SPECIFICATIONS
| Item | Specification |
|---|---|
| Front | Conventional coil spring with a twin tube damper and a high stress stabilizer bar |
COIL SPRING SUSPENSION
| Part Number | Specification | Isolator |
|---|---|---|
| LR 001131 | Green/Yellow/Orange. | LR 001145 |
ROAD SPRING IDENTIFICATION
| Description | Nm |
|---|---|
| Damper locknut* | 80 |
| Front subframe crossbrace | |
| M10* | 45 |
| M16* | 140 + 240° |
| Front subframe to body bolts* | 140 + 240° |
| Front ride height sensor | 10 |
| Halfshaft to hub bolt* | 45 + 80° |
| Lower control arm front bolt | 140 + 45° |
| Lower control arm rear nut and bolt | 175 |
| Lower control arm taper ball joint locknut* | 100 |
| Spring and damper assembly top mounting nuts | 30 |
| Stabilizer bar clamp bolts | 175 |
| Stabilizer bar link nuts* | 60 |
| Wheel knuckle to damper clamp bolt | 110 |
TORQUE SPECIFICATIONS
* New nuts/bolts must be fitted
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Right Hand (RH) spring and damper assembly |
| 2 | Stabilizer bar link |
| 3 | Stabilizer bar |
| 4 | Left Hand (LH) spring and damper assembly |
| 5 | Wheel knuckle |
| 6 | Hub and bearing assembly |
| 7 | Lower control arm |
| 8 | Subframe |
