Electronic Engine Controls: Removal & Installation Land Rover Freelander L359

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 3

Scheme 4

1. Remove the engine cover. Refer to «ENGINE COVER - 3.2L»(ref-531951-S06303498242013022000000) .
2. Torque: 10 Nm

INSTALLATION

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 5

1. Raise and support the vehicle.
2. Remove the engine undershield. Refer to «ENGINE UNDERSHIELD»(ref-531949-S17696129762013022000000) .
3. Torque: 10 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 6

1. Raise and support the vehicle.
2. Remove the intake manifold assembly. Refer to «INTAKE MANIFOLD»(ref-531921-S34523514272013022000000) .
3. Remove the ECT sensor.

1. To install, reverse the removal procedure.

1. For H02S anti-seize compound information, refer to the specification information.
2. Apply anti-seize compound to the sensor threads.
3. Install the HO2S. Wrench, H02S (310-121) Torque: 45 Nm
4. Connect the HO2S electrical connector.
5. Install the engine cover. Refer to «ENGINE COVER»(ref-531951-S06303498242013022000000) .

1. To install, reverse the removal procedure.
2. If required, carry out a long drive cycle. See «POWERTRAIN CONTROL MODULE (PCM) LONG DRIVE CYCLE SELF-TEST»(ref-531942-S33376475422013022000000) .

Scheme 7

1. Torque: 2 Nm

1. To install, reverse the removal procedure.
2. If required, carry out a short drive cycle. See «POWERTRAIN CONTROL MODULE (PCM) SHORT DRIVE CYCLE SELF-TEST»(ref-531942-S21169183272013022000000) .

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Raise and support the vehicle.
2. Remove the engine undershield. Refer to «ENGINE UNDERSHIELD»(ref-531949-S17696129762013022000000) .

1. To install, reverse the removal procedure.
2. If required, carry out a short drive cycle. See «POWERTRAIN CONTROL MODULE (PCM) SHORT DRIVE CYCLE SELF-TEST»(ref-531942-S21169183272013022000000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 12

Scheme 13

Scheme 14

1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
2. Remove the plenum chamber panel. Refer to «PLENUM CHAMBER»(ref-531912-S40693108652013022000000) .
3. Petrol ECM shown, diesel similar.
4. Torque: 6 Nm

1. To install, reverse the removal procedure.
2. Renew the engine oil and filter. Engine Oil Draining and Filling. Refer to «ENGINE OIL DRAINING AND FILLING»(ref-531921-S39036754412013022000000) .
3. If a new component has been installed, configure using Land Rover approved diagnostic equipment.

Note. Removal steps in this procedure may contain installation details.

Scheme 15

1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
2. Remove the fuel rail. Refer to «FUEL RAIL»(ref-531973-S32012270592013022000000) .
3. Torque: 6 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 16

1. Raise and support the vehicle.
2. Remove the oil cooler assembly. Refer to «OIL COOLER»(ref-531921-S26051175902013022000000) .
3. Remove the knock sensor (KS). Torque: 20 Nm

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 17

1. Raise and support the vehicle.
2. Remove the intake manifold. Refer to «INTAKE MANIFOLD»(ref-531921-S34523514272013022000000) .
3. Remove the knock sensor (KS). Torque: 20 Nm

1. To install, reverse the removal procedure.
