Starting System: Removal & Installation Land Rover Freelander L359

INSTALLATION

1. Install the starter motor and tighten the bolts. Torque: 45 Nm
2. Connect the cable and lead to the starter motor solenoid and tighten the nuts. Torque: 10 Nm
3. Install the engine undershield. Refer to «ENGINE UNDERSHIELD»(ref-531949-S17696129762013022000000) .
4. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Using the Land Rover approved diagnostic equipment, interrogate the start control unit and upload the stored data.
2. Make the SRS system safe. Refer to «STANDARD WORKSHOP PRACTICES»(ref-531926-S36228198052013022000000) .
3. Remove the driver lower air bag. Refer to «DRIVER LOWER AIR BAG MODULE»(ref-531958-S02990396332013022000000) .
4. Remove the starter control unit trim cover.
5. Remove the instrument cluster surround.
6. Remove the steering column lower cowl.
7. Adjust the steering column to its lowest position.
8. Remove the start control unit.

1. To install, reverse the removal procedure.
2. Using the Land Rover approved diagnostic equipment, download the previously stored information to a new start control unit.
