result in damage to the vehicle.
  4. Use the approved diagnostic system or a scan tool to retrieve any DTCs before moving onto the symptom chart or DTC index. Make sure that all DTCs are cleared following rectification.

SYMPTOM CHART

SymptomPossible causeAction
NoiseBelt condition Belt tension Pulleys misaligned Driven components (including tensioners)Check the belt condition (see visual inspection). Check the tensioner function. Check the pulley alignment. Check the driven components for excessive resistance to rotation. Rectify as necessary.
Drive belt does not hold tensionBelt condition Tensioner faultCheck the belt condition (see visual inspection). Check the tensioner function. Rectify as necessary.

DTC INDEX

Note. Generic scan tools may not read the codes listed, or may read only 5-digit codes. Match the 5 digits from the scan tool to the first 5 digits of the 7-digit code listed to identify the fault (the last 2 digits give extra information read by the manufacturer-approved diagnostic system). For a full list of ECM DTCs, refer to DTC index .

DTCDescriptionPossible sourceAction
P050600Idle Air Control System RPM Lower Than ExpectedAir intake restriction Accessory drive overload (defective/seized component)Check the air intake system. Check the accessory drive belt and components. Refer to the relevant information.

Scheme 66

Scheme 66: REMOVAL
Scheme 66: REMOVAL
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the cooling fan. For additional information, refer to: «COOLING FAN»(/land-rover/range-rover-sport/i-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-fan) .
  3. Remove the cooling fan drive belt. Rotate the drive belt tensioner arm clockwise.

INSTALLATION

  1. To install, reverse the removal procedure.

Scheme 67

Scheme 67: REMOVAL
Scheme 67: REMOVAL

Scheme 68

Scheme 68
Scheme 68
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the cooling fan belt. For additional information, refer to: «COOLING FAN BELT»(/land-rover/range-rover-sport/i-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  3. Remove the cooling fan drive belt tensioner. Remove the bolt.
  4. Remove the drive belt pulley. Remove the bolt.
  1. To install, reverse the removal procedure. Tighten the pulley bolt to 25 Nm (18 lb.ft). Tighten the tensioner bolt to 40 Nm (30 Ib.ft).

Scheme 69

Scheme 69: REMOVAL
Scheme 69: REMOVAL

Scheme 70

Scheme 70
Scheme 70
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the cooling fan drive belt. For additional information, refer to: «COOLING FAN BELT»(/land-rover/range-rover-sport/i-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  3. Remove the cooling fan drive pulley. Remove the 3 bolts.
  4. Remove the cooling fan drive hub bearing. Remove the 5 bolts.
  5. Remove the cooling fan belt tensioner. Remove the bolt.
  6. Release the accessory drive belt. Rotate the accessory drive belt tensioner counterclockwise.
  7. Remove the accessory drive belt.

Scheme 71

Scheme 71: INSTALLATION
Scheme 71: INSTALLATION
  1. Install the accessory drive belt.
  2. Install the cooling fan belt tensioner. Tighten the M10 bolt to 45 Nm (33 lb.ft).
  3. Install the cooling fan drive hub bearing. Tighten the bolts to 10 Nm (7 lb.ft).
  4. Install the cooling fan drive pulley. Tighten the bolts evenly to 25 Nm (18 lb.ft).
  5. Install the cooling fan drive belt. For additional information, refer to: «COOLING FAN BELT»(/land-rover/range-rover-sport/i-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  6. Connect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .

Scheme 72

Scheme 72: REMOVAL
Scheme 72: REMOVAL

Scheme 73

Scheme 73
Scheme 73
  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the cooling fan assembly. For additional information, refer to: «COOLING FAN»(/land-rover/range-rover-sport/i-2005-2009/remont/cooling-system-mechanical/#engine-cooling-v8-sc-42l-petrol__cooling-fan) .
  3. Release the accessory drive belt. Rotate the accessory drive belt tensioner counter-clockwise, using a 3/8" drive wrench.
  4. Remove the accessory drive belt tensioner. Remove the bolt.
  1. To install, reverse the removal procedure. Clean and inspect the drive pulleys for damage. Tighten the tensioner bolt to 40 Nm (30 Ib.ft).

REMOVAL

  1. Disconnect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
  2. Remove the accessory drive belt. For additional information, refer to: «ACCESSORY DRIVE BELT»(/land-rover/range-rover-sport/i-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  3. Remove the accessory drive belt idler pulley. Remove the bolt.
  1. Install the accessory drive belt idler pulley. Tighten the bolt to 45 Nm (33 lb.ft).
  2. Install the accessory drive belt. For additional information, refer to: «ACCESSORY DRIVE BELT»(/land-rover/range-rover-sport/i-2005-2009/remont/cooling-system-mechanical/#accessory-drive-v8-sc-42l-petrol) .
  3. Connect the battery ground cable. For additional information, refer to: «SPECIFICATIONS»(/land-rover/range-rover-sport/i-2005-2009/remont/charging-system/#battery-mounting-and-cables__specifications) .
