Climate Control: Removal & Installation Land Rover Freelander L359

Automatic HVAC System 64 illustrations ~1717 words

INSTALLATION

  1. To install, reverse the removal procedure.

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL

Scheme 6

Scheme 6
Scheme 6
  1. Make the SRS system safe. Refer to «STANDARD WORKSHOP PRACTICES»(ref-531926-S36228198052013022000000) .
  2. Remove the steering column. Refer to «STEERING COLUMN»(ref-531964-S40777894772013022000000) .
  3. Remove the driver lower air bag module support bracket. Torque: 7 Nm
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Land Rover approved diagnostic equipment.

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL
  1. Remove the instrument panel console. Refer to «INSTRUMENT PANEL CONSOLE»(ref-531962-S30020611172013022000000) .
  2. Remove the climate control assembly.
  1. Install is the reverse of removal.

Scheme 8

Scheme 8: REMOVAL
Scheme 8: REMOVAL
  1. Remove the register.
  1. To install, reverse the removal procedure.
  1. See figure NOTE: Right-hand shown, left-hand similar.
  1. To install, reverse the removal procedure.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL

Scheme 10

Scheme 10
Scheme 10
  1. Remove the glove compartment. Refer to «GLOVE COMPARTMENT»(ref-531962-S10250369972013022000000) .
  1. To install, reverse the removal procedure.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL

Scheme 12

Scheme 12
Scheme 12
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Remove the CJB. Refer to «CENTRAL JUNCTION BOX (CJB)»(ref-531979-S27875171682013022000000) .
  3. Torque: 10 Nm
  4. See figure NOTE: Note the fitted position.
  1. To install, reverse the removal procedure.

Scheme 13

Scheme 13: REMOVAL
Scheme 13: REMOVAL

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Remove the RH wiper arm. Refer to «WIPER PIVOT ARM»(ref-531960-S38560960512013022000000) .
  2. Repeat the above procedure for the other wiper arm.
  3. Remove the plenum chamber panel.
  4. See figure NOTE: Do not disassemble further if the component is removed for access only.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 16

Scheme 16: REMOVAL
Scheme 16: REMOVAL

Scheme 17

Scheme 17
Scheme 17
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Recover the A/C refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-531982-S38456719582013022000000) .
  3. Remove the plenum chamber panel. See «PLENUM CHAMBER»(ref-531912-S40693108652013022000000) .
  4. Torque: 9 Nm
  5. Torque: 4 Nm
  1. To install, reverse the removal procedure.

Note. The removal of this component involves cutting an aperture in the evaporator housing wall and cutting through the high and low pressure A/C lines. A service repair kit is supplied to cover this procedure.

Scheme 18

Scheme 18: REMOVAL
Scheme 18: REMOVAL

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Recover the A/C refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-531982-S38456719582013022000000) .
  3. Remove the plenum chamber panel. See «PLENUM CHAMBER»(ref-531912-S40693108652013022000000) .
  4. If installed, remove the anti-theft alarm horn with integral battery.
  5. Disconnect the A/C pipes from the TXV.
  6. Remove the RH floor console extension.
  7. Remove the glove compartment. Refer to «GLOVE COMPARTMENT»(ref-531962-S10250369972013022000000) .
  8. Remove the CJB bracket.
  9. Remove the 3 spring clips. Release the 4 plastic clips.
  10. Remove the lower cover. Position the upper cover aside for access.
  11. Cut the A/C pipes at the marked position.
  12. Guide the cut evaporator pipes through the bulkhead so that approximately 20mm is visible in the engine compartment.
  13. Remove the evaporator pipes.
  14. Remove the evaporator core.
  15. Remove any debris from the heater core and evaporator core housing.

Scheme 30

Scheme 30: INSTALLATION
Scheme 30: INSTALLATION

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Apply the foam strips from the service kit to the evaporator core.
  2. Install the evaporator core.
  3. Install the service door. Secure the 4 clips. Install the 4 screws.
  4. Install the pollen filter cover.
  5. Apply the asphalt tape from the service kit to the service replacement evaporator pipes.
  6. Remove the TXV assembly from the service replacement evaporator pipes.
  7. Guide the service replacement evaporator pipes through the bulkhead so that approximately 20mm is visible in the engine compartment.
  8. Install the TXV captive clamping plate.
  9. Install the service replacement evaporator pipes to the evaporator. Torque: 5 Nm
  10. Install the CJB bracket. Torque: 10 Nm
  11. Secure the wiring harnesses to the CJB bracket.
  12. Install the CJB.
  13. Connect the 5 electrical connectors to the CJB and secure the front carpet.
  14. Install the CJB lower access cover.
  15. Install the passenger side footwell duct.
  16. Install the glove compartment. Refer to «GLOVE COMPARTMENT»(ref-531962-S10250369972013022000000) .
  17. Install the RH floor console extension.
  18. Install the TXV assembly. Torque: 4 Nm
  19. Connect the A/C pipes to the TXV and tighten the M6 nut. Torque: 9 Nm
  20. Install the anti-theft alarm horn with integral battery.
  21. Install the plenum chamber panel. See «PLENUM CHAMBER»(ref-531912-S40693108652013022000000) .
  22. Recharge the A/C system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-531982-S38456719582013022000000) .
  23. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .

Scheme 33

Scheme 33
Scheme 33
  1. To install, reverse the removal procedure.

Scheme 34

Scheme 34: REMOVAL
Scheme 34: REMOVAL

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Drain the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-531918-S31491615612013022000000) .
  3. Remove the selector lever. Refer to «SELECTOR LEVER»(ref-531944-S07144783472013022000000) .
  4. Remove the cowl side trim panel. Refer to «COWL SIDE TRIM PANEL»(ref-531951-S35657098132013022000000) .
  5. Torque: 6 Nm
  6. See figure CAUTION: Be prepared to collect escaping coolant.
  1. To install, reverse the removal procedure.

Scheme 40

Scheme 40: REMOVAL
Scheme 40: REMOVAL
  1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Raise and support the vehicle.
  3. Recover the A/C refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-531982-S38456719582013022000000) .
  4. Remove the front bumper. Refer to «FRONT BUMPER»(ref-531966) .
  5. Remove the radiator air deflector.
  6. Release power steering cooler and secure aside.
  7. Disconnect the A/C condenser refrigerant lines.
  8. Remove the A/C condenser.
  1. Install the A/C condenser, and tighten the bolt. Torque: 10 Nm
  2. Connect the A/C condenser refrigerant lines, tighten the bolts. Torque: 10 Nm
  3. Install the PAS cooler and tighten the bolts. Torque: 10 Nm
  4. Install the air deflector.
  5. Install the front bumper. Refer to «FRONT BUMPER»(ref-531966) .
  6. Recharge the A/C system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-531982-S38456719582013022000000) .
  7. Connect the battery ground cable and install the cover. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .

Scheme 41

Scheme 41: REMOVAL
Scheme 41: REMOVAL
  1. To install, reverse the removal procedure.
CAUTIONMake sure that the specified amount of refrigerant oil is added.

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Recover the air conditioning (A/C) refrigerant. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-531982-S38456719582013022000000) .
  3. Remove the engine cover. Refer to «ENGINE COVER - 3.2L»(ref-531951-S06303498242013022000000) .
  4. Remove the battery tray. Refer to «BATTERY TRAY»(ref-531940-S37654936752013022000000) .
  5. Remove the air cleaner assembly. Refer to «AIR CLEANER»(ref-531922-S17101109672013022000000) .
  6. Remove the A/C compressor, upper support bracket.
  7. Remove the A/C compressor, lower support bracket.
  8. Using suitable tools, release the accessory drive belt tension.
  9. Disconnect the A/C compressor refrigerant lines.
  10. Remove the A/C compressor.
  1. Install the A/C compressor. Torque: 25 Nm
  2. Connect the A/C compressor refrigerant lines. Torque: 24 Nm
  3. Install the accessory drive belt.
  4. Install the A/C compressor, lower support bracket. Torque: 25 Nm
  5. Install the A/C compressor, upper support bracket. Torques: M10: 45 Nm M8: 25 Nm M6: 10 Nm
  6. Install the air cleaner assembly. Refer to «AIR CLEANER»(ref-531922-S17101109672013022000000) .
  7. Install the battery tray. Refer to «BATTERY TRAY»(ref-531940-S37654936752013022000000) .
  8. Recharge the A/C system. Refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-531982-S38456719582013022000000) .
  9. Install the engine cover. Refer to «ENGINE COVER - 3.2L»(ref-531951-S06303498242013022000000) .
  10. Connect the battery ground cable and install the cover. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .

Scheme 47

Scheme 47: REMOVAL
Scheme 47: REMOVAL

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64
  1. Make the SRS system safe.
  2. Remove the instrument panel. Refer to «INSTRUMENT PANEL - 2.2L DIESEL»(ref-531962) . Refer to «INSTRUMENT PANEL - 3.2L»(ref-531962-S07436042802013022000000) .
  3. Remove the clockspring. Refer to «CLOCKSPRING»(ref-531958-S14768141612013022000000) .
  4. Remove the instrument cluster. Refer to «INSTRUMENT CLUSTER»(ref-531956-S05715501572013022000000) .
  5. Disconnect the keyless start module electrical connector.
  6. Disconnect the in-vehicle temperature sensor.
  7. Remove both upper trim panels.
  8. Remove both instrument panel speakers.
  9. Remove the video display. Refer to «VIDEO DISPLAY»(ref-531969-S18684391542013022000000) .
  10. Remove the center speaker.
  11. Remove the audio unit.
  12. Remove the climate control assembly.
  13. Remove the passenger side instrument panel end trim panel.
  14. Remove the glove compartment. Refer to «GLOVE COMPARTMENT»(ref-531962-S10250369972013022000000) .
  15. Release the wiring harness from the instrument panel upper section.
  16. With assistance, remove the instrument panel upper section.
  17. Remove both front footwell ducts.
  18. Disconnect the wiring harness from the heater core and evaporator core housing.
  19. Disconnect the electric booster heater core.
  20. Remove the heater core and evaporator core housing.
  1. Install the heater core and evaporator core housing. Torque: 7 Nm
  2. Install the electric booster heater assembly.
  3. Connect the electric booster heater core.
  4. Connect the wiring harness to the heater and evaporator core housing.
  5. Install both front footwell ducts.
  6. With assistance, install the instrument panel upper section.
  7. Install the passenger air bag module support bracket bolts. Torque: 10 Nm
  8. Secure the wiring harness to the instrument panel upper section.
  9. Connect the passenger air bag module electrical connectors.
  10. Install the glove compartment. Refer to «GLOVE COMPARTMENT»(ref-531962-S10250369972013022000000) .
  11. Install the passenger side instrument panel end trim panel.
  12. Secure the wiring harness support bracket.
  13. Install the climate control assembly.
  14. Install the audio unit.
  15. Install the center speaker.
  16. Install the video display. Refer to «VIDEO DISPLAY»(ref-531969-S18684391542013022000000) .
  17. Install both instrument panel speakers.
  18. Install both upper trim panels.
  19. Connect the in-vehicle temperature sensor electrical connector.
  20. Connect the keyless start module electrical connector.
  21. Install the instrument cluster. Refer to «INSTRUMENT CLUSTER»(ref-531956-S05715501572013022000000) .
  22. Install the clockspring. Refer to «CLOCKSPRING»(ref-531958-S14768141612013022000000) .
  23. Install the instrument panel. Refer to «INSTRUMENT PANEL - 2.2L DIESEL»(ref-531962) . Refer to «INSTRUMENT PANEL - 3.2L»(ref-531962-S07436042802013022000000) .
  24. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  25. Return the steering column to its original position.

Note. Removal steps in this procedure may contain installation details.

  1. Remove the plenum chamber. See «PLENUM CHAMBER»(ref-531912-S40693108652013022000000) .
  2. Torque: 8 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 65

Scheme 65
Scheme 65
  1. Make the SRS system safe. Refer to «STANDARD WORKSHOP PRACTICES»(ref-531926-S36228198052013022000000) .
  2. Remove the steering column. Refer to «STEERING COLUMN»(ref-531964-S40777894772013022000000) .
  3. Remove the driver lower air bag module support bracket. Torque: 7 Nm
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Land Rover approved diagnostic equipment.

Scheme 66

Scheme 66
Scheme 66
  1. Remove the glove compartment. Refer to «GLOVE COMPARTMENT»(ref-531962-S10250369972013022000000) .
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Land Rover approved diagnostic equipment.

Scheme 67

Scheme 67: REMOVAL
Scheme 67: REMOVAL
  1. Remove the glove compartment. Refer to «GLOVE COMPARTMENT»(ref-531962-S10250369972013022000000) .
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Land Rover approved diagnostic equipment.

Scheme 68

Scheme 68: REMOVAL
Scheme 68: REMOVAL
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-531959-S27829531522013022000000) .
  2. Remove the CJB. Refer to «CENTRAL JUNCTION BOX (CJB)»(ref-531979-S27875171682013022000000) .
  1. To install, reverse the removal procedure.

More articles — Climate Control
