CALIBRATION OF POWER SEAT MODULE
If the power seat module is replaced in service, the replacement module must be calibrated using the Land Rover approved diagnostic equipment. The calibration routine is necessary for the power seat module to reset the seat datum values.
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Seat squab heating element |
| 2 | Seat cushion heating element |
| 3 | Seat heating module |
Depending on vehicle specification, seat heating is available for both the manually operated and the power operated seats. A heating element is incorporated within each seat cushion and squab. A seat heating module and electrical wiring is located beneath each front seat.
The seat heating modules are connected on the LIN bus to the ATC, and are also hardwired to the AJB for the power supply. A ground terminal from each seat heating module completes the circuit. Refer to CONTROL COMPONENTS .
Scheme 2
| Item Number | Description |
|---|---|
| A | Driver's seat manually operated lumbar support system |
| B | Driver's seat power operated lumbar support system |
Depending on the vehicle specification, the driver's seat only may incorporate a manually operated or a power operated lumbar support system.
