Antenna: Overview Land Rover Freelander L359

Antenna Systems 1 illustration ~195 words

OVERVIEW

The antenna systems fitted to the vehicle comprise

  1. AM/FM screen mounted antennae or AM/FM diversity system
  2. FM diversity antenna
  3. GPS antenna (where fitted)
  4. SDARS antenna (NAS only) (NAS only, roof pod mounted) or DAB antenna (where fitted, roof pod)
  5. VICS beacon antenna (Japan only)
  6. Digital Audio Broadcasting (DAB) system antenna (side screen or roof pod mounted depending on system)

The AM/FM antenna is etched onto the right side window glass. The antenna has an amplifier located just above the window. This amplifier will vary upon the entertainment and information system fitted to the vehicle. High line systems will have a larger amplifier for diversity tuning.

The rear window incorporates an FM antenna and a VICS/TMC antenna etched onto the glass. The FM antenna is used in the diversity tuning system along with the respective antenna amplifiers.

The left side window antenna is used for DAB band III signal reception.

Note. The telephone control module incorporates a Bluetooth antenna. This is integral to the module and as such is not serviceable.

Scheme 2

Scheme 2: CONTROL DIAGRAM
Item NumberDescription
1Rear right screen AM/FM antenna
2AM/FM antenna amplifier
3Audio Head Unit (AHU)
4Integrated Audio Module (IAM)
5Integrated Control Panel (ICP)
6DAB tuner
7SDARS tuner
8Navigation computer
9VICS beacon antenna
10TMC antenna amplifier
11GPS antenna roof pod
12SDARS antenna

Note. A = Hardwired; P = MOST; T = CoAxial

For additional information.

Refer to: INFORMATION AND ENTERTAINMENT SYSTEM .
