Wiring diagram: Computer data lines — Diagnostic socket circuit Land Rover Freelander L359
All systems
- Air conditioning
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules
- Computer data lines 2
- Cooling fan
- Cruise control
- Defoggers 3
- Engine performance 2.0l turbo
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 3
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock 3
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 4
Diagnostic socket circuit (1 of 2) — Computer data lines Land Rover Freelander L359
Components on the diagram
Diagnostic socket circuit (2 of 2) — Computer data lines Land Rover Freelander L359
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
