Control Units Land Rover Freelander L314

Memory Modules 6 illustrations ~400 words

86.25.39 CONTROL UNIT - WINDOW LIFT

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 1

Scheme 1: REMOVE
Scheme 1: REMOVE
  1. Remove driver's side fuse box. See «86.70.01 FUSE BOX - PASSENGER COMPARTMENT»(/land-rover/freelander/l314-2003-2006/remont/body-electrical/#wiring-harnesses-fuse-box__867001-fuse-box-passenger-compartment) .
  2. Remove 2 nuts securing window lift control unit and release unit from studs.
  3. Disconnect multiplug from window lift control unit and remove unit from vehicle.

REFIT

  1. Connect multiplug to window lift control unit.
  2. Position unit and secure with 2 nuts.
  3. Fit fuse box. See «86.70.01 FUSE BOX - PASSENGER COMPARTMENT»(/land-rover/freelander/l314-2003-2006/remont/body-electrical/#wiring-harnesses-fuse-box__867001-fuse-box-passenger-compartment) .

86.55.13 RELAY - POWER FOLDING MIRRORS - FROM 02MY

Note. Numbers in figures correspond to step numbers in procedures.

CAUTIONIf the power fold mirrors are operated consecutively more than three times, then they will cease to function for a period of one minute. This is to prevent damage to the power fold mirror motors.

Scheme 2

Scheme 2: REMOVE
Scheme 2: REMOVE
  1. Remove passenger side tread strip.
  2. Release power fold mirror relay from "A" post.
  3. Remove relay from harness block connector.
  1. Fit relay to harness block connector.
  2. Fit relay to securing clip.
  3. Fit tread strip.

86.55.75 CENTRAL CONTROL UNIT (CCU)

Note. Numbers in figures correspond to step numbers in procedures.

Scheme 3

Scheme 3: REMOVE
Scheme 3: REMOVE

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. Disconnect battery earth lead.
  2. Open drivers glove box lid and remove fuse box cover.
  3. Remove bolt securing fuse box mounting plate to steering column bracket.
  4. Remove 2 bolts securing mounting plate to body.
  5. Remove 2 bolts securing fuse box to mounting plate.
  6. Disconnect 3 multiplugs from CCU in rear of fuse box.
  7. Maneuver fuse box to gain access to CCU.
  8. Release retaining clips and remove CCU.
  1. Position CCU and secure in clips.
  2. Align fuse box to mounting plate.
  3. Connect multiplugs to CCU.
  4. Fit bolts securing fuse box to mounting bracket and tighten to 8 Nm (6 lbf.ft).
  5. Position mounting plate and tighten bolts to 8 Nm (6 lbf.ft).
  6. Fit fuse box cover.
  7. Close glove box.
  8. Connect battery earth lead.
  9. Using T4, configure a new CCU.

86.54.30 CONTROL UNIT - POWER FOLD MIRRORS - UP TO 02MY

Note. Numbers in figures correspond to step numbers in procedures.

CAUTIONIf the power fold mirrors are operated consecutively more than three times, then they will cease to function for a period of one minute. This is to prevent damage to the power fold mirror motors.

Scheme 6

Scheme 6: REMOVE
Scheme 6: REMOVE
  1. Remove the front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .
  2. Release the two clips securing the power fold mirror control unit.
  3. Release the control unit from its mounting and disconnect the multiplug.
  4. Remove the control unit.
  1. Locate the control unit in its mounting and ensure the clips are fully engaged.
  2. Connect the multiplug to the control unit.
  3. Fit the front console. See «76.25.01 CONSOLE - FRONT - UP TO 04MY»(/land-rover/freelander/l314-2003-2006/remont/exteriorinterior-trim/#interior-trim__762501-console-front-up) .
