Wipers and Washers Land Rover Freelander L314

Wiper/washer Systems 15 illustrations ~1329 words

84.10.01 RESERVOIR - WASHER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 1

Scheme 1: REMOVE
Scheme 1: REMOVE

Scheme 2

Scheme 2
Scheme 2
  1. Remove front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .
  2. Position container to collect fluid loss.
  3. Remove 2 nuts securing reservoir filler neck and remove filler neck.
  4. Release both washer pumps from reservoir.
  5. Remove and discard pump sealing grommets.
  6. Remove 3 bolts securing washer reservoir and remove.

REFIT

  1. Fit reservoir and secure with bolts.
  2. Fit new pump sealing grommets to reservoir.
  3. Fit pumps to reservoir.
  4. Fit filler neck and secure with nuts.
  5. Fit front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .

84.10.08 JET - WASHER - EACH

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 3

Scheme 3: REMOVE
Scheme 3: REMOVE
  1. Disconnect tube from washer jet.
  2. Depress plastic lugs and remove washer jet from bonnet.
  1. Fit washer jet to bonnet and connect tube.
  2. Adjust jet so the inside spray is to centre of the screen, and the outer spray is to the top of the screen.

84.10.21 PUMP - WASHER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 4

Scheme 4: REMOVE
Scheme 4: REMOVE
  1. Remove front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .
  2. Position container to catch windscreen washer fluid.
  3. Disconnect multiplug and hose from windscreen washer pump.
  4. Release pump from reservoir.
  5. Remove and discard pump sealing grommet.
  1. Fit new pump sealing grommet to reservoir
  2. Fit pump to reservoir.
  3. Connect hose and multiplug to pump.
  4. Fit front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .

84.15.02 ARM - WIPER - EACH

Note. Numbers in figures correspond to step numbers in procedures.

REMOVE

  1. Remove nut cover on wiper arm and remove nut.
  2. Remove wiper arm from spindle. NOTE: Do not carry out further dismantling if component is removed for access only.
  3. Remove wiper blade. See «84.15.06 BLADE - WIPER - EACH»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__841506-blade-wiper-each) .
  1. Fit wiper blade. See «84.15.06 BLADE - WIPER - EACH»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__841506-blade-wiper-each) .
  2. Fit wiper arm to spindle, with tip of wiper blade aligned to screen marks.
  3. Fit nut and tighten to 18 Nm (13 lbf.ft).

84.15.06 BLADE - WIPER - EACH

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 5

Scheme 5: REMOVE
Scheme 5: REMOVE
  1. Lift wiper arm from screen.
  2. Press retaining lever.
  3. Slide blade down arm and withdraw.
  1. Position new blade to wiper arm.
  2. Push blade into engagement with arm, and check blade is retained.
  3. Lower arm onto screen.

84.15.11 MOTOR & LINKAGE - WIPER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 6

Scheme 6: REMOVE
Scheme 6: REMOVE
  1. Remove air intake moulding.
  2. Disconnect multiplug from windscreen wiper motor.
  3. Remove 3 bolts securing wiper motor and linkage to body and remove wiper motor and linkage.
  1. Fit motor and linkage to body, fit bolts and tighten to 5 Nm (3.5 lbf.ft)
  2. Connect multiplug to windscreen wiper motor.
  3. Fit air intake moulding.

84.15.34 SWITCH - WIPER WASHER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 7

Scheme 7: REMOVE
Scheme 7: REMOVE
  1. Remove rotary coupler. For 2002 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-150749-S37201093772002112100000) . For 2003 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-160441-S06918976152004021000000) . For 2004 models, see «ROTARY COUPLER (CLOCKSPRING)»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .
  2. Disconnect multiplug from washer and wiper switch.
  3. Release multiplug connector from switch base on steering column.
  4. Disconnect multiplug from connector.
  5. Remove 2 screws from wiper switch.
  6. Depress retaining tag and remove switch.
  1. Fit washer and wiper switch assembly and secure with screws.
  2. Connect multiplugs to switch.
  3. Secure multiplug to steering column.
  4. Fit rotary coupler. For 2002 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-150749-S37201093772002112100000) . For 2003 models, see «ROTARY COUPLER (CLOCKSPRING)»(ref-160441-S06918976152004021000000) . For 2004 models, see «ROTARY COUPLER (CLOCKSPRING)»(/land-rover/freelander/l314-2003-2006/remont/airbag/#air-bag-restraint-systems) .

84.30.21 PUMP - WASHER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 8

Scheme 8: REMOVE
Scheme 8: REMOVE
  1. Remove front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .
  2. Position container to catch windscreen washer fluid.
  3. Disconnect multiplug from washer pump.
  4. Release hose from pump.
  5. Remove washer pump from reservoir and remove and discard pump seal.
  1. Fit new pump sealing grommet to reservoir.
  2. Fit pump to reservoir.
  3. Connect hose and multiplug to pump.
  4. Fit front bumper. See «76.22.72 BUMPER - ASSEMBLY FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) or «76.22.72 BUMPER - ASSEMBLY - FRONT - FROM 04M»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__762272-bumper-assembly-front) .

84.35.01 ARM - WIPER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 9

Scheme 9: REMOVE
Scheme 9: REMOVE
  1. Remove wiper blade. See «84.35.02 BLADE - WIPER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__843502-blade-wiper) .
  2. Remove spare wheel mounting bracket. See «76.11.18 BRACKET - SPARE WHEEL MOUNTING»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__761118-bracket-spare-wheel-mounting) .
  3. Raise nut cover on wiper arm and remove nut.
  4. Release washer jet tube and remove wiper arm. NOTE: Do not carry out further dismantling if component is removed for access only.
  5. Release washer jet and washer jet tube from wiper arm.
  1. Position and secure washer tube and jet to wiper arm.
  2. Position wiper arm to tail door and connect washer tube.
  3. Set wiper arm with tip contacting joint line between waist seal and rear door. Fit and tighten wiper arm nut to 13Nm (10lbf.ft).
  4. Fit wiper blade. See «84.35.02 BLADE - WIPER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__843502-blade-wiper) .
  5. Fit spare wheel mounting bracket. See «76.11.18 BRACKET - SPARE WHEEL MOUNTING»(/land-rover/freelander/l314-2003-2006/remont/exterior-body-panels/#exterior-fittings__761118-bracket-spare-wheel-mounting) .

84.35.02 BLADE - WIPER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 10

Scheme 10: REMOVE
Scheme 10: REMOVE
  1. Lift wiper arm from tail door glass.
  2. Remove wiper blade from arm.
  1. Position new blade to wiper arm.
  2. Secure blade in retainer.
  3. Position blade to glass.

84.35.12 MOTOR - WIPER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 11

Scheme 11: REMOVE
Scheme 11: REMOVE

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Remove rear wiper arm. See «84.35.01 ARM - WIPER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__843501-arm-wiper) .
  2. Remove tail door plastic sheet. See «76.34.25 PLASTIC SHEET - TAIL DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763425-plastic-sheet-tail-door) .
  3. Remove spindle nut and flat washer and discard rubber seal.
  4. Disconnect multiplug from rear wiper motor.
  5. Remove 2 bolts securing wiper motor to tail door.
  6. Remove wiper motor. NOTE: Do not carry out further dismantling if component is removed for access only.
  7. Remove and discard spindle sealing washer.
  8. Remove motor water shield.
  9. Remove 3 bolts securing mounting plate to wiper motor.
  10. Release multiplug and remove mounting plate.
  1. Position mounting plate, tighten bolts and secure multiplug.
  2. Fit motor water shield and new sealing washer to spindle.
  3. Fit wiper motor and tighten bolts to 5 Nm (3.5 lbf.ft).
  4. Connect multiplug to rear wiper motor.
  5. Fit NEW rubber seal to wiper motor spindle.
  6. Fit flat washer and tighten spindle nut to 5 Nm (3.5 lbf.ft).
  7. Fit tail door plastic sheet. See «76.34.25 PLASTIC SHEET - TAIL DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#doors-door-trim__763425-plastic-sheet-tail-door) .
  8. Fit wiper arm. See «84.35.01 ARM - WIPER»(/land-rover/freelander/l314-2003-2006/remont/wiperwasher-systems/#wipers-and-washers__843501-arm-wiper) .

84.35.34 SWITCH - COMBINED WIPER WASHER

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 14

Scheme 14: REMOVE
Scheme 14: REMOVE
  1. Remove instrument cowl. See «88.20.02 COWL - INSTRUMENT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__882002-cowl-instrument-up) or «88.20.02 COWL - INSTRUMENT FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__882002-cowl-instrument-from-04my) .
  2. Remove rear wiper switch from instrument cowl.
  1. Fit switch to instrument cowl.
  2. Fit instrument cowl. See «88.20.02 COWL - INSTRUMENT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__882002-cowl-instrument-up) or «88.20.02 COWL - INSTRUMENT FROM 04MY»(/land-rover/freelander/l314-2003-2006/remont/gauges-instrument-panels/#instruments__882002-cowl-instrument-from-04my) .

84.35.38 RELAY - TAILGATE WIPE - 5 DOOR

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 15

Scheme 15: REMOVE
Scheme 15: REMOVE
  1. Remove RH rear quarter lower trim casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
  2. Remove rear wiper motor relay.
  1. Fit rear wiper motor relay.
  2. Fit RH rear quarter lower casing. See «76.13.12 TRIM CASING - REAR QUARTER - LOWER - 5 DOOR»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__761312-trim-casing-rear-quarter) .
